Sandman614's Build

Reply

Referenced Products Thread Tools Search this Thread
Old 08-23-2013, 06:05 AM   #161
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Quote:
Originally Posted by Slimwood Shady View Post
First-Class Package Service
Depart USPS Sort Facility
August 23, 2013
RALEIGH, NC 27676
Scheduled Delivery Day:
August 24, 2013
USPS Tracking / Delivery Confirmation™

  Reply With Quote
Old 08-23-2013, 09:15 AM   #162
I love your mom!
Slimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shed

Slimwood Shady's Avatar
Army: Sergeant First Class
Name: Linwood
Joined: Jul 2009, #19585
Location: Hampton, VA
Age: 34
Gender: Dude
Posts: 9,747
Slimwood Shady's Tacoma Gallery
Quote:
Originally Posted by Sandman614 View Post
First-Class Package Service
Depart USPS Sort Facility
August 23, 2013
RALEIGH, NC 27676
Scheduled Delivery Day:
August 24, 2013
USPS Tracking / Delivery Confirmation™

  Reply With Quote
Old 08-24-2013, 11:02 PM   #163
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Ideas: Torque App Plugin

Plugin Development http://torque-bhp.com/wiki/PluginDocumentation
Quote:
Originally Posted by LGE RAW View Post
PID is Parameter ID



All info below has been worked out after page 8. Look there for info on programing PIDs for Torque for 05-09 and 10+ Tacomas.

I found this info on Ian's forum for crossing Scanguage to Torque:

Link: http://torque-bhp.com/forums/?wpforu...wtopic&t=352.0

We need to fill in the following fields on Torque
OBD2 PID
Long Name
Short Name
Min Value
Max Value
Scale Factor
Unit Type
Equation
with the following from SGII
GAUGE
TXD
RXF
RXD
MTH
NAM
NOTES
As we go through the tutorial I will use the following for an example
Engine Oil Temperature 07E0221310 046245130610 3010 00090005F05F EOT Degrees F
OBD2 PID
This field comes from the TXD of the SGII file. There are 2 flavors, CAN (controller Area Network) and the rest of the older OBD2 protocols. If it is CAN, you want to use all the characters after “07DF” or “07E0”. If it is “07E1”, then Torque will likely not work for this gauge as the ELM327 may need specific instructions to communicate the transmission control module.
For all the other protocols, you want to use all the characters after the “F1”.
Our example: 221310
Long Name
Take this value from the GAUGE field
Our example: Engine Oil Temperature
Short Name
Take this value from the NAM field
Our Example: EOT
MIN/MAX
These are really determined by the data you are gathering and can be set up after you have your equation. Torque does a pretty good job of rescaling gauges if the data over steps the range.
Scale Factor
I always leave this as 1 because we can scale in the equation if we need to. However, SGII may do some prescaling that you should be aware of before you implement your equation.
Unit Type
Take this value for the notes field
Our example: F
Equation
Now for the most complicated part.
First look at the RXD field. Don’t worry about the first 2 characters. If the second 2 characters are “08”, then you have 1 byte of data and you will only need an “A” in your equation. If the second 2 characters are “10”, then you have 2 bytes of data and you will need to start off your equation like ((A*256)+B). Don’t ask why. This isn’t a lesson in hexadecimal.
Our example: “10”-> ((A*256)+B)
Now look at the MTH field. It is separated in 3 sections. It may look like this 00090005F05F. The first 4 characters (0009 in our example) are the multiplier. These values are in hex so you must convert them to decimal. Open up the windows calculator and makes sure it is set to scientific view. Click the hex circle and enter in the first 4 characters. Then click the decimal circle. The value displayed is what you want to use in torque. Repeat this step for the second 4 characters (0005 in our example) and you will have the divisor. The final four are the trickiest. If you have an F,E,D,C,B,A,9,8 as the first character as we do in our example, then this will be a negative number. To calculate this use windows calculator and set it to HEX. Enter the value and click XOR and enter “FFFE”. Click “=”, then click the decimal circle and you will see what value you have to subtract from the equation. If there isn’t, then we will be adding this value. And you proceed the same as with the multiply and divide to the value.
Our example: 9/5-4001
The final thing to pay attn to is the RXF field. Which may look like 046245130610. Pay close attn to 0462->4-5130610. If you see a 4 here, then your data must be multiplied by 100. If you see an 8, then your data must be multiplied by 10. If it is 0, then don’t worry about this part.
Our example: *100
Final equation: ((A*256)+B)*100*(9/5)-4001
This is only a guide and not a bible. If you can’t get data for a PID it can me two things, you entered it wrong or your car doesn’t support it. Just b/c your car as a certain sensor it does NOT mean your vehicle will support the PID to get that data.
I got an idea, I need to poll the mileage for.
  Reply With Quote
Old 08-28-2013, 01:38 PM   #164
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Gonna hook up the new lights as Alternating Turn Signals. I gotta get some new screws and do the wiring.

[edit] nix that. The LED bulbs don't like that.
  Reply With Quote
Old 08-30-2013, 04:45 AM   #166
I love your mom!
Slimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shedSlimwood Shady is one of the sharper tools in the shed

Slimwood Shady's Avatar
Army: Sergeant First Class
Name: Linwood
Joined: Jul 2009, #19585
Location: Hampton, VA
Age: 34
Gender: Dude
Posts: 9,747
Slimwood Shady's Tacoma Gallery
Quote:
Originally Posted by Sandman614 View Post
Here's the first glance Linwood.
http://youtu.be/BxZie-t4VWg
did you have to use any kind of diodes or just plug and play?

EDIT: just ordered....now to find a way to put LED fogs in the fog light housings....
  Reply With Quote
Old 08-30-2013, 07:17 AM   #167
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Quote:
Originally Posted by Slimwood Shady View Post
did you have to use any kind of diodes or just plug and play?

EDIT: just ordered....now to find a way to put LED fogs in the fog light housings....
Plug and play (no diodes or resistors). I did have to clean up the corrosion and rust inside the bulb mount inside the housing, they had been neglected.
  Reply With Quote
Old 08-31-2013, 03:19 PM   #169
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Tires: Cooper ATP 112399 miles

Went to Discount Tire to get 4 new Cooper Discoverer ATP put on. When I left I checked the air pressure and one of my sensors were leaking. Quickly backed it up and they checked it out and replaced it . Now to see if it syncs up right, guys said it takes 30 mins of driving, I'm skeptical. 112399 miles.









  Reply With Quote
Old 08-31-2013, 03:22 PM   #170
Vaginas are rad.
Boone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shed

Boone's Avatar
Name: Chris
Joined: Jul 2012, #82731
Location: Boone, NC
Age: 32
Gender: Male
Posts: 3,971
Boone's Tacoma Gallery
Looks good with some fresh rubber on there. It's almost like you're getting ready for winter.
  Reply With Quote
Old 08-31-2013, 03:43 PM   #171
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Quote:
Originally Posted by Boone Taco View Post
Looks good with some fresh rubber on there. It's almost like you're getting ready for winter.
Thanks. Not much in the way of winter down here. Though it should be better on dirt roads. I'll be up there this week, want to go hike?
  Reply With Quote
Old 08-31-2013, 03:47 PM   #172
Vaginas are rad.
Boone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shedBoone is one of the sharper tools in the shed

Boone's Avatar
Name: Chris
Joined: Jul 2012, #82731
Location: Boone, NC
Age: 32
Gender: Male
Posts: 3,971
Boone's Tacoma Gallery
When are you coming up? I'm working 1/2 day then ridin' on Mon and then working the rest of the week.
  Reply With Quote
Old 08-31-2013, 03:56 PM   #173
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Quote:
Originally Posted by Boone Taco View Post
When are you coming up? I'm working 1/2 day then ridin' on Mon and then working the rest of the week.
It's looking like Monday. I have a client that needs computer work done.
  Reply With Quote
Old 09-05-2013, 08:54 AM   #174
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Parts: Transmission Shifter LED

Swapped out the Transmission shifter bulb for a Blue LED.







  Reply With Quote
Old 10-11-2013, 10:34 AM   #175
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Parts: LCA Rebuild

LCA rebuild FU DB NYSTYLZ



Quote:
AND FOR PRICES + PART #'S
MOOG K200772 Control Arm Bushing $ 12.55
MOOG K80827 Ball Joint $ 26.79
MOOG K200773 Control Arm Bushing $ 13.54
MOOG K100128 Caster / Camber Cam Bolt Kit $ 33.79
  Reply With Quote
Old 10-19-2013, 05:49 PM   #176
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Don't use seafoam in Brake Vacuum hose

Quote:
Originally Posted by BamaToy1997 View Post
You do realize that if you add ANY chemical through the booster vac line that only cylinder #3 gets anything? The booster vac port is in the runner for cylinder #3 only.

On the specific thread topic I use STP fuel injector cleaner once a month. It does a good job of keeping the valve stem and back of the face clean, and keeps the carbon down. I had to disassemble my engine at 185k miles (I purchased it at 150k) and the valves were still very clean, and the head surface and piston surface were clear and clean of any carbon.
Quote:
Originally Posted by Sandman614 View Post
Add cleaner/seafoam here not in the brake booster vacuum hose.
.
  Reply With Quote
Old 10-19-2013, 06:18 PM   #177
Senior Member
ckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shed

ckeene9's Avatar
Joined: Sep 2012, #87325
Location: Midlothian, VA
Age: 24
Gender: Male
Posts: 6,140
ckeene9's Tacoma Gallery
Quote:
Originally Posted by Sandman614 View Post
.
Only for NA engines. My brake booster vacuum is tapped into the manifold.
  Reply With Quote
Old 10-19-2013, 07:24 PM   #178
Sandman614 [OP] Sandman614 is online now
LRGRNR
Sandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shedSandman614 is one of the sharper tools in the shed

Sandman614's Avatar
Joined: Oct 2010, #45273
Location: Boone, NC\Cary, NC
Gender: Male
Posts: 6,345
Sandman614's Tacoma Gallery
Quote:
Originally Posted by ckeene9 View Post
Only for NA engines. My brake booster vacuum is tapped into the manifold.
So the charger relocates the brake booster line?

I made some edits after I read your comment a few times.
  Reply With Quote
Old 10-19-2013, 07:28 PM   #179
Senior Member
ckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shedckeene9 is one of the sharper tools in the shed

ckeene9's Avatar
Joined: Sep 2012, #87325
Location: Midlothian, VA
Age: 24
Gender: Male
Posts: 6,140
ckeene9's Tacoma Gallery
Quote:
Originally Posted by Sandman614 View Post
So the charger relocates the brake booster line?

I made some edits after I read your comment a few times.
Yes, I'll snap some pics when I get back to my truck.
  Reply With Quote
