LS3 AWD Swap!! pics and dyno video

Reply

Thread Tools Search this Thread Display Modes
Old 10-09-2012, 07:40 PM   #1
jlee541 [OP] jlee541 is offline
Junior Member
jlee541 is on a distinguished road
Name: john
Joined: Oct 2012, #88655
Location: Canton, GA
Gender: Male
Posts: 4
jlee541's Tacoma Gallery
LS3 AWD Swap!! pics and dyno video

Not mine but thought you guys would enjoy. LS3 in 04 Xtra Cab.
Its a brand new GM crate motor, TR6060 6 speed trans and modified 146 AWD transfer case.
As well as 2010+ Camaro gauges, HUD, auxiliary gauges, and steering wheel. It will be getting a custom fiberglass dash.
























And a dyno video

http://www.youtube.com/watch?list=UU...yer_detailpage
  Reply With Quote
Old 10-09-2012, 07:49 PM   #2
Senior Member
magnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shedmagnetic11 is one of the sharper tools in the shed

magnetic11's Avatar
Marines: MACS2
Name: Matt
Joined: Feb 2012, #72357
Location: "some nuke plant"
Posts: 489
magnetic11's Tacoma Gallery
yep, i know what ill be doing to mine once the engine goes or i get tired of it..lol
  Reply With Quote
Old 10-09-2012, 07:49 PM   #3
DC TRD MallRunner
Taco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shedTaco Man in HD is one of the sharper tools in the shed

Taco Man in HD's Avatar
Name: Evan
Joined: Dec 2009, #27494
Location: Ohio
Gender: Male
Posts: 756
Taco Man in HD's Tacoma Gallery
  Reply With Quote
Old 10-10-2012, 08:39 PM   #4
Member
Twistinemup307 is on a distinguished road

Twistinemup307's Avatar
Name: Alex
Joined: Jul 2012, #82985
Location: Wyoming
Gender: Male
Posts: 71
Twistinemup307's Tacoma Gallery
BAD ASS!!!!!!!
  Reply With Quote
Old 10-12-2012, 09:33 PM   #5
Senior Member
sandman29306 is on a distinguished road
Name: Andrew
Joined: Sep 2010, #43850
Location: Chattanooga TN
Gender: Male
Posts: 118
sandman29306's Tacoma Gallery
Do you know if a shop or an individual did this installation?
  Reply With Quote
Old 10-13-2012, 10:23 AM   #7
Senior Member
Yamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shedYamaha Dave is one of the sharper tools in the shed

Yamaha Dave's Avatar
Joined: Mar 2010, #34080
Location: Austin,TX
Gender: Guy
Posts: 2,652
Yamaha Dave's Tacoma Gallery
Jesus Christ!
  Reply With Quote
Old 10-13-2012, 10:27 AM   #8
The Man!
JLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shedJLee is one of the sharper tools in the shed

JLee's Avatar
Name: Jerry
Joined: Jul 2010, #40461
Location: Bay Area NorCal
Gender: Male
Posts: 14,389
JLee's Tacoma Gallery
Amazing! please tell me your pulling the tiny Toy axles?
  Reply With Quote
Old 10-13-2012, 10:38 AM   #9
Poser Truck
jandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shedjandrews is one of the sharper tools in the shed

jandrews's Avatar
Joined: Jun 2009, #18122
Gender: Guy
Posts: 12,240
jandrews's Tacoma Gallery
Quote:
Originally Posted by JLee View Post
Amazing! please tell me your pulling the tiny Toy axles?
This. I would think the entire drivetrain would need to be swapped to keep from snapping shit.
  Reply With Quote
Old 10-13-2012, 04:57 PM   #11
Red
Large is one of the sharper tools in the shedLarge is one of the sharper tools in the shedLarge is one of the sharper tools in the shedLarge is one of the sharper tools in the shedLarge is one of the sharper tools in the shedLarge is one of the sharper tools in the shedLarge is one of the sharper tools in the shedLarge is one of the sharper tools in the shedLarge is one of the sharper tools in the shedLarge is one of the sharper tools in the shedLarge is one of the sharper tools in the shed
Joined: Sep 2011, #63268
Posts: 10,541
Large's Tacoma Gallery
Where is this located
  Reply With Quote
Old 10-13-2012, 05:22 PM   #12
jlee541 [OP] jlee541 is offline
Junior Member
jlee541 is on a distinguished road
Name: john
Joined: Oct 2012, #88655
Location: Canton, GA
Gender: Male
Posts: 4
jlee541's Tacoma Gallery
Yes, I did all the work at my shop in Atlanta. Owner lives in Florida.
As for the front diff and rear axle they will get changed (prob when they break LOL) But first thing needed is a trac bar of some sort. That rear u-joints hatin life right now!!



Before the trans was sent off to get modified and the Spec 3+ clutch that I used


Heres where I had to notch the oil pan to clear the front diff. This swap would not have been possible had the truck not had the Fabtech front lift kit. Also had to use a Canton remote filter adaptor.



Modified pump assembly. Bosch 044 and I put in an Autometer 240-33 ohm sending unit to work with the Camaro gauge. Which turned out I had to put a series of diodes and resistor in to get the LS3 ECM to read it properly. Camaros have two senders in the saddle tank. That took quite a bit of testing to make work. But the dash now gives instant mpgs and miles to empty WOHOO!!


Gas pedal mount. This was a task in itself as the e-brake mechanism was all in the way. Had to modify this mount a few times to get the pedal in the right spot.


Headers (before ceramic coating)

Trying to get a good angle of how tight this is in the truck



And this is how tight the front is. I used the stock radiator, made an aluminum plate with two 9" and one 16" fan. Running off LS3 ecm I programmed them to come on in series. Absoutely zero overheating problems. , the big fan cycles between 187 and 181 for about 20 seconds.



Used all 08+ Corvette accessories as they are the tightest to the block and had to put a little bit narrower battery to clear the alternator. Also had to notch the frame on the pass side for the ac compressor and hoses.


Full Dual 3" exhaust into a Magnaflow x-pipe muffler with turndowns YEEHAW!! Actually it isnt redneck loud, sounds awesome and absolutely no fumes or anything inside the cab.




This is what controls the transfer case, out of an Astrovan Its basically an on demand AWD and with a switch I can send 6-8 volts to the encoder motor to force it into AWD. Or disconnect the power and the ADD for 2wd operation.






Owner took the truck back to FL today and hopefully get some pics of the finished interior/dash soon.
Also, hes gonna do some sort of hood scoop(s). Why I built the intake that way.
  Reply With Quote
Old 10-13-2012, 05:45 PM   #13
SNAPPIN NECKS AND CASHIN CHECKS.
EL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shedEL TACOROJO is one of the sharper tools in the shed

EL TACOROJO's Avatar
Name: BURRY
Joined: Jun 2009, #18220
Location: south mills NORCAR
Age: 35
Gender: Dude
Posts: 10,640
EL TACOROJO's Tacoma Gallery
Send a message via MSN to EL TACOROJO
Nice work. Like to see more
  Reply With Quote
Old 10-13-2012, 05:56 PM   #14
wes mantooth ™
Joben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shedJoben7726 is one of the sharper tools in the shed
Firefighter: I Babysit Adults
Name: Joben
Joined: Oct 2010, #45285
Location: Western PA/Va Beach
Gender: Male
Posts: 7,044
Joben7726's Tacoma Gallery
  Reply With Quote
Old 10-13-2012, 06:00 PM   #15
Say no to Bro
kirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shedkirkofwimbo is one of the sharper tools in the shed

kirkofwimbo's Avatar
Name: Clayton
Joined: Jul 2010, #40338
Location: Wimberley, TX
Gender: Male
Posts: 1,537
kirkofwimbo's Tacoma Gallery
  Reply With Quote
Old 10-13-2012, 06:18 PM   #19
Senior Member
nelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shednelson18matt is one of the sharper tools in the shed

nelson18matt's Avatar
Air Force: Ex-Cone
Joined: Mar 2009, #14939
Location: CA
Age: 29
Gender: Dude
Posts: 13,663
nelson18matt's Tacoma Gallery
that is freaking awesome

too bad the rest of the truck is, well.... uh...uh...uh... undesirable.
  Reply With Quote
Old 10-13-2012, 06:19 PM   #20
Senior Member
tacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shedtacomonazul is one of the sharper tools in the shed

tacomonazul's Avatar
Name: Luis
Joined: Mar 2012, #74163
Location: SOCAL
Gender: Dude
Posts: 1,448
tacomonazul's Tacoma Gallery
how much hp did it threw?
  Reply With Quote
