Bilstein 5100's.... Want to go 1-2" higher... HELP!

Reply

Thread Tools Search this Thread
Old 08-22-2011, 11:25 PM   #1
Senior Member
jeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to behold
Joined: Apr 2011, #54317
Location: Los Angeles
Gender: Male
Posts: 266
jeremy25056's Tacoma Gallery
Bilstein 5100's.... Want to go 1-2" higher... HELP!

Title says it all, I have 5100 bilstein's set at top hight. How do i got about lifting another inch or two. What complications will i run into? will it be as easy as adding a spacer on top of the strut? or body lift?

Thanks for all your help.

Jeremy



  Reply With Quote
Old 08-22-2011, 11:32 PM   #2
Custom User Title
Zac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shedZac808 is one of the sharper tools in the shed

Zac808's Avatar
Air Force: CSAR
Name: Zac
Joined: Aug 2009, #22040
Location: Viva Las Vegas
Gender: Dude
Posts: 2,820
Zac808's Tacoma Gallery
So ur sitting at 2.5. U could add a .25 spacer to each side. Anything else over that is not recommended.
  Reply With Quote
Old 08-22-2011, 11:40 PM   #3
Senior Member
jeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to behold
Joined: Apr 2011, #54317
Location: Los Angeles
Gender: Male
Posts: 266
jeremy25056's Tacoma Gallery
Quote:
Originally Posted by Zac808 View Post
So ur sitting at 2.5. U could add a .25 spacer to each side. Anything else over that is not recommended.
Gotcha, not recommended meaning...??
  Reply With Quote
Old 08-22-2011, 11:41 PM   #4
Somebody call for a Wambulance?
Mitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shedMitch is one of the sharper tools in the shed

Mitch's Avatar
EMS: Paramedic
Name: Mitch
Joined: Jun 2011, #58964
Location: Tigard, OR
Gender: Male
Posts: 5,646
Mitch's Tacoma Gallery
Quote:
Originally Posted by jeremy25056 View Post
Gotcha, not recommended meaning...??
Its not recommended if you want to keep your truck running in good working condition
  Reply With Quote
Old 08-22-2011, 11:42 PM   #5
Street glide or die
yotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shed

yotamikez's Avatar
Name: Mike
Joined: Nov 2010, #46777
Location: Valrico
Age: 22
Gender: Dude
Posts: 3,600
yotamikez's Tacoma Gallery
Are you 2wd or 4wd?
  Reply With Quote
Old 08-22-2011, 11:43 PM   #6
Pineapples on pizza Hawaiian does not it make.
Konaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shed

Konaborne's Avatar
Name: Cody
Joined: Nov 2010, #46536
Location: Kealakekua, Hawaii
Gender: Male
Posts: 30,937
Konaborne's Tacoma Gallery
Anything higher than 3" puts too much stress on your CV boots and stock UCA's...Overall not a good idea.

To go higher than 3" you need to start looking at dropped bracket lifts.
  Reply With Quote
Old 08-22-2011, 11:45 PM   #7
I've seen things you people wouldn't believe ....
OZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shed

OZ-T's Avatar
Name: Peter North
Joined: Dec 2009, #27584
Location: British Columbia
Gender: Dude
Posts: 12,293
OZ-T's Tacoma Gallery
If you are 2wd you can go spindles

if 4wd , you can go about 3 1/4" max or go to a drop bracket lift to go higher
  Reply With Quote
Old 08-22-2011, 11:46 PM   #8
Street glide or die
yotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shed

yotamikez's Avatar
Name: Mike
Joined: Nov 2010, #46777
Location: Valrico
Age: 22
Gender: Dude
Posts: 3,600
yotamikez's Tacoma Gallery
Quote:
Originally Posted by OZ-T View Post
If you are 2wd you can go spindles

if 4wd , you can go about 3 1/4" max or go to a drop bracket lift to go higher
This is what I was getting at tanks OZ
  Reply With Quote
Old 08-22-2011, 11:49 PM   #9
Senior Member
jeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to behold
Joined: Apr 2011, #54317
Location: Los Angeles
Gender: Male
Posts: 266
jeremy25056's Tacoma Gallery
Quote:
Originally Posted by yotamikez View Post
Are you 2wd or 4wd?
Quote:
Originally Posted by Konaborne View Post
Anything higher than 3" puts too much stress on your CV boots and stock UCA's...Overall not a good idea.

To go higher than 3" you need to start looking at dropped bracket lifts.
Quote:
Originally Posted by OZ-T View Post
If you are 2wd you can go spindles

if 4wd , you can go about 3 1/4" max or go to a drop bracket lift to go higher
I am 4x4. Drop brackets.... Im sorry for being a newb... anyone have a link to some reading up i can do on it?

Say i just do the spacers, will i have to worry about the lift/alignment?

Jeremy
  Reply With Quote
Old 08-22-2011, 11:52 PM   #10
Street glide or die
yotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shedyotamikez is one of the sharper tools in the shed

yotamikez's Avatar
Name: Mike
Joined: Nov 2010, #46777
Location: Valrico
Age: 22
Gender: Dude
Posts: 3,600
yotamikez's Tacoma Gallery
http://www.tacomaworld.com/forum/sus...uide-read.html

Read this it will help.
  Reply With Quote
Old 08-22-2011, 11:52 PM   #11
I've seen things you people wouldn't believe ....
OZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shed

OZ-T's Avatar
Name: Peter North
Joined: Dec 2009, #27584
Location: British Columbia
Gender: Dude
Posts: 12,293
OZ-T's Tacoma Gallery
Quote:
Originally Posted by jeremy25056 View Post

Say i just do the spacers, will i have to worry about the lift/alignment?

Jeremy
You don't wanna stack lifts
  Reply With Quote
Old 08-22-2011, 11:56 PM   #12
Senior Member
jeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to behold
Joined: Apr 2011, #54317
Location: Los Angeles
Gender: Male
Posts: 266
jeremy25056's Tacoma Gallery
Quote:
Originally Posted by OZ-T View Post
You don't wanna stack lifts
I didn't mean lift, i meant just spacing the wheels/tire out.
  Reply With Quote
Old 08-22-2011, 11:56 PM   #13
Pineapples on pizza Hawaiian does not it make.
Konaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shedKonaborne is one of the sharper tools in the shed

Konaborne's Avatar
Name: Cody
Joined: Nov 2010, #46536
Location: Kealakekua, Hawaii
Gender: Male
Posts: 30,937
Konaborne's Tacoma Gallery
Quote:
Originally Posted by jeremy25056 View Post
I am 4x4. Drop brackets.... Im sorry for being a newb... anyone have a link to some reading up i can do on it?

Say i just do the spacers, will i have to worry about the lift/alignment?

Jeremy
I'm not a DB lift expert. look up pro-comp and fabtec 6" lifts. I think rough country makes a 4" too.

With the spacers, on top of the 2.5, you'll probably have alignment issues, on top of stressed CV boots.

EDIT: didnt see you reply to oz about the spacers.
  Reply With Quote
Old 08-22-2011, 11:57 PM   #14
I've seen things you people wouldn't believe ....
OZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shed

OZ-T's Avatar
Name: Peter North
Joined: Dec 2009, #27584
Location: British Columbia
Gender: Dude
Posts: 12,293
OZ-T's Tacoma Gallery
Quote:
Originally Posted by jeremy25056 View Post
I didn't mean lift, i meant just spacing the wheels/tire out.
Oh , sorry

Yes you can add wheel spacers , you shouldn't need to re-align it for that .
  Reply With Quote
Old 08-23-2011, 12:07 AM   #15
Senior Member
jeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to beholdjeremy25056 is a splendid one to behold
Joined: Apr 2011, #54317
Location: Los Angeles
Gender: Male
Posts: 266
jeremy25056's Tacoma Gallery
Quote:
Originally Posted by Konaborne View Post
I'm not a DB lift expert. look up pro-comp and fabtec 6" lifts. I think rough country makes a 4" too.

With the spacers, on top of the 2.5, you'll probably have alignment issues, on top of stressed CV boots.

EDIT: didnt see you reply to oz about the spacers.
Thank you for the input.

Quote:
Originally Posted by OZ-T View Post
Oh , sorry

Yes you can add wheel spacers , you shouldn't need to re-align it for that .

Well i guess i will start there and see how it is. Any recommendations for spacers?

J
  Reply With Quote
Old 08-23-2011, 12:10 AM   #16
I've seen things you people wouldn't believe ....
OZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shedOZ-T is one of the sharper tools in the shed

OZ-T's Avatar
Name: Peter North
Joined: Dec 2009, #27584
Location: British Columbia
Gender: Dude
Posts: 12,293
OZ-T's Tacoma Gallery
Quote:
Originally Posted by jeremy25056 View Post
Well i guess i will start there and see how it is. Any recommendations for spacers?

J
Lots of guys on here running these


http://www.toyteclifts.com/index.php...mart&Itemid=72
  Reply With Quote
