0.75 inch wheel spacer question

Discussion in 'Suspension' started by TPayneNFA, Dec 27, 2016.

  1. Dec 27, 2016 at 10:28 AM
    #1
    TPayneNFA

    TPayneNFA [OP] @prerunner_overland

    Joined:
    Nov 16, 2016
    Member:
    #202541
    Messages:
    85
    Gender:
    Male
    Alpharetta, GA
    Vehicle:
    2016 Tacoma | DCSB | 2.7L I4 | SSM
    7" Maxtrac Lift Fab Fours Bumper Icon Alloys Alpha in Gun Metal 315/70R17 Hankook Dynapro MT TRD LED DRL Headlights 5.29 Gears
    Is anyone running 0.75" spacers? The smallest spacers I have seen anyone run is 1.25". However, I am interested in the 0.75" spacers, to keep my track width narrower. It seems like to me that the 0.75" spacers will be too short for the factory lugs. Would I need to chop the factory lugs shorter? It seems like chopping shorter would be unsafe. If I did, how hard is it to replace them with new ones, to restore it to factory length?

    Here's the back story as to why I am asking... I am wanting to install some lift spindles on my 3rd Gen Tacoma SR5. I am still running the 16" aluminum wheels, which I'd like to try keeping for now. I know my BS is too deep on the factory wheels, to fit the spindles. So, I was considering using some 1.25" wheel spacers on the front, to provide enough clearance. However, the spindles already add 0.75" increased track width, which when combined with the 1.25" spacer will increase each side by 2.0". I'm afraid that much of an increase will be too wide, and will look a little goofy on the truck. If I went that route, I would also add 2.0" spacers to the rear, to make the front and rear even. What should I do?

  2. Dec 27, 2016 at 10:35 AM
    #2
    PETEREDGE

    PETEREDGE Well-Known Member

    Joined:
    Dec 20, 2009
    Member:
    #27855
    Messages:
    426
    Gender:
    Male
    First Name:
    PETER
    TEXAS
    Vehicle:
    2012 BAJA BLACK 4X4
    ARB FRONT BUMPER...16x8 SR8 RIMS ,YOKAHAMA MT'S,DEMELLO SLIDERS,UPGRADED SOUND SYSTEM...
    I have run them before with no problem,had them on for about a year before i got new rims. They require no mod at all just bolt on and your good to go.

    TPayneNFA[OP] likes this.
  3. Dec 27, 2016 at 10:37 AM
    #3
    TPayneNFA

    TPayneNFA [OP] @prerunner_overland

    Joined:
    Nov 16, 2016
    Member:
    #202541
    Messages:
    85
    Gender:
    Male
    Alpharetta, GA
    Vehicle:
    2016 Tacoma | DCSB | 2.7L I4 | SSM
    7" Maxtrac Lift Fab Fours Bumper Icon Alloys Alpha in Gun Metal 315/70R17 Hankook Dynapro MT TRD LED DRL Headlights 5.29 Gears
    Really? Did any part of the factory lug or nut extend past the spacer?

  4. Dec 27, 2016 at 10:57 AM
    #4
    PETEREDGE

    PETEREDGE Well-Known Member

    Joined:
    Dec 20, 2009
    Member:
    #27855
    Messages:
    426
    Gender:
    Male
    First Name:
    PETER
    TEXAS
    Vehicle:
    2012 BAJA BLACK 4X4
    ARB FRONT BUMPER...16x8 SR8 RIMS ,YOKAHAMA MT'S,DEMELLO SLIDERS,UPGRADED SOUND SYSTEM...
    JUST VERY LITTLE BUT NOTHING THAT INTERFERED WITH THE WHEEL. I NEVER HAD ONE PROBLEM I HAD THE BRAND BORA.

  5. Dec 27, 2016 at 11:08 AM
    #5
    T-rev

    T-rev Resident Mall Crawler

    Joined:
    Apr 8, 2008
    Member:
    #5837
    Messages:
    2,058
    Gender:
    Male
    Tempe, AZ
    Vehicle:
    2017 TRD Offroad
    I have the Bora 0.75" spacers on mine.


    Bkoger43 likes this.
  6. Dec 27, 2016 at 11:22 AM
    #6
    mightytacoman

    mightytacoman Mighty-known Member

    Joined:
    Apr 3, 2013
    Member:
    #101270
    Messages:
    2,411
    Gender:
    Male
    First Name:
    Kel
    Vehicle:
    4.5L 1grfe
    Brian Crower stroker kit, Carrillo pistons moly/ceramic coated, BC sportsman rods, arp s2000 head bolts, Darton M.I.D sleeves, Kelford race cams, Magnusson supercharger, hp tuner tuned, 650cc flow matched fuel injectors, CSF radiator, Walbro 255 fuel pump. pulleyboys quick change pulley with 2.3", fpr mod, NST crank, water and alternator pullies, 160° mishimoto thermostat. Puma On-board air, Radflo CDC ext coilovers with 14" 700# springs, extended length rear Radflo shocks with CDC, Dakar leak pack, Brute Force Fab front bumper galvanized and powder coated, DTRL mod, yellow fogs, fog anytime mod, relocated rear differential breather, synthetic fluids, custom airbox, tundra sized intake. 76mm throttle body, secondary air filter removed, Airflow snorkel, 4x innovation sliders powder coated, URD equal length headers, DT y-pipe, Aero-Turbine 2525xl exhaust dumped over axle, seat belt chime disabled, Warn 8000i winch, 1- 20" slim light bar in grill, 42" curved roof light both with custom brackets. Mesh grill, Brute Force Fab rear bumper with extra reverse lights, u bolt flip kit, SS extended brake lines, hockey puck bump stop extension, AT shackle flip kit, Light Racing UCA's, 4crawler 1.5" bodylift. custom built front and mid skid plates, re-geared to 4.56s, windows tinted 25%, Sony stereo, 8" skar sub-woofer, 1000 watt mono amp, retrofit headlights with legal demon eye, Kryptek Marathon seat covers. North Star agm 27f battery, Helo 791 rims, 315/75/r16 Mt/r ARB front air locker
    I'm using 0.75" Bora spacers. Your rim will need to have the negative spaces in between or you'll have to shorten your factory lugs to make them work. On a note worth mentioning- while on a cross country trip (Cali->NY) my front wheel bearing went. The nuts that came with the wheel spacer would NOT come off. They are 19mm and I managed to round them off with a 6 point 19mm socket.. Ended up cutting the spacer in half with a grinder to remove it to replace the bearing. I contacted motorsport tech and told them what I did to the spacer. (not thinking they would warranty it because it only failed when it met the grinder.) They asked for a pic of the damaged spacer so I sent them one. the next day I had a new one sent to me at no cost. That's great customer service and standing behind a product!

  7. Dec 27, 2016 at 7:05 PM
    #7
    TPayneNFA

    TPayneNFA [OP] @prerunner_overland

    Joined:
    Nov 16, 2016
    Member:
    #202541
    Messages:
    85
    Gender:
    Male
    Alpharetta, GA
    Vehicle:
    2016 Tacoma | DCSB | 2.7L I4 | SSM
    7" Maxtrac Lift Fab Fours Bumper Icon Alloys Alpha in Gun Metal 315/70R17 Hankook Dynapro MT TRD LED DRL Headlights 5.29 Gears
    Thanks for all the info, everyone!
