2015 Tacoma trd off-road transmission cooler lines

Discussion in '2nd Gen. Tacomas (2005-2015)' started by Souped, Oct 1, 2023.

  1. Oct 1, 2023 at 5:09 PM
    #1
    Souped

    Souped [OP] New Member

    Joined:
    Oct 1, 2023
    Member:
    #434647
    Messages:
    3
    First Name:
    Souped
    Hi all,

    new member. I messed up. Bought this truck used and wanted to change oil. Drained the transmission pan in error. When I realized it was transmission fluid I put drain plug back in but lost about a quart of fluid.

    from what I understand I can add new fluid back in thru the transmission cooler lines on the drivers side of the radiator. There are three lines on that side. I suspect the two I need to focus on are lower down on the radiator. Which one do I plug and which one do I feel the fluid thru to?

    dumb mistake on my part but would be grateful to anyone that can help. Thank you in advance.

  2. Oct 1, 2023 at 5:30 PM
    #2
    Souped

    Souped [OP] New Member

    Joined:
    Oct 1, 2023
    Member:
    #434647
    Messages:
    3
    First Name:
    Souped
  3. Oct 2, 2023 at 7:21 PM
    #3
    Dm93

    Dm93 Test Don't Guess

    Joined:
    Mar 3, 2015
    Member:
    #150066
    Messages:
    13,773
    Gender:
    Male
    Texas
    Vehicle:
    2014 DC OR 6spd 4x4
    Predator tube steps, Ranch Hand grill guard, Magnaflow CatBack exhaust, Toyota tool box & bed mat, 2LO Module by @Up2NoGood, Rearview Compass/Temp Mirror, Tune by @JustDSM.
  4. Oct 2, 2023 at 8:09 PM
    #4
    Souped

    Souped [OP] New Member

    Joined:
    Oct 1, 2023
    Member:
    #434647
    Messages:
    3
    First Name:
    Souped
    Thank you both! I will do it the right way. Appreciate it very much!
