2016 SR5 V6 Fuse Diagram

Anyone have or know where I can find a fuse box diagram?

Downloaded a copy of the owners manual and couldnt find it.



Fuse box cover has all the fuses labeled. Is there something specific you are looking for? Also, there are two fuse panels on these trucks. Under hood and under dash on driver side.



To be honest I didn't even open them up yet lol

My headlights, low beams, wont turn on so I need to check the fuses.



Those should be under the hood. The box lid has the fuse locations printed on it.



I found it fuses are good so I think it's the relay. Both low beams wont turn on



I tried that... Swapped the relays and the fuses and the head light wont come on. The bulbs illuminate when the high beams are on though. I pulled the bulbs and the look fine also....

Any suggestions?



Try new bulbs?

Have you messed with anything that would cause the bulbs to go out?



Are you trying to do the H11 to H9 bulb mod?



No



Neither lights just stopped working



Left and Right have different fuses I believe so it would be odd to have them both pop at the same time. You need a known good headlight to rule out both low beams burned out, which would also be weird, but you could have had one out for a while and not noticed.



Just for clarification can someone idendity for me high vs low beam bulbs and when which should be on?



The bulb has continuity



H11 is low beam(outside).
H9 is high beam(inside).



Problem sovled.... operator error... *facepalm*

Thanks for all the help guys much appreciated.



Going to need more information about what happened.



It was my failure of understanding which bulbs where high and low and how to operate them... I automatically assumed the truck was faulty and not me. I read the owners manual and face palmed
