2nd gen w/2" lift - rear shocks

Discussion in '2nd Gen. Tacomas (2005-2015)' started by tomrad, Jul 27, 2022.

  1. Jul 27, 2022 at 3:49 PM
    #1
    tomrad

    tomrad [OP] Well-Known Member

    Joined:
    Jul 11, 2022
    Member:
    #401126
    Messages:
    141
    Gender:
    Male
    Vehicle:
    2008 Tacoma Access cab, automatic 4x4
    My truck has original rear shocks at over 300k miles. Left one is now leaking oil. This is the first lifted truck I've owned, so a novice at shock considerations with a lift.
    There's a 2" block at the rear leaf springs, and the springs were replaced in the recall a few years ago.
    Looking for shock absorber recommendations. I picked up a set of the yellow and blue OEM ones cheap (slightly used), but was not sure if they are worth putting on due to the lift. I drive mainly on pavement.
    Also, running 285's.
    Thanks!

  2. Jul 27, 2022 at 3:52 PM
    #2
    pahaf

    pahaf Well-Known Member

    Joined:
    Mar 28, 2020
    Member:
    #323255
    Messages:
    1,429
    Gender:
    Male
    First Name:
    paul
    NorCal
    Vehicle:
    2015 Tacoma TRD Off Road
    Bilstein 6112/5160 OME Meduim leaf pack JBA HD UCA 3* retard exhaust gear TRD Pro Sema rims 265/70R17 Falken Wildpeak AT3W
    All depends on your budget.
    Keep in mind the shocks you picked up, are made for a stock height. So that means if the truck is stock height, the shock can collapse 3” and then expand 3”….not sure if it is 3” either way but just using it as a example. Now that you are lifted, the shock can go down 5” but up only 1”

    so people usally upgrade to a shock that is made for a lifted Tacoma. Popular option is the bilstein 5110.

    stvhwrd likes this.
  3. Jul 27, 2022 at 4:07 PM
    #3
    tomrad

    tomrad [OP] Well-Known Member

    Joined:
    Jul 11, 2022
    Member:
    #401126
    Messages:
    141
    Gender:
    Male
    Vehicle:
    2008 Tacoma Access cab, automatic 4x4
    Thanks, should that model be 5100? I've looked into those, may go that route. I'm not a big fan of the yellow shock look (prefer black, blends with the rest of the suspension). :D

  4. Jul 27, 2022 at 4:13 PM
    #4
    pahaf

    pahaf Well-Known Member

    Joined:
    Mar 28, 2020
    Member:
    #323255
    Messages:
    1,429
    Gender:
    Male
    First Name:
    paul
    NorCal
    Vehicle:
    2015 Tacoma TRD Off Road
    Bilstein 6112/5160 OME Meduim leaf pack JBA HD UCA 3* retard exhaust gear TRD Pro Sema rims 265/70R17 Falken Wildpeak AT3W
    Sorry, you are correct. I’m a little wired up. Had 2 scoops of C4 pre workout. Lol

    bilstein 5100. Great shocks. And they are silver. Agree that the yellow doesn’t look that good.

  5. Jul 27, 2022 at 4:20 PM
    #5
    tomrad

    tomrad [OP] Well-Known Member

    Joined:
    Jul 11, 2022
    Member:
    #401126
    Messages:
    141
    Gender:
    Male
    Vehicle:
    2008 Tacoma Access cab, automatic 4x4
    Cool, thanks fellas. Bear with me, I'm old and not used to lifted trucks. Although I did have a new 88 Ranger STX years ago that had 'high rider' package, which was a mild suspension lift.
    I do appreciate the advice, will order the 5100's.

  6. Jul 28, 2022 at 12:00 PM
    #6
    Inbred

    Inbred Well-Known Member

    Joined:
    Mar 19, 2021
    Member:
    #359904
    Messages:
    180
    Gender:
    Male
    First Name:
    Phinnius
    Vehicle:
    2nd generation euphoria
    Ive read the
    Pretty sure the 5100 rears are designed for stock heights same as the stock blue and yellow Bilsteins.

    Jeffch likes this.
  7. Jul 28, 2022 at 12:11 PM
    #7
    Jeffch

    Jeffch Well-Known Member

    Joined:
    Dec 23, 2011
    Member:
    #69251
    Messages:
    3,057
    Gender:
    Male
    First Name:
    Jeff
    Vermont
    Vehicle:
    2018 off road
    Running 285/75/16s
    I believe the 5100 rears are noted 0-1” lift.

    pahaf likes this.
  8. Jul 28, 2022 at 12:12 PM
    #8
    TacoTuesday1

    TacoTuesday1 Well-Known Member

    Joined:
    Jun 19, 2019
    Member:
    #296781
    Messages:
    6,953
    Gender:
    Male
    NC
    5160
    Icon RXT find a used set for $300

    minimum starting point
    Better than that is archive shock relocate for taller shock

    would not waste time and money bothering with things like AAL/progressive AAL, 5100, etc
    5160 is not much more than 5100

  9. Jul 28, 2022 at 12:31 PM
    #9
    Inbred

    Inbred Well-Known Member

    Joined:
    Mar 19, 2021
    Member:
    #359904
    Messages:
    180
    Gender:
    Male
    First Name:
    Phinnius
    Vehicle:
    2nd generation euphoria
    Fox 2.0 has a version for 2-3 " lift. Available at Accutune. FOX-985-26-117-TACO

  10. Jul 28, 2022 at 2:30 PM
    #10
    nd4spdbh

    nd4spdbh Well-Known Member

    Joined:
    Oct 7, 2013
    Member:
    #114055
    Messages:
    14,148
    Gender:
    Male
    SoCal
    Vehicle:
    13 DCSB TRD OR v6 Auto
    with a 2inch block lift you will want to go with a proper length shock so you actually have some droop. With the b110 5100s you gotta watch out for over extension of brake lines as they are quite long shocks (4.25ish in longer than stock). With the 2 in block you wouldnt have to worry about collapsed lengths.

    You can do the 5125's -

    and not worry as much about brake lines (its what I run on my truck and only had to bend up the bracket on the axle to point them more upwards with the stock lines).

    OR

    You could get shock shaft extensions for the stock shocks which would make up for the block height.

  11. Jul 28, 2022 at 2:41 PM
    #11
    tomrad

    tomrad [OP] Well-Known Member

    Joined:
    Jul 11, 2022
    Member:
    #401126
    Messages:
    141
    Gender:
    Male
    Vehicle:
    2008 Tacoma Access cab, automatic 4x4
  12. Jul 28, 2022 at 2:48 PM
    #12
    nd4spdbh

    nd4spdbh Well-Known Member

    Joined:
    Oct 7, 2013
    Member:
    #114055
    Messages:
    14,148
    Gender:
    Male
    SoCal
    Vehicle:
    13 DCSB TRD OR v6 Auto
    that part number is a stock length shock part number. You wont have much if any droop with your setup and those shocks, and due to the blocks wont have full use of the shock itself. You could pair that shock with some shock shaft extensions

  13. Jul 28, 2022 at 3:21 PM
    #13
    tomrad

    tomrad [OP] Well-Known Member

    Joined:
    Jul 11, 2022
    Member:
    #401126
    Messages:
    141
    Gender:
    Male
    Vehicle:
    2008 Tacoma Access cab, automatic 4x4
    Thanks for the info. I hadn't thought much about it as I am used to non lifted vehicles but what you said makes sense.
    I'm hoping I'll be ok with the B8 5100's since I don't really go off road, and the lift has been on the truck several years with stock shocks. Don't want to do too much other than replace the bad shock, but from what I've read, the 5100 is dramatically better than the OEM shock.
    :DMy first thought was to swap the one leaky shock with a good identical one, but I figured at 300k they both should be replaced. Bushings are dried out also.
    From my experience, shocks last a very long time (but I drive conservatively).
    Thanks again for your help, much appreciated!

  14. Jul 28, 2022 at 5:47 PM
    #14
    jackn7

    jackn7 Old Man Tan Taco

    Joined:
    Feb 9, 2013
    Member:
    #97174
    Messages:
    1,394
    Gender:
    Male
    First Name:
    Art
    So Cal
    Vehicle:
    2008 DCLB 4x4
    Just some stuff...
    Any chance they can switch them out for the correct length shocks? They do make one for lifts up to 2.5 inches. Hopefully customer service can help you out.

    Last edited: Jul 28, 2022
  15. Jul 29, 2022 at 7:29 AM
    #15
    Inbred

    Inbred Well-Known Member

    Joined:
    Mar 19, 2021
    Member:
    #359904
    Messages:
    180
    Gender:
    Male
    First Name:
    Phinnius
    Vehicle:
    2nd generation euphoria
    Dramatically better?



    jackn7 likes this.
  16. Jul 29, 2022 at 8:00 AM
    #16
    tomrad

    tomrad [OP] Well-Known Member

    Joined:
    Jul 11, 2022
    Member:
    #401126
    Messages:
    141
    Gender:
    Male
    Vehicle:
    2008 Tacoma Access cab, automatic 4x4
    :D yep.
    Ok, how about significantly better?
    :D
