3rd Gen HID vs LED vs Halogen H11 projector headlights

Discussion in '3rd Gen. Tacomas (2016+)' started by crashnburn80, Jan 25, 2019.

  1. Dec 8, 2019 at 7:22 PM
    #2161
    jsh139

    jsh139 Member

    Joined:
    Sep 30, 2019
    Member:
    #306733
    Messages:
    10
    Gender:
    Male
    Vehicle:
    2019 Black TRD Pro
    I thinking you’re right. Thanks :thumbsup:

    Juggernaut likes this.
  2. Dec 8, 2019 at 8:34 PM
    #2162
    NMTrailRider

    NMTrailRider Well-Known Member

    Joined:
    Sep 28, 2009
    Member:
    #23469
    Messages:
    4,890
    New Mexico
    I just put my H9’s in tonight and noticed the exact same thing. WOWZERS. Not sure I’m gonna keep them in. I’d love the brighter light but man, I find it hard to believe this isn’t gonna bother oncoming drivers. Especially on dark 2 lane Hiway.

    The amount of increased light is remarkable. They’re like spotlights on buildings far off in the distance.

  3. Dec 8, 2019 at 9:39 PM
    #2163
    Joe671

    Joe671 YouTube Mechanic

    Joined:
    Jul 18, 2019
    Member:
    #299650
    Messages:
    299
    Gender:
    Male
    First Name:
    Joe
    Washington State
    Vehicle:
    2019 Tacoma TRD Off Road
    20191208_175604.jpg Swapped my GE +130's with these tonight. Nothing wrong with the +130's and I haven't had them for too long. Just couldn't wait to swap em with the H9's because who doesn't want a better light right? The 3rd one is a spare in case one burns out and I need to replace asap. Since they are so cheap I may just stock up on a bunch lol.

    Tullie D likes this.
  4. Dec 9, 2019 at 10:06 AM
    #2164
    Sasquatchian

    Sasquatchian Well-Known Member

    Joined:
    May 30, 2018
    Member:
    #254922
    Messages:
    249
    Gender:
    Male
    Your headlights must be properly aligned regardless of whether you have an high performance bulb or not. Misaligned lights, too high or too low are dangerous to both you and everyone else on the road with you. Unfortunately most people don't know how to align and most shops don't have the right equipment. The right equipment is NOT a line in a wall. It's a specialized alignment device like this Symtech DVA 6: https://www.tooldiscounter.com/prod...MI4cTwiZOp5gIVBtlkCh12WAW2EAQYBSABEgLnZfD_BwE Most Toyota dealers will not have anything like this but VW and Porsche dealers usually will.

    NMTrailRider likes this.
  5. Dec 9, 2019 at 10:21 AM
    #2165
    Sasquatchian

    Sasquatchian Well-Known Member

    Joined:
    May 30, 2018
    Member:
    #254922
    Messages:
    249
    Gender:
    Male
    I've been shooting things like this for decades, so it's really not that hard but it is complicated. It's a matter of approaching the object as if it were a mirror and controlling all the reflections. Conceptually easy but all but impossible if you've never done it. In this case, it was two soft boxes plus one large white reflector and a couple of black reflectors and then a series of secondary exposure using a black reflector over the central part of the white reflector, layered in afterward to control the highlight in the lens. In addition there were about a dozen shots that comprised slices or focus that were blended together in Helicon Focus software for the overall product photo. The entire background except for the reflections were generated by me using Photoshop.

    As for Morimoto, they don't exactly have a great track record. I did find some sort of SAE cert for their Ford f-150 replacements but it's hard to know if that's legit or not. Just the fact that they advertise on their website that their Tacoma versions have both vertical and horizontal aim adjuster make the lights not legal in the U.S. (remember that one of the big German makers was busted for just that and forced into a recall) But they also claim that their lights are DOT approved, and the DOT does not approve anything. I'll post a question for Virgil over at Candlepower Forums and see what he has to say about that. Maybe pop off an email to Stern as well.

    crashnburn80 [OP] likes this.
  6. Dec 9, 2019 at 11:05 AM
    #2166
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    9,000
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    I'm definitely not a pro photographer, though I have taken photography classes from the days when people still used film and dark rooms, but the biggest challenge I have photographing lights is the the light source. I don't have anywhere with good diffused ambient lighting which then always seems to cause reflections off of one surface or another. Granted I wasn't using any image post processing.

    Agreed on Morimoto. I don't recall when I had the Morimoto units if the horizontal aim had the required cap on the back or not, it wasn't something I looked for at the time. The 'DOT Approved' labeling is a very common mistake, obviously it should be 'SAE compliant'. Sometimes I think the lexicon gets lost in translation with the marketing dept, so it isn't clear if it is something that was never tested or mis-marketed.

    I'd be really curious if you hear back from Stern, I've been trying to return some of his stuff and he has been MIA.

  7. Dec 9, 2019 at 11:34 AM
    #2167
    Sasquatchian

    Sasquatchian Well-Known Member

    Joined:
    May 30, 2018
    Member:
    #254922
    Messages:
    249
    Gender:
    Male
    In addition, many of those early Morimoto HID units played havoc with electronic systems, but hopefully those are a thing of the past. I've had a lot of email correspondence with Stern, but not in the last couple of years. We were on a quest to upgrade the lights on my '88 911 when my father died and that sort of changed my direction for the last three years. More estate work today and tomorrow. Yay. Dan is an amateur photographer and his husband is a graphic designer and photographer - quite good by the way, so maybe that commonality opened a door between us.

    crashnburn80 [OP] and skierd like this.
  8. Dec 9, 2019 at 4:47 PM
    #2168
    ppat4

    ppat4 Active Member

    Joined:
    Oct 7, 2019
    Member:
    #307325
    Messages:
    36
    Gender:
    Male
    Vehicle:
    2016 Tacoma TRD Off-Road Access Cab
    No mods. Just added toolbox and roof-rack to haul my fishing boat 100's of miles into the backwoods every week.

    Thanks for the link, I'll check into that.

  9. Dec 10, 2019 at 2:15 PM
    #2169
    awwbugman

    awwbugman Well-Known Member

    Joined:
    Sep 14, 2018
    Member:
    #266246
    Messages:
    47
    Crashnburn, you are the man! Read the first few pages and they were extremely informative, thank you for posting your knowledge here. Based on what I've read, I am fairly set on the Hikaris, as I don't care much about high beam performance (have a lightbar if I really need to reach out) and simply want a better low-beam daily use option and do prefer the LED color tones to the warmer from an aesthetic standpoint. My last question which I didn't see covered in depth (apologies if it is covered, I skimmed after the first few pages) do you have any predictions or knowledge as to durability of these aftermarket solutions? In my case, specifically referring to the HIKARI-H11.

    Side note, are you also a flashlight geek by chance?

  10. Dec 10, 2019 at 2:41 PM
    #2170
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    9,000
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    I don't have high confidence in the Hikari longevity, though I haven't seen anyone say they have had them fail on the forum either. There are a handful of reviews on Amazon claiming early product failure though, but that is also a handful out of 1000+ reviews. As far as aftermarket solutions go there is a wide spectrum of product build quality, I'd have much high confidence in mainstream lighting brands like Philips. I have their latest H11 to test out, but I do not anticipate the performance being on par with the Hikaris.

    As to flashlights, I've toyed with it some. I always keep one in the door pocket of the truck, along with work gloves for when whatever need arises. But the real use I get out of flashlights is camping in the remote mountains after a day of 4wheeling to get out there. While ultra high power models seem nice, in a very dark camping environment they actually seem more harmful than helpful by being so bright it constricts your pupils, limiting your vision to only what is within the beam pattern. Then when you turn the light off you end up night blind. When camping I run mine on low power with the beam set to widely disbursed to try and reduce that effect. Ideally I'd like to try a yellow filter on the flashlight to have a warmer light source for camping. I run a pair of yellow KC Cylones off the RTT on a remote switch and really like the color for that environment. I don't have a camping picture of them at hand, but here was a driveway test shot.

    [​IMG]

    Last edited: Dec 10, 2019
  11. Dec 10, 2019 at 3:08 PM
    #2171
    NMTrailRider

    NMTrailRider Well-Known Member

    Joined:
    Sep 28, 2009
    Member:
    #23469
    Messages:
    4,890
    New Mexico
    Are you willing to share where you purchased the Philips H11 LED (low beam, not fog).

  12. Dec 10, 2019 at 3:18 PM
    #2172
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    9,000
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    The easiest place to get international products of course, shipping from Japan:
    https://www.ebay.com/itm/PHILIPS-LE...e=STRK:MEBIDX:IT&_trksid=p2057872.m2749.l2649

    I've ordered a lot internationally off of different regions Amazon sites as well, uk, france, germany ect. You can stumble through it based on familiarity with Amazon. Amazon changes the currency to USD for the transaction to process for you so you don't get hit with foreign currency transaction fees by your banking institution. They are also available on Amazon.jp:
    https://www.amazon.co.jp/PHILIPS-フィ...uPWNsaWNrUmVkaXJlY3QmZG9Ob3RMb2dDbGljaz10cnVl

    NMTrailRider likes this.
  13. Dec 10, 2019 at 3:27 PM
    #2173
    NMTrailRider

    NMTrailRider Well-Known Member

    Joined:
    Sep 28, 2009
    Member:
    #23469
    Messages:
    4,890
    New Mexico
    While I realize they aren’t sae compliant, are they still in the same boat as all the other drop in LED’s like the hikari’s, for example?

  14. Dec 10, 2019 at 3:38 PM
    #2174
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    9,000
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    In what way? In a projector housing the light cut off is maintained by the projector so you won't get glare issues like a reflector. With glare not an issue, it is about maintaining an even light distribution and hot spot focus while keeping good intensity. Focus and intensity are more challenging in smaller assemblies like projectors as the wider LEDs change the lighting geometry relatively more in relation to the internal reflector, which negatively affects the focus.

    NMTrailRider likes this.
  15. Dec 10, 2019 at 6:26 PM
    #2175
    NMTrailRider

    NMTrailRider Well-Known Member

    Joined:
    Sep 28, 2009
    Member:
    #23469
    Messages:
    4,890
    New Mexico
    I guess I was wondering if they can be used in a projector just like all the other thousands of options on Amazon.

    Looking forward to your review!

  16. Dec 10, 2019 at 8:16 PM
    #2176
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    9,000
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    Yes, just be sure it is the headlight model which is not readily available domestically, unlike the low output foglight model that is. Focus and distance projection milage results may vary. Waiting on the weather and my schedule to coordinate a date for the review.

    NMTrailRider likes this.
  17. Dec 10, 2019 at 9:43 PM
    #2177
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    9,000
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    You've seen my previous posts about the aux lights tied into the high beams, using the SAE KC Pro6 Driving lights. I've got my custom grill for the project, just need to get it all installed.

    Another local member was interested in doing the same project, but wanted to use a selective yellow light bar instead. I suggested @Diode Dynamics driving light bar as it is available in selective yellow and the performance specs looked very impressive with their unique and highly efficient Total Internal Reflector Optics. While twin 12" bars are SAE compliant, a single 18" bar is not as the intensity values are too high, but he selected a single 18" driving bar for easier packaging on the mount. A non-SAE product is technically not street legal, though with a high beam application it should never be run where it would affect forward/oncoming traffic. Of course I had to check this product out in person before we installed it.

    Very first thing that jumped out at me right away is the breather. I've never seen one this robust looking, most are a glued on piece of gortex like material which is a common failure point on some popular entry level lights. This protruding bolt with 4 holes is a breather, while internally it likely uses a similar type of material air permeable material, it wouldn't appear the breather will delaminate or otherwise mechanically fail and let moisture into the light like some other lights. Yes, I get excited about things like quality breather valves.


    The included product spec sheet was highly detailed, while there are a couple more specs I'd like to see like beam distance, it is impressively thorough. I always advocate for lighting companies to provide as much data as possible in their product specs. Those that just provide a raw lumens spec can be highly misleading of actual product performance.

    Diode Dynamics spec is 79.8w. After 20min run time I measured 75.9w.

    Beam pattern at 18'

    The output of this light bar was better than I expected for its very compact size. I selected the KC Pro6 driving lights based on best in class SAE specs, like candela, lux at 10m, and beam distance. But the Diode Dynamics lights give them a surprising run for the money in a more compact form at a fraction of the price and I actually like the Diode Dynamics yellow color better than the KCs with the amber covers. Although an intended use with the KCs is to be able to switch colors based on season, which is not available with the light bar.

    Mounting behind the grill using the BAMF behind the grill light bar mount. Unfortunately the legs of the Diode Dynamics light bar mount were too tall for this purpose and caused the light to be partially positioned behind the center of the Pro grill center bar on this 2nd Gen. Shorter mounting legs will need to be fabbed for the application.


    It was then easy to tap the high beam circuit to activate the lights automatically with the high beam. Using SAE compliant lights the auto high beam would be street legal, non-SAE lights are not. It would be exciting if @Diode Dynamics would make this as a twin section SAE light bar like Rigid for easier packaging than 2 separate 12" bars. I look forward to testing out their TIR fog pods.

    Last edited: Dec 11, 2019
  18. Dec 10, 2019 at 10:27 PM
    #2178
    mynameistory

    mynameistory Well-Known Member

    Joined:
    Jul 3, 2012
    Member:
    #81862
    Messages:
    288
    Gender:
    Male
    First Name:
    Tory
    Redondo Beach, CA
    Vehicle:
    4Runner
    I tell everyone that asks: I am super impressed with the Stage Series and recommend them to anyone looking for quality "midrange price" light bar(s).

    At one time I was considering a pair of 6" SS bars for auxiliaries in the upper grill, as you've noted that the two 12" lights don't package easily. Most of their product line appears to be modular and set on fixed, swappable components like heatsinks, end caps, and lenses. I assume that this helps in keeping their product mix low and their manufacturability high. I asked if they'd consider a 36" bar and they responded "not at this time". Same with people asking for curved bars, etc.

    It looks like these bars use the same temperature LEDs whether you select white or yellow, because those lenses look very amber to correct the difference. They technically are swappable, but it is a little more intensive with O-rings and small machine screws. No snap-on covers like the KC setup.

    My mind was made up when I saw the SS3 debut though. More light than the 6" bars in a slightly easier form factor. And unlike the bars, the optics and final pattern are molded as one piece. Neat!

    [​IMG]
    [​IMG]
    [​IMG]

  19. Dec 13, 2019 at 11:29 AM
    #2179
    Roldy

    Roldy Member

    Joined:
    Jul 9, 2019
    Member:
    #298771
    Messages:
    18
    Gender:
    Male
    First Name:
    Harry
    Vehicle:
    2017 Tacoma TRD
    TRD Pro Grille BFG KO2 265/75/16 K&N Cold Air Intake Bed Mat 35% Front Windows Tint
    So I wanted to give an update to everyone that I did get the change to install the relay hardness and it did help but I still got issues with my right (passenger side) headlight not coming on consistently and as of lately, not turning on anymore. I've narrowed down that the issue is probably due to a faulty ballast. I've contacted the vendor and they are going to warranty the ballast. Still annoying having to go through this but hopefully when the new ballast comes, I don't have to keep checking if my headlights are on.

    Jpalafox and crashnburn80 [OP] like this.
  20. Dec 13, 2019 at 12:25 PM
    #2180
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    9,000
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    If one failed, your other may likely as well. I'd suggest swapping to OEM Denso ballasts, they do cost significantly more but quality and reliability will be top notch.
    https://www.theretrofitsource.com/amp-denso-slim-35w.html

    Roldy likes this.
