3rd Gen HID vs LED vs Halogen H11 projector headlights

Discussion in '3rd Gen. Tacomas (2016-2023)' started by crashnburn80, Jan 25, 2019.

  1. Sep 15, 2020 at 7:29 PM
    #3161
    RoostrC0gburn

    RoostrC0gburn Well-Known Member

    Joined:
    Mar 5, 2020
    Member:
    #321337
    Messages:
    309
    Gender:
    Male
    Oregon
    Vehicle:
    2017 Super White DCLB TRD Sport 4x4
    maybe less expensive to do an LED projector retrofit?

  2. Sep 15, 2020 at 7:31 PM
    #3162
    awwbugman

    awwbugman Well-Known Member

    Joined:
    Sep 14, 2018
    Member:
    #266246
    Messages:
    258
    Kings/Deavers/SPCs 35x10.5 Kendas, LRA FuelTank, WARN Zeon10s SDHQ mount, Switch Pro, LightForce rock lights, reverse light & Lightbar, Baja Design Squadron Pro fogs, CaliRaised Sliders, RLD Canopy, Odyssey group 31, Dometic CFX3-55IM
    My understanding is that requires the entire headlight housing swap, which I feel the juice is absolutely not worth the squeeze as far as ROI is concerned. No knock to those who've done it, however not the path that I'd go. That money will go to a long range fuel tank, far before doing that. I already have Baja Design Squadron Pro (4,900 lumen each) full flood fogs and a 30" dual row hidden LightForce light bar that is spot only for off road. The goal here was to get a better light for daily driving purposes.

  3. Sep 15, 2020 at 8:00 PM
    #3163
    mynameistory

    mynameistory My member is well known

    Joined:
    Jul 3, 2012
    Member:
    #81862
    Messages:
    1,041
    Gender:
    Male
    First Name:
    Tory
    Redondo Beach, CA
    Vehicle:
    4Runner
    Your goal for daily (street legal) lighting is best served by H9 halogen bulbs to replace the low beam bulbs. You might also look into SAE fog lights, as those Baja ones cannot be used on the street. Lastly, consider SAE driving lights. They are legal to use as auxiliary high beams (i.e. not legal for full time use, only when not opposing traffic).

  4. Sep 15, 2020 at 8:04 PM
    #3164
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    14,563
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2003 DCSB TRD OR
    Go Hawks!
    @mynameistory has good advice, the only thing I might add is to consider the Hella 2.0 performance H9 bulbs over the Philips H9s if looking for a slightly whiter light, as they are noticeably whiter than the Philips without taking too large of a hit in output. The Hella 2.0 H9 review is linked in post #2.

  5. Sep 15, 2020 at 8:45 PM
    #3165
    awwbugman

    awwbugman Well-Known Member

    Joined:
    Sep 14, 2018
    Member:
    #266246
    Messages:
    258
    Kings/Deavers/SPCs 35x10.5 Kendas, LRA FuelTank, WARN Zeon10s SDHQ mount, Switch Pro, LightForce rock lights, reverse light & Lightbar, Baja Design Squadron Pro fogs, CaliRaised Sliders, RLD Canopy, Odyssey group 31, Dometic CFX3-55IM
    Thank you for the input gents, I'll take a gander at both of those as they may fit the bill. Not sure why I had it in my mind that LED was the way to go, but this might be it. To clarify, I'm definitely not going to swap the fogs I have, as I intentionally purchased them fully knowing what I was getting and the limitations of off road use only (which I adhere to unless on back roads). They work very well for flood/ intermediate distances and are much brighter and throw better than my OEM low beams. I'm just looking to improve the low beams for DD purposes, as mentioned previously. Link to current light setup:
    https://youtu.be/Jyr0rahXV4g

  6. Sep 15, 2020 at 9:00 PM
    #3166
    daveeasa

    daveeasa FBC Harness Solutions Vendor

    Joined:
    May 14, 2020
    Member:
    #328079
    Messages:
    6,733
    Gender:
    Male
    First Name:
    David
    PNW
    Vehicle:
    2016 Tacoma OR DCSB 6MT, 2005 RC 5MT PreRunner, 2002 Tundra SR5 RCLB 4x4
  7. Sep 15, 2020 at 9:12 PM
    #3167
    daveeasa

    daveeasa FBC Harness Solutions Vendor

    Joined:
    May 14, 2020
    Member:
    #328079
    Messages:
    6,733
    Gender:
    Male
    First Name:
    David
    PNW
    Vehicle:
    2016 Tacoma OR DCSB 6MT, 2005 RC 5MT PreRunner, 2002 Tundra SR5 RCLB 4x4
    OK, so, I was curious and did some quick searching, a long range tank for DCSB (maybe you have LB?) Tacoma is potentially in the realm of $1800 for 32 gallons? Holy S!

    I get the convenience aspect of it but even going with a full set of 4+ large rotopax fuel containers to add enough reserve to top off a completely empty stock tank could be done for less than $500 and be far more versatile. At say 15 mpg, 40 gallons of fuel gets you 600 miles of range. Are you really going that far off the grid that you need more than that? Genuinely curious.

    Maybe there are cheaper options for aux fuel tanks?

    I bet the set of Tacoma owners willing to spend on long range fuel tanks but not willing to drop $1500 on LED lighting is a pretty small group.

  8. Sep 15, 2020 at 9:19 PM
    #3168
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    14,563
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2003 DCSB TRD OR
    Go Hawks!
    More about convenience of not needing racks and rotopax to cary spare fuel, saving space to carry other things. But yes it certainly isn't the most economical way to carry spare fuel, but it is the cleanest in execution. There is a tank by the same company that replaces the spare with an aux secondary tank for a fair amount less, for those running oversized tires on a swing out carrier.

    daveeasa[QUOTED] likes this.
  9. Sep 15, 2020 at 9:28 PM
    #3169
    Tullie D

    Tullie D Well-Known Member

    Joined:
    Mar 5, 2019
    Member:
    #285417
    Messages:
    2,555
    Gender:
    Male
    First Name:
    Tullie
    Wilson, NC
    Vehicle:
    2019 SR5 V6 SSM Access Cab



    Last edited: Sep 16, 2020
  10. Sep 15, 2020 at 9:56 PM
    #3170
    mynameistory

    mynameistory My member is well known

    Joined:
    Jul 3, 2012
    Member:
    #81862
    Messages:
    1,041
    Gender:
    Male
    First Name:
    Tory
    Redondo Beach, CA
    Vehicle:
    4Runner
    Everyone's got different oranges to squeeze. I get the appeal of a LR tank AND great lighting. Wallet is the limiting factor.

    crashnburn80[OP] likes this.
  11. Sep 15, 2020 at 10:06 PM
    #3171
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    14,563
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2003 DCSB TRD OR
    Go Hawks!
  12. Sep 15, 2020 at 10:10 PM
    #3172
    harpo1

    harpo1 Well-Known Member

    Joined:
    Sep 1, 2019
    Member:
    #303921
    Messages:
    77
    Gender:
    Male
    Anyone know where I can get the GE Nightbreaker Xenon +120? The link in the 1st and 2nd post go to an H1 bulb. Are they no longer in production since GE sold their light business? I looked for them under the Tungsram name and can't find them either. If they're no longer available what's the next best thing to replace the stock fog light bulb in a halogen bulb?

  13. Sep 15, 2020 at 10:15 PM
    #3173
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    14,563
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2003 DCSB TRD OR
    Go Hawks!
    I haven't seen them available yet under the Tungsram label, and the ones under the GE label all appeared to sell out. The 2nd best is the GE/Tungsram Megalight +130. PowerBulbs is sold out, but there are some on ebay out of the UK here.

    This site contains affiliate links for which the site may be compensated.
    harpo1[QUOTED] likes this.
  14. Sep 15, 2020 at 10:19 PM
    #3174
    harpo1

    harpo1 Well-Known Member

    Joined:
    Sep 1, 2019
    Member:
    #303921
    Messages:
    77
    Gender:
    Male
    Thanks for the info.

    This site contains affiliate links for which the site may be compensated.
  15. Sep 15, 2020 at 10:21 PM
    #3175
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    14,563
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2003 DCSB TRD OR
    Go Hawks!
    I should add, an H9 swap is higher in output, costs less and is readily available. You just need to trim a small internal plastic tab off the bulb which only takes a minute with a small knife.

    Tullie D likes this.
  16. Sep 15, 2020 at 10:25 PM
    #3176
    harpo1

    harpo1 Well-Known Member

    Joined:
    Sep 1, 2019
    Member:
    #303921
    Messages:
    77
    Gender:
    Male
    Yeah I ordered the wiring harness to modify and the Philips H9's for the low beams. Would this be just as good as the Nighthawks for the fog lights?

  17. Sep 15, 2020 at 10:29 PM
    #3177
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    14,563
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2003 DCSB TRD OR
    Go Hawks!
    I didn't realize you were talking for the fogs. No, you don't want to use an H9 in the fogs, you want to stay with H11. The H9 bulb doesn't have a glare cap and will emit excessive uncontrolled glare. If possible, more ideal than a bulb change is to swap the assembly with Diode Dynamics SS3 SAE LED fogs in selective yellow.

    Edit: Also note only 12-15 trucks, and 16-19 TRD trucks use H11s in the fogs.

  18. Sep 15, 2020 at 10:44 PM
    #3178
    harpo1

    harpo1 Well-Known Member

    Joined:
    Sep 1, 2019
    Member:
    #303921
    Messages:
    77
    Gender:
    Male
    Yeah I have a 19. Thanks for the info on the Diode Dynamics. They're currently on back order so I may wait and see if they do a black Friday sale. Are the Sports good enough or do I need the Pro? I live in Northern Cali and we get some thick ass fog in the winter months.

  19. Sep 15, 2020 at 10:47 PM
    #3179
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    14,563
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2003 DCSB TRD OR
    Go Hawks!
    You can’t go wrong with either one. Sports have a shorter beam with tighter cut offs than the Pros. You can see my review on them in post #2725 here:
    https://www.tacomaworld.com/posts/22622437

    xxTacocaTxx and harpo1[QUOTED] like this.
  20. Sep 15, 2020 at 11:57 PM
    #3180
    awwbugman

    awwbugman Well-Known Member

    Joined:
    Sep 14, 2018
    Member:
    #266246
    Messages:
    258
    Kings/Deavers/SPCs 35x10.5 Kendas, LRA FuelTank, WARN Zeon10s SDHQ mount, Switch Pro, LightForce rock lights, reverse light & Lightbar, Baja Design Squadron Pro fogs, CaliRaised Sliders, RLD Canopy, Odyssey group 31, Dometic CFX3-55IM
    I strongly disagree, but hey, that's why Baskin Robins makes 31 flavors! :cheers:

    The tank is 34 gallons, approximately a 14 gallon increase over stock, and has been selling for apprx $1,500 shipped to TW members. In addition Be it rotopax or jerry cans, not only would you need 3x 5 gallon receptacles, but you'd need to store them somewhere taking up a significant amount of space. For me, I'm trying to keep the exterior of the truck relatively clean, so that would take up bed space which I'd prefer not to. Not only does that take up precious space, but anywhere you'd mount the aux fuel cans places significant amount of weight (90+ lbs) higher up, raising center of gravity. Lastly it is indeed a pain to fuel, three times over, as opposed to just having the fuel there on demand. I personally see a significant benefit to the added fuel capacity, far over that of additional low beam brightness. In addition, I could reach 90% of the effectiveness of the 2020 OEM LED headlight conversion at a fraction of the cost with drop-in LED's or HID's. Of course this is unfortunately not to my preferred color temp, the cost vs benefit doesn't shake out to me.

    More info on the tank here, for those interested. Apologies for the derail. https://www.tacomaworld.com/threads/long-range-automotive-fuel-tank-34-gallon.490548/ BTW I really do appreciate the input on light options, knowledge is king and it helps to know what is out there.

    Last edited: Sep 16, 2020
    daveeasa[QUOTED] likes this.
