3rd Gen HID vs LED vs Halogen H11 projector headlights

Discussion in '3rd Gen. Tacomas (2016+)' started by crashnburn80, Jan 25, 2019.

  1. Jan 26, 2021 at 8:19 AM
    #4181
    Saturnine

    Saturnine I am a meat popsicle

    Joined:
    Jun 25, 2020
    Member:
    #332540
    Messages:
    733
    North of the wall
    Vehicle:
    17 TRD OR AC MGM
    Can't really do any better than what's in there. German-made philips h9

  2. Jan 26, 2021 at 10:17 PM
    #4182
    GrahamJ

    GrahamJ Member

    Joined:
    Oct 8, 2020
    Member:
    #343240
    Messages:
    9
    Gender:
    Male
    First Name:
    Graham
    Thanks for all the great info. I am definitely going to follow your advice and upgrade my low beams. What is your recommendation for the high beam?

  3. Jan 26, 2021 at 11:26 PM
    #4183
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    11,260
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    The comment was specifically around how 6000k is fatiguing, blue light on black road doesn't offer good contrast and surface glare from short wavelength light in wet environments is also difficult to process, as well as the short wavelength light being more distracting reflecting off of precipitation. In the case of plug and play 3rd Gen lights, the OEM LED 6000k units are the highest performing. But in the case of HID, where 4300k is the industry norm I wouldn't go out of my way to try for a lower output 6000k HID bulb.

    907rx7 and travadol like this.
  4. Jan 26, 2021 at 11:26 PM
    #4184
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    11,260
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    #4TOY4ME and travadol like this.
  5. Jan 27, 2021 at 11:47 AM
    #4185
    klavender1

    klavender1 Well-Known Member

    Joined:
    Sep 8, 2015
    Member:
    #163705
    Messages:
    1,380
    Columbia/Lugoff, South Carolina
    Vehicle:
    2005 GX 470
    Per this thread helped a coworker with his 2013 Highlander which has H11 low beams. Threw some H9s in and made a big difference! His fog lights were the funny thing. Every thing we read, the fogs took 9006s. So he ordered some 9012 HIRs. We pulled his bulbs out and they were PSX26Ws. I've never seen a bulb like that before. Is there a legit halogen upgrade for PSX26W fog lights?

  6. Jan 27, 2021 at 12:14 PM
    #4186
    daveeasa

    daveeasa Slowest crimp in the West

    Joined:
    May 14, 2020
    Member:
    #328079
    Messages:
    1,671
    Gender:
    Male
    First Name:
    David
    San Diego
    Vehicle:
    2016 OR 4x4 DCSB MGM 6MT
    Thanks for this. The contrast problems seem obvious/intuitive, well demonstrated trying to read a stamped part number on a part in the engine bay with 6000k flashlight vs a warmer light source. And the wet/ice/snow trouble I can intuit as well from wet roads (hope to some day observe first hand, never had an LED headlight anywhere near the snow before but hoping those days are coming.)

    The fatigue part got me interested. I did some quick searching and I would like to learn and read more based on what I came across. If you have additional sources worth posting, I'd be very appreciative. I assume we're talking about an increase in eye fatigue vs daylight driving as a reference when we discuss ideal light wavelength for minimizing fatigue? To compare 4000k directly with 6000k you'd likely want to use the same intensity and pattern which could be a legitimate challenge. Perhaps that is actually easiest with HID?

    It seems clear that driving in general causes some basic eye fatigue but I didn't easily find a study which isolates light wavelength as an input variable and attempts to measure driver fatigue as a function of that.

    This article in particular was rather well done but I am not sure it really discusses headlight peak wavelength specifically.
    https://deepblue.lib.umich.edu/bitstream/handle/2027.42/61186/100999.pdf?sequence=1&isAllowed=y

    Intuition (or at least my intuition) doesn't directly make the leap from higher wavelength headlights to increased eye fatigue. Admittedly I have no long trips with my one and only LED headlamps so my direct observations also don't help me out on this either. I'll accept others' opinions that whiter light increases their fatigue. My own observations with H9's in low beams on a 3h drive are that I get a bit sleepy with the warmer color, but it's awfully difficult to know if I'm more sleepy than the lousy OEM bulbs which were a bit whiter and certainly a lot more dim.

    And, yes, I also do get that the comment was specifically about HID industry norm 4300k vs higher wavelength 6000k and how clear and good that specific recommendation is.

    907rx7 likes this.
  7. Jan 27, 2021 at 1:18 PM
    #4187
    907rx7

    907rx7 Well-Known Member

    Joined:
    Jul 1, 2019
    Member:
    #298028
    Messages:
    544
    First Name:
    James
    Vehicle:
    '20 Tacoma DCSB SR 4x4
    This is interesting. From my limited knowledge on the subject, it may be worthwhile to separate eye fatigue from general fatigue. The reason I say this is there are variables affecting both. A few factors that come to mind that cause eye fatigue while driving.
    • Not refocusing. Applies to long trips while cruising more than anything. If your eyes are constantly focused at the same distance they get tired, similar to staring at a computer screen. It's good to be mindful of this and check your mirrors etc. occasionally to change focus distance.
    • High temp light. The more 'blue light' the more strain on your eyes in theory.
    Now the flip side to this is general fatigue. I think eye fatigue can lead to general fatigue over a long duration. But the interesting thing is the correlation between blue light and sleep. Blue light blocks the production of melatonin. Which is why you should avoid screen time close to bed or use programs like f.lux to reduce the color temperature of your screen after the sun goes down.

    I'm not trying to detract from your post @daveeasa hopefully this adds to the conversation, but this peaked my interest. Now I'm going to look for information on correlation between eye fatigue and general fatigue/sleepiness.

    daveeasa likes this.
  8. Jan 27, 2021 at 1:26 PM
    #4188
    bacon_st

    bacon_st Well-Known Member

    Joined:
    Jun 10, 2016
    Member:
    #189261
    Messages:
    1,172
    First Name:
    Alex
    San Diego
    Vehicle:
    16' Taco TRD sport
    Bought over $1000 worth of headlights mod parts and lights from retrofitparts


  9. Jan 27, 2021 at 1:27 PM
    #4189
    907rx7

    907rx7 Well-Known Member

    Joined:
    Jul 1, 2019
    Member:
    #298028
    Messages:
    544
    First Name:
    James
    Vehicle:
    '20 Tacoma DCSB SR 4x4
    :eek:

    bacon_st likes this.
  10. Jan 27, 2021 at 1:27 PM
    #4190
    RoostrC0gburn

    RoostrC0gburn Well-Known Member

    Joined:
    Mar 5, 2020
    Member:
    #321337
    Messages:
    182
    Gender:
    Male
    Oregon
    Vehicle:
    2017 Super White DCLB TRD Sport 4x4
    watcha makin over there?

    bacon_st likes this.
  11. Jan 27, 2021 at 1:30 PM
    #4191
    GarlicFarts

    GarlicFarts Bang Ding Ow

    Joined:
    Dec 12, 2019
    Member:
    #313138
    Messages:
    5,455
    Gender:
    Male
    Lil Rhody
    Vehicle:
    2020 White DCSB TRD OR
    SOS bolt-on sliders In-cab sleeping platform Soft Topper
    Drove home in the snow last night.

    1 - 3500k low and fogs killed it.
    2 - Bunch of oncoming cars with bright white lights. These were enough that they actually reflected off my housings, reflected off the snow from there and then back into my eyes. Color me impressed - at least in the snow, I'm happy to have 3500k lights! Maybe when I move to Texas I'll get some of the white ones again but for now, F that.

  12. Jan 27, 2021 at 2:04 PM
    #4192
    DawgLover

    DawgLover Well-Known Member

    Joined:
    Apr 12, 2020
    Member:
    #324458
    Messages:
    240
    Gender:
    Male
    First Name:
    Jordan
    McDonough, GA
    Vehicle:
    2020 Cement SR5 DCSB
    Leather, TRD cat-back performance exhaust, Predator side steps, black overlays, 4R TRD Pro wheels, Nitto Terra Grappler G2s 265/70/17, TRD Pro shift knob, bed mat, Diamondback SE, TRD Pro grille, OV Tune, interior LEDs
    I'm very curious to see what's in those boxes...

    bacon_st likes this.
  13. Jan 27, 2021 at 2:08 PM
    #4193
    bacon_st

    bacon_st Well-Known Member

    Joined:
    Jun 10, 2016
    Member:
    #189261
    Messages:
    1,172
    First Name:
    Alex
    San Diego
    Vehicle:
    16' Taco TRD sport

    Few weeks ago I came here to this thread seeking some advice.
    @TacoFergie was kind to explain, help put together parts and give advice to me.
    (No thanks to @mynameistory)
    I had previously modded my lights with BHLM and Meso side marker lights, and Meso Amber DRLs

    But both low as well as high beam performance on road was poor, though my headlight housing looked badass (see pic comparison below).
    Also a recent long road trip taught me good lights are as important as seat belts, it's a safety feature.

    So I decided to do a dual projector retrofit. RX350s for Low/High and also separate HighBeam projectors.
    Changed Fog lamps to DD SS3 Sport Driving White
    And few other things.


    1. Bi-Xenon: Lexus RX350 STi Lens
    Lexus RX350 Bi-Xenon Projectors: 2 X Bi-Xenon: Lexus RX350 (Non-AFS) (LHD) $290.00
    Clear Lens Upgrade: 2 X Lens: STi-R
    2. D2S: Osram Xenarc Night Breaker Laser HID (Bulbs (CBH = CLOSEOUT): 2 X (5700K)) (Duobox) $160
    3. H11: Pass-Through Harnesses with Grommet (Adapters: 1 X Harness: H-Series housing pass-through cables w/ grommet (H11)(2x)) $10.00
    4. Rubber Housing Caps (Housing Caps: 2 X Housing Cap: Cylinder (75mm))
    5. AMP to D2S Ballast Adapters (Straight)(AMP to D2S Ballast Adapters (Straight): 2 X AMP > D2S Ballast Adapters (Straight))
    6. HD Relay: H11 (2x Relay Harness: 1 X HD Relay: H11/H9/H8/880)
    7. AMP: Hylux A0050 (Ballasts: 2 X 45W / AMP: Hylux A0050 Ballast)
    8. Bought a 270V aftermarket alternator from DC Power Inc for my truck. $1000
    9. Diode Dynamics White (Driving) Max lights as fogs. $300
    10. High Beam: Morimoto Mini HB LED Projectors
    11. Mini Graphite Shrouds: 2 × Mini Graphite (Black Series) Shrouds
    12. H-Series housing pass-through cables w/ grommet (H11)(2x)
    13. Optional Centric Rings: 2 × Centric Rings: Mini H1
    14. Diode Dynamics Switchback LED DRLs with Turn light functionality. (replace Meso DRL) $200
    15. KC Lites, Cyclone LED - 2-Light Universal Under Hood Lighting System - 5W Flood Beam (for under the hood)
    16. Rigid Industries Ignite Flood Black Surface Mount $89 (for side mirror integrated ditch lights mod)


    Current setup (MGM truck below):

    Last edited: Feb 24, 2021
    TacoFergie, mynameistory and antlab67 like this.
  14. Jan 27, 2021 at 2:22 PM
    #4194
    Saturnine

    Saturnine I am a meat popsicle

    Joined:
    Jun 25, 2020
    Member:
    #332540
    Messages:
    733
    North of the wall
    Vehicle:
    17 TRD OR AC MGM
    @crashnburn80 Looks like the alpharex/tacomabeast sales team is out in full force. So many new reviews about how bright and awesome they are. It's a shame, really.

    Aws123 and Yodastacotruck like this.
  15. Jan 27, 2021 at 4:35 PM
    #4195
    i8boots

    i8boots Well-Known Member

    Joined:
    Mar 10, 2014
    Member:
    #125032
    Messages:
    200
    Gender:
    Male
    UT - 801
    Vehicle:
    2017 MGM DC SB TRDOR JBL
    Hood/bed lights, pop-n-lock, Bak X2 Tonneau, custom breaker box, Husky mudflaps, white interior LEDs, Morimoto xB v2 Headlights, Bilstein 6112/5160, Sumo Springs.
    Is there a post from crash tearing down the alpharex lights? I don't think I've read it.

  16. Jan 27, 2021 at 4:42 PM
    #4196
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    11,260
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    One? LOL. Here is one one their projector lights. Their reflector lights are even worse, I'd have to comb together a few posts on those.

  17. Jan 27, 2021 at 5:00 PM
    #4197
    RoostrC0gburn

    RoostrC0gburn Well-Known Member

    Joined:
    Mar 5, 2020
    Member:
    #321337
    Messages:
    182
    Gender:
    Male
    Oregon
    Vehicle:
    2017 Super White DCLB TRD Sport 4x4
    any word on oem led vs mori xb gen 2?

  18. Jan 27, 2021 at 6:50 PM
    #4198
    Yodastacotruck

    Yodastacotruck Well-Known Member

    Joined:
    Nov 10, 2020
    Member:
    #346407
    Messages:
    195
    Gender:
    Male
    Vehicle:
    2021 MGM 4x4 trd off road
    Stock
    So in conclusion is the best upgrade modifying h9 bulbs into the housing and which h9 were the brightest? Sorry kind of overloaded by information now

  19. Jan 27, 2021 at 7:13 PM
    #4199
    Yodastacotruck

    Yodastacotruck Well-Known Member

    Joined:
    Nov 10, 2020
    Member:
    #346407
    Messages:
    195
    Gender:
    Male
    Vehicle:
    2021 MGM 4x4 trd off road
    Stock
    curious does a h9 upgrade outperform the oem led or right there with it in terms of lux? Sorry didn’t see you test the oem led headlights or maybe I just missed it

  20. Jan 27, 2021 at 7:35 PM
    #4200
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    11,260
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    OEM LED is superior. See review in post #3626. Best H9 is the stock Philips German H9s.

    I know I am way overdue on the XB Gen2s. I'll get to them soon.
