3rd Gen HID vs LED vs Halogen H11 projector headlights

Discussion in '3rd Gen. Tacomas (2016+)' started by crashnburn80, Jan 25, 2019.

  1. Jul 4, 2019 at 11:06 AM
    #1321
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    7,722
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    The headlights at 18’ had very heavy overlap of the dual projector hotspots and came in ~2.2x stock lux. Since both projectors are equal in output I think it is a reasonable conclusion that each individual projector is roughly 1.1x lux at the hot spot. But I did not measure the projectors independently.

    The housing is aimed like OEM, though I thought I saw info there was a horizontal adjustment for the step cut off in the outer projector, though I haven’t looked for it on my units.

    The inner projector does point slightly more inward, though I’m not certain to what degree. You can see in the 18’ shot the hot spot is wide, the center of the outer projector hot spot is at the step whereas the outer edge of the inner projector hot spot is roughly at the step so they have overlap. At 42’ the hot spots are so spread it is difficult to visually judge and requires a meter. I’d have to setup at 42’ cover one projector, measure and mark the wall, then repeat with the other projector.

    With each individual projector producing slightly higher than stock output, I don’t think there is risk of ending up with less light than stock down road, especially being each projector pattern is going to have overlap with the other. These are a definite upgrade over the stock light assemblies running the stock bulbs.

    As to pattern width, it wasn’t something I measured but it didn’t stand out as noticeably different than stock either at the distance test.

    ERod27, skierd and Semper_Fi like this.
  2. Jul 4, 2019 at 11:22 AM
    #1322
    Semper_Fi

    Semper_Fi Well-Known Member

    Joined:
    May 15, 2019
    Member:
    #293432
    Messages:
    129
    Gender:
    Male
    AZ
    Vehicle:
    '17 TRD OR
    @crashnburn80 your profile picture begs the question... Do you enjoy being a motore?

  3. Jul 4, 2019 at 2:41 PM
    #1323
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    7,722
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    LOL. Pic is from one of my performance 22RE builds. Don’t recall what I was doing in there but it was likely the clutch.

    Shiney oversized valve head


    mcharfauros, se7enine and MGMSangTaco like this.
  4. Jul 7, 2019 at 3:42 PM
    #1324
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    7,722
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    DaBigDogg, Boghog1 and ratcityrain like this.
  5. Jul 7, 2019 at 5:49 PM
    #1325
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    7,722
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    Already sold and picked up.

  6. Jul 9, 2019 at 3:45 PM
    #1326
    Garab

    Garab Well-Known Member

    Joined:
    Dec 29, 2018
    Member:
    #277398
    Messages:
    303
    Gender:
    Male
    Vehicle:
    2018 TRD Sport MT6 DCSB
    OVtune 1.05 91 TRD Sema wheels 265/70/17 Falken Wildpeak AT/3 SL ADM
    I'd love to see an additional datapoint thrown in on your comparison graphs to show where the phillips HID bulbs match up.

  7. Jul 9, 2019 at 3:53 PM
    #1327
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    7,722
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    Philips HIDs are far brighter. You can compare the raw D1 and D2 lux data below.



    mcharfauros, Inferno__Taco and Garab like this.
  8. Jul 13, 2019 at 10:19 AM
    #1328
    Sequoia1321

    Sequoia1321 Well-Known Member

    Joined:
    Jun 15, 2019
    Member:
    #296416
    Messages:
    68
    Gender:
    Male
    Dallas, Texas
    Vehicle:
    2019 Tacoma SR Crew 4cyl
    I want to upgrade my 2019 Tacoma SR 4cylinder headlights and backup lights with LEDs, that are not too bright for oncoming traffic. Anybody know of some good quality options that are not expensive? Also want to add LED fog lights, on a budget. Any good options there? I was thinking getting stock fog lights and then switch them out to LEDs. Any good LED bulbs you recommend? Or is it better to get LED pre-installed fog lights?

  9. Jul 13, 2019 at 11:11 AM
    #1329
    El Duderino

    El Duderino Howzit \000/

    Joined:
    Dec 29, 2015
    Member:
    #173469
    Messages:
    9,645
    Gender:
    Male
    First Name:
    Jeremy
    Kahalu'u Oahu
    Vehicle:
    16 MGM Sport 4x4 DCSB & 19 nautical blue SR5 premium 4x4
    Stuff, things, this, an ADS
    Get the kc hilites fog lights. This whole thread tells you why you shouldn’t use LEDs in our headlights and fogs. They just don’t put the out put at distance and the glare blinds on coming drivers especially if you are running your fogs with LEDs. So crash will not recommend any LEDs for factory housing. Don’t believe the advertisements LEDs company’s say on their website crash has prove this time in and time out that they are wrong.

    YDCtaco, Sequoia1321 and CAG Gonzo like this.
  10. Jul 13, 2019 at 1:11 PM
    #1330
    Sequoia1321

    Sequoia1321 Well-Known Member

    Joined:
    Jun 15, 2019
    Member:
    #296416
    Messages:
    68
    Gender:
    Male
    Dallas, Texas
    Vehicle:
    2019 Tacoma SR Crew 4cyl
    Wow, I had no idea about not putting LEDs in original headlights. Sorry, thread is very long. I saw some youtube vids of people that did it and it seemed ok. The light was cleaner and brighter. They even did comparisons. I guess I should read this threat from the beginning before I say more. If I skip LED headlights and go with better halogen bulbs, which is a bright halogen that won't be anoying to other drivers? I have an SR which doesn't come with fog lights pre-installed so I have the option to go with original LED housing. But the KC lights are like over $300. Aren't there any decent LED fog lights in the $100 or less range?

  11. Jul 13, 2019 at 1:16 PM
    #1331
    Boghog1

    Boghog1 Jack of all trades, master of none.

    Joined:
    Dec 31, 2018
    Member:
    #277600
    Messages:
    1,547
    Gender:
    Male
    Southern, NH
    Vehicle:
    2019 AC V6 4x4 SR
    at least the first 2 post

    Sequoia1321 likes this.
  12. Jul 13, 2019 at 1:21 PM
    #1332
    Sequoia1321

    Sequoia1321 Well-Known Member

    Joined:
    Jun 15, 2019
    Member:
    #296416
    Messages:
    68
    Gender:
    Male
    Dallas, Texas
    Vehicle:
    2019 Tacoma SR Crew 4cyl
    My bad. Will look into it. Such a technical post. Good stuff. Thanks OP.

    Boghog1 likes this.
  13. Jul 13, 2019 at 3:31 PM
    #1333
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    7,722
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    As mentioned drop in LEDs do not project, the data is covered in the original post and some follow up posts in post #3. In halogen reflectors like fogs, LEDs also do not project and in addition cause significant glare to oncoming drivers. KC lights are some the best LED fogs, there are more budget friendly options like OEM Toyota LED fogs. All the info and options are in the SAE J583 fog thread below. Here is the post on the Toyota LED fogs that are just over $100.

    https://www.tacomaworld.com/threads...fog-light-review.554813/page-37#post-20419703

  14. Jul 13, 2019 at 4:45 PM
    #1334
    Sequoia1321

    Sequoia1321 Well-Known Member

    Joined:
    Jun 15, 2019
    Member:
    #296416
    Messages:
    68
    Gender:
    Male
    Dallas, Texas
    Vehicle:
    2019 Tacoma SR Crew 4cyl
    Thanks OP. What about 6kled.com fog lights, found here: https://www.6kled.com/tacoma-led-foglight-kit-p/bk90010.htm ?
    They're cheaper than the Toyota ones and also have their own housing. Saw a youtube video about them. Don't like how they look though with the black line in the middle, but not sure if they perform better.

  15. Jul 13, 2019 at 4:51 PM
    #1335
    Sequoia1321

    Sequoia1321 Well-Known Member

    Joined:
    Jun 15, 2019
    Member:
    #296416
    Messages:
    68
    Gender:
    Male
    Dallas, Texas
    Vehicle:
    2019 Tacoma SR Crew 4cyl
    Also, why do you say in another post not to use fog lights all the time? I used to have my fog lights on all the time in my Mitsubishi Montero Sport 2002 and they made things brighter at nights, and didn't seem anoying for other drivers. That's why I was planing to get fog lights. Otherwise I don't really have much use for them for fog purposes.

  16. Jul 13, 2019 at 4:59 PM
    #1336
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    7,722
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    Definitely no. Those lights are not a fog light and not J583 compliant. They have forward facing exposed LEDs which mean they have no cut offs and are basically the same as a light bar, they will blind other drivers and perform poorly in the conditions that fogs are designed for. People produce lots of poor uneducated videos on youtube.

    The OEM halogen fogs do a poor job of glare control, legal, but not great. Most of the aftermarket LED SAE fogs do much better. The usual goal is to see further at night, and outside of areas that have lots of ambient light, you see further when there is less near field light. Fogs produce a bunch of near field light which then will reduce your ability to see as far as possible. Fogs are a short distance wide angle light, they are not intended to help you see further or better down road, just immediately around you in poor weather conditions.

    SconnieTaco, ERod27 and Sequoia1321 like this.
  17. Jul 13, 2019 at 6:40 PM
    #1337
    Sequoia1321

    Sequoia1321 Well-Known Member

    Joined:
    Jun 15, 2019
    Member:
    #296416
    Messages:
    68
    Gender:
    Male
    Dallas, Texas
    Vehicle:
    2019 Tacoma SR Crew 4cyl
    Good to know. Will stay away from the 6kLED. Glad I found your thread. Very high level stuff. Was actually reading a thread here about LEDs, and after watching some Youtube vids with positive reviews about Tacoma LED mods I was sure I was going to plug in one of those LEDs. Then I ran into a post from El Duderino which linked to this thread. Glad I did. Will study it further before thinking about putting LEDs in the headlights. Great resource. Thanks again.

  18. Jul 13, 2019 at 7:10 PM
    #1338
    Gr8escapR

    Gr8escapR New Member

    Joined:
    Jun 25, 2019
    Member:
    #297413
    Messages:
    2
    Gender:
    Male
    First Name:
    Andrew
    Vehicle:
    2019 Cement TRD OR Three pedal
    i Wish there was an auto read feature so I could listen to all these posts while I do other stuff, what a thread... must get off TW now, Thanks for the info @crashnburn80

    crashnburn80 [OP] likes this.
  19. Jul 13, 2019 at 9:37 PM
    #1339
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    7,722
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    If you want LED headlights that perform decent, check out the Morimoto complete assemblies or the upcoming 2020 LED headlights. Will be significantly more expensive though.

    Should be able to do auto read by page on a smart phone. Might be kinda challenging to listen to though.

    Sequoia1321 likes this.
  20. Jul 13, 2019 at 10:25 PM
    #1340
    Sequoia1321

    Sequoia1321 Well-Known Member

    Joined:
    Jun 15, 2019
    Member:
    #296416
    Messages:
    68
    Gender:
    Male
    Dallas, Texas
    Vehicle:
    2019 Tacoma SR Crew 4cyl
    Does the chrome is the PT413-42190 make it significantly brighter than the PT413-42191?
