3rd Gen HID vs LED vs Halogen H11 projector headlights

Discussion in '3rd Gen. Tacomas (2016+)' started by crashnburn80, Jan 25, 2019.

  1. Jan 31, 2019 at 10:27 AM
    #121
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    8,532
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    I could take some IR temp measurements to compare, I’d expect the Hellas to run ~30% hotter. Not not an issue with the GEs since the total power into the system is the same.

  2. Jan 31, 2019 at 10:36 AM
    #122
    hyper15125

    hyper15125 Headlight Retrofitting Hobbyist Vendor

    Joined:
    Feb 11, 2015
    Member:
    #148420
    Messages:
    1,911
    Gender:
    Male
    NJ (609)
    Vehicle:
    ‘13 Taco, ‘14 T4R, SC430
    Nice work! :thumbsup:

  3. Jan 31, 2019 at 10:40 AM
    #123
    Tacosrus

    Tacosrus ipso facto

    Joined:
    Apr 19, 2018
    Member:
    #251056
    Messages:
    1,076
    First Name:
    Mike
    Northern California
    Vehicle:
    2018 Blazing Blue Pearl SR5 DCSB
  4. Jan 31, 2019 at 10:42 AM
    #124
    TiHo

    TiHo Well-Known Member

    Joined:
    Aug 26, 2018
    Member:
    #264160
    Messages:
    226
    Gender:
    Male
    Vehicle:
    2018 TRD Sport
  5. Jan 31, 2019 at 10:44 AM
    #125
    Tacosrus

    Tacosrus ipso facto

    Joined:
    Apr 19, 2018
    Member:
    #251056
    Messages:
    1,076
    First Name:
    Mike
    Northern California
    Vehicle:
    2018 Blazing Blue Pearl SR5 DCSB
    I'll mod these instead of the bulbs. Plug and Play afterwards

  6. Jan 31, 2019 at 10:50 AM
    #126
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    8,532
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    Instead of trimming the tab on the inside of an H9 bulb like below (trimmed left, stock right)

    [​IMG]


    You add a small wire harness extension and trim the harness as shown in post #78 below:
    https://www.tacomaworld.com/threads...de-not-led-or-hid.475064/page-4#post-18845649

    So rather than trimming the bulbs every time there is a bulb change, with the trimmed harness you only have to do it once and now you have a plug and play solution going forward.

    DartFrog, JeffB, mu.n8ball and 2 others like this.
  7. Jan 31, 2019 at 11:07 AM
    #127
    TiHo

    TiHo Well-Known Member

    Joined:
    Aug 26, 2018
    Member:
    #264160
    Messages:
    226
    Gender:
    Male
    Vehicle:
    2018 TRD Sport
    I ordered the GE +130's instead of going the H9 route but if the bulb life is significantly longer with the H9's I might switch to those after these burn out.

    crashnburn80 [OP] likes this.
  8. Jan 31, 2019 at 11:18 AM
    #128
    Tacosrus

    Tacosrus ipso facto

    Joined:
    Apr 19, 2018
    Member:
    #251056
    Messages:
    1,076
    First Name:
    Mike
    Northern California
    Vehicle:
    2018 Blazing Blue Pearl SR5 DCSB
    Just ordered 4 H9 Hella Bulbs.
    With the extensions comes to 55 Bucks Total. Jazzed.

  9. Jan 31, 2019 at 11:37 AM
    #129
    TNInferno

    TNInferno Well-Known Member

    Joined:
    May 21, 2017
    Member:
    #219568
    Messages:
    78
    Gender:
    Male
    First Name:
    Steve
    Tennessee
    Vehicle:
    2017 Inferno TRD OR DC
    @crashnburn80

    I have ordered 4 of the GE Ultra +130 bulbs for the lows and fogs. However, I am now wondering if there is something like these in amber for the fogs that will produce better light output? I can not remember reading anything concerning amber lights.

    crashnburn80 [OP] likes this.
  10. Jan 31, 2019 at 12:51 PM
    #130
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    8,532
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    Already on it. Hows this for color?


    You can see a teaser of what I am working on putting together in my fog thread post #378 here. This is using a 2300k (measured at 2500k) interference coated bulb from Xencn (Osram China). These are offered in an H11 +80 which would be plug and play for the fogs, though I have not tried the H11 version.

    Interference coated bulbs are more efficient than color coated (absorption) ones, but all filters reduce output. Fortunately halogen light does not produce much blue short wave light, so filtering the output to remove the blue short wave light to have the beam become more yellow/amber doesn't have anywhere near the negative effect as putting a blue filter on a bulb to filter out the yellow output, which is the majority of the light output. Lunex has their interference filtered Plasma Golds +80s at 2900k and Nokya offers standard interference filtered 2900k All Weather bulbs. I'm experimenting with Xencn because they use a more aggressive filter for lower color temp while also claiming to use an increased performance bulb. So far the results look promising but I am waiting on more product to arrive. I currently run an All Season interference bulbs in my headlights. You can see a comparison for how this works in my headlight post #1520 here.

    Geeterman and r1200gs4ok like this.
  11. Jan 31, 2019 at 2:09 PM
    #131
    TNInferno

    TNInferno Well-Known Member

    Joined:
    May 21, 2017
    Member:
    #219568
    Messages:
    78
    Gender:
    Male
    First Name:
    Steve
    Tennessee
    Vehicle:
    2017 Inferno TRD OR DC

    Thank you

    I had previously read that post but had forgotten the information about the all-weather bulbs.

    crashnburn80 [OP] likes this.
  12. Jan 31, 2019 at 2:26 PM
    #132
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    8,532
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    Just for clarification, note that picture is not the All Weather bulb, that is an Xencn 2300k bulb which is much more yellow/amber.

  13. Jan 31, 2019 at 2:37 PM
    #133
    TNInferno

    TNInferno Well-Known Member

    Joined:
    May 21, 2017
    Member:
    #219568
    Messages:
    78
    Gender:
    Male
    First Name:
    Steve
    Tennessee
    Vehicle:
    2017 Inferno TRD OR DC

    Thanks

    Where do you purchase these (Xencn 2300k H11 bulb) from - do not see them on Amazon.

  14. Jan 31, 2019 at 4:25 PM
    #134
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    8,532
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    They don’t distribute to North America. You can sometimes find them on eBay, but Aliexpress is cheaper.

    XENCN H11 2300K Golden Eyes Super Yellow Halogen E1 DOT Fog Lamp
    https://s.click.aliexpress.com/e/c1idYs6M

    I don’t typically buy any Chinese products for my truck if I can avoid it. The quality just usually isn’t there. For example I replaced my Chinese Hella fog relay with a Bosch European one. I’ve so far tested a couple bulbs from Xencn, and their build precision seems decent, better than some much more expensive bulbs I’ve seen. Just looking at their packaging quality is way better than most. I have no data though on bulb life or brand quality (other than it is an Osram company) outside of the very limited bulbs I’ve tried though.

    Last edited: Jan 31, 2019
    r1200gs4ok likes this.
  15. Jan 31, 2019 at 7:38 PM
    #135
    DohoTaco

    DohoTaco Well-Known Member

    Joined:
    Dec 2, 2016
    Member:
    #203895
    Messages:
    60
    Gender:
    Male
    Vehicle:
    3rd gen tacoma
    why did you tag me in this

  16. Jan 31, 2019 at 8:06 PM
    #136
    steezymac

    steezymac Well-Known Member

    Joined:
    Nov 13, 2016
    Member:
    #202309
    Messages:
    409
    Gender:
    Male
    First Name:
    Chris
    SoCal
    Vehicle:
    2016 Black Tacoma TRD Off-Road
    neat info about light modZ

    crashnburn80 [OP] likes this.
  17. Jan 31, 2019 at 9:11 PM
    #137
    r1200gs4ok

    r1200gs4ok Well-Known Member

    Joined:
    Aug 8, 2016
    Member:
    #194111
    Messages:
    1,733
    Gender:
    Male
    First Name:
    O. K.
    Irvine, Ca
    Vehicle:
    2016 Tacoma TRD Sport DCLB w/ Tech, Nav, Tow Pkg, MGM
    would you use Xenon Hella H9 or the GEs for the fogs......or better still use the Xenon Hella H9 for lows and GEs for fog........damn, so many options

  18. Jan 31, 2019 at 11:38 PM
    #138
    crashnburn80

    crashnburn80 [OP] Vehicle Design Engineer

    Joined:
    Jun 6, 2015
    Member:
    #156893
    Messages:
    8,532
    Gender:
    Male
    Kirkland, WA
    Vehicle:
    2015 DCSB TRD OR MGM
    Go Hawks!
    The H9s do not have a glare cap for open reflector use like in the fogs. In the projector headlights the internal light shield protects against glare from the missing glare cap. For a plug and play solution you will want to use an H11 in the fogs.

    r1200gs4ok likes this.
  19. Feb 1, 2019 at 5:36 AM
    #139
    Castle 4

    Castle 4 Well-Known Member

    Joined:
    Oct 6, 2018
    Member:
    #268465
    Messages:
    59
    Gender:
    Male
    First Name:
    Dan
    Richmond, VA
    Vehicle:
    2018 TRD Sport DCSB
    Falken Wildpeaks 275/70R17s; TRD Pro wheels; Meso Ultimate Turns, Maps, Dome, Gasshole, Coin Tray; Kicker Tweeters & Speakers; TVD Decals; Glovebox & Console Organizer; Hella H9s; OEM Tube Steps, Bed Mat, Tonneau Cover, Bed Extender.
    @crashnburn80, I work a lot with interior/exterior lighting in theatrical, historic, and commercial applications, and your analysis (and the science behind it) is spot on! The science behind lighting and lighting technology can be mind boggling, and you definitely know your shit. This forum is lucky to have you and your technical expertise!

  20. Feb 1, 2019 at 7:45 AM
    #140
    Tibetan Nomad

    Tibetan Nomad Well-Known Member

    Joined:
    Dec 9, 2016
    Member:
    #204436
    Messages:
    462
    Gender:
    Male
    First Name:
    2016TRDOR:DCLB:JBL
    Vehicle:
    B6112,1/4"spcr,SPC:UCA,Diff-drop,ECGS,SBumps
    B5160,3Leaf:AAL+OL,UBolt flip kit,Superbumps
    Link please!
