A/C blows hot at higher engine temps

Discussion in '2nd Gen. Tacomas (2005-2015)' started by Maninthebox88, Aug 12, 2020.

  1. Aug 12, 2020 at 1:08 PM
    #1
    Maninthebox88

    Maninthebox88 [OP] Member

    Joined:
    Jan 7, 2019
    Member:
    #278507
    Messages:
    12
    Gender:
    Male
    First Name:
    Randall
    Vehicle:
    2014 Silver Tacoma 4x4
    Sorry to start another thread on this guys but I have scoured the others and no ones problem sounds identical to mine. My average coolant temp day to day is about 184-186 degrees. On hotter days (100+ degrees in Texas) the temp will get as high as 220 degrees. Around 216 and up my A/C will begin blowing hot air. I’ve had the A/C checked and recharged at the dealership, I’ve personally replaced the thermostat, water pump and fan clutch. I’m at a loss for what it could be. Any help would be appreciated. Thanks.

  2. Aug 12, 2020 at 1:20 PM
    #2
    amend89

    amend89 Active Member

    Joined:
    Jun 6, 2020
    Member:
    #330546
    Messages:
    25
    Gender:
    Male
    First Name:
    Art
    Vehicle:
    2003 Tacoma PreRunner
    Almost 40 degree variation? Wow. I thought mine was bad. On a cool morning, under normal driving, my temp stays in the 195-197 range. 100+ degree weather, or under heavier acceleration, I've seen as high as 203. But never outside of that range. Radiator maybe?

  3. Aug 12, 2020 at 1:24 PM
    #3
    Maninthebox88

    Maninthebox88 [OP] Member

    Joined:
    Jan 7, 2019
    Member:
    #278507
    Messages:
    12
    Gender:
    Male
    First Name:
    Randall
    Vehicle:
    2014 Silver Tacoma 4x4
    That was my suspicion, but I’ve flushed the coolant twice. Granted, not with distilled water but the coolant looked fairly clean both times. I’ve used the orielly premix coolant each time along with the special coolant funnel to check for air bubbles.

  4. Aug 12, 2020 at 1:30 PM
    #4
    Clearwater Bill

    Clearwater Bill Never answer an anonymous letter

    Joined:
    Oct 11, 2014
    Member:
    #140097
    Messages:
    24,507
    Gender:
    Male
    First Name:
    Billy
    Largo Florida
    Vehicle:
    '13 5 lug AC w/convenience package
    A few OE parts from fancy trucks
    180* stat, that sounds about right

    That's not right. Some rise is to be expected, but no where near that much.

    Have you pressure tested the system? Not that you're having coolant loss, but just to see what it reads?

    When it gets hot, have you turned on the heat full blast to see if the temp will drop by using this 'second radiator'?

    Is the condensor and radiator clean on the outside, nothing jammed between them (mud, hay, etc) or in the fins?

    Do things change between open air cruising speeds and stop/go driving?

    IMHO the key here is to solve the cooling system situation (before you blow a headgasket) and then see what happens with the AC.

  5. Aug 12, 2020 at 1:35 PM
    #5
    Maninthebox88

    Maninthebox88 [OP] Member

    Joined:
    Jan 7, 2019
    Member:
    #278507
    Messages:
    12
    Gender:
    Male
    First Name:
    Randall
    Vehicle:
    2014 Silver Tacoma 4x4
    Yes sir I have tried the heater method and it slowly lowers the coolant temp. I’ve cleaned the coils on the exterior before. I have not done a pressure test, and I don’t seem to be losing coolant, no weird stuff in my oil or fouled plugs. I haven’t seen any signs to suggest a head gasket so far. Would the color change kit to detect exhaust leak be a viable option as well?

  6. Aug 12, 2020 at 1:40 PM
    #6
    Maninthebox88

    Maninthebox88 [OP] Member

    Joined:
    Jan 7, 2019
    Member:
    #278507
    Messages:
    12
    Gender:
    Male
    First Name:
    Randall
    Vehicle:
    2014 Silver Tacoma 4x4
    I should also add that this is really prominent at idle. I’m a homebuilding superintendent so I spend a lot of time in my “mobile office” a.k.a. My truck. Once I start driving, it will get the coolant back down in the 195-210 range and the AC will blow cool again.

  7. Aug 12, 2020 at 1:44 PM
    #7
    amend89

    amend89 Active Member

    Joined:
    Jun 6, 2020
    Member:
    #330546
    Messages:
    25
    Gender:
    Male
    First Name:
    Art
    Vehicle:
    2003 Tacoma PreRunner
    Airflow maybe? Fan/shroud, anything blocking the radiator?

  8. Aug 12, 2020 at 1:44 PM
    #8
    Clearwater Bill

    Clearwater Bill Never answer an anonymous letter

    Joined:
    Oct 11, 2014
    Member:
    #140097
    Messages:
    24,507
    Gender:
    Male
    First Name:
    Billy
    Largo Florida
    Vehicle:
    '13 5 lug AC w/convenience package
    A few OE parts from fancy trucks
    I don't suggest you have a blown head gasket. Yet. Just want to avoid that.

    You might try pulling the tstat and see what happens. Not that you should stay that way, as the ECU wants temp to change fuel mix. But if it's easy for you to do, it's worth a shot. I know you said it was new, but improper placement, or even being bad out of the both are possible.

    Can you see flow in the radiator when the cap is off (remove cap cold, then watch as it warms). This gives some comfort that the new water pump is pumping. And double checking that new fan clutch for engagement isn't a bad idea either.

    I've also seen lower radiator hoses collapse at higher RPMs/flow, creating an almost instant restriction and heat rise. So do your hoses seem firm and pliable, but not mushy?

  9. Aug 12, 2020 at 1:45 PM
    #9
    Clearwater Bill

    Clearwater Bill Never answer an anonymous letter

    Joined:
    Oct 11, 2014
    Member:
    #140097
    Messages:
    24,507
    Gender:
    Male
    First Name:
    Billy
    Largo Florida
    Vehicle:
    '13 5 lug AC w/convenience package
    A few OE parts from fancy trucks

    New info. Important. That screams fan. Forced air from driving makes things right, while idleing is dependent on the fan.

    CurtB and 0xDEADBEEF like this.
  10. Aug 12, 2020 at 1:51 PM
    #10
    Maninthebox88

    Maninthebox88 [OP] Member

    Joined:
    Jan 7, 2019
    Member:
    #278507
    Messages:
    12
    Gender:
    Male
    First Name:
    Randall
    Vehicle:
    2014 Silver Tacoma 4x4
    I used an OEM denso fan clutch. Are they likely to be bad out of the box? I will give it a couple tests to see if it is out, it didn’t occur to me to recheck that because it was new. Thank you for all your help so far sir.

  11. Aug 12, 2020 at 2:11 PM
    #11
    Zacowacko

    Zacowacko Well-Known Member

    Joined:
    Oct 16, 2015
    Member:
    #166800
    Messages:
    1,142
    Gender:
    Male
    First Name:
    Zack
    SW, OK
    Vehicle:
    2013 DCSB TE 4x4 6spd
    TRD Pro Susp., Icon AAL, Bags w/cradles, US OR Bumper w/Smitty, 2Lo Mod
    Using the Zerex Asian stuff? Not sure it matters, remember there was some reason to use it, lol. Electric fans may help? Not sure if thats an option for our trucks or not. If it matters, mine is pretty shitty cooling at a standstill (not moving). Always has been.

  12. Aug 12, 2020 at 2:15 PM
    #12
    Lester Lugnut

    Lester Lugnut Well-Known Member

    Joined:
    Mar 3, 2010
    Member:
    #32477
    Messages:
    2,822
    Gender:
    Male
    N of Mex-S of Canada-E of LA-W of NC
    Vehicle:
    '15 Tacoma PreRunner V6 SR5 Auto
    Tomorrow morning before you start the engine for the first time, try spinning the fan blades by hand. If there's little movement, the clutch is likely OK. If it spins freely on a cold engine, it's likely tired.
    Some people say a healthy fan clutch should roar when engaged. I've seen that happen on some european cars, but have yet to get a noticeable roar from my Tacoma or the wife 4Runner.

    Torspd likes this.
  13. Aug 12, 2020 at 2:30 PM
    #13
    Maninthebox88

    Maninthebox88 [OP] Member

    Joined:
    Jan 7, 2019
    Member:
    #278507
    Messages:
    12
    Gender:
    Male
    First Name:
    Randall
    Vehicle:
    2014 Silver Tacoma 4x4
    I will definitely give that a shot. I’ve never heard a roar either. I have a buddy whose F-150 sounds like a swamp boat when it engages.

  14. Aug 12, 2020 at 2:39 PM
    #14
    Zacowacko

    Zacowacko Well-Known Member

    Joined:
    Oct 16, 2015
    Member:
    #166800
    Messages:
    1,142
    Gender:
    Male
    First Name:
    Zack
    SW, OK
    Vehicle:
    2013 DCSB TE 4x4 6spd
    TRD Pro Susp., Icon AAL, Bags w/cradles, US OR Bumper w/Smitty, 2Lo Mod
    My wifes old Explorer and parents F250 was like that. But i figured out it was those extra electric fan(s) making all the noise. We lack those on our Tacomas. Funny to note though, her 2019 Highlander does have the additional electric fans and cools hella better than my Tacoma ever did. Maybe i need to look into those damn fans, lol.

  15. Aug 12, 2020 at 2:46 PM
    #15
    Maninthebox88

    Maninthebox88 [OP] Member

    Joined:
    Jan 7, 2019
    Member:
    #278507
    Messages:
    12
    Gender:
    Male
    First Name:
    Randall
    Vehicle:
    2014 Silver Tacoma 4x4
    I’ve never even looked into them man. Didn’t think it was an option given how little room there is.

  16. Aug 12, 2020 at 3:11 PM
    #16
    Torspd

    Torspd Tor-nication

    Joined:
    Sep 18, 2009
    Member:
    #22958
    Messages:
    26,318
    Gender:
    Male
    First Name:
    Tor
    The Great America!
    Vehicle:
    MMVI 4.4L 4x4 Access Cab
    Torspd Custom Turbo kit [] Borg Warner 9180EFR Turbo [] Haltech Elite 2500 [] TiAL Q BOV [] TiAL V44 Wastegate @ 15psi [] CP Pistons [] CP Carrillo Rods [] ARP Head studs [] ARP Main Studs [] ARP Header - Head Studs [] Ported Heads w/ 1mm oversized valves intake/exhaust [] Brian Crower Forged Stroker Crank [] Darton M.I.D. Sleeved Block [] Kelford Camshafts [] Torspd 160* T-stat mod [] APR Large Fuel Rail [] Walbro 460 LPH E85 Fuel Pump [] FueLab FPR [] APR T56 Conversion Kit [] KP RACING Built T56 [] McLeod Racing Custom Twin Disk Clutch [] One Piece Aluminum Driveshaft [] MGW Shifter [] Custom lowering kit [] Ohlins Front Coilovers [] QA1rear shocks [] Custom Ron Davis Radiator [] Dual SPAL Electric Fans []
    Mine has done this as well, while driving through the desert portion of I-8. Had to turn the A/C off actually to keep the engine temps from climbing any higher.

    My best recommendation is the CSF Radiator upgrade, with a 170° t-stat. A better electric fan setup would also benefit the system. Simply put, your lack of airflow is over taxing that thin OEM radiator.

    BassAckwards likes this.
  17. Aug 12, 2020 at 3:52 PM
    #17
    Lester Lugnut

    Lester Lugnut Well-Known Member

    Joined:
    Mar 3, 2010
    Member:
    #32477
    Messages:
    2,822
    Gender:
    Male
    N of Mex-S of Canada-E of LA-W of NC
    Vehicle:
    '15 Tacoma PreRunner V6 SR5 Auto
    After leaving the grocery store awhile ago, I drove about 40 miles in the same kind of heat the OP describes. Engine definitely warmed up on return.
    Hood up - rolled down the drivers side window- reached in to turn off ignition. Fan blades stopped on a dime.

    So in the case of my '15 4.0L Tacoma, the fan blades have a great deal of resistance when spinning them when engine is cold and stop immediately when I shut off a fully warmed up motor.

  18. Aug 12, 2020 at 4:26 PM
    #18
    Clearwater Bill

    Clearwater Bill Never answer an anonymous letter

    Joined:
    Oct 11, 2014
    Member:
    #140097
    Messages:
    24,507
    Gender:
    Male
    First Name:
    Billy
    Largo Florida
    Vehicle:
    '13 5 lug AC w/convenience package
    A few OE parts from fancy trucks
  19. Aug 12, 2020 at 4:36 PM
    #19
    Lastplace

    Lastplace Well-Known Member

    Joined:
    Jun 29, 2013
    Member:
    #107250
    Messages:
    538
    Gender:
    Male
    Southeast VA
    My 3.4 2000 4Runner roars when you start it.

  20. Aug 12, 2020 at 5:22 PM
    #20
    MattCowsmasher

    MattCowsmasher ( -_・)ᡕᠵ᠊ᡃ່࡚ࠢ࠘⸝່ࠡࠣ᠊߯᠆ࠣ࠘ᡁࠣ࠘᠊᠊ࠢ࠘

    Joined:
    Apr 7, 2017
    Member:
    #215629
    Messages:
    48,698
    Gender:
    Male
    Temple, Tx
    Vehicle:
    O3 Rubicon wrangler
    Frankenstein lift, warn winch, heavy rear bumper swing out
    Dude we’re in TX my truck struggles as well. Cruising home today the ac was cool but not cold everything Cooling and AC system is in good working order.
