Amateur (Ham) Radio BS and Callsign Thread!

Discussion in 'Sports, Hobbies & Interests' started by The Traveler, Jan 29, 2013.

  1. Mar 19, 2019 at 6:59 PM
    #4901
    Cudgel

    Cudgel “Tonka”

    Joined:
    Mar 28, 2017
    Member:
    #214640
    Messages:
    3,156
    Gender:
    Male
    Live in: An Ocean of Plastic Trash
    Vehicle:
    2017 OR DCLB
    ICON8 Lift -285s. upTOPoverland rack.
    This power tilt works pretty well and solved my fold over issues.

  2. Mar 19, 2019 at 7:01 PM
    #4902
    Cudgel

    Cudgel “Tonka”

    Joined:
    Mar 28, 2017
    Member:
    #214640
    Messages:
    3,156
    Gender:
    Male
    Live in: An Ocean of Plastic Trash
    Vehicle:
    2017 OR DCLB
    ICON8 Lift -285s. upTOPoverland rack.
    Splice
    Solder
    Tape

  3. Mar 19, 2019 at 7:08 PM
    #4903
    nats

    nats Well-Known Member

    Joined:
    Jan 2, 2019
    Member:
    #277793
    Messages:
    70
    Gender:
    Male
    Lakewood, CO USA
    Vehicle:
    '10 TRD Sport DCSB
    (this will change)
    The connector is an RJ-12 and not difficult to source. it's the same connector that was used for years on corded telephones (between phone and handset). You can still find coiled cords with all 6-conductors present and simply rewire into the Mic...

    Alternately, you could use the opportunity to add an extension in there, and maybe get a little less wear, or something that you wouldn't chew on so much.

    MonkeyProof likes this.
  4. Mar 19, 2019 at 7:39 PM
    #4904
    Bastek

    Bastek Member

    Joined:
    Jun 6, 2017
    Member:
    #220876
    Messages:
    3,682
    Gender:
    Male
    First Name:
    Seb
    SI NY
    Vehicle:
    '17 OR dcsb
    Some stickers, plastidip and radio knobs
    Not sure what is that for, but there is an 8 conductor replacement cable for Kenwood radios that you can buy on Amazon

  5. Mar 19, 2019 at 7:51 PM
    #4905
    Bastek

    Bastek Member

    Joined:
    Jun 6, 2017
    Member:
    #220876
    Messages:
    3,682
    Gender:
    Male
    First Name:
    Seb
    SI NY
    Vehicle:
    '17 OR dcsb
    Some stickers, plastidip and radio knobs
    Thanks. Although I was looking for external speaker in headliner pics :oops:
    OK, so that's a Yaesu right? Not sure how much original replacement microphone costs, but here is a cheap replacement abcGoodefg MH-48A6J 6 Pin 22" Coil Cord DTMF Speaker Microphone with Button for Yaesu MH-48A6J FT-7800R FT-8800R FT-8900R FT-7900R FT-7100M1 https://www.amazon.com/dp/B00YBTM5A4/ref=cm_sw_r_cp_apa_i_0LAKCb11165G8 if it isn't good at all, you could use it for a donor cable Here is a cheap replacement microphone cable
    Pasow Replacement Microphones Mic Cable Cord Wire for Yaesu MH-36 MH-36A6J MH-36B6JS MH42 MH-42B6J MH-42C6J MH-48 MH-48A6JA MH-48A6J FT-1500M FT-2800M FT-7100M FT-7800 FT-8800 FT-8900 FT-8900R https://www.amazon.com/dp/B018FNQ58E/ref=cm_sw_r_cp_apa_i_CRAKCb1FZFK5F

    Or, part-out sounds reasonable!

    Last edited: Mar 19, 2019
    MonkeyProof likes this.
  6. Mar 19, 2019 at 8:22 PM
    #4906
    MonkeyProof

    MonkeyProof Power Top

    Joined:
    Oct 7, 2008
    Member:
    #9774
    Messages:
    11,789
    SoCal- SGV
    That's amazing! you rock :headbang: https://www.amazon.com/dp/B018FNQ58E

    I had to replace a missing MIC for my other FT-2800M radio, and that costed 75 bucks.

    Bastek likes this.
  7. Mar 19, 2019 at 8:38 PM
    #4907
    Bastek

    Bastek Member

    Joined:
    Jun 6, 2017
    Member:
    #220876
    Messages:
    3,682
    Gender:
    Male
    First Name:
    Seb
    SI NY
    Vehicle:
    '17 OR dcsb
    Some stickers, plastidip and radio knobs
    :humble:
    I can only take partial credit for that. I wouldn't even think of looking for it there, if not for @5nahalf finding 8 conductor Kenwood replacement :thumbsup:

    Last edited: Mar 20, 2019
    MonkeyProof and 5nahalf like this.
  8. Mar 20, 2019 at 11:57 AM
    #4908
    Rome604

    Rome604 I am the Captain now

    Joined:
    Feb 23, 2017
    Member:
    #211478
    Messages:
    4,211
    Gender:
    Male
    First Name:
    Dave
    Alexandria, VA
    Vehicle:
    2020 White Sienna AWD
    Did you use the provided switch to raise and lower it? I've been trying to find a wiring diagram for it to see if I can rig up something else since that switch seems kinda bulky.

  9. Mar 20, 2019 at 11:58 AM
    #4909
    Gunshot-6A

    Gunshot-6A Je Suis Stun Gun

    Joined:
    Dec 29, 2009
    Member:
    #28389
    Messages:
    16,071
    Gender:
    Male
    First Name:
    Conner
    Salt Lake City
    Vehicle:
    2015 TRD Offroad
    Switchpro...

    pop.tremuloides and CO MTN Steve like this.
  10. Mar 20, 2019 at 12:02 PM
    #4910
    Rome604

    Rome604 I am the Captain now

    Joined:
    Feb 23, 2017
    Member:
    #211478
    Messages:
    4,211
    Gender:
    Male
    First Name:
    Dave
    Alexandria, VA
    Vehicle:
    2020 White Sienna AWD
    Exactly, but I always like to map things out in my head before I buy stuff. I want to make sure a switchpro or similar setup can trigger the motor.

  11. Mar 20, 2019 at 12:03 PM
    #4911
    Gunshot-6A

    Gunshot-6A Je Suis Stun Gun

    Joined:
    Dec 29, 2009
    Member:
    #28389
    Messages:
    16,071
    Gender:
    Male
    First Name:
    Conner
    Salt Lake City
    Vehicle:
    2015 TRD Offroad
    Probably easier to just run a SPDT switch. Switchpro does explicitly state that their unit isn't to be used as a winch controller, but not sure if that is just legal language.

  12. Mar 20, 2019 at 12:10 PM
    #4912
    Ensemble88

    Ensemble88 Well-Known Member

    Joined:
    Jun 17, 2018
    Member:
    #256661
    Messages:
    736
    San Diego
    Vehicle:
    2017 Black Tacoma OR DCLB
    So glad I found this thread! I'm going up for my tech license on Saturday. I wanted to use ham for off roading like most everyone else. I was doing a bit of research and think I kind of overbought on my radio. Got a TYT UV-380. It's capable of DMR, but mainly I got it because I read it xmits/rcvs really clear. I don't do well with picking out voice from static.

    Has anyone used this radio before? I'm still a new guy and am not sure how to set up the analog features on it. Looked at videos for it and they're all about it's DMR capabilities. Any help would be appreciated!

    pop.tremuloides likes this.
  13. Mar 20, 2019 at 12:59 PM
    #4913
    Cudgel

    Cudgel “Tonka”

    Joined:
    Mar 28, 2017
    Member:
    #214640
    Messages:
    3,156
    Gender:
    Male
    Live in: An Ocean of Plastic Trash
    Vehicle:
    2017 OR DCLB
    ICON8 Lift -285s. upTOPoverland rack.
    No the existing switch is a piece of shit. Here is my write up in the Clean VHF/CB radio installs thread:

    Problem:
    Yesterday I installed the Power Antenna tilt motor and mounts and it really is great (see my hog of posts above). While the motor and mounts are a good balance of durable and affordable, the provided switch which reverses polarity for up/down, is really questionable and of course power plugs for installed accessories is not my full definition of "installed":
    [​IMG]


    Solution:
    Make a reversing switch with a power window switch (DPDT with cross jumpers): Yes I did a "professional" wiring diagram as well to show my kids how it works!:
    [​IMG]


    Using the latest lithium powered - lazar guided - GPS enabled - self powering adaptable tools, create the proper opening in some place on your truck that "you" like. I chose console for right handed person:
    [​IMG]


    Stick it in the hole before you make all your connections:
    [​IMG]



    Enjoy your earth-shattering mod in ways hard to describe even to us Taco-nuts:
    [​IMG]

    Littles, pop.tremuloides and Rome604 like this.
  14. Mar 20, 2019 at 1:02 PM
    #4914
    Rome604

    Rome604 I am the Captain now

    Joined:
    Feb 23, 2017
    Member:
    #211478
    Messages:
    4,211
    Gender:
    Male
    First Name:
    Dave
    Alexandria, VA
    Vehicle:
    2020 White Sienna AWD
    Awesome thanks. So I assume you hold the button down (in the correct direction) when you want to raise or lower it?

  15. Mar 20, 2019 at 1:08 PM
    #4915
    Cudgel

    Cudgel “Tonka”

    Joined:
    Mar 28, 2017
    Member:
    #214640
    Messages:
    3,156
    Gender:
    Male
    Live in: An Ocean of Plastic Trash
    Vehicle:
    2017 OR DCLB
    ICON8 Lift -285s. upTOPoverland rack.
    Down to Lower
    Up to Raise

    The switch is a "momentary on" power window switch.
    Once you wire it, just test it to figure out which way is up and install it in the whole that way.

    There are 4 posts on https://www.tacomaworld.com/threads/clean-vhf-cb-radio-installs.415584/page-54 showing my whole setup.

    The switch is a DPDT.
    • you cross wire the 1 & 6 and 2 & 5 leads.
    • you power 3, 4
    • you load 1, 2 (or 5, 6)

    1. when you push "up" the polarity on 1, 2 is the same as 3, 4
    2. when you push "down" the polarity on 1, 2 (linked to 6, 5) is reversed


    Rome604 likes this.
  16. Mar 20, 2019 at 1:56 PM
    #4916
    medic2230

    medic2230 @Koditten Pirate Radio member #002

    Joined:
    Oct 13, 2008
    Member:
    #9942
    Messages:
    60,852
    Gender:
    Male
    First Name:
    Murph
    Bama! Roll Tide
    Vehicle:
    2011 Taco 4x4 DCLB 2019 TRD PRO 4runner
    20% Tint, OME 3"complete lift with Dakar's, Light Racing UCA's, 285/75/16 Nitto Terra Grapplers, 10 HP TW sticker, Ultraguage, B.A.M.F. Rock Sliders, MedicFab Bed Rack, Relentless front bumper, Air Flow Snorkel, Ham comms, Tech Deck
    golfindia likes this.
  17. Mar 20, 2019 at 2:07 PM
    #4917
    MonkeyProof

    MonkeyProof Power Top

    Joined:
    Oct 7, 2008
    Member:
    #9774
    Messages:
    11,789
    SoCal- SGV
  18. Mar 20, 2019 at 2:13 PM
    #4918
    medic2230

    medic2230 @Koditten Pirate Radio member #002

    Joined:
    Oct 13, 2008
    Member:
    #9942
    Messages:
    60,852
    Gender:
    Male
    First Name:
    Murph
    Bama! Roll Tide
    Vehicle:
    2011 Taco 4x4 DCLB 2019 TRD PRO 4runner
    20% Tint, OME 3"complete lift with Dakar's, Light Racing UCA's, 285/75/16 Nitto Terra Grapplers, 10 HP TW sticker, Ultraguage, B.A.M.F. Rock Sliders, MedicFab Bed Rack, Relentless front bumper, Air Flow Snorkel, Ham comms, Tech Deck

    I use a local DMR repeater here mostly. Easy when I’m out of town to communicate with the local guys here when the locals there don’t talk to the out of town guy. Haha

    Honestly I may even get D-Star eventually to see what it’s all about. DMR is popular over this way.

    Our local DMR and analog are linked full time here.

    MonkeyProof likes this.
  19. Mar 20, 2019 at 3:29 PM
    #4919
    Rome604

    Rome604 I am the Captain now

    Joined:
    Feb 23, 2017
    Member:
    #211478
    Messages:
    4,211
    Gender:
    Male
    First Name:
    Dave
    Alexandria, VA
    Vehicle:
    2020 White Sienna AWD


    Ok cool. Got it, thank you.

  20. Mar 21, 2019 at 7:10 AM
    #4920
    muffyinva

    muffyinva Well-Known Member

    Joined:
    Mar 7, 2019
    Member:
    #285707
    Messages:
    110
    Gender:
    Male
    First Name:
    Reid
    Lynchburg, VA
    Vehicle:
    2019 Cement Tacoma DCSB OR
    Awesome! 73, K8JLW

    pop.tremuloides likes this.
