anything welding

Discussion in 'Garage / Workshop' started by EL TACOROJO, Sep 17, 2010.

  1. Oct 21, 2014 at 12:21 PM
    #4301
    RelentlessFab

    RelentlessFab Tacoma offroad armor fabricating beast Vendor

    Joined:
    Feb 17, 2008
    Member:
    #4772
    Messages:
    13,376
    Gender:
    Male
    First Name:
    Eric
    Eastern side of the Sierras, NV
    Vehicle:
    07 SR5 4x4> 03 SR5 4x4 total> 14 Crewmax TRD
    Had tons on the Taco's.... new truck is pretty stock
    I'm not. And I have noticed if theres a blued/oxidized ball on the end of the wire that those are the times it will initially sputter when striking the arc. I gues I should try that and see if it solves the issue, just a bit more time consuming between beads. Just find it strange as my other machines start smooth each time without cutting the ball off.

  2. Oct 21, 2014 at 12:31 PM
    #4302
    achirdo

    achirdo First Class White Trash

    Joined:
    Apr 7, 2010
    Member:
    #34819
    Messages:
    10,148
    Gender:
    Male
    First Name:
    Adam
    North DFW
    Vehicle:
    06 dodge ram 3500 5.9 cummins
    Any one see the new Lincoln Power Mig 210? It's a dual voltage 110/220v machine, Mig and DC stick and Tig welder. Rugged construction, 40 lbs, digital color screen diaplay. Msrp of $999

  3. Oct 21, 2014 at 12:35 PM
    #4303
    isu2014

    isu2014 RAT Products

    Joined:
    Apr 12, 2010
    Member:
    #35140
    Messages:
    12,423
    Gender:
    Male
    First Name:
    Ryan
    Farmington, MN
    Vehicle:
    01 SUPERCHARGED TRD OR MANUAL 4x4 V6
    View the build. Too much to list.

    Saw that. The local weld shop guy started in on it pretty quickly after I got there. It must be good commission or something.

  4. Oct 21, 2014 at 9:16 PM
    #4304
    JLee

    JLee The Man! Vendor

    Joined:
    Jul 20, 2010
    Member:
    #40461
    Messages:
    15,164
    Gender:
    Male
    First Name:
    Jerry
    Bay Area NorCal
    Vehicle:
    02 Extra cab SAS Linked front and rear
    I lost track thousands of dollars ago.
    Yeah its second nature for me if it cools enough to not be glowing I snip it off before starting the next weld.

  5. Oct 22, 2014 at 5:50 AM
    #4305
    koditten

    koditten Well-Known Member

    Joined:
    Sep 8, 2013
    Member:
    #112077
    Messages:
    1,843
    Gender:
    Male
    First Name:
    Kirk
    Central Michigan
    Vehicle:
    04 trd x-cab 4 x 4 3.4l
    When I'm done it will have a custom fabbed winch bumper and hopefully a Softtopper.
    Remember, if you have switched from flux core to solid core with gas, you need to switch the polarity on the welding machine.

    KO

  6. Oct 22, 2014 at 6:01 PM
    #4306
    jeverich

    jeverich Well-Known Member

    Joined:
    Mar 25, 2008
    Member:
    #5517
    Messages:
    2,053
    Gender:
    Male
    First Name:
    Jake
    PNW/Kodiak
    Vehicle:
    07 2.7 4x4
    OME 886/Old Man Doug Suspension Lift, ARB Bumper, Bruteforce High Clearance w/Swing Out, De-badge, Block Heater, Homemade IFS Skid, 7" Kragens, Blue Seas Fuse Block, BlitzPro Fogs, 12k BadLands Winch, BAMF Sliders, ARB Locker, 4.88s Yaesu FT-1900R, Larsen 150B NMO Mount Antenna
    Forgot how much I love my plasma.. Bumped my air pressure up by ~5 PSI - amazing how much dross that it eliminated from my cuts.

    Latest project, geometric firepit.

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

  7. Oct 22, 2014 at 6:11 PM
    #4307
    JLink

    JLink Well-Known Member

    Joined:
    May 9, 2010
    Member:
    #36795
    Messages:
    10,564
    Gender:
    Male
    First Name:
    Josh
    Ocean, NJ
    Vehicle:
    The "Big Nig"
    Lifted, Locked, Armored. Ready To Wheel.
    Thanks for the replies guys.

    - I always try to grind down the area where the ground clamp will be, but I guess I should make sure the ground clamp isn't dirty and check the connections.
    - I always cut the tip off the end before starting each weld. Only because I thought you were supposed too.
    - I did switch from flux but I changed the polarity- I will double check though.
    - I'll check the gas hose and connections.
    - I'll check the liner and drive wheels.

    And I'll test what Eric said about when it happens to him he just stops and restarts and it works better.

    Thanks again guys. It's awesome to see the talent in here. Keep up the good work!

  8. Oct 22, 2014 at 6:42 PM
    #4308
    OutbackHack

    OutbackHack Well-Known Member

    Joined:
    Dec 3, 2009
    Member:
    #26963
    Messages:
    259
    Gender:
    Male
    First Name:
    Mike
    Seattle, WA
    Vehicle:
    2010 DCSB V6 6sp TRD-Sport
    $$$
    I'm having an electrician come install a 6-20R outlet in the garage soon for charging the wife's Nissan Leaf and thinking it would be good to have him put in another 240V outlet while he's here so I can hook up a welder eventually.

    I'm having a hard time finding what type of wiring and outlets are most commonly used for welding and seems like there's a ton of options. Is there a standard or most common setup you guys use for powering your welder? Or do I have to wait till I buy one to find out what kind of wiring I need?

  9. Oct 22, 2014 at 7:13 PM
    #4309
    isu2014

    isu2014 RAT Products

    Joined:
    Apr 12, 2010
    Member:
    #35140
    Messages:
    12,423
    Gender:
    Male
    First Name:
    Ryan
    Farmington, MN
    Vehicle:
    01 SUPERCHARGED TRD OR MANUAL 4x4 V6
    View the build. Too much to list.
    I've wired up a few welder outlets. 50 amp breaker, 6/3 wire, and a 3 prong welder receptacle will get you what you need.

  10. Oct 22, 2014 at 7:22 PM
    #4310
    nagorb

    nagorb Well-Known Member

    Joined:
    Feb 28, 2011
    Member:
    #52025
    Messages:
    4,094
    Gender:
    Male
    california
    Vehicle:
    2001 dbl cab 4x4
    It really depends on the welder. If you don't have one yet you could have him put in a 220 single phase breaker, usually 30 amps, and the standard outlet, not sure what it's called, looks like this http://www.google.com/imgres?imgurl...iact=rc&uact=3&dur=486&page=1&start=0&ndsp=18. I ran 6 awg. If you need to change the breaker or plug later all the hard stuff was already done.

  11. Oct 22, 2014 at 9:43 PM
    #4311
    JLee

    JLee The Man! Vendor

    Joined:
    Jul 20, 2010
    Member:
    #40461
    Messages:
    15,164
    Gender:
    Male
    First Name:
    Jerry
    Bay Area NorCal
    Vehicle:
    02 Extra cab SAS Linked front and rear
    I lost track thousands of dollars ago.
    I'm pretty sure it's a NEMA 6-50 for most welders. On a 40 amp breaker and 6 gauge wire should cover it but your electrician should know what fits your code.

  12. Oct 22, 2014 at 9:45 PM
    #4312
    JLee

    JLee The Man! Vendor

    Joined:
    Jul 20, 2010
    Member:
    #40461
    Messages:
    15,164
    Gender:
    Male
    First Name:
    Jerry
    Bay Area NorCal
    Vehicle:
    02 Extra cab SAS Linked front and rear
    I lost track thousands of dollars ago.
    Pretty sweet I'm doing a monster 6' fire pit in my back yard.

  13. Oct 22, 2014 at 9:47 PM
    #4313
    medic2230

    medic2230 Ditch Doctor

    Joined:
    Oct 13, 2008
    Member:
    #9942
    Messages:
    10,266
    Gender:
    Male
    First Name:
    Murph
    Columbus, Ga
    Vehicle:
    2011 Taco 4x4 DCLB
    20% Tint, OME 3"complete lift with Dakar's, Light Racing UCA's, 285/75/16 Nitto Terra Grapplers, 10 HP TW sticker, Ultraguage, B.A.M.F. Rock Sliders, MedicFab Bed Rack, Relentless front bumper
    Mine looks like this.


    [​IMG]

  14. Oct 22, 2014 at 10:29 PM
    #4314
    RelentlessFab

    RelentlessFab Tacoma offroad armor fabricating beast Vendor

    Joined:
    Feb 17, 2008
    Member:
    #4772
    Messages:
    13,376
    Gender:
    Male
    First Name:
    Eric
    Eastern side of the Sierras, NV
    Vehicle:
    07 SR5 4x4> 03 SR5 4x4 total> 14 Crewmax TRD
    Had tons on the Taco's.... new truck is pretty stock
    This

  15. Oct 22, 2014 at 11:30 PM
    #4315
    jeverich

    jeverich Well-Known Member

    Joined:
    Mar 25, 2008
    Member:
    #5517
    Messages:
    2,053
    Gender:
    Male
    First Name:
    Jake
    PNW/Kodiak
    Vehicle:
    07 2.7 4x4
    OME 886/Old Man Doug Suspension Lift, ARB Bumper, Bruteforce High Clearance w/Swing Out, De-badge, Block Heater, Homemade IFS Skid, 7" Kragens, Blue Seas Fuse Block, BlitzPro Fogs, 12k BadLands Winch, BAMF Sliders, ARB Locker, 4.88s Yaesu FT-1900R, Larsen 150B NMO Mount Antenna
    [​IMG]

    Since I've got a Square D panel, it's relatively simple to add a breaker. Ran individual 6AWG wire through the conduit to my outlet, made the penetration into the box on the underside, in between the studs.

    See if your electrician might be able to sell you some 8/3, or 6/3 QO cord at cost. It's great for an extension cord for your welder/plasma/etc..

    I scored the wire for mine at the local scrapyard for $25 IIRC.

    It's not a tricky job.

    [​IMG]

    [​IMG]

  16. Oct 29, 2014 at 3:10 PM
    #4316
    tacomonazul

    tacomonazul Well-Known Member

    Joined:
    Mar 4, 2012
    Member:
    #74163
    Messages:
    3,402
    Gender:
    Male
    First Name:
    Luis
    SOCAL
    Vehicle:
    07 DCSB LT/4LINK
    http://www.tacomaworld.com/forum/2nd-gen-builds/227832-my-never-end-build.html
    What welder do you use??

  17. Oct 30, 2014 at 8:05 AM
    #4317
    tacomonazul

    tacomonazul Well-Known Member

    Joined:
    Mar 4, 2012
    Member:
    #74163
    Messages:
    3,402
    Gender:
    Male
    First Name:
    Luis
    SOCAL
    Vehicle:
    07 DCSB LT/4LINK
    http://www.tacomaworld.com/forum/2nd-gen-builds/227832-my-never-end-build.html
    Looking at this lincoln welder, anyone has had any experience with it? Is it good? My plans for welding are: tube bumper, in bed rack, engine cage and maybe a cab cage if I get good at it.

    [​IMG]

  18. Oct 30, 2014 at 9:00 AM
    #4318
    JLee

    JLee The Man! Vendor

    Joined:
    Jul 20, 2010
    Member:
    #40461
    Messages:
    15,164
    Gender:
    Male
    First Name:
    Jerry
    Bay Area NorCal
    Vehicle:
    02 Extra cab SAS Linked front and rear
    I lost track thousands of dollars ago.
    It looks small what amp is it?

  19. Oct 30, 2014 at 9:03 AM
    #4319
    JLee

    JLee The Man! Vendor

    Joined:
    Jul 20, 2010
    Member:
    #40461
    Messages:
    15,164
    Gender:
    Male
    First Name:
    Jerry
    Bay Area NorCal
    Vehicle:
    02 Extra cab SAS Linked front and rear
    I lost track thousands of dollars ago.
    On Another note I just picked up a Dynasty 280DX with coolmate pretty stoked!

  20. Oct 30, 2014 at 9:27 AM
    #4320
    tacomonazul

    tacomonazul Well-Known Member

    Joined:
    Mar 4, 2012
    Member:
    #74163
    Messages:
    3,402
    Gender:
    Male
    First Name:
    Luis
    SOCAL
    Vehicle:
    07 DCSB LT/4LINK
    http://www.tacomaworld.com/forum/2nd-gen-builds/227832-my-never-end-build.html
    70 amp
