Anything welding

Discussion in 'Garage / Workshop' started by EL TACOROJO, Sep 17, 2010.

  1. May 19, 2019 at 9:14 AM
    Rakso

    Rakso CeRaTi

    Joined:
    Feb 26, 2009
    Member:
    #14105
    Messages:
    8,250
    Gender:
    Male
    First Name:
    OsKaR
    Cali
    Vehicle:
    09 PreRunner
    LSK LT in Progress, custom bed cage, DMZ SUA kit with 2.5 kings triple bypass, kings bump stops, baja bumper, rear custom tube bumper, glass all around, Weather Tech Liners, wet okole seat covers, Cluster LED Swap, HU LED Swap, hood LEDs, bed LEDs, etc etc etc
    :spending:

    koditten likes this.
  2. May 20, 2019 at 11:43 AM
    cynicalrider

    cynicalrider #NFG

    Joined:
    Jul 25, 2012
    Member:
    #83399
    Messages:
    12,544
    Gender:
    Male
    Jersey
    Vehicle:
    01 SR5 TRD 4x4
    Drop bracket lift and booger welds
    @weldertaco and any other stick guys out there, are these a good start? Honestly am looking for any advice. First time working with thicker stuff and I want to make sure penetration looks good.

    Running Board Man likes this.
  3. May 20, 2019 at 12:01 PM
    la0d0g

    la0d0g Its 4 o’clock somewhere

    Joined:
    Jan 25, 2011
    Member:
    #49903
    Messages:
    17,411
    Gender:
    Male
    First Name:
    Matt
    running for the hills
    Vehicle:
    For crawling not hauling
    Cut your welds in half and you'll find out :D

    Running Board Man and stumbles like this.
  4. May 20, 2019 at 12:09 PM
    cynicalrider

    cynicalrider #NFG

    Joined:
    Jul 25, 2012
    Member:
    #83399
    Messages:
    12,544
    Gender:
    Male
    Jersey
    Vehicle:
    01 SR5 TRD 4x4
    Drop bracket lift and booger welds
    That I can't do on this particular piece, but might cut myself some to play with. Also I was amazed at how easy it would be to burn through the 3/16, on some of the bigger gaps I saw the puddle drop in. Makes me very nervous about working on the thin ass 1/8" frame. But I also will be using 3/32 rods on the frame as opposed to the 1/8 I used on these pieces.

    EDIT:

    The top weld on this photo is referring to where the weld puddle dropped in a bit on me.

    [​IMG]

    la0d0g likes this.
  5. May 20, 2019 at 12:45 PM
    kystnTRD

    kystnTRD Ramblin Man

    Joined:
    Sep 19, 2007
    Member:
    #2741
    Messages:
    698
    Gender:
    Male
    NW Pennsylvania
    Vehicle:
    2016 TRD Sport 6MT
    Try some 7018. 60series rod is good for dirty steel but 70series will lay in much nicer on clean steel. Good rule of thumb for setting your amps is just divide the rod size. For example 3/32 diameter rod 3÷32= .9375 so 94amp that will give you a good baseline to adjust from. Works on all diameters. From there you can work on your consistency and travel speed

    Canadian Joe likes this.
  6. May 20, 2019 at 1:00 PM
    cynicalrider

    cynicalrider #NFG

    Joined:
    Jul 25, 2012
    Member:
    #83399
    Messages:
    12,544
    Gender:
    Male
    Jersey
    Vehicle:
    01 SR5 TRD 4x4
    Drop bracket lift and booger welds
    I want to but I was hoping to master the 60's first. But I do know the 70's are better for close fitups. 6011 is good for bigger gaps/roots correct? I also hate that I can't store the 70's properly, but I do agree it's the best option for the work on my frame. I've been writing the best amperage that's been working for my rods so far. Since my machine is the AC225, it only lets me adjust amps in like 15 amp increments IIRC. I typically go on the lower end of the range it says on the rod package and then go up if the rod can't maintain the arc.

    Maybe I'll just dive into the 70's since it's really what I should use on the frame. Can use it to reinforce my skid plates first as practice.

  7. May 20, 2019 at 2:16 PM
    INBONESTRYKER

    INBONESTRYKER Well-Known Member

    Joined:
    Apr 6, 2015
    Member:
    #152650
    Messages:
    538
    Gender:
    Male
    First Name:
    John
    WY
    Vehicle:
    '96 access cab 3.4 5 spd manual 4X4
    Be sure to get 7018 AC rods.

    Running Board Man likes this.
  8. May 20, 2019 at 2:16 PM
    Wyoming09

    Wyoming09 Well-Known Member

    Joined:
    Apr 24, 2015
    Member:
    #153833
    Messages:
    8,240
    Gender:
    Male
    New Tripoli Pa
    Vehicle:
    2000 Work truck
    Super Springs
    I would use 6013 if I had to weld a frame with that process.

    Do what you need to do to control the heat

    It has been so long since I used anything but 7018 or 10018 or 7010

  9. May 20, 2019 at 3:31 PM
    weldertaco

    weldertaco Mr.13%bodyfat

    Joined:
    Dec 16, 2014
    Member:
    #144371
    Messages:
    11,820
    Gender:
    Male
    texas
    Vehicle:
    TrailRunner
    4wd to 2wd conversion
    Man I’m a fan of the whip motion with a circle. A cursive lowercase e really.

    Some welds look okay and others don’t. You can tell you’re not consistent with your motions and arc length. It looks like the whip and pause worked best for you as others you didn’t Feed enough rod.

    Really in a non rude way, your welds are just kinda all over. Need to figure out a consisten pattern and then improve from there.

    Keep it cool while practicing and first learning and don’t be afraid to slow down. I still to this day struggle with trying to go too fast.

    jubei and INBONESTRYKER like this.
  10. May 20, 2019 at 7:24 PM
    cynicalrider

    cynicalrider #NFG

    Joined:
    Jul 25, 2012
    Member:
    #83399
    Messages:
    12,544
    Gender:
    Male
    Jersey
    Vehicle:
    01 SR5 TRD 4x4
    Drop bracket lift and booger welds
    I forgot to mention that I realized I’m just going to be tacking the metal in for the stuff on the frame, so 6013 will work. My buddy will be bringing his mig for me to burn it in.

    I whole heartedly agree. Some times I didn’t realize arc length was to far or too close till sound changed. I did like practicing the whip and pause because I just felt like I understood it. But I kept going with circles because I felt like it was something I was familiar with with MIG. I have some thicker stuff to weld soon, I’ll try the whip and pause for that.

    This was one of my favorites, but judging by the length of the pools, it’s too fast right?

    [​IMG]

    And most importantly, looks aside, do they look strong?

  11. May 20, 2019 at 7:50 PM
    GoJo

    GoJo Well-Known Member

    Joined:
    Mar 6, 2014
    Member:
    #124740
    Messages:
    204
    Gender:
    Male
    First Name:
    Chris
    Utah
    Bed bars for dads truck got his new rtt

    Still learning, any feedback appreciated.

    EDIT: realizing that is a horrible picture. Didn't notice it was so blurry when I took it. My bad



    Back door for my bed rack. Keep the dogs in at night while camping

  12. May 20, 2019 at 9:06 PM
    mjbtaco

    mjbtaco low and slow

    Joined:
    Mar 21, 2008
    Member:
    #5423
    Messages:
    3,612
    Gender:
    Male
    First Name:
    Michael
    Montclair , so cal
    Vehicle:
    slammed 95.5 extra cab and 2013 Silver DCSB TRD Sport
    PERFORMANCE Custom GT3576 Turbo Setup FRONT SUSPENSION Lower Ball Joint flip 01-04 Swaybar Endlinks Energy Suspension Endlink Bushings Custom Upper Control arms by KANE QA1 coilovers with 8" spring Custom 4 pot Brembo BBK Modified lower control arms with Beefed Taco qa1 mounting plates REAR SUSPENSION Chasis Tech drop leafs QA1 adjustable shocks weld in drop notch Gas tank cross member bridge 3" angled blocks 2013 Double Cab Short Bed TRD Sport Eibach Pro Truck Shocks front and rear Lifted to the 3rd setting on the front shocks
    I'm on vacation but my friend sent me pics of my next project. Coilover adapters for 2nd gen 5 lug Tacomas. Gonna weld them up when I get home this weekend.



  13. May 21, 2019 at 6:25 AM
    cynicalrider

    cynicalrider #NFG

    Joined:
    Jul 25, 2012
    Member:
    #83399
    Messages:
    12,544
    Gender:
    Male
    Jersey
    Vehicle:
    01 SR5 TRD 4x4
    Drop bracket lift and booger welds
    Also looking down the tube I can see the heat from the welds.


    Considering how thick this is I assume that’s a good sign of penetration but not sure. :notsure:

    Bigdaddy4760 and Rakso like this.
  14. May 21, 2019 at 6:27 AM
    EatSleepTacos

    EatSleepTacos Well-Known Member

    Joined:
    Mar 24, 2015
    Member:
    #151688
    Messages:
    45,734
    Gender:
    Male
    First Name:
    Randy
    Hampton Roads, VA
    Vehicle:
    4x4 2005 SR5 AC 6MT
    Haha that’s how I always judge penetration, not sure how good that really is though. I just look at the back of what I’m welding and if there’s consistent heat marks I call it good.

  15. May 21, 2019 at 12:51 PM
    Wyoming09

    Wyoming09 Well-Known Member

    Joined:
    Apr 24, 2015
    Member:
    #153833
    Messages:
    8,240
    Gender:
    Male
    New Tripoli Pa
    Vehicle:
    2000 Work truck
    Super Springs
    By far the best thing outside of a bend test is to Weld a Tee Joint on one side and break it.

    Shows just what you have .

    If you use 4"x4" pieces you can weld quite a few joints

    Bigdaddy4760 and koditten like this.
  16. May 21, 2019 at 8:29 PM
    Rakso

    Rakso CeRaTi

    Joined:
    Feb 26, 2009
    Member:
    #14105
    Messages:
    8,250
    Gender:
    Male
    First Name:
    OsKaR
    Cali
    Vehicle:
    09 PreRunner
    LSK LT in Progress, custom bed cage, DMZ SUA kit with 2.5 kings triple bypass, kings bump stops, baja bumper, rear custom tube bumper, glass all around, Weather Tech Liners, wet okole seat covers, Cluster LED Swap, HU LED Swap, hood LEDs, bed LEDs, etc etc etc
    Have you tried any of these?

    Bigdaddy4760 and Shmellmopwho like this.
  17. May 21, 2019 at 8:35 PM
    Shmellmopwho

    Shmellmopwho Well-Known Member

    Joined:
    Apr 10, 2014
    Member:
    #127399
    Messages:
    9,969
    Gender:
    Male
    First Name:
    Ryan
    Lomita CA
    Vehicle:
    2013 White DCLB TRD sport
    Bunch of stuff
    I use the benchmark abrasives on the right and they’ve been great so far. I buy those flap discs and cut off wheels. Cheap and last quite a while

  18. May 21, 2019 at 8:36 PM
    Rakso

    Rakso CeRaTi

    Joined:
    Feb 26, 2009
    Member:
    #14105
    Messages:
    8,250
    Gender:
    Male
    First Name:
    OsKaR
    Cali
    Vehicle:
    09 PreRunner
    LSK LT in Progress, custom bed cage, DMZ SUA kit with 2.5 kings triple bypass, kings bump stops, baja bumper, rear custom tube bumper, glass all around, Weather Tech Liners, wet okole seat covers, Cluster LED Swap, HU LED Swap, hood LEDs, bed LEDs, etc etc etc
    I've got both brands for $10 for 10 flap disks. Multiple grits.

    Shmellmopwho likes this.
  19. May 21, 2019 at 8:36 PM
    Shmellmopwho

    Shmellmopwho Well-Known Member

    Joined:
    Apr 10, 2014
    Member:
    #127399
    Messages:
    9,969
    Gender:
    Male
    First Name:
    Ryan
    Lomita CA
    Vehicle:
    2013 White DCLB TRD sport
    Bunch of stuff
    Seriously can’t beat that price

    Rakso likes this.
  20. May 21, 2019 at 8:38 PM
    01Tac0ma

    01Tac0ma Bash Fabriction & Off-Road

    Joined:
    Jun 11, 2010
    Member:
    #38782
    Messages:
    6,275
    Gender:
    Male
    First Name:
    Chad
    West Columbia, SC
    Vehicle:
    SAS 01 TRD 4x4
    Look at build!
    Ive used the benchmark abrassives and theyre ok.. I found some Walters on sale on Amazon for about half price and I tell you what, id buy them for full price all day over any flapper ive ever used. I did a SAS, built a couple sets of sliders 2 bedracks and some furniture before using up 1. I bought a brand new dewalt xl wheel today and it burnt up already. Im 100% sold on those Walters when I order! Ill look for a link.

    Edit: heres the link..

    https://www.amazon.com/Walter-Surfa...teway&sprefix=walter+flex,aps,227&sr=8-3&th=1

    Last edited: May 21, 2019
    Drainbung likes this.
