Axle wrap. Help me beat a dead horse.

Discussion in '1st Gen. Tacomas (1995-2004)' started by mjhenks, Mar 26, 2010.

  1. Mar 26, 2010 at 12:28 PM
    #1
    mjhenks

    mjhenks [OP] Well-Known Member

    Joined:
    Feb 2, 2010
    Member:
    #30553
    Messages:
    94
    Gender:
    Male
    So.Cal
    Vehicle:
    04 Jade Green TRD V6 DC
    I have read almost every post over the last month on this topic. Info is starting to run together as i figure out if i should replace my leaf pack to solve my rather savier problem.

    My question is aimed at those of you who bought your Gen 1 new and are dealing with axle wrap. New did Gen 1's have a knock and it got worse over time or did they start out with nothing and axle wrap just starts as the leaf pack wears out.

    Contemplating the group buy. To Wheelers credit, Dan was up front and honest saying that a new 4 leaf pack will/may not solve the problem. Only a traction bar will do that and i do not want the lift of the 4 pack.

    So.... any more info out there as many of us decide what we will do?

    BTW, i have a 04 DC with 93K miles.

  2. Mar 26, 2010 at 12:30 PM
    #2
    steve o 77

    steve o 77 braaap

    Joined:
    Nov 29, 2009
    Member:
    #26726
    Messages:
    19,968
    Gender:
    Male
    First Name:
    Steven
    In a corn field, OH
    Vehicle:
    1990 Chevy Siveraydo
    245k+ miles, rust, working AC, bald eagles
  3. Mar 26, 2010 at 12:31 PM
    #3
    desertdude59

    desertdude59 CRAZY 4WHEELER

    Joined:
    Dec 28, 2008
    Member:
    #11966
    Messages:
    1,094
    Gender:
    Male
    From the Mojave desert now in Wild and Wonderful W
    Vehicle:
    1991 toyota 4x4 sr5-lost but not forgotten
    4" lift after market front bumper bed mount lightbar/roll bar (4)6" kc's on the roll bar (2) kc flat back bumper mounts f/r gears for the 33's
    Trac bars will get rid of the axle wrap if done right

  4. Mar 26, 2010 at 1:00 PM
    #4
    trailinTaco

    trailinTaco Well-Known Member

    Joined:
    May 18, 2008
    Member:
    #6721
    Messages:
    221
    Gender:
    Male
    Bel Air, MD
    Vehicle:
    2000 Tacoma SR5 TRD 3.4L 4x4
    3 inch suspension lift, 33 inch bfgoodrich mud terrain tires, toytech diff drop, Procomp alloy wheels, hella fog lights, black projector headlights with 8000k HID's, blacked out tail lights, two 12 inch subs, 20% tint, pioneer head unit and speakers
    Ive given up with this problem. Ever since i bought my truck ive had this problem. I lifted my truck using add a leafs and that problem did not go away at all. So i really doubt that the leaf springs have anything to do with it. My guess is its from the drive shaft.

  5. Mar 26, 2010 at 1:02 PM
    #5
    bigburrito

    bigburrito Local Man

    Joined:
    Mar 13, 2009
    Member:
    #14660
    Messages:
    557
    Gender:
    Male
    DuPage County
    Vehicle:
    '09 TRD OR
    Demello sliders, fog lights anytime, 265/75R16 Duratracs, 60" HiLift, VIAIR OBA 2.5 gallon tank, FM Super 44, TSB springs, 5100s at .85, bent tailgate
  6. Mar 26, 2010 at 1:03 PM
    #6
    s2kvtak

    s2kvtak Well-Known Member

    Joined:
    Aug 3, 2009
    Member:
    #20598
    Messages:
    310
    Gender:
    Male
    First Name:
    Lee
    Tulsa, OK
    Vehicle:
    2004 Tacoma 4x4 SR5
    Grillecraft grill w/ TRD badge, Bilstein 5100s on all 4 corners set at 2.5" and Toytec AAL in the rear. 285/75-17 Interco TRXUS M/T
    its probably not the springs. try lubing the driveshaft with some grease and ill bet it goes away or greatly reduces it. i had the same thing and put an aal on my truck hoping to solve it (plus it gave me an excuse to lift it) and it just slightly reduced it. ill also be buying a new transmission mount to help reduce other problems as they are under a $100 and cant hurt either way.

  7. Mar 26, 2010 at 2:37 PM
    #7
    mjhenks

    mjhenks [OP] Well-Known Member

    Joined:
    Feb 2, 2010
    Member:
    #30553
    Messages:
    94
    Gender:
    Male
    So.Cal
    Vehicle:
    04 Jade Green TRD V6 DC
    Thank you.

    Still no-on who bought theirs new and has this issue or are some of these responces from original owners.

    I have already lubed the drive shaft. Pumped it full. It reduced the knock for about a week and it was back full force. Now i have the smell of grease on the hot exhaust as it flings out. :)

  8. Mar 26, 2010 at 2:43 PM
    #8
    tacomaman06

    tacomaman06 Carolina Alliance: Enforcer

    Joined:
    May 1, 2007
    Member:
    #1475
    Messages:
    26,258
    Gender:
    Male
    First Name:
    Will
    York,South Carolina
    Vehicle:
    '16 Tundra TRD Pro
    getting there....
    the 4 leaf pack from wheelers is a stock height replacement. i got the 5 pack, and it helped greatly with mine..............BUT.....i also took the shaft apart from the rear diff and cleaned it out....packed new grease in, put back together and the hit it with the grease gun. my axle wrap doesnt ever appear anymore really.

  9. Mar 26, 2010 at 9:12 PM
    #9
    mtucker

    mtucker Tacoma addict

    Joined:
    Aug 3, 2009
    Member:
    #20610
    Messages:
    269
    Gender:
    Male
    First Name:
    Matt
    Escondido, CA.
    Vehicle:
    03 Prerunner DC
    Replaced chrome badges with Sockmonkey black badges, painted billet grill black, K&N cold air intake, my corner light turn signal circuit, Speedfreek traction bars, RAAMaudio BXT/Ensolite, Stereo: Kenwood KIV-701 USB/Bluetooth deck, 10" Pioneer shallow sub behind the rear seat, Infinity 6822cf 6x8 front and rear doors, Fosgate P400-2 (sub), US Acoustics USX-4065 (four main speakers)
    I have been there. I still have grease from the slip yoke all over my muffler :)

    Sorry, not the original owner, but traction bars took care of it. The grease, and the spring helpers didn't do much. Traction bars were night and day!

    Matt

  10. Mar 27, 2010 at 10:21 AM
    #10
    scocar

    scocar Scouting the perimeter for weakness

    Joined:
    Nov 11, 2009
    Member:
    #25814
    Messages:
    31,275
    Gender:
    Male
    First Name:
    Dick
    In close proximity to an undisclosed location
    Vehicle:
    2015 DCLB 4x4 SR5
    Back to square one after the 2001. So...
    So let's see those traction bars! I've seen some pretty crazy heavy duty ones that seem over-the-top for a daily driver...

    :worthless:

  11. Mar 27, 2010 at 11:32 AM
    #11
    steve o 77

    steve o 77 braaap

    Joined:
    Nov 29, 2009
    Member:
    #26726
    Messages:
    19,968
    Gender:
    Male
    First Name:
    Steven
    In a corn field, OH
    Vehicle:
    1990 Chevy Siveraydo
    245k+ miles, rust, working AC, bald eagles
    x2

  12. Mar 27, 2010 at 12:07 PM
    #12
    Janster

    Janster Old & Forgetful

    Joined:
    Mar 25, 2007
    Member:
    #1138
    Messages:
    14,253
    Gender:
    Female
    First Name:
    Jandy
    Lancaster, PA
    Vehicle:
    2016 GMC Canyon SLT w/ LineX and....
    Leaf springs, leaf springs, leaf springs.....

    Not necessarily an option in todays standards - but - when I owned my 96 tacoma, I had the axle wrap also. I lifted my truck about 2" = I actually had my leaf springs re-arched PLUS added 2 custome made extra leafs in the pak. It was one-hell-of-a heavy duty leaf spring setup. It was stiff, handled loads like it was nothing and I loved it. Axle wrap was a thing of the past!

  13. Mar 27, 2010 at 12:56 PM
    #13
    747

    747 function > form

    Joined:
    Jan 27, 2008
    Member:
    #4465
    Messages:
    3,000
    Gender:
    Male
    Vehicle:
    1st Gen.
    Front bracket...

    [​IMG]

    Rear bracket (both pics)...

    [​IMG]


    [​IMG]

    Profile view (from front)...

    [​IMG]

    Pain in the a$$ to install: Yeah;
    Expensive: Yeah; and,
    Solves Problem: Yeah.

    I'd recommend trying AAL/new leafs first.

  14. Mar 27, 2010 at 4:21 PM
    #14
    mtucker

    mtucker Tacoma addict

    Joined:
    Aug 3, 2009
    Member:
    #20610
    Messages:
    269
    Gender:
    Male
    First Name:
    Matt
    Escondido, CA.
    Vehicle:
    03 Prerunner DC
    Replaced chrome badges with Sockmonkey black badges, painted billet grill black, K&N cold air intake, my corner light turn signal circuit, Speedfreek traction bars, RAAMaudio BXT/Ensolite, Stereo: Kenwood KIV-701 USB/Bluetooth deck, 10" Pioneer shallow sub behind the rear seat, Infinity 6822cf 6x8 front and rear doors, Fosgate P400-2 (sub), US Acoustics USX-4065 (four main speakers)
    ^^ those are perdy.

    I bought these
    [​IMG]

    From a local guy (North San Diego) http://speed-freek.net/?page_id=39
    He made them for 5-lug Tacomas. The five lugs don't tend to have axle wrap, but he made them for people that like to put 300+ ponies in them. I contacted him at a local Tacoma event and he said he would use my truck as the guinea pig for six-lug trucks. He had to do very little to install them (shave the bracket here or there).

    An overall shot. There is that slip yoke grease all over the Magnaflow.
    [​IMG]


    The traction bar plate under the leafs
    [​IMG]


    He (Jason) asked me before hand if I off road. I don't. Dirt roads is about all I ever see. He said these may limit suspension travel at the very extreme ends and that he could make some off-road worthy ones if anyone needed them.

    I also looked at these guys.
    http://www.budbuilt.com/new/traction_bars.html

    The traction bars not only stopped the axle wrap, but it also seems more sure footed. The rear end would get wobbly on fast sweeping corners with bumps.

    Matt

  15. Mar 27, 2010 at 4:40 PM
    #15
    scocar

    scocar Scouting the perimeter for weakness

    Joined:
    Nov 11, 2009
    Member:
    #25814
    Messages:
    31,275
    Gender:
    Male
    First Name:
    Dick
    In close proximity to an undisclosed location
    Vehicle:
    2015 DCLB 4x4 SR5
    Back to square one after the 2001. So...
    Cool. Thanks for taking time to post pix. Interesting setup. I've seen the Budbuilt one before, and it is spendy, as much as new leaf packs from Wheelers.

  16. Mar 27, 2010 at 5:31 PM
    #16
    747

    747 function > form

    Joined:
    Jan 27, 2008
    Member:
    #4465
    Messages:
    3,000
    Gender:
    Male
    Vehicle:
    1st Gen.
    mtucker: Having any problems with that setup? I'm not suggesting that you are/will...just wondering.

  17. Mar 27, 2010 at 8:23 PM
    #17
    mtucker

    mtucker Tacoma addict

    Joined:
    Aug 3, 2009
    Member:
    #20610
    Messages:
    269
    Gender:
    Male
    First Name:
    Matt
    Escondido, CA.
    Vehicle:
    03 Prerunner DC
    Replaced chrome badges with Sockmonkey black badges, painted billet grill black, K&N cold air intake, my corner light turn signal circuit, Speedfreek traction bars, RAAMaudio BXT/Ensolite, Stereo: Kenwood KIV-701 USB/Bluetooth deck, 10" Pioneer shallow sub behind the rear seat, Infinity 6822cf 6x8 front and rear doors, Fosgate P400-2 (sub), US Acoustics USX-4065 (four main speakers)
    At sometime >> 6 months, I developed a crack in the passenger side plate. It looked like it cracked from the leaf spring stop (whatever that short leaf spring that isn't in the leaf spring pack is called) pushing down on it. He had never seen that before (on the 5-lugs). He said they normally bend a bit, but never brake. He made me new plates that were extra thick (don't know the exact thickness, but the pictures are of the new thicker plates) and installed them.

    I've never noticed any binding or weird noises other than the Heim joint (the ball socket looking thing) needing a little grease to stop it from squeaking.

    Matt

  18. Mar 27, 2010 at 8:51 PM
    #18
    747

    747 function > form

    Joined:
    Jan 27, 2008
    Member:
    #4465
    Messages:
    3,000
    Gender:
    Male
    Vehicle:
    1st Gen.
    mtucker,

    When you put the truck on a lift, did you notice whether the rear driveshaft was sliding back and forth/compressing and decompressing at the (what I'll call) "joint"?

    The reason I ask: From the looks of your setup, it seems like the rear axle would be able to move up and down, but not forward and backward, and no articulation. While this would stop axle wrap (which was the goal), I'm wondering whether the driveshaft "joint" is being used and/or what kind of stress(es) the restriction of movement is putting on other components or on the traction bars/mounts themselves. Did Jason tell you what the cracks in the mounts were caused by (other than stress)?

  19. Mar 27, 2010 at 9:15 PM
    #19
    mtucker

    mtucker Tacoma addict

    Joined:
    Aug 3, 2009
    Member:
    #20610
    Messages:
    269
    Gender:
    Male
    First Name:
    Matt
    Escondido, CA.
    Vehicle:
    03 Prerunner DC
    Replaced chrome badges with Sockmonkey black badges, painted billet grill black, K&N cold air intake, my corner light turn signal circuit, Speedfreek traction bars, RAAMaudio BXT/Ensolite, Stereo: Kenwood KIV-701 USB/Bluetooth deck, 10" Pioneer shallow sub behind the rear seat, Infinity 6822cf 6x8 front and rear doors, Fosgate P400-2 (sub), US Acoustics USX-4065 (four main speakers)
    I didn't notice if the driveshaft was moving in/out when it was jacked up.
    The plate crack formed right on the bend where the leaf spring stop was pushing down on it. It looked light a straight forward stress crack from being flexed too much. He said they normally bend there, but had never seen one actually crack.

    Matt

  20. Mar 27, 2010 at 9:24 PM
    #20
    747

    747 function > form

    Joined:
    Jan 27, 2008
    Member:
    #4465
    Messages:
    3,000
    Gender:
    Male
    Vehicle:
    1st Gen.
    Gotcha. Sick running and fog lights btw...waiting for the writeup/howto...if you've posted it somewhere, let me know (uber-interested)!
