BSM randomly quit working?

Discussion in '3rd Gen. Tacomas (2016-2023)' started by Max713, Mar 30, 2021.

  1. Mar 30, 2021 at 4:29 PM
    #1
    Max713

    Max713 [OP] Well-Known Member

    Joined:
    Nov 29, 2013
    Member:
    #117569
    Messages:
    629
    Gender:
    Male
    First Name:
    Max
    Eugene, OR
    Vehicle:
    2017 MGM TRD OR
    Anyone had their blind spot monitoring quit working?
    I was driving down the road, randomly got a light on the dash and a warning came up saying "Blind spot monitoring unavailable".

    Turned the truck and switch on and off several times, it's been 4 days now. I pressure washed the area of the rear bumper around the sensors, nothing. About to start pulling things apart to clean them thoroughly...

    Just wondering if anyone else has had this issue and what the fix was. Avoiding taking it to the dealer, I'm out of warranty.

  2. Mar 30, 2021 at 5:26 PM
    #2
    Dchief

    Dchief Member

    Joined:
    Aug 21, 2016
    Member:
    #195139
    Messages:
    9
    Gender:
    Male
    First Name:
    Pat
    Northern IL
    Vehicle:
    2016 MGM Tacoma TRD OR
    My 16 OR started having same issue with BSM three days ago. Cycled power without improvement. I plan to dissect sensors this weekend.

  3. Mar 30, 2021 at 5:27 PM
    #3
    brandon78lusch

    brandon78lusch Well-Known Member

    Joined:
    Oct 22, 2019
    Member:
    #308678
    Messages:
    4,029
    Gender:
    Male
    First Name:
    Brandon
    East Carolina University
    Vehicle:
    2019 TRD Sport DCSB, 1978 Pontiac Firebird Trans Am
    Have you tried disconnecting and reconnecting the battery? That seems to fix some random issues.

    RedWings44 likes this.
  4. Mar 30, 2021 at 5:29 PM
    #4
    ksimms92

    ksimms92 Well-Known Member

    Joined:
    Sep 23, 2020
    Member:
    #341721
    Messages:
    548
    Gender:
    Male
    First Name:
    Kevin
    West of Chicago
    Vehicle:
    2020 Silver TRD OR DCLB 4X4
    I had this issue after hitting some trails and surprisingly it fixed itself after going through the car wash.

    Apparently they can sometimes recalibrate themselves if you drive around. Not always from what I’ve read, but sometimes you get lucky.

    After getting a wash I drove around with that warning for maybe 30 minutes? I wasn’t very optimistic at the time but it did eventually start working again.

    My suggestion would be to drive around for a while (if you haven’t already) and maybe you can avoid taking it apart.

    mud likes this.
  5. Mar 30, 2021 at 5:32 PM
    #5
    Shellshock

    Shellshock King Shit of Turd Island

    Joined:
    Nov 21, 2015
    Member:
    #170338
    Messages:
    23,323
    Iowa
    Vehicle:
    2019 Tundra TRD PRO / 2024 GRC Circuit
    Mine died too. I had issues last year but after a cleaning in the spring it was fine. This year its dead and hasn’t come back

    Pretty sure its toast

  6. Mar 30, 2021 at 5:45 PM
    #6
    Kremtok

    Kremtok Well-Known Member

    Joined:
    Jan 15, 2017
    Member:
    #207630
    Messages:
    1,770
    Gender:
    Male
    First Name:
    Gary
    Houston, TX
    Vehicle:
    2021 Tesla Model 3 Long Range AWD
    2018 Triumph Street Triple RS
    Mine stopped working about a year ago so I turned it off. I don't miss it.

  7. Mar 30, 2021 at 5:51 PM
    #7
    Shellshock

    Shellshock King Shit of Turd Island

    Joined:
    Nov 21, 2015
    Member:
    #170338
    Messages:
    23,323
    Iowa
    Vehicle:
    2019 Tundra TRD PRO / 2024 GRC Circuit
    I don’t really care about BSM but RCTA is kinda nice.. i miss that

  8. Mar 30, 2021 at 6:14 PM
    #8
    MadKatt

    MadKatt In need of serious help..

    Joined:
    Dec 14, 2019
    Member:
    #313265
    Messages:
    1,407
    Gender:
    Male
    Frozen Midwest Tundra
    Vehicle:
    2019 TRD OR DCLB Calvary Blue
    There is a tsb on this it’s a known issue that the sensors get beat up and go bad. Mine went out during a winter snow storm contacted dealer they looked at them ordered a new set. One week later went back in 3 hrs later new sensors bsm working great zero cost to me.

    Kremtok likes this.
  9. Mar 30, 2021 at 7:41 PM
    #9
    Kremtok

    Kremtok Well-Known Member

    Joined:
    Jan 15, 2017
    Member:
    #207630
    Messages:
    1,770
    Gender:
    Male
    First Name:
    Gary
    Houston, TX
    Vehicle:
    2021 Tesla Model 3 Long Range AWD
    2018 Triumph Street Triple RS
    I'm going to try to find the TSB but if you can link to it you'd save me the trouble, please and thank you.

  10. Mar 30, 2021 at 7:44 PM
    #10
    RedWings44

    RedWings44 Well-Known Member

    Joined:
    Apr 28, 2020
    Member:
    #326226
    Messages:
    8,017
    Gender:
    Male
    Michigan
    Vehicle:
    2017 Black TRD Off Road 4x4, 2019 MGM 4Runner SR5
    Mine randomly told me it needed service one day. However, after restarting the truck, it went away and hasn't come back in several months.

  11. Mar 30, 2021 at 7:56 PM
    #11
    brandon78lusch

    brandon78lusch Well-Known Member

    Joined:
    Oct 22, 2019
    Member:
    #308678
    Messages:
    4,029
    Gender:
    Male
    First Name:
    Brandon
    East Carolina University
    Vehicle:
    2019 TRD Sport DCSB, 1978 Pontiac Firebird Trans Am
    This is one reason why I didn’t go with this package

  12. Mar 31, 2021 at 7:02 AM
    #12
    Max713

    Max713 [OP] Well-Known Member

    Joined:
    Nov 29, 2013
    Member:
    #117569
    Messages:
    629
    Gender:
    Male
    First Name:
    Max
    Eugene, OR
    Vehicle:
    2017 MGM TRD OR
    Thanks for all the replies.
    I did more searching after posting this thread. Found threads of people removing the bumper covers and cleaning the sensors, then driving around with BSM ON for a few days (I had been driving with it off because the warning and dash light are annoying).
    I took my bumper covers off, went to move my truck to the hose and BSM was magically working...
    I washed the sensors off anyways, although they didn't look that dirty. Put the bumper covers back on and everything seems to be working again.

    If they turn off again, I plan to pressure wash the area without removing the covers and drive around with BSM on for a few days, but I hope the problem doesn't come back.

    Last edited: Mar 31, 2021
    Steve Armstrong and mud like this.
  13. Mar 31, 2021 at 7:07 AM
    #13
    mud

    mud Djentleman

    Joined:
    Dec 21, 2018
    Member:
    #276560
    Messages:
    1,346
    Gender:
    Male
    SoCal
    Vehicle:
    2019 TRD OR DCSB LMNOP QRS TUVWXYZ
    I had just about this exact series of events. Makes you think you’re nuts huh?

  14. Mar 31, 2021 at 7:10 AM
    #14
    Max713

    Max713 [OP] Well-Known Member

    Joined:
    Nov 29, 2013
    Member:
    #117569
    Messages:
    629
    Gender:
    Male
    First Name:
    Max
    Eugene, OR
    Vehicle:
    2017 MGM TRD OR
    Haha, yes. Got in my truck to move it and was like "the fu..."

    mud[QUOTED] likes this.
  15. Mar 31, 2021 at 7:13 AM
    #15
    Astr0Aar0n

    Astr0Aar0n Well-Known Member

    Joined:
    Oct 11, 2019
    Member:
    #307706
    Messages:
    696
    Gender:
    Male
    Portland, OR
    Vehicle:
    19' Tacoma TRD OR V6 4x4 DCSB cavalry blue
    Quite a few things at this point..
    Yes, it's happened a few times. You have to keep BSM on in order for it to reset/recalibrate. Do not turn it off despite how annoying it can be to keep clearing the error, it will eventually fix itself.

    Max713[QUOTED][OP] likes this.
  16. Mar 31, 2021 at 7:16 AM
    #16
    Steve Armstrong

    Steve Armstrong Well-Known Member

    Joined:
    Mar 23, 2021
    Member:
    #360297
    Messages:
    257
    Gender:
    Male
    SoCal
    Vehicle:
    2021 TRD Sport DCSB
    Woot! :bananadance:
