DIY - Build and install a Bussmann RTMR Fuse/Relay Block

Discussion in 'Technical Chat' started by tacozord, Nov 4, 2015.

  1. Apr 22, 2016 at 11:41 AM
    #241
    IronPeak

    IronPeak PermaLurker

    Joined:
    Mar 9, 2016
    Member:
    #180799
    Messages:
    3,225
    Gender:
    Male
    First Name:
    AuggieX
    Back to Back
    Vehicle:
    2007 sr5 4x4 DCLB/2015 TRD sport 4x4 DCLB sold
    Bigger Taller Slower
    That is actually remarkably flexible

  2. Apr 25, 2016 at 8:31 PM
    #242
    alphabravo

    alphabravo Well-Known Member

    Joined:
    Jan 6, 2014
    Member:
    #120082
    Messages:
    1,738
    Gender:
    Male
    First Name:
    Christopher
    Canada via FL
    Vehicle:
    2003 Tacoma TRD
    Supercharger AntiDark Hood Light Redline Tuning Hood Struts Morimoto Projectors Grey Wire Mod Tundra 13WL Brake Conversion EBC ED Pads and GD Rotors Mean Green Starter DC Power 250A Alternator Odyssey PC2150 Battery, Artec Cage ADS shocks Total Chaos UCA ComeUp Winch, Factor 55 Splicer Relentless bumpers OTRATTW Switches, Bussman 15304-2-2-4 RTMR, Paranoid Fabrication switch brackets Jensen JHD3630BT Morimoto XB LED Fogs Deaver Custom Springs Ivan Stewart TRD Wheels, Pro Series TRD Wheels
    I didn't really think of this til all my stuff arrived but how do you wire, say, a pair of led backup lights in parallel with MetriPack connectors?

    If you use a 4 pin connector then you have to add jumpers on the female side which means doubling up the wire when you crimp the pin (as shown). If you are using 12ga or 14ga wire I don't see how this will fit in the seals.

    If you use only 2 pin connectors then you have to run the wires from LED2 into the back of the LED1 connector which means doubling the wire when you crimp the male pins.

    Just wondering what do...

    [​IMG]

  3. Apr 25, 2016 at 8:38 PM
    #243
    Manwithoutaplan

    Manwithoutaplan the full Monty

    Joined:
    Jan 30, 2008
    Member:
    #4500
    Messages:
    54,411
    Gender:
    Male
    ID
    Vehicle:
    07 Tacoma Speedway Blue Trd 4x4
    -Nitro 4.56 gears - Arb Front and Rear lockers. -Rear Swing out bumper Curiosity of ( Dept .94) https://www.facebook.com/Dept94 -Tinted, -ProComp 6 inch lift with Icon Coil overs and Bilstein's 7100Resi -315/70/17 - 17x8 in Pro Comp Matte black rims 4.5 bs -East Coast Gear Supply Sliders -ALL Pro EXP LEaf pack -Camburg UCA's -CAB mount CHOP
    very impressed by this thread well done OP :thumbsup:

  4. Apr 26, 2016 at 5:44 AM
    #244
    diverdale

    diverdale #sosconceptscrew

    Joined:
    Sep 22, 2015
    Member:
    #164936
    Messages:
    1,730
    Gender:
    Male
    First Name:
    Dale
    Raleigh, NC
    Vehicle:
    2015 TRD OR DCSB
    Fox 2.5 Coilovers, Fox 2.0 Rear Resi, Icon 3 Leaf AAL
    I did mine this way


    rob1208 likes this.
  5. Apr 26, 2016 at 7:21 AM
    #245
    alphabravo

    alphabravo Well-Known Member

    Joined:
    Jan 6, 2014
    Member:
    #120082
    Messages:
    1,738
    Gender:
    Male
    First Name:
    Christopher
    Canada via FL
    Vehicle:
    2003 Tacoma TRD
    Supercharger AntiDark Hood Light Redline Tuning Hood Struts Morimoto Projectors Grey Wire Mod Tundra 13WL Brake Conversion EBC ED Pads and GD Rotors Mean Green Starter DC Power 250A Alternator Odyssey PC2150 Battery, Artec Cage ADS shocks Total Chaos UCA ComeUp Winch, Factor 55 Splicer Relentless bumpers OTRATTW Switches, Bussman 15304-2-2-4 RTMR, Paranoid Fabrication switch brackets Jensen JHD3630BT Morimoto XB LED Fogs Deaver Custom Springs Ivan Stewart TRD Wheels, Pro Series TRD Wheels
    Ok cool. So you just doubled up the wire when you crimped the top two pin connector?

  6. Apr 26, 2016 at 7:24 AM
    #246
    G.T.

    G.T. Official TW Burrito Inspector

    Joined:
    Jul 14, 2010
    Member:
    #40169
    Messages:
    17,555
    Gender:
    Male
    First Name:
    G.T.
    CONUS
    Vehicle:
    2011 Pyrite Mica 4WD DCLB TRDSport w/ FlipPac
    Some stick on chrome from pep boys
    You guys are doing all of this amazing wiring and I'm sitting here still trying to relearn how to tie my shoes. Overtime I come back to this thread I am even more impressed with my fellow TW members. Great work folks.

    Crom and Chux like this.
  7. Apr 26, 2016 at 7:26 AM
    #247
    alphabravo

    alphabravo Well-Known Member

    Joined:
    Jan 6, 2014
    Member:
    #120082
    Messages:
    1,738
    Gender:
    Male
    First Name:
    Christopher
    Canada via FL
    Vehicle:
    2003 Tacoma TRD
    Supercharger AntiDark Hood Light Redline Tuning Hood Struts Morimoto Projectors Grey Wire Mod Tundra 13WL Brake Conversion EBC ED Pads and GD Rotors Mean Green Starter DC Power 250A Alternator Odyssey PC2150 Battery, Artec Cage ADS shocks Total Chaos UCA ComeUp Winch, Factor 55 Splicer Relentless bumpers OTRATTW Switches, Bussman 15304-2-2-4 RTMR, Paranoid Fabrication switch brackets Jensen JHD3630BT Morimoto XB LED Fogs Deaver Custom Springs Ivan Stewart TRD Wheels, Pro Series TRD Wheels
    LoL. I'm learning alot too. Those WeatherPack/MetriPack type connectors make it look easy. I think all the GM vehicles use WeatherPacks now so it's basically OEM.

  8. Apr 26, 2016 at 7:33 AM
    #248
    diverdale

    diverdale #sosconceptscrew

    Joined:
    Sep 22, 2015
    Member:
    #164936
    Messages:
    1,730
    Gender:
    Male
    First Name:
    Dale
    Raleigh, NC
    Vehicle:
    2015 TRD OR DCSB
    Fox 2.5 Coilovers, Fox 2.0 Rear Resi, Icon 3 Leaf AAL
    Yep...no problem at all

  9. Apr 26, 2016 at 7:48 AM
    #249
    pinchetaco

    pinchetaco Well-Known Member

    Joined:
    Apr 6, 2009
    Member:
    #15658
    Messages:
    657
    Gender:
    Male
    First Name:
    Chris
    Winston Salem, NC
    Vehicle:
    06 Taco 6 inch ProComp Lift 35's
    6 inch ProComp Lift, 35s, ProComp Wheels, 4.88 gears, Debadged, BHLM, Dome Light Mod, Trailer Plug Relocated
    I ordered all the stuff to make a relay box. When I got it all, I had ordered the wrong box. It only had one bussbar. coulda made it work but I wanted two bussbars. That was another $12 shipping charge from waytek. Then I had to ship that box back. Cost $4 to ship it to them wtf! Oh well. Ive got my box built, but in my stupidity I forgot to order the correct pins for the 2 pin weatherpak connectors.

  10. Apr 26, 2016 at 10:36 AM
    #250
    TaylorU

    TaylorU KC HiLiTES Vendor

    Joined:
    May 19, 2013
    Member:
    #104501
    Messages:
    1,535
    Gender:
    Male
    First Name:
    Taylor
    Flagstaff, Arizona
    Vehicle:
    2010 4x4 TRD Off-Road
    ADS 2.5" coilovers, Light Racing UCAs, 2.125" rear ADS shocks, Raptor-Style Grille using Homertaco mesh and BAMF letters, MB 352 wheels, 285/75r16 Cooper ATPs, Mini D2S 3.0 HID Projectors retrofitted, KC Flex 20", KC Pro6 light bar, KC G4 LED fog lights, Pelfreybilt front bumper
    Does anybody know the bolt specs that are on the 2nd gen drivers side fender where many people are mounting their brackets? Also the specs on the bolts for the Bussmann RTMR itself? Mine didn't come with any mounting hardware. I made a bracket last night, but these are the only pieces I'm missing from having this preliminary step finished.

    EDIT: It looks like for the bussmann what's needed are #10-32 or M5 threaded inserts. Source

  11. Apr 26, 2016 at 11:02 AM
    #251
    diverdale

    diverdale #sosconceptscrew

    Joined:
    Sep 22, 2015
    Member:
    #164936
    Messages:
    1,730
    Gender:
    Male
    First Name:
    Dale
    Raleigh, NC
    Vehicle:
    2015 TRD OR DCSB
    Fox 2.5 Coilovers, Fox 2.0 Rear Resi, Icon 3 Leaf AAL
    fender bolts are M8

    TaylorU likes this.
  12. Apr 26, 2016 at 12:02 PM
    #252
    alphabravo

    alphabravo Well-Known Member

    Joined:
    Jan 6, 2014
    Member:
    #120082
    Messages:
    1,738
    Gender:
    Male
    First Name:
    Christopher
    Canada via FL
    Vehicle:
    2003 Tacoma TRD
    Supercharger AntiDark Hood Light Redline Tuning Hood Struts Morimoto Projectors Grey Wire Mod Tundra 13WL Brake Conversion EBC ED Pads and GD Rotors Mean Green Starter DC Power 250A Alternator Odyssey PC2150 Battery, Artec Cage ADS shocks Total Chaos UCA ComeUp Winch, Factor 55 Splicer Relentless bumpers OTRATTW Switches, Bussman 15304-2-2-4 RTMR, Paranoid Fabrication switch brackets Jensen JHD3630BT Morimoto XB LED Fogs Deaver Custom Springs Ivan Stewart TRD Wheels, Pro Series TRD Wheels
    Ok so this is the wiring diagram for the backup lights. Same deal for the fog pair and anything else that wants to be in parallel.
    [​IMG]

  13. Apr 27, 2016 at 11:00 AM
    #253
    mountainmonkey

    mountainmonkey Well-Known Member

    Joined:
    Mar 30, 2014
    Member:
    #126570
    Messages:
    3,996
    Gender:
    Male
    Colorado
    Vehicle:
    '13 Double Cab TRDOR DCSB
    Never enough
    How much does this flexible cable cost and where can I get it?

  14. Apr 27, 2016 at 11:20 AM
    #254
    manethon

    manethon TTAS

    Joined:
    Oct 9, 2013
    Member:
    #114161
    Messages:
    3,580
    Gender:
    Male
    First Name:
    John
    Toronto
    Many
    You can get it through me once it lands mid may.
    I didnt think anyone on TW or some one outside of an audio world would really be interested in something like this. The cost is not cheap and is only sold in a 50ft spool. Works out to be 15.8$ per foot for a cable under rated at 1000Amps per 20ft section

  15. Apr 27, 2016 at 12:11 PM
    #255
    mountainmonkey

    mountainmonkey Well-Known Member

    Joined:
    Mar 30, 2014
    Member:
    #126570
    Messages:
    3,996
    Gender:
    Male
    Colorado
    Vehicle:
    '13 Double Cab TRDOR DCSB
    Never enough
    Does that mean $15.80 per foot or 15.8¢ per foot? One is in my budget, the other is not haha. Looks like a sweet product though.

  16. Apr 27, 2016 at 12:13 PM
    #256
    manethon

    manethon TTAS

    Joined:
    Oct 9, 2013
    Member:
    #114161
    Messages:
    3,580
    Gender:
    Male
    First Name:
    John
    Toronto
    Many
    lol i think you know the answer to that one :p

    mountainmonkey likes this.
  17. Apr 27, 2016 at 4:18 PM
    #257
    diverdale

    diverdale #sosconceptscrew

    Joined:
    Sep 22, 2015
    Member:
    #164936
    Messages:
    1,730
    Gender:
    Male
    First Name:
    Dale
    Raleigh, NC
    Vehicle:
    2015 TRD OR DCSB
    Fox 2.5 Coilovers, Fox 2.0 Rear Resi, Icon 3 Leaf AAL
    Yeah...I've worked with some big ass copper running power to DC power plants. It was called 750 and I can't remember what it was but I do remember it was like $20/ft or some shit

  18. Apr 27, 2016 at 5:25 PM
    #258
    manethon

    manethon TTAS

    Joined:
    Oct 9, 2013
    Member:
    #114161
    Messages:
    3,580
    Gender:
    Male
    First Name:
    John
    Toronto
    Many
    Yeah big wire! Stuff is about as stiff as your frame lol. I know a few people who ran it as a chassis ground in unibody cars

  19. Apr 27, 2016 at 11:59 PM
    #259
    kitsym

    kitsym Well-Known Member

    Joined:
    Feb 23, 2015
    Member:
    #149453
    Messages:
    1,426
    Gender:
    Male
    Portland, OR
    Vehicle:
    2015 4x4 MGM DCSB TRD Sport
    Did you end up wiring your backup pods/LEDS to a switch or to turn on automatically when reversing? Just curious.

  20. Apr 28, 2016 at 7:26 AM
    #260
    alphabravo

    alphabravo Well-Known Member

    Joined:
    Jan 6, 2014
    Member:
    #120082
    Messages:
    1,738
    Gender:
    Male
    First Name:
    Christopher
    Canada via FL
    Vehicle:
    2003 Tacoma TRD
    Supercharger AntiDark Hood Light Redline Tuning Hood Struts Morimoto Projectors Grey Wire Mod Tundra 13WL Brake Conversion EBC ED Pads and GD Rotors Mean Green Starter DC Power 250A Alternator Odyssey PC2150 Battery, Artec Cage ADS shocks Total Chaos UCA ComeUp Winch, Factor 55 Splicer Relentless bumpers OTRATTW Switches, Bussman 15304-2-2-4 RTMR, Paranoid Fabrication switch brackets Jensen JHD3630BT Morimoto XB LED Fogs Deaver Custom Springs Ivan Stewart TRD Wheels, Pro Series TRD Wheels
    I'm still in the middle of wiring but thinking you should be able to do both. If the LED can get power from the OEM reverse wire or from the switch then it would come on/off when in reverse or it would come on/off with the switch.
