    Coulda been done but I didnt wanna cut up his tranny tunnel...lol. His case was a forward shift and the donor was a top shift so had to convert it. What a PITA. Anyone who takes apart one of the case beware...dont play with the shift rails :eek:

    I ended up doing this thing three times bc I would test it and move the 4wd rail a little too far and then you just hear "tink tink tink" there goes the pawls on the 4wd drive synchro dropping in the case...shit do it all over again.

    Anyways pics and a video when I get to a PC. Peace yall.
