Flare Repair - GE Black Silicone Caulking

Discussion in '2nd Gen. Tacomas (2005-2015)' started by HBMurphy, Aug 29, 2010.

  1. Aug 29, 2010 at 10:50 AM
    #1
    HBMurphy

    HBMurphy [OP] Ban Pending

    Joined:
    Jun 27, 2009
    Member:
    #18993
    Messages:
    6,090
    Gender:
    Male
    First Name:
    Paul
    So California Coast
    Vehicle:
    09 Off Road Delete Model
    None
    WARNING!!! If you have never seen a dirt trail and don't know what an "orange clip" or a "blue clip" is - LEAVE THIS Thread!!! It won't make sense to you and it will leave you confused. ...and don't forget the next meet - we'll meet at the Footlocker!

    Now back to folks that may have had some trail damage...

    The clips and the knife edge thick connections on the original flares are breakage waiting to happen!

    (sorry for the crappy pics! Had the lens on manual focus :( - If someone else does this mod, could your redeem me with some good pics! :eek:

    I have cured mine with black silicone GE from Home Depot (caulking gun cartridge)

    - Blue tape an outline about a 1/16"-1/4" smaller than the flare

    [​IMG]

    (Manny please don't get too excited at the sight of JD's butt!)

    - Scuff up the paint on the fender (where the flare will be attached to) with green scuff pad

    [​IMG]

    - Clean up to the blue tape line with alcohol - I used rubbing alcohol but I think that East Coast moonshine would work just fine!

    - Remove those crappy clip bosses - they didn't do anything other than let the assembly line pop those fenders on - I find using a putty knife is a good way to scrape 'em off.

    - Scuff up the top 1 1/2 inches of the flare with coarse sandpaper

    - Clean the inside of the flare 2 inches from the top of the flare and follow up with an alcohol cleaning too.

    [​IMG]

    - Put on the silicone - one thick pass building about a 5/8" bead of silicone on the flare and on the fender

    - Screw on the flare (the screws on the flare lip)

    - Position the flare on and tape it on where you want it to stay (except if you have a hybrid - half mall crawler/half 3/4 hardcore wheeler like Brandon H - man I don't know how he keeps from denting his truck!!! But there was soooo much wax and tire polish that noting would stick so JD was kind enough to hold on :).)

    After the silicone is cured - pull off the blue tape :)

    FEILD TEST: I have put them through their paces during the last 10 months and those things are not coming off by any trail riding yet (as much as my bumper would like to change that - it hits the flare but it stays put), I think I should be able to pull em off (fishing line) if I need to.

    This work was done to BrandonH's truck - he tore his flares off at MDR race while he was prancing on his 35s on very clean Walker Evans beadlocks! :D

    Also had to do the Silverback All Pro bumper cutout - I think he should be set.

    [​IMG]

    If anyone does this and wants to improve the pics please let me know. :)

    I hope this saves at least one guy the hassle of wondering what to do with broken fender flares! The next thing would be to have bumper manufactures design their bumpers to allow for frame/bumper flex without ripping the damn things off in the first place!!! :)

  2. Aug 29, 2010 at 11:01 AM
    #2
    jdkeller

    jdkeller How many words can be fit in this s

    Joined:
    Nov 26, 2008
    Member:
    #11040
    Messages:
    12,983
    Gender:
    Male
    First Name:
    Jonathan
    Inland Empire, Ca
    Vehicle:
    2008 Tacoma Prerunner TRD Offroad
    Dome light LED, 6000k HID Headlights and fogs, Grillcraft black mesh, rear 5100's, Total Chaos UCA's, 285/75/16 BFG KM2's, Spidertrax spacers, Blacked out emblems, cb,kenwood tm270 ham radio, All Pro 3" leaf pack, Fox 2.0 coilovers, Revenge Fab Sliders, u bolt flip kit, Pioneer avh4200, bed bar with light and antenna, Wet Okoles, Weathertech Mats, Wet Okole Armrests, Rear KR Fab bumper, bed mat, N-Fab spare tire carrier with full size spare on 16" TRD rim, Bedlinered flares and grille. Camburg Spindles, All Pro front fenders.
    Nice writeup! I really hope manny doesn't see this thread.

  3. Aug 29, 2010 at 11:03 AM
    #3
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    nice write up......

  4. Aug 29, 2010 at 12:09 PM
    #4
    T0LLPHR33

    T0LLPHR33 Well-Known Member

    Joined:
    Sep 26, 2007
    Member:
    #2817
    Messages:
    1,596
    Gender:
    Male
    S1N C1TY...(from Hilo, HI)...
    Vehicle:
    BSP TRD Off-Road
    APR X-1 | TRD CAI w/Clear Cover | TRD Short Shifter w/ TRD "RED" Shift Knob | SGII w/Blendmount| Snugtop SL w/KeyLess Entry | 5% Tint | Pop-n-Lock | Bosch Icon WB | S2K Antenna | HRM | LS 8K Projectors w/BSP HLM & 8K Fogs w/FLM | Debadged |Tinted Tails | Black Weathertechs | MX RGM & RBM | Optima Red Top 35 | Gatorback Belt |
    i noticed my front passenger side flare popping off as well...i wonder if toyota would repair that under my extended warranty...

    awesome write-up...

  5. Aug 29, 2010 at 4:02 PM
    #5
    HBMurphy

    HBMurphy [OP] Ban Pending

    Joined:
    Jun 27, 2009
    Member:
    #18993
    Messages:
    6,090
    Gender:
    Male
    First Name:
    Paul
    So California Coast
    Vehicle:
    09 Off Road Delete Model
    None
    Thanks.

  6. Aug 29, 2010 at 4:14 PM
    #6
    STR8_BEAST

    STR8_BEAST Well-Known Member

    Joined:
    Dec 28, 2009
    Member:
    #28323
    Messages:
    1,581
    Gender:
    Male
    First Name:
    Collin
    HB, SoCal
    Vehicle:
    07 PRERUNNER TRD OR
    MAGNAFLOW EXHAUST, SOUND SYSTEM, KENWOOD DNX 7140, WINDOW TINT, REAR TSB, FRONT COIL SPACER, SATOSHI MOD, BHLM, WHITE CALIPERS, CB RADIO W/4FT FIRESTIK, MAGLITE MOD
    no mall crawlers? :pout:

  7. Aug 29, 2010 at 4:18 PM
    #7
    HBMurphy

    HBMurphy [OP] Ban Pending

    Joined:
    Jun 27, 2009
    Member:
    #18993
    Messages:
    6,090
    Gender:
    Male
    First Name:
    Paul
    So California Coast
    Vehicle:
    09 Off Road Delete Model
    None
    :)

  8. Aug 29, 2010 at 4:23 PM
    #8
    jesus

    jesus Well-Known Member

    Joined:
    Oct 31, 2009
    Member:
    #25236
    Messages:
    944
    Gender:
    Male
    First Name:
    jesus
    bakersfield
    Vehicle:
    02
    K&N ram intake & doug exs.
    good write up do you have any pics of them on now???

  9. Aug 29, 2010 at 4:27 PM
    #9
    HBMurphy

    HBMurphy [OP] Ban Pending

    Joined:
    Jun 27, 2009
    Member:
    #18993
    Messages:
    6,090
    Gender:
    Male
    First Name:
    Paul
    So California Coast
    Vehicle:
    09 Off Road Delete Model
    None
    Well, here's mine...

    [​IMG]

  10. Aug 29, 2010 at 4:27 PM
    #10
    rumrunner358

    rumrunner358 Member

    Joined:
    Jun 2, 2010
    Member:
    #38257
    Messages:
    21
    Gender:
    Male
    It'll probably be fine, but a lot of silicone products break down in UV rays. A polysulfide would probably be a better option.


    still, good write up!

  11. Aug 29, 2010 at 4:28 PM
    #11
    STR8_BEAST

    STR8_BEAST Well-Known Member

    Joined:
    Dec 28, 2009
    Member:
    #28323
    Messages:
    1,581
    Gender:
    Male
    First Name:
    Collin
    HB, SoCal
    Vehicle:
    07 PRERUNNER TRD OR
    MAGNAFLOW EXHAUST, SOUND SYSTEM, KENWOOD DNX 7140, WINDOW TINT, REAR TSB, FRONT COIL SPACER, SATOSHI MOD, BHLM, WHITE CALIPERS, CB RADIO W/4FT FIRESTIK, MAGLITE MOD
    :D:p






    oh be careful parking on your lawn in HB, your neighbors might call the cops :rolleyes:

  12. Aug 29, 2010 at 4:29 PM
    #12
    HBMurphy

    HBMurphy [OP] Ban Pending

    Joined:
    Jun 27, 2009
    Member:
    #18993
    Messages:
    6,090
    Gender:
    Male
    First Name:
    Paul
    So California Coast
    Vehicle:
    09 Off Road Delete Model
    None
    It's just most people don't have the misfortune to rip off flares unless they have 35s or an aftermarket bumper! :)

  13. Aug 29, 2010 at 4:31 PM
    #13
    STR8_BEAST

    STR8_BEAST Well-Known Member

    Joined:
    Dec 28, 2009
    Member:
    #28323
    Messages:
    1,581
    Gender:
    Male
    First Name:
    Collin
    HB, SoCal
    Vehicle:
    07 PRERUNNER TRD OR
    MAGNAFLOW EXHAUST, SOUND SYSTEM, KENWOOD DNX 7140, WINDOW TINT, REAR TSB, FRONT COIL SPACER, SATOSHI MOD, BHLM, WHITE CALIPERS, CB RADIO W/4FT FIRESTIK, MAGLITE MOD
    Misfortune?! It's a trophy to bring home and put up on the wall ;)

  14. Aug 29, 2010 at 4:34 PM
    #14
    Stupid hurts.

    Stupid hurts. Hoogie boogie!

    Joined:
    Sep 22, 2008
    Member:
    #9408
    Messages:
    1,511
    Gender:
    Male
    First Name:
    Steven
    So☆Cal
    Vehicle:
    '07 5-Lug Impluse Red Pearl Access Cab 2WD
    American Motorsports Front Long Travel Kit, Total Chaos Rear Dual Shock Hoop Kit, Engage 50T Leaf Pack, Engage Front & Rear Hangers, American Motorsports Shackles
    When did you get the new wheels, Paul? Looking good! :thumbsup:

  15. Aug 29, 2010 at 4:38 PM
    #15
    HBMurphy

    HBMurphy [OP] Ban Pending

    Joined:
    Jun 27, 2009
    Member:
    #18993
    Messages:
    6,090
    Gender:
    Male
    First Name:
    Paul
    So California Coast
    Vehicle:
    09 Off Road Delete Model
    None
    Yeah, you're right!

    Had em for a while just didn't put them on the truck until a mini-mod day to put on JDs Spindles and take care of these flares.

  16. Aug 29, 2010 at 4:44 PM
    #16
    DTacoms

    DTacoms Well-Known Member

    Joined:
    Jun 15, 2007
    Member:
    #1844
    Messages:
    657
    Gender:
    Male
    Frisco, Texas
    Vehicle:
    05 4x4 DC LB BSP
    Those wheels and tires are very nice!

    And good write up btw. I won't be doing this because I'm 3/4 mall crawler.:D

  17. Aug 29, 2010 at 4:45 PM
    #17
    HBMurphy

    HBMurphy [OP] Ban Pending

    Joined:
    Jun 27, 2009
    Member:
    #18993
    Messages:
    6,090
    Gender:
    Male
    First Name:
    Paul
    So California Coast
    Vehicle:
    09 Off Road Delete Model
    None
    thanks - you may have the mis-fortune some day! :)

  18. Aug 29, 2010 at 5:15 PM
    #18
    HBMurphy

    HBMurphy [OP] Ban Pending

    Joined:
    Jun 27, 2009
    Member:
    #18993
    Messages:
    6,090
    Gender:
    Male
    First Name:
    Paul
    So California Coast
    Vehicle:
    09 Off Road Delete Model
    None
    may have to make those into these:

    [​IMG]
