Front main seal leaking??

Discussion in '2nd Gen. Tacomas (2005-2015)' started by Metallikatz3, Nov 18, 2010.

  1. Nov 18, 2010 at 4:50 PM
    #1
    Metallikatz3

    Metallikatz3 [OP] Well-Known Member

    Joined:
    Sep 10, 2008
    Member:
    #9124
    Messages:
    625
    SLC, UT
    Vehicle:
    2017 DCLB OR (on the way)
    Well I think my front main seal is leaking. The bottom of my engine is covered in oil and it only happens when the truck is running. Never once have it left a spot of oil on the ground. Nor is it bad enough to make the level drop on the dip stick (which I check weekly after discovering this). The leak appears to be coming from the front main seal as opposed to an of the oil lines. I have yet to pull off the crank pulley and check under that.


    I was just wondering if anyone else has ever heard of this problem??

  2. Nov 18, 2010 at 4:56 PM
    #2
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    does it look like this
    [​IMG]

    [​IMG]

  3. Nov 18, 2010 at 5:05 PM
    #3
    Metallikatz3

    Metallikatz3 [OP] Well-Known Member

    Joined:
    Sep 10, 2008
    Member:
    #9124
    Messages:
    625
    SLC, UT
    Vehicle:
    2017 DCLB OR (on the way)
    Not nearly that bad.. I just have a light film of oil that occassionally forms a drop if I dont clean it off for more than a week.

  4. Nov 18, 2010 at 5:07 PM
    #4
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    yea just had my leak fixed it was a crackcase gasket.....
    if you had pics of exactly where it is forming it would be better

  5. Nov 18, 2010 at 5:13 PM
    #5
    Metallikatz3

    Metallikatz3 [OP] Well-Known Member

    Joined:
    Sep 10, 2008
    Member:
    #9124
    Messages:
    625
    SLC, UT
    Vehicle:
    2017 DCLB OR (on the way)
    I was looking around on here, it seems like the timing cover is a place known to develop leaks

    I just have a light film basically everywhere but it seems to start around the front main/crank seal, so thats my best guess for now

  6. Nov 18, 2010 at 5:15 PM
    #6
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    yea i thought it was mine also but i cleaned it up real nice with engine cleaner and then you could see it

  7. Nov 18, 2010 at 5:26 PM
    #7
    2gtacoma

    2gtacoma Well-Known Member

    Joined:
    Mar 28, 2010
    Member:
    #34125
    Messages:
    201
    Gender:
    Male
    First Name:
    Daniel
    H-town
    Vehicle:
    05 -PreRunner sr5
    URD Maf Cal, Airaid intake, Gibson exhaust, Urd short shifter,Trd shift knob, 2.25 lift,Satoshi grill, Trex eyelids
    i had my front timing cover seal start leaking. It would leak at the bottom left corner very light then it got a little bad over time. Dealer wanted $1500 to fix it i bought oem toyota parts and fixed it for $90.

  8. Nov 18, 2010 at 5:41 PM
    #8
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    yup thats what i would have done if it wasnt warrentied...
    i got more leaks than a subamarine on mine:cool:

  9. Nov 19, 2010 at 10:09 PM
    #9
    Fortech

    Fortech Well-Known Member

    Joined:
    Mar 31, 2008
    Member:
    #5636
    Messages:
    878
    Gender:
    Male
    CANADA
    Vehicle:
    2005 Toyota Tacoma TRD OR
    Bilstein 5100's, rear TSB, Firestone bags
    I replaced my front engine oil seal (crank seal) myself about 2 months ago. The seal was around $20 and can be done in a few hours. I made a pulley holder from a piece of flat stock. Tried using the ratchet strap/chain to the frame method without luck. Loosened the bolt by bumping the starter with the breaker bar against the frame.

  10. Nov 19, 2010 at 10:27 PM
    #10
    4WD

    4WD cRaZy oLdmAn

    Joined:
    Jul 2, 2009
    Member:
    #19185
    Messages:
    23,950
    Gender:
    Male
    First Name:
    Doug
    Lakeside, Ca / Gardnerville, Nevada
    Vehicle:
    No Truck..well, maybe
    Grey wire MOD, deck plate, diff breather MOD, 2nd gen. OME 883# on Tundra 5100's, OMD custom 3" leafsprings, rear shock relocation, Ivan Stewart TRD rims w/285/75/16's, '02 bumper MOD, Famous Fabrications sliders , LED interior/exterior lights, bed bar, Custom tube bumper, Old school KC day lighters,Red Ring 8" HID flood, Kenwood vhf 2M.. umm some other shit I'm forgetting right now
    Loosened the bolt by bumping the starter with the breaker bar against the frame.


    Yep, thats the ticket !!! :D:D

  11. Dec 5, 2010 at 12:55 PM
    #11
    lightnin

    lightnin Member

    Joined:
    Nov 24, 2010
    Member:
    #46655
    Messages:
    19
    Gender:
    Male
    First Name:
    jeff
    west palm beach
    Vehicle:
    05' 4x4
    33'" tires
    just replaced the front main on my 05 there are other posts on here about the pulley causing the oil leak somehow. it rubs a grove into the metal or something. i cant find it now.

  12. Dec 5, 2010 at 1:02 PM
    #12
    brutalguyracing

    brutalguyracing BIG DADDY

    Joined:
    Jun 28, 2009
    Member:
    #19000
    Messages:
    24,038
    Gender:
    Male
    F.U> GUYZ
    broken mods
    :eek::canada:

  13. Dec 5, 2010 at 2:59 PM
    #13
    Metallikatz3

    Metallikatz3 [OP] Well-Known Member

    Joined:
    Sep 10, 2008
    Member:
    #9124
    Messages:
    625
    SLC, UT
    Vehicle:
    2017 DCLB OR (on the way)
    I forgot about this thread.. well they replaced the main seal and reinstalled my stock pulley.

    Ans then the leak started again... turns out the stock pulley wasn't creating a good seal either and it needs to be replaced too. Good news is that the dealer is replacing the seal again without charging me any labor. I only have to pay for the new pulley ($300 but it could be worse)
