Garage lifts?

Discussion in 'Garage / Workshop' started by cntstan, Apr 17, 2009.

  1. Apr 17, 2009 at 1:43 PM
    #1
    cntstan

    cntstan [OP] Well-Known Member

    Joined:
    Nov 24, 2008
    Member:
    #10998
    Messages:
    602
    Gender:
    Male
    First Name:
    Chuck
    Wisconsin now, North Carolina will always be HOME
    Vehicle:
    08 DC SR5 4X4 ; 94 Ford Bronco
    3" Toytec coilovers, rear AAL,satoshi'd grill,ARE topper,TRD exhaust, All Pro winch bumper, Warn winch, All Pro skid, Pro comp 7089's, Supersprings, Wet Okole seat covers
  2. Apr 17, 2009 at 2:18 PM
    #2
    paintdiddy

    paintdiddy Machine gun shits

    Joined:
    Oct 12, 2008
    Member:
    #9924
    Messages:
    10,327
    Gender:
    Male
    First Name:
    shithead
    nj and not from "the jersey shore"
    Vehicle:
    silver bullet
    i know nothing about these lifts, but make sure you pour enough concrete under the posts.im not sure what the thickness should be. i assume every city/town/state has their own code.

  3. Apr 17, 2009 at 2:24 PM
    #3
    AUDITECH

    AUDITECH Carolina Alliance: LAZY DIVISION

    Joined:
    Feb 10, 2007
    Member:
    #875
    Messages:
    840
    charlotte nc
    Vehicle:
    07 double cab prerunner
    none
    looks like the ones i used at auto shops as long as they are installed properly and the car or truck is on the lift properly then you should be ok

  4. Apr 17, 2009 at 2:53 PM
    #4
    bryce71780

    bryce71780 Member

    Joined:
    Mar 4, 2009
    Member:
    #14324
    Messages:
    7
    Gender:
    Male
    ILLINOIS
    Vehicle:
    05 TRD sport 4X4
    we have a 10,000 lb 2 post lift in our shop at the farm. we also installed it ourselves. we poured the concrete 6 inches deep and used standard anchors. fairly easy to install, but you will need some scaffolding, a backhoe came in real handy but you may not be able to get it in your shop,( we have 16 foot ceiling. As far as stability goes, alot of it depends on the vehicle. the tacoma is pretty stable best vehicle we have had on it was a canyon, it was super solid. I would'nt worry too much about a vehicle falling off. As long as you use a little common sense you will be fine. If yodo get a lift you will find yourself doing alot more maintanence than you normally do, just because it is SO much easier. I changed the belt out on my tacoma from the bottom last week. dropped skid plate and there it was made it a 5 min job. it was the best investment we made when we built the new shop for sure.

  5. Apr 17, 2009 at 3:09 PM
    #5
    cntstan

    cntstan [OP] Well-Known Member

    Joined:
    Nov 24, 2008
    Member:
    #10998
    Messages:
    602
    Gender:
    Male
    First Name:
    Chuck
    Wisconsin now, North Carolina will always be HOME
    Vehicle:
    08 DC SR5 4X4 ; 94 Ford Bronco
    3" Toytec coilovers, rear AAL,satoshi'd grill,ARE topper,TRD exhaust, All Pro winch bumper, Warn winch, All Pro skid, Pro comp 7089's, Supersprings, Wet Okole seat covers
    That's what I was looking for! When you say standard anchors, do you mean some type of bolt drilled into the concrete or having an anchor (bolt or rebar) placed in the concrete while it's still wet? Plus we only have 12' ceilings.

  6. Apr 17, 2009 at 10:11 PM
    #6
    bryce71780

    bryce71780 Member

    Joined:
    Mar 4, 2009
    Member:
    #14324
    Messages:
    7
    Gender:
    Male
    ILLINOIS
    Vehicle:
    05 TRD sport 4X4
    just drilled holes and beat the anchors in. the lift has to be exactly level. that is really important. It will come with shims that make it pretty easy. not a bad idea to have some various thickness washers handy just in case. we set one post then did the other. measured from a wall so it would be as square as we could get it. Pull the trigger on it you won't regret it.

  7. Apr 24, 2009 at 6:08 PM
    #7
    Forthedogs

    Forthedogs Member

    Joined:
    Apr 3, 2009
    Member:
    #15538
    Messages:
    23
    Gender:
    Male
    Walnut Creek, Ca.
    Vehicle:
    09 SR5 Access Cab
    First mod-license plate frame reads... "Driver carries no cash-wife shows dogs"
    the company has been around awhile. Bend-Pak is fine for home use but it is not the same as Rotary lift. That's top of the heap stuff. Wiring and stuff comes in to play with a above ground type like these. If you do go this route look at the ones that are asymmetrical. Two of the arms will be long The other two short. This way you will be able to position the vehicle on the lift and still get the doors open without the posts in the way for example. You would be able to roll the vehicle in forwards or backwards to have the best access or even just swap the arms front to back.

    If your intended use is just for futtsing around on the weekends you might want to look at the portable scissors lifts they have on the web site. Portable on wheels with the pump on a roll around cart. When you are done at the end of the day you can roll it over to the wall, lift it up on it's side and lock it down with strong bungies or RokStraps so it won't fall over.

    And yeah every "Man Shack" is not complete until it has a lift of some kind in it.

  8. Apr 24, 2009 at 6:14 PM
    #8
    wildjerseyfirefighter

    wildjerseyfirefighter I sell fishing and fishing accessories

    Joined:
    Dec 17, 2008
    Member:
    #11677
    Messages:
    7,966
    Gender:
    Male
    First Name:
    Joe
    NJ
    Vehicle:
    05 Tacoma TRD Sport
    stock, for now
    what ever you decide for a lift, once you get it installed just wait and see how many "friends" you make..lol
