General Fabrication

Discussion in 'Long Travel Suspension' started by linked2002, Aug 19, 2011.

  1. Aug 19, 2011 at 1:43 PM
    #1
    linked2002

    linked2002 [OP] Well-Known Member

    Joined:
    Aug 17, 2011
    Member:
    #61872
    Messages:
    812
    Gender:
    Male
    san diego
    Vehicle:
    02 tacoma, 3 linked, 6 over custom arms, cage
    links, custom 6 over arms, full 1.75 d.o.m. cage, 35 gallon cell, etc
    ive started this thread after talking it over with a mod about opening a actual all new topic area under the "garage" section. It would be nice for alot of you that have fabrication and design questions to have somewhere to go where experienced fabricators can help you out as best as we can. I (and i hope WE) all know that everyone has to start somewhere and no one is born with the ability to lay perfect welds and fabricate a trophy truck out of the womb. so lets keep this topic fresh and no bullshit. this is a place to ask for help so no flaming people.


    On another note. along with that last sentence you just read, i have to shoot a disclaimer out to all posting here as well. no fabricator is going to give you every measurement and detail you need to design something the way we do. that would then defeat the purpose of us being able to make money off of the skills we have dedicated years to learn. so please dont come in here asking if we can give you every little detail of how to build something. remember.. this is fabrication.. if you have to ask for that much help, whatever your building you probably dont have the complete understanding of how it works and you may potentially seriously harm someone! so remember.... stay within your comfort level and i hope to help give some of you the many experiences i have had through trial and error.

  2. Aug 19, 2011 at 3:44 PM
    #2
    Mxpatriot

    Mxpatriot Busted Knuckles Fabrication

    Joined:
    Nov 18, 2009
    Member:
    #26163
    Messages:
    2,693
    Gender:
    Male
    First Name:
    Chase
    Vehicle:
    '06 4x4 AP LT
    Money pit.
    Good idea. I'm a developing garage fabricator right now. My question is:

    What tool do you find best for cutting large pieces of flat steel (up to 1/4''). Right now I use cut off saw and angle grinder for all my cutting, and it can get tedious. I was looking at larger, metal cutting bandsaws but they are damn expensive; basically in the plasma cutter range.

  3. Aug 19, 2011 at 3:48 PM
    #3
    JLee

    JLee The Man! Vendor

    Joined:
    Jul 20, 2010
    Member:
    #40461
    Messages:
    15,160
    Gender:
    Male
    First Name:
    Jerry
    Bay Area NorCal
    Vehicle:
    02 Extra cab SAS Linked front and rear
    I lost track thousands of dollars ago.
    X2 on the good Idea


    Plasma cutter FTW on plate steel that will be one of my next investments.

  4. Aug 19, 2011 at 3:49 PM
    #4
    Mxpatriot

    Mxpatriot Busted Knuckles Fabrication

    Joined:
    Nov 18, 2009
    Member:
    #26163
    Messages:
    2,693
    Gender:
    Male
    First Name:
    Chase
    Vehicle:
    '06 4x4 AP LT
    Money pit.
    How difficult is it to cut a straight line with a plasma cutter?

  5. Aug 19, 2011 at 3:52 PM
    #5
    JLee

    JLee The Man! Vendor

    Joined:
    Jul 20, 2010
    Member:
    #40461
    Messages:
    15,160
    Gender:
    Male
    First Name:
    Jerry
    Bay Area NorCal
    Vehicle:
    02 Extra cab SAS Linked front and rear
    I lost track thousands of dollars ago.
  6. Aug 19, 2011 at 9:59 PM
    #6
    03aztaco

    03aztaco Well-Known Member

    Joined:
    Dec 14, 2010
    Member:
    #47676
    Messages:
    601
    Gender:
    Male
    First Name:
    adam
    lake havasu,mesa
    Vehicle:
    03 prerunner
    tc lt kit, king shocks, deavers, tc hangers,tc 12" shackels, king double bypasses, cab caged, beefed taco carrier bearing drop bracket, soild motor mounts,some more to lazy haha
  7. Aug 20, 2011 at 7:41 AM
    #7
    linked2002

    linked2002 [OP] Well-Known Member

    Joined:
    Aug 17, 2011
    Member:
    #61872
    Messages:
    812
    Gender:
    Male
    san diego
    Vehicle:
    02 tacoma, 3 linked, 6 over custom arms, cage
    links, custom 6 over arms, full 1.75 d.o.m. cage, 35 gallon cell, etc
    Cutting materials that thick I would have to say either way you will need to be saving for a plasma cutter. I did the cutting with a hand grinder thing for a while and it will get old. Go on your local craigslist and see if anyone has a mid grade plasma for sale. Will speed shit up 20 fold.

  8. Aug 20, 2011 at 9:59 AM
    #8
    Mxpatriot

    Mxpatriot Busted Knuckles Fabrication

    Joined:
    Nov 18, 2009
    Member:
    #26163
    Messages:
    2,693
    Gender:
    Male
    First Name:
    Chase
    Vehicle:
    '06 4x4 AP LT
    Money pit.
    How about tube notching, what's your preferred method? I've been using the chop saw/grinder method and it's tedious.

  9. Aug 20, 2011 at 4:19 PM
    #9
    Joels98taco

    Joels98taco Well-Known Member

    Joined:
    Mar 10, 2011
    Member:
    #52782
    Messages:
    2,337
    Gender:
    Male
    First Name:
    joel
    chino hills
    Vehicle:
    98 5 lug tacoma
    fabtech 3" spindles, icon aal, 10" bilstein 7100 rear shocks, daystar coil spacers, AFE Pro Dry-s drop in filter, sony head unit, 2 12" pioneer subs, pioneer 6.5s all around, custom 1.25 lift shackles, custom lower ball joint brackets fabbed by me
    a fab section would be cool. im trying to find someone local to make me front shock hoops :D

  10. Aug 20, 2011 at 5:21 PM
    #10
    username

    username Fluffer

    Joined:
    Oct 15, 2010
    Member:
    #44704
    Messages:
    4,284
    Pendleton, Or
    Vehicle:
    05 Taco with some crap welded to it
    mostly stock
    I got this from Summit and it just won't die. It has cut thousands of notches, still on the original holesaw. The bearing is getting worn out and it's not as precise as when new, but still works good. Can't beat it for $69.95. http://www.summitracing.com/parts/HCK-SPPIPE/

    [​IMG]

  11. Aug 20, 2011 at 5:27 PM
    #11
    Timicha

    Timicha Timicha

    Joined:
    Dec 23, 2008
    Member:
    #11854
    Messages:
    2,727
    Gender:
    Male
    First Name:
    TIM
    Tillamook / Portland , Oregon
    Vehicle:
    04 White Tacoma
    Fabtech 4 inch lift, tinted windows, diff drop, 33 inch MTZ tires on Raceline Raptor wheels, ELITE OFF-ROAD bumpers and sliders
    i've got a similar one from JD squared and it works Great.

    Good idea with the thread also :thumbsup:

  12. Aug 20, 2011 at 5:38 PM
    #12
    cummins6speed

    cummins6speed Well-Known Member

    Joined:
    Jan 9, 2009
    Member:
    #12426
    Messages:
    1,851
    Gender:
    Male
    Vehicle:
    '05 4Runner Limited Edition
    Custom extended travel 2.5" King RR coilovers, 1.25" Camburg uniball uppers, homebuilt tube bumper
    Oxy/fuel cutting torch if you can't afford a plasma cutter

  13. Aug 20, 2011 at 5:38 PM
    #13
    linked2002

    linked2002 [OP] Well-Known Member

    Joined:
    Aug 17, 2011
    Member:
    #61872
    Messages:
    812
    Gender:
    Male
    san diego
    Vehicle:
    02 tacoma, 3 linked, 6 over custom arms, cage
    links, custom 6 over arms, full 1.75 d.o.m. cage, 35 gallon cell, etc
    Yea I use the pro tools industrial notcher. I love the thing and it usa never served me wrong.

  14. Aug 20, 2011 at 7:36 PM
    #14
    Mxpatriot

    Mxpatriot Busted Knuckles Fabrication

    Joined:
    Nov 18, 2009
    Member:
    #26163
    Messages:
    2,693
    Gender:
    Male
    First Name:
    Chase
    Vehicle:
    '06 4x4 AP LT
    Money pit.
    You guys have got me wanting a plasma cutter bad now. I wanted one before, but I thought they were more expensive and had a steeper learning curve. I've been seeing them on craigslist for $400.

    Think my next truck related purchase will have to be delayed so I can pick up a plasma cutter and tube notcher.

    Username, are you using a woodward tube bender as well? I noticed they were $299 plus $99 for the stand on that link you posted.

  15. Aug 20, 2011 at 8:36 PM
    #15
    username

    username Fluffer

    Joined:
    Oct 15, 2010
    Member:
    #44704
    Messages:
    4,284
    Pendleton, Or
    Vehicle:
    05 Taco with some crap welded to it
    mostly stock
  16. Aug 20, 2011 at 9:48 PM
    #16
    Socalrunner

    Socalrunner Toyota Its Like A Jeep Thing Only Better

    Joined:
    Oct 25, 2010
    Member:
    #45226
    Messages:
    1,979
    Gender:
    Male
    First Name:
    Chris
    Glendora
    Vehicle:
    2010 TRD Offroad 4x4 DCSB
    Icon Coilovers
    ^^^ how did it do bending .120 wall dom?

  17. Aug 20, 2011 at 9:55 PM
    #17
    linked2002

    linked2002 [OP] Well-Known Member

    Joined:
    Aug 17, 2011
    Member:
    #61872
    Messages:
    812
    Gender:
    Male
    san diego
    Vehicle:
    02 tacoma, 3 linked, 6 over custom arms, cage
    links, custom 6 over arms, full 1.75 d.o.m. cage, 35 gallon cell, etc
    Dang I've never seen one of those actually work. I went with the pro tools hydro bender. Thing is Fucking tits and all compressor powered.

  18. Aug 20, 2011 at 10:01 PM
    #18
    username

    username Fluffer

    Joined:
    Oct 15, 2010
    Member:
    #44704
    Messages:
    4,284
    Pendleton, Or
    Vehicle:
    05 Taco with some crap welded to it
    mostly stock
    It works, but it'll make a man out of you. A cromo .120 wall 90* bend will result in muscle failure. The protools hydro is light years ahead of this pos, but the end result is the same. For guys that just do one or two bumpers a month it will get the job done, but if you have the cash get something else. The only cool thing about the affordablebender is that it's portable and doesn't require a stand. I can build a bumper in a the middle of the desert with my readywelder, the bender, and a cordless drill powering the tubing notcher.

  19. Aug 20, 2011 at 10:09 PM
    #19
    mikesdoublecab

    mikesdoublecab LT Chase Truck

    Joined:
    Jun 15, 2008
    Member:
    #7334
    Messages:
    5,974
    Gender:
    Male
    First Name:
    Mohawk Mike
    Glendale, CA
    Vehicle:
    01 Tacoma DoubleCab V6 Prerunner
    Engage Offroad custom LT kit with King coilovers and bypasses, Deaver J59 leaf packs with custom 8 inch shackles and Bilstein 7100 12" travel shocks, 16x8 Eagle Alloy 137s, 285-75-16 BFG KM2s, custom front bumper and skid, Procomp H911 foglights, custom rear bumper and spare tire carrier, bed bar, Engage Offroad custom chase light rack, Icom V8000 radio
    hit up Chris, aka Tacorunner87 here on TW... he is in your neck of the woods...

  20. Aug 20, 2011 at 11:16 PM
    #20
    Joels98taco

    Joels98taco Well-Known Member

    Joined:
    Mar 10, 2011
    Member:
    #52782
    Messages:
    2,337
    Gender:
    Male
    First Name:
    joel
    chino hills
    Vehicle:
    98 5 lug tacoma
    fabtech 3" spindles, icon aal, 10" bilstein 7100 rear shocks, daystar coil spacers, AFE Pro Dry-s drop in filter, sony head unit, 2 12" pioneer subs, pioneer 6.5s all around, custom 1.25 lift shackles, custom lower ball joint brackets fabbed by me
    ohh yeahhh haha forgot about chris. we could probably do it when we do my rear shock mounts :rolleyes: i have a picture of your truck on mine...:anonymous: :D

    [​IMG]
