Hit a pothole and my dash stopped working

Discussion in '1st Gen. Tacomas (1995-2004)' started by SkeetFighter, Jun 9, 2022.

  1. Jun 9, 2022 at 7:59 PM
    #1
    SkeetFighter

    SkeetFighter [OP] Condad

    Joined:
    Sep 18, 2021
    Member:
    #377463
    Messages:
    105
    Gender:
    Male
    First Name:
    Conrad
    Austin Texas
    Vehicle:
    2000 Blue Metallic Tacoma TRD / 2001 Black Tacoma TRD
    Howdy y'all I was dropping a buddy off at his apartment and while driving home I hit a pothole and then my tachometer stopped working. Seconds later my speedometer stopped working, then my odometer, then my gas gauge. I pulled over and turned the truck off a few minutes while I inspected the truck and continued my blind drive home. The gas gauge began working again but none of the other dash components still work.

    It's most likely a fuse or wire connection broke but I'm not sure where to begin. Has this happened to anybody before?

  2. Jun 9, 2022 at 8:11 PM
    #2
    Bivouac

    Bivouac Well-Known Member

    Joined:
    Sep 5, 2021
    Member:
    #376253
    Messages:
    11,580
    Northern Lehigh Valley Pa
    Vehicle:
    2000 Tacoma 5 speed 3.4
    Remains to be seen I bought the tires and wheels the rest came along
    Check your gauge fuse !

    If not that break out the Meter loose connection or broken wire causing a open circuit some place.

    Might be a Circuit Ground.

  3. Jun 9, 2022 at 8:32 PM
    #3
    ColoradoTJ

    ColoradoTJ Retired cat herder Moderator

    Joined:
    Sep 3, 2018
    Member:
    #265097
    Messages:
    10,170
    Gender:
    Male
    First Name:
    Chris
    Colorado
    Vehicle:
    3500 Duramax, Roush Mustang, Jeep Crawler
    Damn….was it like this?


    Wulf, Kolter45 and SkeetFighter[OP] like this.
  4. Jun 9, 2022 at 9:44 PM
    #4
    Diablo169

    Diablo169 ROKRAPR

    Joined:
    Mar 12, 2016
    Member:
    #181079
    Messages:
    2,908
    Gender:
    Male
    First Name:
    Max
    Santa Cruz, CA
    Vehicle:
    99’ Bro-Coma’s Revenge 3RZ 345k+
    Stock
    Make a fist and smash the dash. It’s works every time on my 88’ Runner.

  5. Jun 10, 2022 at 7:15 AM
    #5
    MalinoisDad

    MalinoisDad Misanthropic dog person

    Joined:
    Jul 16, 2017
    Member:
    #224205
    Messages:
    1,481
    Gender:
    Male
    First Name:
    Michael
    Vehicle:
    01 TRD PreRunner 5VZ
    5100s w/ 881s, JBA UCAs, J59s, other stuff and things
    Sounds like a loose ground wire to me. Check all of them, as well as battery cable connections.

    SkeetFighter[OP] likes this.
  6. Jun 10, 2022 at 9:26 AM
    #6
    jbrandt

    jbrandt Made you look

    Joined:
    Feb 12, 2011
    Member:
    #51038
    Messages:
    17,612
    Gender:
    Male
    First Name:
    Justin
    El Dorado, CA (NOT El Dorado Hills)
    Vehicle:
    '04 TRD Tacoma 4x4 DC
    Kings, J59's Total Chaos UCAs Custom skids Sticker mod
    Fuses don't magically repair themselves, so the fact that your gas gauge came back, tells me it's not a fuse.

    As others said, likely a ground, or a loose connection on the back of the dash. I see pulling the dash apart in your near future.

  7. Jun 10, 2022 at 9:47 AM
    #7
    SkeetFighter

    SkeetFighter [OP] Condad

    Joined:
    Sep 18, 2021
    Member:
    #377463
    Messages:
    105
    Gender:
    Male
    First Name:
    Conrad
    Austin Texas
    Vehicle:
    2000 Blue Metallic Tacoma TRD / 2001 Black Tacoma TRD
    Thanks man! I'm about to go out there and give it a try. Good advice!

  8. Jun 10, 2022 at 9:48 AM
    #8
    SkeetFighter

    SkeetFighter [OP] Condad

    Joined:
    Sep 18, 2021
    Member:
    #377463
    Messages:
    105
    Gender:
    Male
    First Name:
    Conrad
    Austin Texas
    Vehicle:
    2000 Blue Metallic Tacoma TRD / 2001 Black Tacoma TRD
    Lmaooo basically XD it was a massive pothole under an underpass. I could have sworn my taco has hit bigger bumpers harder LOL

    ColoradoTJ[QUOTED] likes this.
  9. Jun 10, 2022 at 9:48 AM
    #9
    SkeetFighter

    SkeetFighter [OP] Condad

    Joined:
    Sep 18, 2021
    Member:
    #377463
    Messages:
    105
    Gender:
    Male
    First Name:
    Conrad
    Austin Texas
    Vehicle:
    2000 Blue Metallic Tacoma TRD / 2001 Black Tacoma TRD
    Lol my first step while driving while it went out was to give it a good wack but didnt help

  10. Jun 10, 2022 at 2:37 PM
    #10
    Bivouac

    Bivouac Well-Known Member

    Joined:
    Sep 5, 2021
    Member:
    #376253
    Messages:
    11,580
    Northern Lehigh Valley Pa
    Vehicle:
    2000 Tacoma 5 speed 3.4
    Remains to be seen I bought the tires and wheels the rest came along
    The broken hand and the 2 weeks unable to work was a very expensive lesson.

    About $3000.00

  11. Jun 11, 2022 at 8:13 PM
    #11
    SkeetFighter

    SkeetFighter [OP] Condad

    Joined:
    Sep 18, 2021
    Member:
    #377463
    Messages:
    105
    Gender:
    Male
    First Name:
    Conrad
    Austin Texas
    Vehicle:
    2000 Blue Metallic Tacoma TRD / 2001 Black Tacoma TRD
    I checked all the fuses I could and nothing is blown. The gas gauge definitely doesn’t work anymore , I turned it on and it says I got a full tank when I know it’s empty. In the morning I’m pulling the dash before the sun gets too hot

    Wulf likes this.
  12. Jun 11, 2022 at 8:36 PM
    #12
    Bivouac

    Bivouac Well-Known Member

    Joined:
    Sep 5, 2021
    Member:
    #376253
    Messages:
    11,580
    Northern Lehigh Valley Pa
    Vehicle:
    2000 Tacoma 5 speed 3.4
    Remains to be seen I bought the tires and wheels the rest came along
    Good Luck You could trouble shoot things without pulling the dash apart till you narrow things down more.

    It is only the Tach and Speedometer and Fuel gauge. or the whole cluster ? Do the lights on the Cluster still work??

    Check the Ground behind the left kick panel.

    SkeetFighter[OP] likes this.
  13. Jun 11, 2022 at 8:38 PM
    #13
    SkeetFighter

    SkeetFighter [OP] Condad

    Joined:
    Sep 18, 2021
    Member:
    #377463
    Messages:
    105
    Gender:
    Male
    First Name:
    Conrad
    Austin Texas
    Vehicle:
    2000 Blue Metallic Tacoma TRD / 2001 Black Tacoma TRD
    So the tach, speedometer, odometer do not work. The fuel gauge says my tank is overflowing lol. My dash is all lit up from lights and my temperature gauge works too. I checked the fuses but I didn't test any wires yet. I got an electrician friend coming tomorrow afternoon with a multimeter to try and help me figure out the problem.

    Good cal about the ground, ill do some more reading and looking at images and ill test that! :)

  14. Jun 11, 2022 at 8:54 PM
    #14
    Bivouac

    Bivouac Well-Known Member

    Joined:
    Sep 5, 2021
    Member:
    #376253
    Messages:
    11,580
    Northern Lehigh Valley Pa
    Vehicle:
    2000 Tacoma 5 speed 3.4
    Remains to be seen I bought the tires and wheels the rest came along
    i have fixed many electrical problems other then changing bulbs most times it is a waste of time pulling the cluster out .

    Check the speed sensor on the case to see if that has not come apart or been damaged .

    Did you hit the front or rear ?

    The impact may have jarred the float enough it hung up or moved showing full tank.

    The tach signal comes from the igniter Power Source is The Dome light fuse.

    Hope that helps

  15. Jun 11, 2022 at 9:01 PM
    #15
    Scotfree

    Scotfree I drive slow

    Joined:
    Aug 17, 2021
    Member:
    #374496
    Messages:
    1,697
    Gender:
    Male
    Vehicle:
    2021 sr 4x4 2.7
    Haven’t had this exact thing happen, but did hit a bad bump that popped both my headlights.. check your fuses and your negative battery cable not at the battery but the cable wire itself.

    SkeetFighter[OP] likes this.
  16. Jun 11, 2022 at 9:52 PM
    #16
    MalinoisDad

    MalinoisDad Misanthropic dog person

    Joined:
    Jul 16, 2017
    Member:
    #224205
    Messages:
    1,481
    Gender:
    Male
    First Name:
    Michael
    Vehicle:
    01 TRD PreRunner 5VZ
    5100s w/ 881s, JBA UCAs, J59s, other stuff and things
    A hard bump setting this off really sounds like a loose ground somewhere to me. Practically the same thing happened to a guy on here months ago and his truck died all together until he found the loose wire.

  17. Jul 18, 2022 at 8:18 AM
    #17
    curth0man

    curth0man Well-Known Member

    Joined:
    Oct 28, 2018
    Member:
    #270835
    Messages:
    56
    First Name:
    Curt
    Vehicle:
    2001 Toyota Tacoma SR5 4x4
    Run over an even bigger pot hole and see if it fixes it!

    Scotfree and MalinoisDad like this.
  18. Jul 18, 2022 at 10:05 AM
    #18
    MalinoisDad

    MalinoisDad Misanthropic dog person

    Joined:
    Jul 16, 2017
    Member:
    #224205
    Messages:
    1,481
    Gender:
    Male
    First Name:
    Michael
    Vehicle:
    01 TRD PreRunner 5VZ
    5100s w/ 881s, JBA UCAs, J59s, other stuff and things
    Reminds me of this:


    Wulf likes this.
  19. Jul 18, 2022 at 1:56 PM
    #19
    Tbrad7128

    Tbrad7128 Well-Known Member

    Joined:
    Jun 18, 2022
    Member:
    #399663
    Messages:
    95
    Gender:
    Male
    First Name:
    Tyler
    Boerne Texas
    Vehicle:
    2003 Tacoma 3.4 v6 TRD double cab 4x4 elock
    That's a tough one. Sorry to hear your trouble. I did just have to replace my cluster because of a short somewhere. Lost the gauges when I was replacing light bulbs in the cluster. I had to buy a replacement cluster and it has been working fine. There is something back there that is very sensitive. I chased all the wires with a voltmeter and it didn't get me anywhere.

    i will say that i did blow the gauge fuse the first time. I replaced it and did the same thing again. except this time something else shorted in the cluster.

    I have a local automotive electrician that helped me (in San Antonio, TX). If you need cluster work, he is the guy.
