Horn no longer works

Discussion in '2nd Gen. Tacomas (2005-2015)' started by Amanwithnoplan, Dec 11, 2021.

  1. Dec 11, 2021 at 9:35 PM
    #1
    Amanwithnoplan

    Amanwithnoplan [OP] Member

    Joined:
    Jul 22, 2021
    Member:
    #371949
    Messages:
    10
    Gender:
    Male
    First Name:
    Sievrrhyn
    Vehicle:
    2015 Black Tacoma TRD Pro
    I noticed around Thanksgiving that the horn on my 2015 no longer works after someone almost hit me on the freeway. I have looked into the issue and my guess is a bad clock spring. Is replacing a clock spring terribly difficult? I have only ever changed oil and breaks, never anything else.

  2. Dec 11, 2021 at 9:41 PM
    #2
    stickyTaco

    stickyTaco Fuck Cancer

    Joined:
    Dec 11, 2012
    Member:
    #92904
    Messages:
    5,939
    Gender:
    Male
    First Name:
    Zack
    Reno/Tahoe
    Vehicle:
    '12 DCSB TRD-OR
    Fox/Dakar with Relentless goodies and stuff
    It is pretty straight forward. I had mine replaced in about the same amount of time it takes to change the oil. I found a YouTube video that covered the repair.

    Easy way to confirm is to see if the horn beeps when you press the panic button with the keyfob. If it does, follow the video linked in this post for troubleshooting: https://www.tacomaworld.com/threads/horn-not-working.731618/#post-26061733

    Last edited: Dec 11, 2021
  3. Dec 11, 2021 at 10:23 PM
    #3
    davidstacoma

    davidstacoma Friendly Curmudgeon

    Joined:
    Nov 2, 2019
    Member:
    #309695
    Messages:
    4,655
    Gender:
    Male
    First Name:
    David
    NC
    Vehicle:
    2019 Tacoma SR Access cab - Utility
    *OEM Mods: Intermittent wipers, Fogs, Keyless Entry, Lomax
    Have you checked the fuse and the relay for the horn? I would do that before replacing the clock spring if you haven’t already.

  4. Dec 13, 2021 at 3:52 AM
    #4
    AwArD

    AwArD Well-Known Member

    Joined:
    May 3, 2021
    Member:
    #364640
    Messages:
    147
    Gender:
    Male
    Vehicle:
    2012 Tacoma Trail Teams TRD sport Double Cab V6 4.0
    Icon Rxt rear leaf option 2 Elka 2.5 DC Reservoir Front/Rear with 600lbs/14inch coil JBA Offroad STD high caster UCA Whiteline LCA inner bushing Mevotech TTX LCA Ball joint Woodward U-Joints Intermidate steering shaft mod Uni filter mod TRD Cat-Back Exhaust Timbren Active Off-Road Bumpstops Front/Rear Overland Torque Tune (OTT) by Yotatune Amsoil signature engine/transmission Amsoil SEVERE GEAR 80W-90 Front/rear diff and T-case Tacoma bed mat Weathertech mat front and rear cabin Summer BFG Ko2 265/65r17 E rated / Fuel Rebel 6 Bronze wheels Winter Nokian Hakkapeliitta 10 studded, 265/65r17 / oem Toyota wheels
    Very easy to replace the clock spring.

    You can short the relay in the fuse box under the hood, if it honk it's not the horn, after that you can do a continuity test from the relay to the steering, open the little door with the screw under the lever for the turn signal on your steering and you will see a black wire plugged with a tab in the middle. Take some long nose and tap your alligator clip and see the resistance. If it's under 1 ohm from the relay to the steering the problem is 99.999% the clock spring.

    Torque for the steering nut is 37 lb/ft if i remember right. Don't forget to mark the center it's easy to misalign the steering wheel.

    this dude know is shit https://youtu.be/VblczY9PzMc

    I did mine 2 month ago with a cheap Amazon clockspring @ 45$ cad shipped. Still work, took 30 minutes


    PS: If you go with the cheap clock spring, check every connector pin in the housing, if one is missaligned, you will bend it and it's no go, the connector under take some force to remove and to reconnect, take it easy and bring a mirror or your cellphone to see how thing are placed when you remove/replace each part.

    Marc70 likes this.
  5. Dec 13, 2021 at 4:47 AM
    #5
    fixnfly

    fixnfly Well-Known Member

    Joined:
    Oct 1, 2011
    Member:
    #64450
    Messages:
    751
    Gender:
    Male
    First Name:
    Mike
    S.W.PA
    Vehicle:
    05 Access cab 4.0 4WD
