How to add factory DTRL

Discussion in '2nd Gen. Tacomas (2005-2015)' started by toku58, Jun 9, 2009.

  1. Jun 9, 2009 at 11:06 PM
    #1
    toku58

    toku58 [OP] Well-Known Member

    Joined:
    Oct 10, 2008
    Member:
    #9882
    Messages:
    1,026
    Gender:
    Male
    HAWAII
    Vehicle:
    4x4 Beast!
    6" Fabtech Stage II, 17x9" Centerline Eclipse rims, with 12.5x35x17" BFG KM2's. On board air system,Toyota skid plate, spidertrax wheel spacers, TRD CAI w/AFE ProDry filter (21-90045),Flowmaster Dual exhaust, GrillCraft grill w/custom emblem, Custom Shifter, BushWacker fender flares, Hood struts, Underhood lights, TW driveshaft, Wet Okole seat covers, Dashlight mod, Many other little things to make the truck complete!
    Here is a DIY for the installation of the factory DTRL.
    Part # 82241-04030 and # 81980-35020 Relay and jumper. You can order it from here: http://www.trdparts4u.com/oem_parts.html


    Here are the tool I used.
    [​IMG]

    start by removing the rocker panel cover. Just pull up it is held on with clips.
    [​IMG]

    Then remove the Foot pad; this is also held by clips; just pull:
    [​IMG]

    There is a small plastic nut which needs to be removed:
    [​IMG]

    Remove the kick panel by pulling it towards the back it is held on by 2 clips.
    [​IMG]

    Then remove the 2-10 mm. bolts from the lower panel. Then pull out the little storage tray on the right side. (Just pull straight back) It is held on with clips.
    [​IMG]

    Then pull the lower panel out. It is held on with the 2-10mm bolts (Which you removed in the previous step) and 3 clips which can be seen in the photo. Remember to remove the wire harnesses and the hood release.
    [​IMG]

    Now remove the 3-10mm bolts that hold on the fuse box. Remove any wire harnesses that impede you from pulling the fuse box out. For me it was the 3 on the front left & one on the rear top portion. Use a needle nose to remove the clip without damage.
    [​IMG]

    Now tilt the fuse box outwards and you will see the original relay. A square Tan relay.
    [​IMG]

    Remove that and the gray plug that is located at the bottom of the rear of the fuse block. Below the flasher relay.
    [​IMG]

    SORRY! The picture below is kind of confusing because the gray Jumper plug is already in the slot for the flasher!
    [​IMG]

    Here is a picture of the 2 parts that you need to remove.
    [​IMG]

    Now you need to assemble the new jumper and the new relay.
    [​IMG]

    [​IMG]

    Now plug the gray end of the jumper into the slot where the old relay was located and the white plug into the slot where the gray blank plug was located. (This is how it should look when your done)
    [​IMG]

    Now clip the new relay on to the holder which is located on the side of the fuse block near the steering:
    [​IMG]

    And secure the wire with the clip that came on the jumper to the hole located on the back of the fuse block.
    [​IMG]
    When you are done it should look like it came from the factory that way.

    Now simply revers the process to put your panels back together and you are done!! DTRL work exactly like the factory install!!
    If you have any questions please fell free to ask!!
    Good luck!!

    O.K. Remember that when you test it out, and turn your truck on? You need to release the parking brake for it to come on!
