Icon rxt leaf pack

Discussion in '3rd Gen. Tacomas (2016+)' started by blackohio, Aug 12, 2017.

  1. Aug 18, 2020 at 6:42 AM
    #581
    MGMStudioTaco

    MGMStudioTaco Member

    Joined:
    May 2, 2019
    Member:
    #292061
    Messages:
    352
    First Name:
    Trey
    Charlotte, NC
    Vehicle:
    2018 MGM Tacoma Limited 4x4
    Grande Tires W/Kings
    Bushing are squeaking on my RXT's on option 2 anyone found a solution to this?

  2. Sep 2, 2020 at 7:19 AM
    #582
    chuymoreno

    chuymoreno Well-Known Member

    Joined:
    Nov 22, 2016
    Member:
    #203101
    Messages:
    221
    Gender:
    Male
    El Paso, Texas
    Vehicle:
    Tacoma SR5
    Hello everyone
    I’m currently on option 1.
    I’m planning going on a trip in one week so trying to decide if I should go to option 2.
    I think that with the camping equipment and coolers I’m going to carry about 150-250LBs and I was wondering if the best option was to go to option #2. I wont be doing any off-Roading just your normal fire roads to get to the campsites.

    If I do need to make the change, do I have to take the leaf springs off the truck ? or can i do it with the help of the C clamp while they are still on the truck?

    thanks

  3. Sep 2, 2020 at 7:40 AM
    #583
    Shellshock

    Shellshock King Shit of Turd Island

    Joined:
    Nov 21, 2015
    Member:
    #170338
    Messages:
    13,276
    Iowa
    Vehicle:
    2017 DCSB TRD OR MT QUICKSAND
    You’d be fine staying on option 1.

    you might be able to do it on the truck, but I’d just take it off.

    chuymoreno, Island Cruiser and SR-71A like this.
  4. Sep 2, 2020 at 9:44 AM
    #584
    cdex8357

    cdex8357 HE>i

    Joined:
    Apr 7, 2018
    Member:
    #249677
    Messages:
    495
    Gender:
    Male
    First Name:
    charles
    Vehicle:
    2013 tacoma
    FOX 2.5 Coilovers
    you dont have to completely remove the leaf spring. just have come C clamps, loosen the u bolts and remove those "chingaderas" at the ends. slide out the one leaf and replace it with Opt 2 spring. took me about an hour.

    probably a good time to lube them and install the leaf liners. these things are like a dogs chew toy, squeeky AF.

    chuymoreno likes this.
  5. Sep 2, 2020 at 9:47 AM
    #585
    Shellshock

    Shellshock King Shit of Turd Island

    Joined:
    Nov 21, 2015
    Member:
    #170338
    Messages:
    13,276
    Iowa
    Vehicle:
    2017 DCSB TRD OR MT QUICKSAND
    Mine are fairly quiet. They will get a little squeaky from time to time if they get full of dirt but usually after a wash they are fine.

    SR-71A likes this.
  6. Sep 2, 2020 at 9:51 AM
    #586
    cdex8357

    cdex8357 HE>i

    Joined:
    Apr 7, 2018
    Member:
    #249677
    Messages:
    495
    Gender:
    Male
    First Name:
    charles
    Vehicle:
    2013 tacoma
    FOX 2.5 Coilovers
    im in houston, the humidity and moisture is a killer.. like living in an arm pit

    Island Cruiser likes this.
  7. Sep 2, 2020 at 10:46 AM
    #587
    Island Cruiser

    Island Cruiser TVita

    Joined:
    May 20, 2012
    Member:
    #79166
    Messages:
    3,166
    Gender:
    Male
    Kauai
    Vehicle:
    Baja
    Lather some deodorant in between the leafs lol

    BRFAb and cdex8357 like this.
  8. Sep 2, 2020 at 11:07 AM
    #588
    ramonortiz55

    ramonortiz55 Not A Well-Known Member

    Joined:
    Nov 28, 2012
    Member:
    #92013
    Messages:
    33,878
    Gender:
    Male
    First Name:
    Ramon
    Texas
    Vehicle:
    2015 DCSB Offroad 4x4
    stock
    quoted for chingaderas.


    Does it matter which leaf gets slid out and replaced?
    Also, what do I do with the C Clamps?

    chuymoreno likes this.
  9. Sep 2, 2020 at 11:11 AM
    #589
    ramonortiz55

    ramonortiz55 Not A Well-Known Member

    Joined:
    Nov 28, 2012
    Member:
    #92013
    Messages:
    33,878
    Gender:
    Male
    First Name:
    Ramon
    Texas
    Vehicle:
    2015 DCSB Offroad 4x4
    stock
  10. Sep 2, 2020 at 11:20 AM
    #590
    cdex8357

    cdex8357 HE>i

    Joined:
    Apr 7, 2018
    Member:
    #249677
    Messages:
    495
    Gender:
    Male
    First Name:
    charles
    Vehicle:
    2013 tacoma
    FOX 2.5 Coilovers


    I c clamped them to keep them together when I removed the center Bolt on the leaf pack.. then exchanged the leafs and aligned them up and c clammed them. Put Center bolt back and chingaderas. Jacked the axle up to the leaf and installed u bolts

    PB FAB and Island Cruiser like this.
  11. Sep 7, 2020 at 8:38 PM
    #591
    Tacompa

    Tacompa Well-Known Member

    Joined:
    Mar 10, 2019
    Member:
    #286094
    Messages:
    109
    Gender:
    Male
    San Jose, CA
    Vehicle:
    2019 Toyota Tacoma OR DCSB 4x4
    Hey everyone! I just installed the Icon RXT leaf pack. I'm currently running option 2 with tundra fox 2.5 with dsc and I'm getting 24.75" center hub to fender. My truck is stock. This is about 2.75" of lift in the rear. I was expecting 2.25" as per Icon documentation. Is this normal?

  12. Sep 7, 2020 at 9:27 PM
    #592
    Island Cruiser

    Island Cruiser TVita

    Joined:
    May 20, 2012
    Member:
    #79166
    Messages:
    3,166
    Gender:
    Male
    Kauai
    Vehicle:
    Baja
    It will settle over time. I think mine on Option 1 settled about half an inch

    Tacompa likes this.
  13. Sep 7, 2020 at 10:25 PM
    #593
    Tacompa

    Tacompa Well-Known Member

    Joined:
    Mar 10, 2019
    Member:
    #286094
    Messages:
    109
    Gender:
    Male
    San Jose, CA
    Vehicle:
    2019 Toyota Tacoma OR DCSB 4x4
    @Island Cruiser I think I'm going to tow my dump trailer around to help it settle.

    Island Cruiser likes this.
  14. Sep 16, 2020 at 4:31 PM
    #594
    Tacompa

    Tacompa Well-Known Member

    Joined:
    Mar 10, 2019
    Member:
    #286094
    Messages:
    109
    Gender:
    Male
    San Jose, CA
    Vehicle:
    2019 Toyota Tacoma OR DCSB 4x4
  15. Sep 16, 2020 at 5:58 PM
    #595
    Island Cruiser

    Island Cruiser TVita

    Joined:
    May 20, 2012
    Member:
    #79166
    Messages:
    3,166
    Gender:
    Male
    Kauai
    Vehicle:
    Baja
    From center of hub to bottom of fender:
    Driver’s side: 23 3/4”
    Passenger’s side: 24 1/4”

    I wish I jotted down if I had a full tank of gas in my notes, but it was definitely at least a half tank of gas

    Tacompa likes this.
  16. Sep 16, 2020 at 7:32 PM
    #596
    BRFAb

    BRFAb Well-Known Member

    Joined:
    Sep 24, 2018
    Member:
    #267226
    Messages:
    103
    Gender:
    Male
    BC
    Vehicle:
    '19 Alien Grey TRD OR
    I have used these at all 3 levels for one reason or another.
    Started with no weight on level 1. Changed to 3 when we thought we were going to get a slide in camper, which didn't work out. Settled on 2 since we have about 300-400# of bumper, winch and armor with a Rtt and gear when we can.
    They all ride nicely, almost soft and supple while over all fairly similar from the seat. The height though is not similar at all. 3 with no weight in the back is up there stink bug style.
    It's a nice set of leafs with choices.
    What more could one ask for?

    Tacompa and Nomad26 like this.
  17. Sep 17, 2020 at 11:55 PM
    #597
    Tacompa

    Tacompa Well-Known Member

    Joined:
    Mar 10, 2019
    Member:
    #286094
    Messages:
    109
    Gender:
    Male
    San Jose, CA
    Vehicle:
    2019 Toyota Tacoma OR DCSB 4x4
    @Island Cruiser thanks for sharing.

    I'm currently running option two with no extra weight (and Tundra Fox 2.5 w/ DSC). I have hub to fender measurements in the rear of 25" driver and 24.75" passenger. I still have to fine tune the front. I'm considering going to option #1. Based on your response, I should still be able to get ~2" lift in the rear on option #1. I'm so thinking if won't be as stiff.

    What are your thoughts?

    Island Cruiser likes this.
  18. Sep 18, 2020 at 12:11 AM
    #598
    Tacompa

    Tacompa Well-Known Member

    Joined:
    Mar 10, 2019
    Member:
    #286094
    Messages:
    109
    Gender:
    Male
    San Jose, CA
    Vehicle:
    2019 Toyota Tacoma OR DCSB 4x4
    @BRFAb the only thing I would ask for; is that I knew exactly what I wanted and to have beforehand experience with this leaf pack. I'm new to lifted trucks. It's a learning experience and l'll have to make adjustments as I go until I am satisfied with the results.

    Last edited: Sep 18, 2020
  19. Sep 18, 2020 at 1:12 AM
    #599
    Island Cruiser

    Island Cruiser TVita

    Joined:
    May 20, 2012
    Member:
    #79166
    Messages:
    3,166
    Gender:
    Male
    Kauai
    Vehicle:
    Baja
    That’s good to know, I’ve always wondered what Option 2 would be like without extra weight in the back. I’d say move down to Option 1 as long as you know for sure you won’t be adding substantial weight. I have loaded some power equipment, toolbox and etc. with this option and didn’t notice much of sag. It did soften up the ride as expected. What are your measurements up front?

  20. Sep 18, 2020 at 10:04 AM
    #600
    Tacompa

    Tacompa Well-Known Member

    Joined:
    Mar 10, 2019
    Member:
    #286094
    Messages:
    109
    Gender:
    Male
    San Jose, CA
    Vehicle:
    2019 Toyota Tacoma OR DCSB 4x4
    I don't think my leaf pack has settled yet. It still much higher than I expected.

    Fronts are 23.5" driver side and 23.75" passenger side. I'm bringing that down <= 23" as soon as I get some time. I figure this is also adding to the rear height. The good news is I WFH so its not a DD. I'm starting to realize that the best ride quality will not be a 3/2 lift. I have to find the balance between max lift height and ride quality. I foolishly thought I could get both.

    Last edited: Sep 18, 2020
    Island Cruiser likes this.
