Icon Stage 4 Install Detailed Instructions

Discussion in 'Suspension' started by DrSpaceman, Jan 2, 2012.

  1. Jun 25, 2015 at 10:55 AM
    #101
    RogueTRD

    RogueTRD Learn to swim...

    Joined:
    Aug 11, 2011
    Member:
    #61546
    Messages:
    2,681
    Gender:
    Male
    First Name:
    Cade
    So. Oregon
    Vehicle:
    Supercharged '14 Pyrite Mica DCSB 4x4 TRD OR
    Stacked spacer lift, 22x12 wheels with stretched 33's, tow mirrors, bull nuts.
    Great write up!

  2. Dec 26, 2015 at 8:53 PM
    #102
    Jonas111

    Jonas111 Well-Known Member

    Joined:
    Nov 4, 2015
    Member:
    #168624
    Messages:
    92
    Gender:
    Male
    Kelowna, BC, Canada
    I have a quick question and sorry in advance if it's a stupid question.

    Do I need to disconnect the tie rod or ball joint to change the coil over?

    I purchased some Icon Coil overs and my truck has light racing UCA's installed already.

    Thanks in advance.

  3. Dec 27, 2015 at 6:47 AM
    #103
    Erik65

    Erik65 Dog slave

    Joined:
    Jun 13, 2011
    Member:
    #58228
    Messages:
    3,423
    Gender:
    Male
    First Name:
    Erik
    Oxford, MA
    Vehicle:
    2011 Timberland Mica TX Pro DC
    Stainless exhaust, 16" TRD wheels, 285x75x16 MTR Kevlars, Icon Stage IV, Icon Secondary shock hoop with adjustable remote reservoir bypass shocks, ATO shackle flip kit, AP U-bolt flip, AP Skids (IFS, transmission, T-case, diff cover)
    It will make your job a lot easier if you do...

    samsung likes this.
  4. Dec 27, 2015 at 7:10 AM
    #104
    samsung

    samsung Well-Known Member

    Joined:
    Jan 2, 2011
    Member:
    #48601
    Messages:
    1,145
    Gender:
    Male
    First Name:
    George
    Sugar Land, Texas
    Vehicle:
    2011 PreRunner doublecab TRD Offroad
    undercover lid/Ipod integration kit/Pop n lock/bed rug, fumoto drain valve, full piping Wet Okole covers, Blacked out badges, Lamin-X fog light cover yellow, window tint, ARB deluxe bumper with fog light kit,DSM UCA'S,3 support shrockworks sliders,complete OME lift with 886X coil and dakar leaf spring with 3 degree axle shims and center pin lenghtener,warn VR10000 winch,amsteele blue synthetic rope, daystar winch isolator, daystar delrin rollers, IPF 900xs Extreme Driving H9 Kit 900XSD (900XSD),Horn on fire with shot Penning,
    i don't know why you have to disconnect the tie rod. Icon's instruction tells you to disconnect the tie rod as well. i just did an icon stage 5 on my runner basically was the same set up i was even able to reuse my dessert uca's from my 2011 tacoma on the 4 runner, just did a uca refurb with new bushings and uniball. and did not have to remove the tie rod. I can only guess that'll make it easier to take the coil over out. i was able to just get it on the right angle and move the coil over out of the housing. i also had my factory uca's out before i took out the coil over.

  5. Jan 3, 2016 at 7:13 PM
    #105
    Miyagi

    Miyagi Well-Known Member

    Joined:
    Apr 29, 2015
    Member:
    #154225
    Messages:
    78
    Gender:
    Male
    Honolulu, HI
    Vehicle:
    '15 SW DCSB SR 4WD
    ICON non-resi ext trav coilovers, LR UCA's, ICON vs 2.0 rear shocks, ICON AAL
    Getting Icon 58635 ext. travel non-res coilovers put on my truck next weekend. It's a 2015 DCSB SR 4x4. What amount of lift are those coilovers pre-set to from Icon? Is it 2" or 2.5"?

  6. Jan 17, 2016 at 11:55 AM
    #106
    Erik65

    Erik65 Dog slave

    Joined:
    Jun 13, 2011
    Member:
    #58228
    Messages:
    3,423
    Gender:
    Male
    First Name:
    Erik
    Oxford, MA
    Vehicle:
    2011 Timberland Mica TX Pro DC
    Stainless exhaust, 16" TRD wheels, 285x75x16 MTR Kevlars, Icon Stage IV, Icon Secondary shock hoop with adjustable remote reservoir bypass shocks, ATO shackle flip kit, AP U-bolt flip, AP Skids (IFS, transmission, T-case, diff cover)
    What you net for lift depends on what you got going on with your rig--is it stock or have you added upgraded skids and a bumper? Straight stock will likely net you between 2 and 2.5 and naturally you can go from there using your spanner wrench. Icon specifies you maintain at least 1" difference between the fully loaded hub-to-fender measurement and the full droop hub to fender measurement to ensure optimal downtravel and ride quality

  7. Jan 17, 2016 at 1:43 PM
    #107
    Miyagi

    Miyagi Well-Known Member

    Joined:
    Apr 29, 2015
    Member:
    #154225
    Messages:
    78
    Gender:
    Male
    Honolulu, HI
    Vehicle:
    '15 SW DCSB SR 4WD
    ICON non-resi ext trav coilovers, LR UCA's, ICON vs 2.0 rear shocks, ICON AAL
  8. Feb 3, 2016 at 6:29 AM
    #108
    jtweezy

    jtweezy Well-Known Member

    Joined:
    Feb 9, 2014
    Member:
    #122631
    Messages:
    1,218
    Gender:
    Male
    Austin
    Vehicle:
    2014 4X4 DCSB OR V6
    Depending on the overall diameter of the new coilover assembly, maneuvering it out between the CV axle, tie rod and LCA can be very difficult. I found that pushing the spindle towards the front of the truck gives you more room, but it's still a squeeze. OP was doing this as a one-man job, so I can definitely see the benefit of disconnecting the TRE.

  9. Oct 17, 2016 at 12:28 PM
    #109
    farnorth01

    farnorth01 Member

    Joined:
    Oct 3, 2016
    Member:
    #198884
    Messages:
    19
    Gender:
    Male
    First Name:
    Ben
    British Columbia
    Vehicle:
    2011 SR5 4x4 ACLB
    Icon Stage 1, Dakars, Duratracs
    Does anyone know what size the 12pt cap bolt is for the UCA?

  10. Nov 29, 2016 at 9:03 AM
    #110
    Shikokaon

    Shikokaon Slacker Extraordinaire

    Joined:
    Oct 20, 2016
    Member:
    #200256
    Messages:
    157
    Gender:
    Male
    Portland, OR
    Vehicle:
    2017 Tacoma D-Cab Off Road (MT)
    Awesome write-up. Video made it much easier (unfortunately they used the "easy" side when it comes to the UCA bolt). Still a bit apprehensive about the UCA bolts issue... The whole bending/cutting the sheet metal to take them out in one piece makes me cringe...

    Thinking about just cutting them and replacing them with new ones, but I wonder if putting them in backwards has any side effects (vibrations loosening nut and bolt sliding down)... Or maybe I'm just worrying for no reason...

    Anyone that put them backwards use anything else on the nut end to secure it a bit more???

  11. Nov 29, 2016 at 12:48 PM
    #111
    jtweezy

    jtweezy Well-Known Member

    Joined:
    Feb 9, 2014
    Member:
    #122631
    Messages:
    1,218
    Gender:
    Male
    Austin
    Vehicle:
    2014 4X4 DCSB OR V6

    Blue Loctite.

    Shikokaon likes this.
  12. Nov 29, 2016 at 1:50 PM
    #112
    Bambino

    Bambino Well-Known Member

    Joined:
    May 6, 2015
    Member:
    #154731
    Messages:
    50
    Gender:
    Male
    First Name:
    Ben
    Vehicle:
    2014 metallic grey Tacoma TRD 4.0 6 speed access cab
    Just did mine last week, the bending isn't bad as long as you have a large set of channel lock pliers. In my option its a lot easier than cutting them out and having to purchase new ones. And I can hardly tell where the frame was bent.


  13. Nov 29, 2016 at 2:01 PM
    #113
    Shikokaon

    Shikokaon Slacker Extraordinaire

    Joined:
    Oct 20, 2016
    Member:
    #200256
    Messages:
    157
    Gender:
    Male
    Portland, OR
    Vehicle:
    2017 Tacoma D-Cab Off Road (MT)
    I guess I'll need to actually look at it (all I've been looking at are pictures and videos of people who have done it), I haven't crawled under truck yet as I just received lift kit today.

    Thank you all!

  14. Dec 7, 2016 at 6:22 PM
    #114
    farnorth01

    farnorth01 Member

    Joined:
    Oct 3, 2016
    Member:
    #198884
    Messages:
    19
    Gender:
    Male
    First Name:
    Ben
    British Columbia
    Vehicle:
    2011 SR5 4x4 ACLB
    Icon Stage 1, Dakars, Duratracs
    Bending isn't so bad, just take your time and make sure your bends will be covered by the plastic flaps when you're done and you cant even tell.

    Put the passenger side in backwards but don't try and put the drivers side UCA bolt in backwards, it goes in much easier in the original direction. I tried to put in backwards the first time and got it half way in there and it all bound up on me and the head of bolt got stuck behind those hard lines that run just inside the wheel well. Took me 45 minutes or so to get it out, but it slips in perfect in the original direction.

    Shikokaon likes this.
  15. Dec 7, 2016 at 7:05 PM
    #115
    Shikokaon

    Shikokaon Slacker Extraordinaire

    Joined:
    Oct 20, 2016
    Member:
    #200256
    Messages:
    157
    Gender:
    Male
    Portland, OR
    Vehicle:
    2017 Tacoma D-Cab Off Road (MT)
    Awesome! Thank you for the tips! Haven't pulled the trigger on it yet, so I'll def write this down!

  16. Mar 30, 2017 at 11:40 AM
    #116
    st101

    st101 Well-Known Member

    Joined:
    May 1, 2013
    Member:
    #103289
    Messages:
    143
    Gender:
    Male
    I notice that this video states that you should not lubricate the outer part of the UCA bushing, yet the ICON installation instructions tell me to place lubricant on both sides:

    [​IMG]

    What's the right answer here?

    brucehutchinson likes this.
  17. Mar 30, 2017 at 11:59 AM
    #117
    deeezy

    deeezy Well-Known Member

    Joined:
    Sep 1, 2013
    Member:
    #111645
    Messages:
    4,346
    Gender:
    Male
    First Name:
    Dana
    Hawaii
    Vehicle:
    2013 4x4 DC, 6 spd, TRD Sport
    ADS ext travel coilovers with clickers, Icon tubular UCA's Rear-Icon VS 10" RR, Allpro Expos, TRD cat-back, Hurst/Core short shift kit, etc...
    I grease all surfaces of the bushings and they are still looking new after a long time.

  18. Mar 31, 2017 at 10:48 AM
    #118
    Bambino

    Bambino Well-Known Member

    Joined:
    May 6, 2015
    Member:
    #154731
    Messages:
    50
    Gender:
    Male
    First Name:
    Ben
    Vehicle:
    2014 metallic grey Tacoma TRD 4.0 6 speed access cab
    ^^^ This. I did the same with my ICON UCA and no issues

  19. Apr 2, 2017 at 6:44 AM
    #119
    Erik65

    Erik65 Dog slave

    Joined:
    Jun 13, 2011
    Member:
    #58228
    Messages:
    3,423
    Gender:
    Male
    First Name:
    Erik
    Oxford, MA
    Vehicle:
    2011 Timberland Mica TX Pro DC
    Stainless exhaust, 16" TRD wheels, 285x75x16 MTR Kevlars, Icon Stage IV, Icon Secondary shock hoop with adjustable remote reservoir bypass shocks, ATO shackle flip kit, AP U-bolt flip, AP Skids (IFS, transmission, T-case, diff cover)
    That may be true for the tubular UCAs but don't do it to the billet ones
