Idaho BS thread in the PNW

Discussion in 'North West' started by Jensonbt, Aug 28, 2011.

  1. Nov 13, 2023 at 7:20 PM
    m3bassman

    m3bassman Well-Known Member

    Joined:
    Jan 16, 2011
    Member:
    #49376
    Messages:
    14,875
    Gender:
    Male
    Vehicle:
    Green truck
    I said I think, not that it is a fact. I thought it was a combination of an electric solenoid and a vacuum line.

  2. Nov 13, 2023 at 7:34 PM
    Reh5108

    Reh5108 Well-Known Member

    Joined:
    Feb 18, 2013
    Member:
    #97832
    Messages:
    5,587
    Gender:
    Male
    First Name:
    Ryan
    Idaho
    Vehicle:
    2004 SR5 4X4 2.7L Extra Cab
    OME lift, 4x sliders, Demello rear bumper, custom front bumper, Engo 9000lb winch
    J shift case is 100% mechanical. It has a few sensors that let the computer know it's position. The ADD actuators in the early years were vacuum actuated but the later years all electric. They have a vent breather that could be confused as a vacuum line.

    m3bassman[QUOTED] likes this.
  3. Nov 13, 2023 at 11:38 PM
    Digiratus

    Digiratus Adventurer

    Joined:
    Mar 26, 2010
    Member:
    #34006
    Messages:
    22,902
    Gender:
    Male
    First Name:
    Mike
    Roaming the PNW
    Vehicle:
    The RedHead
    2002 XtraCab TRD 4x4 SCv6 AutoTrans With Lots of Mods ADS COs w/Compression Adjusters Camburg Uniball UCAs Whiteline Lower Control Arm Bushings Kartek 7" Limit Straps Plastics Guy Front Bumpstops Custom Alcan Springs +800 lbs +3" ADS 10" Stroke Triple Bypass w/Resi Rear Shocks Custom Rear Shock Relocate All-Pro U-bolt Flip w/Timbren Bumpstops 4.88 Nitro Gears ARB Front Locker ARB Twin Compressor Black 17x8 Konig Countersteer Type X 285/70r17 Falken A/T3w Gunmetal 16x8 SCS Ray10s 255/85r16 Maxxis Bighorns Limited Edition (Relentless) Elite Front Bumper Smittybilt X2O 10K Winch Diode Dynamics SS3 Sport Selective Yellow Fog Lights in the Bumper Diode Dynamics SS3 Pro 4,000 Kelvin SAE Driving Lights with Clear Lenses on the Bumper Morimoto D2S Projectors XB35 Ballasts + 4300K Bulbs Badland Sliders FrankenFab Tire Carrier Swingout bumper w/kitchen BudBuilt Front & Bellypan Skids BAMF Rear Diff Skid Dometic CFX 55im Fridge/Freezer Alpha II Hardshell RTT Badland Custom Bed Rack Denso 210-0461 105 amp alternator Dual Northstar 24F AGM batteries BlueSea 7622 ML-ACR Battery controller Peak DBI Dual Battery Voltage Monitor Magnuson MP62 Supercharger w/2.37" Pulley Haltech Elite 2000 Standalone ECU Denso 650cc Fuel Injectors Doug Thorley Headers Aeromotive Stealth 340 Fuel Pump TransGo A340F Reprogramming Shift Kit Magnaflow Hi-Flow CAT, Magnaflow 18" Muffler w/Vibrant Resonator 13WL Brake Calipers Braided Steel Brake Lines ScanGauge II OBDII Scanner Kenwood TM-71A Dual Band Ham Radio Larson 70CM/2M Antenna Uniden 520xl CB radio 3' Firestik Adjustable tip antenna Pioneer DEH-P9400BH HU Alpine Amps & Type R components (F) and coaxials (R) Wet Okole Seat Covers Weathertech Digital Liners Deck Plate Mod 1" Diff Drop Carrier Bearing Drop
    It is not as simple as it sounds. My friend Dan just did this on his Tacoma.

    @drr Care to share what you described to me the other day?

  4. Nov 14, 2023 at 5:54 AM
    Reh5108

    Reh5108 Well-Known Member

    Joined:
    Feb 18, 2013
    Member:
    #97832
    Messages:
    5,587
    Gender:
    Male
    First Name:
    Ryan
    Idaho
    Vehicle:
    2004 SR5 4X4 2.7L Extra Cab
    OME lift, 4x sliders, Demello rear bumper, custom front bumper, Engo 9000lb winch
    You will want a case from the same transmission as what it's coming off of. I do know that the input spline counts can differ.

  5. Nov 14, 2023 at 7:59 AM
    drr

    drr Primary Prognosticator

    Joined:
    Oct 17, 2013
    Member:
    #114681
    Messages:
    2,513
    Gender:
    Male
    First Name:
    Dan
    Seattle-ish
    Vehicle:
    02 4WD Tacoma
    Not quite as simple as just swapping the case over, unfortunately. And it's all electric, unless you have a really old model (I believe 97 and earlier Tacomas have vacuum shifted ADD, not sure about 4runners).

    The spline counts are all the same for the same engine type (i.e. the A340f or R150 transmissions, not the 3RZ with whatever transmissions those have), you can put either transfer case type behind either a manual or auto transmission for the V6. The input shaft is slightly different length, but I had no problems when I wheeled with a push button case behind my 5 speed swap.

    The real issue is the electronics - the j-shift system is completely different than the push button. The push button uses a 4wd ECU (under the radio, big green box) to send and receive signal from the t-case actuator that it has shifted, then sends power to the front diff to shift the ADD. The j-shift has a much simpler system that uses a relay as a switch to shift the ADD once it sees that the t-case has shifted to 4wd. So you can swap from push button to j-shift fairly easily, but going the other way would be a nightmare.

    You can basically unpin or cut the wires from the green 4wd ECU, and about half of them need to be pinned into the new connector for the relay. The relay is called the Transmission Control Relay, no idea why since it doesn't have anything to do with the transmission. The part number is 89531-35050.

    I have the wiring diagrams for both, as well as a map of what wires need to be spliced to the new relay. Let me know if you want all that info.

  6. Nov 14, 2023 at 12:30 PM
    Jensonbt

    Jensonbt [OP] Well-Known Member

    Joined:
    Dec 15, 2018
    Member:
    #275931
    Messages:
    939
    Gender:
    Male
    First Name:
    Beckler
    Idaho
    Vehicle:
    2012 gray tacoma DCLB
    Just enough to look kinda cool.
    I have a buddy that blew up his front diff and smoked his tcase on a 02 and he was considering trying a j-shift swap because he’s had problems with it before. But I think he’s just going to stay with the button shift. If there’s anybody that would know the know I figured I could reach them here or the Wyoming thread.

    drr[QUOTED] likes this.
  7. Nov 14, 2023 at 6:09 PM
    Reh5108

    Reh5108 Well-Known Member

    Joined:
    Feb 18, 2013
    Member:
    #97832
    Messages:
    5,587
    Gender:
    Male
    First Name:
    Ryan
    Idaho
    Vehicle:
    2004 SR5 4X4 2.7L Extra Cab
    OME lift, 4x sliders, Demello rear bumper, custom front bumper, Engo 9000lb winch
    Can the wires from the push button be tied together so it's just waiting to see a position sensor change states? I would think the system could easily be fooled to think it's functioning normally.

  8. Nov 14, 2023 at 6:51 PM
    drr

    drr Primary Prognosticator

    Joined:
    Oct 17, 2013
    Member:
    #114681
    Messages:
    2,513
    Gender:
    Male
    First Name:
    Dan
    Seattle-ish
    Vehicle:
    02 4WD Tacoma
    Possibly, but I don’t think it would be as simple as splicing some wires together. The 4wd ECU is looking for a certain signal back from the t-case actuator to know that it successfully shifted, that sounds to me like you’d need to wire in a resistor to fool it. I’m shit at wiring though, so who knows.

    At the end of the day it wasn’t terribly hard to swap the relay in, since all the wires you need are already in place, just a bit of work to trace the wiring diagrams and map it all out.

    Jensonbt[OP] and Reh5108[QUOTED] like this.
  9. Nov 23, 2023 at 11:54 AM
    Jensonbt

    Jensonbt [OP] Well-Known Member

    Joined:
    Dec 15, 2018
    Member:
    #275931
    Messages:
    939
    Gender:
    Male
    First Name:
    Beckler
    Idaho
    Vehicle:
    2012 gray tacoma DCLB
    Just enough to look kinda cool.
    Happy Thanksgiving everyone!

    POOLGUY, Reh5108 and m3bassman like this.
  10. Nov 27, 2023 at 4:13 PM
    HCFab

    HCFab Hudson Custom Fabrication

    Joined:
    Apr 28, 2017
    Member:
    #217564
    Messages:
    913
    Gender:
    Male
    First Name:
    Zach
    Central Idaho
    Vehicle:
    Overland 04' v6 4x4 5spd Xtracab, Lunar Mist.
    Bit late, but Happy Thanksgiving!

    Just found a smoking deal on a first gen 4x4 auto transmission in Boise, had to log in to share.

    I would buy for a spare it's such a good deal, but I am lacking funds for toys.

  11. Nov 27, 2023 at 7:23 PM
    Reh5108

    Reh5108 Well-Known Member

    Joined:
    Feb 18, 2013
    Member:
    #97832
    Messages:
    5,587
    Gender:
    Male
    First Name:
    Ryan
    Idaho
    Vehicle:
    2004 SR5 4X4 2.7L Extra Cab
    OME lift, 4x sliders, Demello rear bumper, custom front bumper, Engo 9000lb winch
    Turn it into a 4x4 manual!

    Jensonbt[OP] likes this.
  12. Dec 15, 2023 at 5:57 PM
    Jensonbt

    Jensonbt [OP] Well-Known Member

    Joined:
    Dec 15, 2018
    Member:
    #275931
    Messages:
    939
    Gender:
    Male
    First Name:
    Beckler
    Idaho
    Vehicle:
    2012 gray tacoma DCLB
    Just enough to look kinda cool.
    Can we start taking bets on how long in and out will have the village parking lot messed up?

  13. Dec 15, 2023 at 7:22 PM
    m3bassman

    m3bassman Well-Known Member

    Joined:
    Jan 16, 2011
    Member:
    #49376
    Messages:
    14,875
    Gender:
    Male
    Vehicle:
    Green truck
    I drove by the other night, seems insane. I give it 6 months for the novelty to wear off. In and out has great burgers and shit fries, but there's plenty of places in the valley that do great burgers and fries. So what's the appeal?

    Jensonbt[QUOTED][OP] likes this.
  14. Dec 15, 2023 at 7:25 PM
    Speedytech7

    Speedytech7 Toyota Cult Ombudsman

    Joined:
    Feb 20, 2014
    Member:
    #123587
    Messages:
    51,645
    Gender:
    Male
    First Name:
    ゼイン
    Spokinawa, WA
    Vehicle:
    93 80 Series LC & 96 Turbo V6 Taco 4WD
    I've done a mod or two
    With ya there. But it may always be packed, lots of them in the phoenix metro and they were all always swamped when I lived there. I liked a 4x4 but I always skipped the fries cause anyway you order them they're awful.

    m3bassman[QUOTED] likes this.
  15. Dec 16, 2023 at 10:11 AM
    Jensonbt

    Jensonbt [OP] Well-Known Member

    Joined:
    Dec 15, 2018
    Member:
    #275931
    Messages:
    939
    Gender:
    Male
    First Name:
    Beckler
    Idaho
    Vehicle:
    2012 gray tacoma DCLB
    Just enough to look kinda cool.
    I’m hoping they keep the line contained in the parking lot… because once those 200 some extra employees leave isn’t going to be a mess getting through the south side of the village.

  16. Dec 16, 2023 at 3:50 PM
    Tacoma~Gal

    Tacoma~Gal Well-Known Member

    Joined:
    Nov 7, 2019
    Member:
    #310075
    Messages:
    424
    Vehicle:
    '23 LR OR
    Took advantage of the nice day and gave my truck a rinseless wash. Almost a year of ownership and its got over 13k miles :eek:


    Jensonbt[OP], POOLGUY and m3bassman like this.
  17. Dec 16, 2023 at 5:02 PM
    m3bassman

    m3bassman Well-Known Member

    Joined:
    Jan 16, 2011
    Member:
    #49376
    Messages:
    14,875
    Gender:
    Male
    Vehicle:
    Green truck
    I have a feeling they have a pretty good method for opening stores and once their travel team leaves the place will be ready for the hustle and bustle. Curious how long it's this crazy though. But even noticed the traffic east of the village on Fairview was packed. Figure between that and holiday shopping maybe? Since I moved to Nampa, I have a lot less traffic near my house which is nice.
    You're brave, it was cold today!

  18. Dec 16, 2023 at 5:33 PM
    Tacoma~Gal

    Tacoma~Gal Well-Known Member

    Joined:
    Nov 7, 2019
    Member:
    #310075
    Messages:
    424
    Vehicle:
    '23 LR OR
    I think I might of froze all my nerve endings last month steelhead fishing on the clearwater for 8+ hours in below freezing temps. Cause today felt warm, LOL.

    Reh5108 likes this.
  19. Dec 16, 2023 at 6:42 PM
    m3bassman

    m3bassman Well-Known Member

    Joined:
    Jan 16, 2011
    Member:
    #49376
    Messages:
    14,875
    Gender:
    Male
    Vehicle:
    Green truck
    Ok now you're just bragging. How was the fishing? Love that area, although I prefer further up into the Lochsa.

  20. Dec 16, 2023 at 7:14 PM
    Tacoma~Gal

    Tacoma~Gal Well-Known Member

    Joined:
    Nov 7, 2019
    Member:
    #310075
    Messages:
    424
    Vehicle:
    '23 LR OR
    We went over Thanksgiving, fished Thur-Sat. It was my first time steelhead fishing and I got 1 everyday. Between 4 of us and 3 days I think we ended up landing 7. I'm completely hooked, I'd do it every weekend if I could.
