Ignition wire question

Im installing winjet fog lights and i didnt want to do the fuse tap thing the dude did in the video, the winjet site says splice/tap into an ignition wire.

I cant seem to find one without a wiring diagram. Any help please?



Well dang guess nobody has a clue either



Here you go.



I mean this with all due respect for your truck and wallet.

If you cannot wire up a set of foglights, head straight to your nearest MobileOne Audio



I agree with this fully, Kyle.



Injection not ignition.



Im a helo electrician, its not that i cant do it. Its the lack of electrical schematics for this truck



The website and wire definitely said ignition



They made a simple mistake.



@caribe makaira is that true?



The point is to have it on an ignition source though, so it probably doesn't matter whether it's INJ or ignition (source). As long as whichever wire/fuse is tapped, it will only be on while ignition is on. I'm actually one of the people who don't want to use INJ for any taps, so I go for another source.



Dont ever tie into a injector or anything drivability wise to run anything. If it shorts out and blows fuse, your dead in the water. Looking at the underhood fuse/relay box, there should be a open relar spot with constant poer and possible a open fuse spot with keyed power. Then you could wire in a relay and do it right.



I do not know...My tea leaves/sea shells/rune stones are mostly correct.



Don't stand too close to the vortex!



Don't worry, OP's a helo electrician.. see's no issue splicing $50 ebay fogs directly into the ignition..
