Is my timing chain set up right?

Ouch



I think you need less ugga-duggas when installing things.. more finesse



This is my new compression I just did after I fix the passenger intake position. It looks like piston 5 is a little lower.



I tend to think your compression numbers are good. 176 avg and everything within 5%.



maybe I got to break the cams in?



How does the run?
That’s the important part.

I’d drive it 500 miles and see what happens if it runs good.



I need to put it together. I guess that's all I can probably do. I can check the compression after 500 miles. Maybe I can adjust the lash also. these were my numbers

Driver side intake= .15 to .25 Exhaust= .29 to .39

E2 E3 E4
1).305mm,38 1).305mm,35 1).305mm,35
2).305mm,40 2).305mm,41 2).305mm,42

I2 I3 I4
1).200mm,46 1).178mm,48 1).200mm,48
2).200mm,48 2).200mm,50 2).178mm,46

Passenger side

E2 E3 E4
1).305mm,40 1).305mm,38 1).305mm,40
2).305mm,35 2).305mm,37 2).305mm,38

I2 I3 I4
1).178mm,46 1).178mm,48 1).200mm,50
2).200mm,46 2).178mm,50 2).178mm,48



passenger side intake valve clearance has a tighter spec. But it should wear down after a while. That is the only difference I see. that could be the reason why the passenger side is a little lower comprssion



If my math is right, that’s less than .0009”
I don’t think that’s the cause, but I’m not really all that concerned with an 11 psi difference.
At least not on a semi-new top end.

If your timing is right, what else are you going to do?
After all, you have 2 other intakes sitting at .178mm.
If “tight” were the issue, I’d expect to see lower compression on those cylinders too.

I’d stick it together and run it.
I would not worry about it until it becomes an issue.
You’ll know when/if it does become an issue.



This ^^^



Turn it it on and it sounds good now. Not shaking anymore. Took it out for a drive and it pulls harder with the new camshafts.I'm happy with it. Well see how it goes.
https://www.youtube.com/shorts/pQHlfx-AVUI



Bravo for sticking through it and overcoming the issue! Glad that was all that it was. You've put in some serious wrenching lately.



it was a good learning Experience. I'm lucky I'm still off work for medical leave. I wouldn't have the time to mess around like this
