Leer 100R Install - What is needed?

Discussion in '2nd Gen. Tacomas (2005-2015)' started by brandob9, Sep 21, 2009.

  1. Sep 21, 2009 at 11:58 AM
    #1
    brandob9

    brandob9 [OP] Well-Known Member

    Joined:
    Jun 26, 2009
    Member:
    #18937
    Messages:
    248
    Gender:
    Male
    First Name:
    Brandon
    Portland, OR
    Vehicle:
    09 DC Long Bed
    Soundproofed cab, beeps purged, bed lights, extra bed tie-downs and TSB springs.
    To the guys with LEER toppers:

    What does it take to install one of these on a truck that hasn't seen one before? Does it just attach to the bed rails?

    I'm picking one up this evening and don't want any surprises.

    Thanks!

  2. Sep 21, 2009 at 12:11 PM
    #2
    RedskinRedTaco

    RedskinRedTaco Well-Known Member

    Joined:
    Aug 16, 2009
    Member:
    #21263
    Messages:
    121
    Gender:
    Male
    First Name:
    Paul
    Virginia Beach, VA
    Vehicle:
    07 TRD 4x4 Offroad Crewcab
    Trifecta folding Touneau Cover, 275/70/16 LTX M/S, Running Boards, Dynamat, tint, Alpine W404 Video system w/ backup cam, Sirius Sat, Polk Audio Component Speakers frt and back, Alpine 4x50 amp. Billy's 5100's set @ 1 3/4, 1" rear blocks, Rear TSB, trimmed frt mud flaps 4", TRD Exhuast, K&N filter. Electric Brake.
    i have the XR Leer top. There are only four bolts holding it on. make sure it is pushed all the way forward. the top should come with 4 threaded nuts and bolts that fit into the bed rail system on your truck. If not go get you some 1/4" j bolts from home depot. you may need to drill a hole in the bottom of the tracks for the j-bolt.

    Paul


  3. Sep 21, 2009 at 12:48 PM
    #3
    Ty's Taco

    Ty's Taco Well-Known Member

    Joined:
    Mar 24, 2009
    Member:
    #15107
    Messages:
    247
    Gender:
    Male
    First Name:
    Tyler
    Sweet home Alabama
    Vehicle:
    2009 Prerunner SR5 Sport Pearl Black
    Ask visa or my wife. They both constantly remind me how much I've got left to spend.
    The dealer should install it for free, at least mine did. It's not hard if you want to do it yourself. Here is a pic of how it fit together, hope this helps out.

    [​IMG]

  4. Sep 21, 2009 at 12:53 PM
    #4
    brandob9

    brandob9 [OP] Well-Known Member

    Joined:
    Jun 26, 2009
    Member:
    #18937
    Messages:
    248
    Gender:
    Male
    First Name:
    Brandon
    Portland, OR
    Vehicle:
    09 DC Long Bed
    Soundproofed cab, beeps purged, bed lights, extra bed tie-downs and TSB springs.
    I'm buying a used one from a private party, so there is no dealer involvement. That photo is exactly what I needed to see, though. :D

    I don't suppose you can grab one of the wiring, can you?

  5. Sep 21, 2009 at 12:56 PM
    #5
    RedskinRedTaco

    RedskinRedTaco Well-Known Member

    Joined:
    Aug 16, 2009
    Member:
    #21263
    Messages:
    121
    Gender:
    Male
    First Name:
    Paul
    Virginia Beach, VA
    Vehicle:
    07 TRD 4x4 Offroad Crewcab
    Trifecta folding Touneau Cover, 275/70/16 LTX M/S, Running Boards, Dynamat, tint, Alpine W404 Video system w/ backup cam, Sirius Sat, Polk Audio Component Speakers frt and back, Alpine 4x50 amp. Billy's 5100's set @ 1 3/4, 1" rear blocks, Rear TSB, trimmed frt mud flaps 4", TRD Exhuast, K&N filter. Electric Brake.
    the wiring harness runs down to the driver side tail light its just two wires. Hot and ground real easy. This shell is coming off another taco right? its only going to fit another taco.

  6. Sep 21, 2009 at 12:58 PM
    #6
    brandob9

    brandob9 [OP] Well-Known Member

    Joined:
    Jun 26, 2009
    Member:
    #18937
    Messages:
    248
    Gender:
    Male
    First Name:
    Brandon
    Portland, OR
    Vehicle:
    09 DC Long Bed
    Soundproofed cab, beeps purged, bed lights, extra bed tie-downs and TSB springs.
    Yes, this shell had been on a 2005 AC. It's going onto my 2009 DC LB.

    Were the wires just t-eed in?

  7. Sep 21, 2009 at 2:25 PM
    #7
    Ty's Taco

    Ty's Taco Well-Known Member

    Joined:
    Mar 24, 2009
    Member:
    #15107
    Messages:
    247
    Gender:
    Male
    First Name:
    Tyler
    Sweet home Alabama
    Vehicle:
    2009 Prerunner SR5 Sport Pearl Black
    Ask visa or my wife. They both constantly remind me how much I've got left to spend.
    Got ya covered!! My guys that did the install didn't do a good job with the wiring so I reworked it. I pulled the fabric up and ran the wiring underneath from the light to the top of the seal and then just ran it along the seal to the side and along the edge of the shell to the tail light and reattached the fabric with spray on upholstery adhesive. The pics should help explain.

    [​IMG]



    [​IMG]

  8. Sep 21, 2009 at 2:29 PM
    #8
    ozmon420

    ozmon420 Well-Known Member

    Joined:
    Aug 23, 2008
    Member:
    #8699
    Messages:
    1,078
    Gender:
    Male
    miami, florida
    Vehicle:
    08 tacoma
    18x9 pro comp 7031 rims, alpine iva-d310 w/sirius sat radio, ipod connection, tv tuner, reverse camera, bug deflector, wet okole seat covers, tinted windows, running boards, toytec coilovers front set at 2.5'' , AAL rear,5100's rear, TC UCA, leer topper, bruteforce rear bumper, ARB rear locker.
    just have dealer install it

  9. Sep 21, 2009 at 2:43 PM
    #9
    brandob9

    brandob9 [OP] Well-Known Member

    Joined:
    Jun 26, 2009
    Member:
    #18937
    Messages:
    248
    Gender:
    Male
    First Name:
    Brandon
    Portland, OR
    Vehicle:
    09 DC Long Bed
    Soundproofed cab, beeps purged, bed lights, extra bed tie-downs and TSB springs.
    I'm picking it up at the guy's house.
