Lift shopping list, what am I missing?

Discussion in '3rd Gen. Tacomas (2016-2023)' started by darkfader, Mar 17, 2019.

  1. Mar 17, 2019 at 2:39 PM
    #1
    darkfader

    darkfader [OP] Will this fit without rubbing?

    Joined:
    Jul 29, 2014
    Member:
    #134971
    Messages:
    663
    Gender:
    Male
    First Name:
    Josh
    West Virginia
    Vehicle:
    2018 DCSB6MTFTMFW
    hey guys, I’m ready to start ordering. Hoping you can let me know if I’m missing anything.

    The plan:

    6112/5160
    Headstrong leaf pack, leave overload in
    ECGS bushing
    JBA UCA’s (I think just the standard version?)

    Planning on 2” front and rear. As I sit now, I have around 3/4” rake which is fine to me.

    The questions are:

    Is the 5160 ok with 2” of lift in the rear?

    Are most folks finding they need angled wedges for the rear with 2” of lift, or is this something where I need to install the lift and measure my pinion/drive shaft angle and then order?

    I don’t need max droop, but will the brake lines need to be extended at 2”?

    I think that’s it. Any advice is greatly appreciated. Now if I can just find someone with a set of 6112’s on the shelf.


  2. Mar 17, 2019 at 2:41 PM
    #2
    Matmo215

    Matmo215 Well-Known Member

    Joined:
    Sep 15, 2016
    Member:
    #197333
    Messages:
    7,645
    Gender:
    Male
    First Name:
    Matthew
    Waco, TX
    Vehicle:
    2015 Sport DCSB
    You might experience driveline vibes, but you wont know until you install the lift. I’d wait and see if you do, and go from there. The issue can be solved with shims on the leaf pack or with the carrier bearing spacer. You’ll want the standard JBA’s, I have them and I love them. Other than that, you seem to be set!

    darkfader[OP] likes this.
