Lifter Noise on 2009 V6

Discussion in 'Technical Chat' started by JoeSchmuck, May 23, 2009.

  1. May 23, 2009 at 7:23 AM
    #1
    JoeSchmuck

    JoeSchmuck [OP] Well-Known Member

    Joined:
    May 19, 2009
    Member:
    #17443
    Messages:
    267
    Gender:
    Male
    First Name:
    Joe
    Virginia
    Vehicle:
    09 PreRunner SR5 2x4 O.R., Timberline Green
    NASTA Black 3" Nerf Bars, Pop & Lock, Access LE Rollup Cover, Alpine PDX-5 Amp, Image Dynamics CS-6/CX-6 & 10" Sub (using stock Head Unit)
    I have noticed what appears to be lifter noise (clanking) on my engine, noticed it shortly after buying it. I have just over 500 miles on it and was hoping it would go away (wishfull thinking) and cuirious if this is normal. The engine could be hot or cold, makes no difference. It's only annoying that it may be out of adjustment and causing undue wear or contributing to less gas mileage. I will probably live with it until time for the first oil change, take it to the dealer (free oil changes) and make them listen to it first and try to explain what's going on. If it's not better when I leave the dealership I plan to install a high quality synthetic motor oil but I would expect that to make things louder, but overall engine wear would be better.

    Any thoughts on the lifter noise, is this normal for this new engine?

    Thanks,
    Joe

  2. May 23, 2009 at 7:32 AM
    #2
    chris4x4

    chris4x4 With sufficient thrust, pigs fly just fine. Staff Member

    Joined:
    May 8, 2008
    Member:
    #6497
    Messages:
    104,125
    Gender:
    Male
    First Name:
    FlimFlubberJAM
    Tenoe, AZ
    Vehicle:
    2013 Rubicon Unlimited,
    4.10 gears, sliders, and lots of buttons.
    Its normal for Toyota truck engines. Many things contribute to the "Lifter Tick" and generally loud engine characteristic. Fuel injectors, timing chain, emisions purge device, and the Shim under Bucket design of the valve train.

  3. May 23, 2009 at 8:05 AM
    #3
    alan

    alan Active Member

    Joined:
    Mar 15, 2009
    Member:
    #14768
    Messages:
    30
    Gender:
    Male
    san jose, ca
    Vehicle:
    05 dbl cab prerunner
    free of charge noise

  4. May 23, 2009 at 9:14 AM
    #4
    steve r

    steve r Well-Known Member

    Joined:
    May 3, 2009
    Member:
    #16724
    Messages:
    283
    Gender:
    Male
    buford ga
    Vehicle:
    06 tacoma
    normal

  5. May 24, 2009 at 4:00 AM
    #5
    JoeSchmuck

    JoeSchmuck [OP] Well-Known Member

    Joined:
    May 19, 2009
    Member:
    #17443
    Messages:
    267
    Gender:
    Male
    First Name:
    Joe
    Virginia
    Vehicle:
    09 PreRunner SR5 2x4 O.R., Timberline Green
    NASTA Black 3" Nerf Bars, Pop & Lock, Access LE Rollup Cover, Alpine PDX-5 Amp, Image Dynamics CS-6/CX-6 & 10" Sub (using stock Head Unit)
    Now that sounds like something I've said all this week to a customer dealing with a software delivery. ;)

    Also, Thanks to all who replied. Guess I'll not give this another though until I get to the dealers and I'll still ask them. I already figured they would say it was normal.

    Cheers,
    Joe

  6. May 24, 2009 at 4:38 AM
    #6
    fletch aka

    fletch aka www.BeLikeBrit.org

    Joined:
    Jan 4, 2009
    Member:
    #12223
    Messages:
    7,122
    Gender:
    Male
    First Name:
    Gary
    Left Coast
    Vehicle:
    09 Magnetic Gray TRD OffRoad
    TRD cat back exhaust, TRD Cold Air Intake, differential breather mod' Hellwig rear sway bar, 16x8 TRD Ivan Stewart's, Michelin LTX A/T2, DTRL Stealth Mode Mod, custom "Texas Edition" shift knob, Sock's "Classic" bedside decals, MetalMiller custom grill emblem, 20% front tinted windows, tinted taillights, Viper alarm, ScanGauge II, Flyzeye Designs V2W Tacoma Interior LED lighting, de-mud flapped, de-badged, extra D-rings under bed bolts, WeatherTech ED floor mats, G4 Elite Fold a Cover ,Toyota bed mat, tailgate theft deterrent device and absolutely no plasti-dip!
    Same noise on my 09, took it in three times, each time told it was normal. Trying to ignore it.

  7. May 25, 2009 at 5:22 AM
    #7
    JoeSchmuck

    JoeSchmuck [OP] Well-Known Member

    Joined:
    May 19, 2009
    Member:
    #17443
    Messages:
    267
    Gender:
    Male
    First Name:
    Joe
    Virginia
    Vehicle:
    09 PreRunner SR5 2x4 O.R., Timberline Green
    NASTA Black 3" Nerf Bars, Pop & Lock, Access LE Rollup Cover, Alpine PDX-5 Amp, Image Dynamics CS-6/CX-6 & 10" Sub (using stock Head Unit)
    I guess the good thing is to have it documented that you took it in three times that way if it does fail you at least have something to fall back on. I will still take mine in and see what they say. I'm expecting the same answer but at least it will be documented.

    Thanks all for those answers.

    Joe

  8. May 26, 2009 at 6:02 PM
    #8
    Pyro-Rob

    Pyro-Rob Active Member

    Joined:
    Feb 25, 2009
    Member:
    #14054
    Messages:
    35
    Gender:
    Male
    North of Denver, CO
    Vehicle:
    09 DC TRD Sport Mag Gray Metallic
    Ideal Turn-Key Clamp (to secure tailgate), On Anytime Fogs, DTRL, Hood Scoop Running Lights, more in the works
    I hadn't left the lot yet before I noticed the noise. I pulled right into the service bay where the service manager checked it and said it was the injectors. It's the noisiest Toy engine I have ever had with less than 200K miles on it.

    YMMV,

    --->Rob

  9. May 26, 2009 at 6:16 PM
    #9
    Ghost96Romeo

    Ghost96Romeo What is the Search Tab for????

    Joined:
    Oct 24, 2008
    Member:
    #10228
    Messages:
    1,963
    Gender:
    Male
    Kyle, TX
    Vehicle:
    06 TRD Off-Road D-Cab
    3" Pro-Comp Suspension Lift AAL Rear w/TSB, All-Pro Plate Bumper, Lightforce 240 Blitz lights, Lund Genesis Roll-top Bed cover, K&N Filters, Spidertrax Wheel spacers, Built-by-Me Rock Sliders, Jeep Tow-Hook, Black Leather seats, 48"Hi-Lift Jack mounted in the bed, Blacked out TRD Rims, BHLM, FLM..... and Awesomeness
    Hmm.... I have the same issue but and hoped it was just the engines "way of sounding" and not the lifters. Glad I'm not going crazy. ;)

  10. May 26, 2009 at 6:56 PM
    #10
    chris4x4

    chris4x4 With sufficient thrust, pigs fly just fine. Staff Member

    Joined:
    May 8, 2008
    Member:
    #6497
    Messages:
    104,125
    Gender:
    Male
    First Name:
    FlimFlubberJAM
    Tenoe, AZ
    Vehicle:
    2013 Rubicon Unlimited,
    4.10 gears, sliders, and lots of buttons.
    The Tacoma uses Shim under Bucket valve adjusters. There is always going to be a bit of "play" in them. When you hear the term "Lifter tick", as there are no "Lifters" in the Tacoma engines, what you hear are the valve buckets "tapping" or "Ticking". Its completely normal. Also, Toiyota doesnt try and use sound dampeners or baffles in their engines to reduce what you hear. Those cost money, and would more than likely affect the bottom line. FWIW, If you want to hear a nosisy engine, Drop by a Duccati or Triumph dealer. :)

  11. May 26, 2009 at 6:58 PM
    #11
    fletch aka

    fletch aka www.BeLikeBrit.org

    Joined:
    Jan 4, 2009
    Member:
    #12223
    Messages:
    7,122
    Gender:
    Male
    First Name:
    Gary
    Left Coast
    Vehicle:
    09 Magnetic Gray TRD OffRoad
    TRD cat back exhaust, TRD Cold Air Intake, differential breather mod' Hellwig rear sway bar, 16x8 TRD Ivan Stewart's, Michelin LTX A/T2, DTRL Stealth Mode Mod, custom "Texas Edition" shift knob, Sock's "Classic" bedside decals, MetalMiller custom grill emblem, 20% front tinted windows, tinted taillights, Viper alarm, ScanGauge II, Flyzeye Designs V2W Tacoma Interior LED lighting, de-mud flapped, de-badged, extra D-rings under bed bolts, WeatherTech ED floor mats, G4 Elite Fold a Cover ,Toyota bed mat, tailgate theft deterrent device and absolutely no plasti-dip!
    That is exactly why I am doing it.

  12. May 27, 2009 at 11:33 AM
    #12
    Caddmannq

    Caddmannq MotoNerd

    Joined:
    Sep 1, 2008
    Member:
    #8917
    Messages:
    431
    Gender:
    Male
    California
    Vehicle:
    PreRunner SR5 TRD Sport DC LB
    Undercover toneau
    Sure there are. They're just mechanical and not hydraulic.

  13. May 27, 2009 at 11:34 AM
    #13
    chris4x4

    chris4x4 With sufficient thrust, pigs fly just fine. Staff Member

    Joined:
    May 8, 2008
    Member:
    #6497
    Messages:
    104,125
    Gender:
    Male
    First Name:
    FlimFlubberJAM
    Tenoe, AZ
    Vehicle:
    2013 Rubicon Unlimited,
    4.10 gears, sliders, and lots of buttons.
    Yes, Your correct.

  14. May 27, 2009 at 11:36 AM
    #14
    Kenobe

    Kenobe Well-Known Member

    Joined:
    Apr 28, 2009
    Member:
    #16534
    Messages:
    586
    Gender:
    Male
    First Name:
    Ken
    Colorado Springs, CO
    Vehicle:
    09 Tacoma TRD Sport
    I noticed the noise as well. Not a huge issue, but the noisiest 'new' engine I've heard outside of any Ducati ever made.

  15. May 27, 2009 at 4:40 PM
    #15
    JoeSchmuck

    JoeSchmuck [OP] Well-Known Member

    Joined:
    May 19, 2009
    Member:
    #17443
    Messages:
    267
    Gender:
    Male
    First Name:
    Joe
    Virginia
    Vehicle:
    09 PreRunner SR5 2x4 O.R., Timberline Green
    NASTA Black 3" Nerf Bars, Pop & Lock, Access LE Rollup Cover, Alpine PDX-5 Amp, Image Dynamics CS-6/CX-6 & 10" Sub (using stock Head Unit)
    So, the engine is a 1GR-FE and am I correct in stating this is an Intake VVT-i only engine? I have the 2009 model.

    I have found some literature in the form of the engine manual and did not see any shims listed for the valve train. I didn't see any adjustments of any sort. Maybe that is why it's noisy? I'm sure there is an adjustment.

    So there has been "lifter noise" since 2003 when this engine was first introduced?

    Cheers,
    Joe

  16. May 27, 2009 at 5:11 PM
    #16
    chris4x4

    chris4x4 With sufficient thrust, pigs fly just fine. Staff Member

    Joined:
    May 8, 2008
    Member:
    #6497
    Messages:
    104,125
    Gender:
    Male
    First Name:
    FlimFlubberJAM
    Tenoe, AZ
    Vehicle:
    2013 Rubicon Unlimited,
    4.10 gears, sliders, and lots of buttons.
    I dont think there are rockers on the 1gr-fe engine...The cams push down on the Buckets, which are on the valve stems. No threaded adjusters, as different thinckness buckets are use for adjusting the valves. Cant find a pic, and I dont want to take my valve cover off right now to take a pic. :eek:

  17. May 27, 2009 at 5:15 PM
    #17
    lipripr

    lipripr Member

    Joined:
    May 3, 2009
    Member:
    #16742
    Messages:
    23
    Gender:
    Male
    Colorado
    Vehicle:
    2006 TRD 4x4
    If you want to hear a nosisy engine, Drop by a Duccati or Triumph dealer.
    Very true:)
    [​IMG]

  18. May 27, 2009 at 5:16 PM
    #18
    chris4x4

    chris4x4 With sufficient thrust, pigs fly just fine. Staff Member

    Joined:
    May 8, 2008
    Member:
    #6497
    Messages:
    104,125
    Gender:
    Male
    First Name:
    FlimFlubberJAM
    Tenoe, AZ
    Vehicle:
    2013 Rubicon Unlimited,
    4.10 gears, sliders, and lots of buttons.
    LOL, I had a 900ss (big bore kit), and a couple of Trumpets. ;)

  19. May 27, 2009 at 5:19 PM
    #19
    lipripr

    lipripr Member

    Joined:
    May 3, 2009
    Member:
    #16742
    Messages:
    23
    Gender:
    Male
    Colorado
    Vehicle:
    2006 TRD 4x4
    Sweet! I'm hopin to upgrade to a sport clasic 1000 soon :)

  20. May 27, 2009 at 6:11 PM
    #20
    JoeSchmuck

    JoeSchmuck [OP] Well-Known Member

    Joined:
    May 19, 2009
    Member:
    #17443
    Messages:
    267
    Gender:
    Male
    First Name:
    Joe
    Virginia
    Vehicle:
    09 PreRunner SR5 2x4 O.R., Timberline Green
    NASTA Black 3" Nerf Bars, Pop & Lock, Access LE Rollup Cover, Alpine PDX-5 Amp, Image Dynamics CS-6/CX-6 & 10" Sub (using stock Head Unit)
    You are correct. I downloaded a FSM for a 2006 Tacoma with the 1GR-FE engine. Here is the adjustment procedure for the valves and very true, no shims but the lifter cap is replaced with the proper height cap.

    Also you can anyone can d/l these manuals from the following url: http://www.ncttora.com/fsm/

    Thanks for all the help.

    Joe
