Light Pod Wiring Question / Help

Discussion in 'Lighting' started by CO_0321er, Aug 9, 2016.

Post Reply

Page 2 of 2

Aug 10, 2016 at 3:17 PM

#21

#21
Sandman614 Ex-Snarky TWSS elf, Travis #hotsavannahdotcom

Joined:

Oct 26, 2010

Member:

#45273

Messages:

35,882

Gender:

Male

First Name:

Tim

Garner, NC/Boone, NC

Vehicle:

'06 SR5 Off Road

ARB Front Bumper, Projector Headlights w/Slimcubby 4300K HID's, Oznium LED's, LED taillights, DIY Washable Cabin Moose Filter, Sockmonkey SR5 Off Road, Aux Audio plug, OME 886x, OME Nitrochargers, Wheelers 3 Leaf Progressive AAL, ImMrYo Rear-View Mirror Lift Bracket, Dodge D-Rings

Patch92 said: ↑

It's all good. I think I'm going to leave what I got for now. I'll change it down the line when I get another bar. And the next light I'll piece the harness together myself. Do you think it's fine for now being connected to the battery? What sort of issues could come about if I keep it how it is for a little while?
Click to expand...

The switch light will stay on and could possibly run the battery down. Also you could leave the accessory on and run your battery dead(like accidentally turning it on in the daytime)

Sandman614, Aug 10, 2016

#21

Aug 10, 2016 at 7:43 PM

#22

#22
caribe makaira Well-Known Member

Joined:

Feb 13, 2011

Member:

#51121

Messages:

11,724

Gender:

Male

Caribbean, Puerto Rico

Vehicle:

05 PreRunner TRD Offroad AutoTrans

Hood Struts, My version Fogs always ON, Map & Overhead Light Mod,

Last edited: Aug 11, 2016

caribe makaira, Aug 10, 2016

#22

Aug 11, 2016 at 1:44 PM

#23

#23
caribe makaira Well-Known Member

Joined:

Feb 13, 2011

Member:

#51121

Messages:

11,724

Gender:

Male

Caribbean, Puerto Rico

Vehicle:

05 PreRunner TRD Offroad AutoTrans

Hood Struts, My version Fogs always ON, Map & Overhead Light Mod,

Last edited: Aug 11, 2016

caribe makaira, Aug 11, 2016

#23

Aug 11, 2016 at 4:31 PM

#24

#24
caribe makaira Well-Known Member

Joined:

Feb 13, 2011

Member:

#51121

Messages:

11,724

Gender:

Male

Caribbean, Puerto Rico

Vehicle:

05 PreRunner TRD Offroad AutoTrans

Hood Struts, My version Fogs always ON, Map & Overhead Light Mod,

caribe makaira, Aug 11, 2016

#24
