locating lowbeam lead on head lights

Discussion in 'Lighting' started by 907taco, Jun 4, 2011.

  1. Jun 4, 2011 at 12:11 PM
    #1
    907taco

    907taco [OP] Alaskan Assassin

    Joined:
    Mar 27, 2010
    Member:
    #34091
    Messages:
    1,358
    Gender:
    Male
    First Name:
    Bobby
    Alaska
    Vehicle:
    2010 BlackSandPearl 4x4
    ultimate lift kit ( toytec ) ome dakar leaf pack , w/ extended length billies, LR uca's, Pro comp 7089s, KM2's 285 70 17, neoprene seat covers, weather techs, CBI sliders w/kickout, URD ss, cab mount chop, VHT night shade tint>tails,3rd B-light. Debadged. Grillecraft grille, rear diff breather mod. CBI Moab front bumper, warn M8000 winch, HID kragens 7", Hella's micro fogs. retrofit headlights HIDS, LED solutions maps/license! 886 back up light mod,
    can anyone help out locating this, my electrical tester is broken. I am hooking up my micro hella fogs and i need to tap into this lead.
    I have a 2010 access cab, 2.7 4x4 if that helps, i am not sure what color wiring that would be, it could be anyone one of the headlights, I just need to know coloring of said wire.




    [​IMG]

  2. Jun 4, 2011 at 6:23 PM
    #2
    907taco

    907taco [OP] Alaskan Assassin

    Joined:
    Mar 27, 2010
    Member:
    #34091
    Messages:
    1,358
    Gender:
    Male
    First Name:
    Bobby
    Alaska
    Vehicle:
    2010 BlackSandPearl 4x4
    ultimate lift kit ( toytec ) ome dakar leaf pack , w/ extended length billies, LR uca's, Pro comp 7089s, KM2's 285 70 17, neoprene seat covers, weather techs, CBI sliders w/kickout, URD ss, cab mount chop, VHT night shade tint>tails,3rd B-light. Debadged. Grillecraft grille, rear diff breather mod. CBI Moab front bumper, warn M8000 winch, HID kragens 7", Hella's micro fogs. retrofit headlights HIDS, LED solutions maps/license! 886 back up light mod,
  3. Jun 10, 2011 at 6:36 PM
    #3
    Tacokevin

    Tacokevin Well-Known Member

    Joined:
    Mar 17, 2011
    Member:
    #53205
    Messages:
    83
    Gender:
    Male
    First Name:
    Kevin
    East Hartford, CT
    Kenwood Excelon DNX9960, Hertz speakers, Extang Trifecta Tonneau, 3" Toytec Bilstien 5100 coilovers, LR UCA, Diff Drop, Rear AAL Bilstien 5100's, XD Series Bully Wheels, 285/74R16 Nitto Terra Grapplers, Yellow fog lights w/ anytime mod to FJ oem switch, DTRL custom mod w/Switchback LED and stealth switch, Smoked Headlights, Wired Streamlight Rechargable LED flashlight, Color matched grill, Color matched power mirrors w/oem switch, Heated Murth Bicolor signal mirrors w/Highlander oem heater switch, URD short shifter
    left hand headlight Red-yellow right hand headlight Red-black. Its wire 1 on both connectors. i included a pdf of the factory wiring....hope this helps.
