Longer studs needed

Discussion in '2nd Gen. Tacomas (2005-2015)' started by Guess2010, May 3, 2012.

  1. May 3, 2012 at 7:26 AM
    #1
    Guess2010

    Guess2010 [OP] Well-Known Member

    Joined:
    May 2, 2010
    Member:
    #36413
    Messages:
    236
    Gender:
    Male
    First Name:
    DAVE
    Saskatchewan
    Vehicle:
    2010 trd tacoma double cab
    Just a few dont tell the wife!!!
    Ok bought a new set of rims Fuel Boost
    and i only get about 7turns each.im also using a tappered wheel nut to.
    So i wanna get longer studs?
    How long are the factory ones? i have a 2010 taco
    also where can u buy them? i live in canada
    any input would be app

  2. May 3, 2012 at 7:32 AM
    #2
    Wicked 2007

    Wicked 2007 Well-Known Member

    Joined:
    Dec 16, 2010
    Member:
    #47770
    Messages:
    571
    Gender:
    Male
    Bay Area, CA
    Vehicle:
    2007 Tacoma AT DC SB 4x4
    2007 Tacoma Double Cab SB 4WD - Auto -TRD Off Road - Icon Billet UCA - 8" ORI Front Struts - Bilstein 5100 11" RCD Shock - AllPro Expo Springs - Demello Sliders - Tom Woods 1 Piece Driveshaft - 16x8 Mojave Teflon Rims - Locker Mod - Locker Guard - 35" MT MTZ's - ARB Bumper - Warn 8000 winch w/synthetic line - All-Pro Front Skid/Transmission Skid/Rear Armor - ARB Front Locker - Nitro 4.56 gears - Marlin 4.7 crawl box - Twin Stick FJ t-case - ATO high clearance rear bumper
    Well after putting my 35" tires on I noticed something and had a bit of concern. My stock wheel studs didnt seem to be very long and upon closer inspection I see that the lugs only bit about 6-8mm of threads. I know it a general rule to have at least (minimum) bite to be equal to at least the diameter of the bolt/stud (almost 12mm).

    Since I felt I was riding around on a potential time bomb - especially with the added weight of the new tires I decided it was time for new studs.

    Stock:
    Type: Serrated Stud
    Thread: M12-1.5
    Knurl Dia: 14.20mm (0.559inch)
    Length: 40mm (1.575inch)
    Shoulder Length: 8mm (.315inch)

    New (from a 2002-2003 Toyota matrix):
    Type: Serrated Stud
    Thread: M12-1.5
    Knurl Dia: 14.20mm (0.559inch)
    Length: 55mm (2.165inch)
    Shoulder Length: 26.60mm (1.05inch)

    I got the new studs from Summit. Dorman PN # 610-463. They sell in bulks of 10 - so I got 30 and now have extra.

    The new bite is well past the safe zone and I am happy to have upgrade. The longer shoulder on the new studs holds the rotor and drum better along with the rim when mounting.

    Fairly easy job - a bit time consuming to do all 24. This can all be done without taking anything off except the front caliper/rotor and for the rear just the drum.

  3. Jun 6, 2012 at 11:56 PM
    #3
    xyourlocaldjx

    xyourlocaldjx Well-Known Member

    Joined:
    Dec 22, 2009
    Member:
    #27990
    Messages:
    423
    Gender:
    Male
  4. Jun 7, 2012 at 6:09 AM
    #4
    Wicked 2007

    Wicked 2007 Well-Known Member

    Joined:
    Dec 16, 2010
    Member:
    #47770
    Messages:
    571
    Gender:
    Male
    Bay Area, CA
    Vehicle:
    2007 Tacoma AT DC SB 4x4
    2007 Tacoma Double Cab SB 4WD - Auto -TRD Off Road - Icon Billet UCA - 8" ORI Front Struts - Bilstein 5100 11" RCD Shock - AllPro Expo Springs - Demello Sliders - Tom Woods 1 Piece Driveshaft - 16x8 Mojave Teflon Rims - Locker Mod - Locker Guard - 35" MT MTZ's - ARB Bumper - Warn 8000 winch w/synthetic line - All-Pro Front Skid/Transmission Skid/Rear Armor - ARB Front Locker - Nitro 4.56 gears - Marlin 4.7 crawl box - Twin Stick FJ t-case - ATO high clearance rear bumper
    I would go with the Dorman ones. I can confirm they are a fit and I don't like
    How the others have full threads vs the press fit shoulder like the Dorman.

  5. Jun 7, 2012 at 7:48 AM
    #5
    username

    username Fluffer

    Joined:
    Oct 15, 2010
    Member:
    #44704
    Messages:
    5,660
    Pendleton, Or
    Vehicle:
    05 Taco with some crap welded to it
    mostly stock
  6. Jun 7, 2012 at 8:26 AM
    #6
    Wicked 2007

    Wicked 2007 Well-Known Member

    Joined:
    Dec 16, 2010
    Member:
    #47770
    Messages:
    571
    Gender:
    Male
    Bay Area, CA
    Vehicle:
    2007 Tacoma AT DC SB 4x4
    2007 Tacoma Double Cab SB 4WD - Auto -TRD Off Road - Icon Billet UCA - 8" ORI Front Struts - Bilstein 5100 11" RCD Shock - AllPro Expo Springs - Demello Sliders - Tom Woods 1 Piece Driveshaft - 16x8 Mojave Teflon Rims - Locker Mod - Locker Guard - 35" MT MTZ's - ARB Bumper - Warn 8000 winch w/synthetic line - All-Pro Front Skid/Transmission Skid/Rear Armor - ARB Front Locker - Nitro 4.56 gears - Marlin 4.7 crawl box - Twin Stick FJ t-case - ATO high clearance rear bumper

    2.65" - those are long. nice option though.

    the dormans I converted have held up fine through any wheeling i've done with lockers and crawler and since you end up with about 6 extras - you got plenty of spares :)

    Know cost on the ARP's?

  7. Jun 7, 2012 at 8:45 AM
    #7
    username

    username Fluffer

    Joined:
    Oct 15, 2010
    Member:
    #44704
    Messages:
    5,660
    Pendleton, Or
    Vehicle:
    05 Taco with some crap welded to it
    mostly stock
  8. Jun 7, 2012 at 8:51 AM
    #8
    Engage Offroad

    Engage Offroad Dezert Lovers Unite Vendor

    Joined:
    Mar 2, 2010
    Member:
    #32442
    Messages:
    722
    Gender:
    Male
    First Name:
    Engage Marketing
    Pomona, CA
  9. Jun 7, 2012 at 8:57 AM
    #9
    username

    username Fluffer

    Joined:
    Oct 15, 2010
    Member:
    #44704
    Messages:
    5,660
    Pendleton, Or
    Vehicle:
    05 Taco with some crap welded to it
    mostly stock
  10. Jun 12, 2012 at 8:00 PM
    #10
    xyourlocaldjx

    xyourlocaldjx Well-Known Member

    Joined:
    Dec 22, 2009
    Member:
    #27990
    Messages:
    423
    Gender:
    Male
  11. Jun 19, 2012 at 2:57 PM
    #11
    xyourlocaldjx

    xyourlocaldjx Well-Known Member

    Joined:
    Dec 22, 2009
    Member:
    #27990
    Messages:
    423
    Gender:
    Male
    For those who plan on doing this mod... Do yourself a favor and get 2 huge nuts as spacers. Using your brake rotor as a spacer is bullsh*t and it doesnt even work.

    Not sure why no one mentioned this in the previous how to posts.

    took 4 hours to do 6 studs before i went and got the nuts. After i got the right spacers to torque the studs into place it took me around 1.5 hours to do 18.

    I also measured with a caliper and the doorman studs are MUCH larger in diameter than the stock tacoma studs. .200ths i believe. impact wrench was working overtime to smash them in. god what a headache it was.

  12. Jun 19, 2012 at 3:06 PM
    #12
    04LTtacoma

    04LTtacoma Well-Known Member

    Joined:
    May 15, 2010
    Member:
    #37190
    Messages:
    11,138
    Gender:
    Male
    Vehicle:
    2004 SR5 TRD tacoma
    Camburg LT
    I would go with the ARP wheel studs, rant them for a long time, no complaints!

  13. Jun 20, 2012 at 5:52 PM
    #13
    jr4452

    jr4452 New Member

    Joined:
    Jun 17, 2012
    Member:
    #80808
    Messages:
    2
    Gender:
    Male
    First Name:
    John
    Central California
    Vehicle:
    99 SR5 4X4 Extended Cab
    I have a 99 4x4 taco and just ran into the "too short" wheel stud issue when putting on after market wheels. will this work on a 99 too???

  14. Jun 20, 2012 at 5:54 PM
    #14
    xyourlocaldjx

    xyourlocaldjx Well-Known Member

    Joined:
    Dec 22, 2009
    Member:
    #27990
    Messages:
    423
    Gender:
    Male
  15. Jun 20, 2012 at 6:42 PM
    #15
    jr4452

    jr4452 New Member

    Joined:
    Jun 17, 2012
    Member:
    #80808
    Messages:
    2
    Gender:
    Male
    First Name:
    John
    Central California
    Vehicle:
    99 SR5 4X4 Extended Cab
    oh, I got ya, I'll look into it, just bought the truck last Friday for my Kid, the first thing he did was go by wheels and ran into the studs being too short. Of course I am out of town trying to help him out over the phone, it sure would help if I could see what he was talking about!

    Thanks

  16. Jun 20, 2012 at 7:33 PM
    #16
    xyourlocaldjx

    xyourlocaldjx Well-Known Member

    Joined:
    Dec 22, 2009
    Member:
    #27990
    Messages:
    423
    Gender:
    Male
    skype!! :D
