Marlin Crawler's New Rock Crawling Long Travel IFS Suspension System (#RCLT)

Discussion in 'Long Travel Suspension' started by BigMike, Feb 2, 2019.

  1. May 6, 2019 at 6:16 PM
    #261
    ovrlndkull

    ovrlndkull STUKASFK - HC4LIFE

    Joined:
    Jan 7, 2017
    Member:
    #206806
    Messages:
    37,785
    Gender:
    Male
    First Name:
    Skip
    Burlington, NC
    Vehicle:
    2005 DCLB Silver
    63s, XD Machete, Beat not Babied
    Read your entire build thread and information on this kit in the Marlin Crawler forum. Most of us here are just anxiously awaiting pricing, release, and if it'll be more readily available than the crawl box.

    hoverlover, Slashaar and Mully like this.
  2. May 6, 2019 at 6:44 PM
    #262
    Boundlesstaco

    Boundlesstaco Well-Known Member

    Joined:
    Jan 2, 2017
    Member:
    #206382
    Messages:
    208
    Gender:
    Male
    Oakland 510
    Vehicle:
    2016 Tacoma TRD
  3. May 6, 2019 at 7:12 PM
    #263
    mynewtoy

    mynewtoy I like men

    Joined:
    Apr 16, 2011
    Member:
    #55023
    Messages:
    2,559
    Gender:
    Male
    First Name:
    greg
    Mississippi
    Vehicle:
    09 double cab 4x4
    Detriot locker rear ARB air locker front 4.56 gears OME 3" lift, SPC uca's , moto metal 951 wheels 315/75/r16 Treadwright guard dogs, homemade front plate bumper with smittybilt 9.5k winch, homemade skids, homemade Bed bars, Mobtown offroad high clearance rear bumper with tire carrier, Homemade rock sliders , U-bolt flip, Wheeler's super bumps, BORA 1" wheel spacers , Black headlight mod , black tail lights, Satoshi Grill , autoPage C3 RS-665 alarm with remote start, flowmaster 40 series exhaust, cruise control,bed/ground effect lights, wet okole seat covers, tinted,windows, weather tech floor mats, AVS vent shades, debadged, hidden cobra 19 cb, 7" offroad lights behind grill, rear diff breather relocate, abs kill switch
  4. May 6, 2019 at 7:36 PM
    #264
    TACOVRD

    TACOVRD I Identify As A Prius

    Joined:
    Jul 11, 2015
    Member:
    #159264
    Messages:
    6,437
    Gender:
    Male
    First Name:
    TW Addict
    AZ/WA
    Vehicle:
    2019 T4R ORP - Formerly 2013 DCSB OR Spruce Mica
    Workin' on it....
    Wow....pretty slick. Sub'd for updates.

    GT7 likes this.
  5. May 7, 2019 at 11:13 AM
    #265
    SGTCap

    SGTCap Well-Known Member

    Joined:
    Oct 30, 2013
    Member:
    #115529
    Messages:
    3,834
    Gender:
    Male
    First Name:
    Cap
    Summerville, SC
    Vehicle:
    4x4 6-spd,
    37s, 4x4 6-spd, OME 886s, Allpro Expos, SOS sliders and front/rear bumpers,Rack,Skids, 4.56s, Lockers,Recon Winch, TJM RTT, Lots of tools, boxes and gear. Shaggy mutt behind the seat
    This

  6. May 7, 2019 at 11:19 AM
    #266
    GT7

    GT7 One piece at a time

    Joined:
    Aug 15, 2014
    Member:
    #136201
    Messages:
    2,502
    Gender:
    Male
    First Name:
    Grant
    Phoenix
    Vehicle:
    2013 DCLB
    Give us a stock length mar rack too

    If you build it, they will come

    hoverlover, Slashaar, JesseB and 2 others like this.
  7. May 7, 2019 at 11:20 AM
    #267
    ovrlndkull

    ovrlndkull STUKASFK - HC4LIFE

    Joined:
    Jan 7, 2017
    Member:
    #206806
    Messages:
    37,785
    Gender:
    Male
    First Name:
    Skip
    Burlington, NC
    Vehicle:
    2005 DCLB Silver
    63s, XD Machete, Beat not Babied
    You going to the DTOR trip?

  8. May 7, 2019 at 11:25 AM
    #268
    SGTCap

    SGTCap Well-Known Member

    Joined:
    Oct 30, 2013
    Member:
    #115529
    Messages:
    3,834
    Gender:
    Male
    First Name:
    Cap
    Summerville, SC
    Vehicle:
    4x4 6-spd,
    37s, 4x4 6-spd, OME 886s, Allpro Expos, SOS sliders and front/rear bumpers,Rack,Skids, 4.56s, Lockers,Recon Winch, TJM RTT, Lots of tools, boxes and gear. Shaggy mutt behind the seat
    Nope. Doing Windrock next weekend and for Toyota Jamboree later this year. Can't get the time for DTOR. I am going to look at a SXS this weekend also. That'll probably be happening sooner rather than later.

    ovrlndkull[QUOTED] likes this.
  9. May 7, 2019 at 11:25 AM
    #269
    ovrlndkull

    ovrlndkull STUKASFK - HC4LIFE

    Joined:
    Jan 7, 2017
    Member:
    #206806
    Messages:
    37,785
    Gender:
    Male
    First Name:
    Skip
    Burlington, NC
    Vehicle:
    2005 DCLB Silver
    63s, XD Machete, Beat not Babied
    The jamboree in TX or the ATR

  10. May 7, 2019 at 11:29 AM
    #270
    SGTCap

    SGTCap Well-Known Member

    Joined:
    Oct 30, 2013
    Member:
    #115529
    Messages:
    3,834
    Gender:
    Male
    First Name:
    Cap
    Summerville, SC
    Vehicle:
    4x4 6-spd,
    37s, 4x4 6-spd, OME 886s, Allpro Expos, SOS sliders and front/rear bumpers,Rack,Skids, 4.56s, Lockers,Recon Winch, TJM RTT, Lots of tools, boxes and gear. Shaggy mutt behind the seat
    At Windrock in August I believe. Hopefully I'll have my Dana 60 by then. Hopefully we'll know the status of this kit before I order the 60.

    ovrlndkull[QUOTED] likes this.
  11. May 7, 2019 at 11:36 AM
    #271
    ovrlndkull

    ovrlndkull STUKASFK - HC4LIFE

    Joined:
    Jan 7, 2017
    Member:
    #206806
    Messages:
    37,785
    Gender:
    Male
    First Name:
    Skip
    Burlington, NC
    Vehicle:
    2005 DCLB Silver
    63s, XD Machete, Beat not Babied
    I'll be there, waiting on the snail mail for all the information. Should be a pretty cool little trip. Looking forward to seeing some cool old FJs and stuff.

  12. May 8, 2019 at 6:19 AM
    #272
    Usethe2nd

    Usethe2nd Well-Known Member

    Joined:
    Mar 26, 2015
    Member:
    #151849
    Messages:
    4,726
    Gender:
    Male
    First Name:
    Justin
    Fall city
    Welded metal
    I’m interested in this. Great work @BigMike

    BigMike[OP] likes this.
  13. May 8, 2019 at 10:30 AM
    #273
    Usethe2nd

    Usethe2nd Well-Known Member

    Joined:
    Mar 26, 2015
    Member:
    #151849
    Messages:
    4,726
    Gender:
    Male
    First Name:
    Justin
    Fall city
    Welded metal
    Sorry i forgot to ask earlier @BigMike , what’s the wheel travel on the +2RC kit?

  14. May 8, 2019 at 3:24 PM
    #274
    ovrlndkull

    ovrlndkull STUKASFK - HC4LIFE

    Joined:
    Jan 7, 2017
    Member:
    #206806
    Messages:
    37,785
    Gender:
    Male
    First Name:
    Skip
    Burlington, NC
    Vehicle:
    2005 DCLB Silver
    63s, XD Machete, Beat not Babied
    My guess is it'll be pretty close to the same as typical +2 kits so you can look at those guys to good estimate.

    Slashaar likes this.
  15. May 8, 2019 at 6:04 PM
    #275
    Usethe2nd

    Usethe2nd Well-Known Member

    Joined:
    Mar 26, 2015
    Member:
    #151849
    Messages:
    4,726
    Gender:
    Male
    First Name:
    Justin
    Fall city
    Welded metal
    I’m thinking less due to the fact that the CV is moved forward and down. The ground clearance on this kit is insane

  16. May 8, 2019 at 6:51 PM
    #276
    ovrlndkull

    ovrlndkull STUKASFK - HC4LIFE

    Joined:
    Jan 7, 2017
    Member:
    #206806
    Messages:
    37,785
    Gender:
    Male
    First Name:
    Skip
    Burlington, NC
    Vehicle:
    2005 DCLB Silver
    63s, XD Machete, Beat not Babied
    It's not moved down the control arms are designed differently than the typical straight ones. You can't really move the CV down or you'll run into interference issues with lower balljoint. Possibly a little limited in down travel based on moving it forward but I doubt it's going to be a lot. I think it will be a lot in how you set up your coilovers and stuff to take full advantage. That and getting some RCVs.

    hoverlover, TaKoToy and Mully like this.
  17. May 17, 2019 at 7:21 AM
    #277
    BigMike

    BigMike [OP] Applied common sense Vendor

    Joined:
    Apr 2, 2014
    Member:
    #126847
    Messages:
    1,153
    Gender:
    Male
    Fresno, CA
    Vehicle:
    2016 56-speed 580:1 Triple Marlin Crawler-equipped TRD Sport
    Good morning TW! Got some updates to share today :D

    edit: I have moved this info to the next reply to get all updates on the same page

    Last edited: May 17, 2019
    hoverlover and Slashaar like this.
  18. May 17, 2019 at 7:21 AM
    #278
    BigMike

    BigMike [OP] Applied common sense Vendor

    Joined:
    Apr 2, 2014
    Member:
    #126847
    Messages:
    1,153
    Gender:
    Male
    Fresno, CA
    Vehicle:
    2016 56-speed 580:1 Triple Marlin Crawler-equipped TRD Sport
    Last night I updated my build thread (starting from reply #875) so this will be much of the same info. I haven't looked over the many replies yet but I will hold responses until after posting this new info and take questions after this. I'll also be updating the opening post with current info, thanks!

    To take a quick step back, on May 7 I posted the following updated regarding progress on RCLT:

    ===========QUOTE (Reply #856 from my build thread)=============

    Winter/Spring 2019: An Overview

    If I may speak freely for a moment, before our Round-Up I had torn both CV boots (again) back in Aug/Sept, at a time when I was originally planning to install the first prototype Rock Crawling Long Travel IFS kit (RCLT) to my Tacoma. I told people it would be on the truck for the Round-Up, which came and passed, with more plans and scheduling going to sh*t among a really long and messed up fall/winter. Many plans were shifted around on a number of projects. I've had my share of things to be upset about over the last 8 or 9 months, including re-tearing the meniscus in my left knee while finishing up the RCLT KOH project 4Runner... During all of this I've let the Tacoma run itself into the ground.

    After getting the first Prototype RCLT HD done on January 3rd, I took a two week break and then began on V2 Prototype.

    I know many are asking for RCLT and MarRack updates. These things take time and we've only produced one article; It will be longer until we start on pricing. It feels like V1 Prototype MarRack has been on my Tacoma for many years but in reality it was only finished two months before starting on RCLT. I've been working extremely hard on everything plus I have a company to run. Here is an updated project summary:

    Prototype MarRack & RCLT Updates
    Spring 2018: The MarRack is born & V1 Prototype installed to my Tacoma
    Spring 2018: RCLT is born
    Nov 27, 2018: Work on V2 Prototype MarRack begins!!
    Dec 25, 2018: V2 Prototype MarRack design is finished on Christmas Day
    Dec 27, 2018: V2 Prototype MarRack installation on KOH 4R is finished!
    Jan 01, 2019: V1 Prototype RCLT HD installation begins on New Years Day
    Jan 03, 2019: V1 Prototype RCLT HD installation on KOH 4R is finished!
    Jan 16, 2019: Work on V2 Prototype RCLT HD begins!!
    Feb 06, 2019: V1 Prototype RCLT HD + V2 Prototype MarRack competes in the King Of The Hammers. It was the only Toyota-based IFS system in all of KOH!!
    Feb 21, 2019: V2 Prototype RCLT HD reaches Feature Lock with more than 100 (mostly small) improvements over V1
    Mar 07, 2019: V2 Prototype RCLT HD starts pre-production!!!
    ======================END QUOTE========================

    So from early March I waited for V2.0 parts to began trickling in and by early April raw goods were in, my lead fabricator Rocky and I built RCLT HD V2.0, sent it out for powder coating, then finally I prepped my Tacoma by ditching my old custom-built LT setup and proceeded to taste RCLT for myself!!

    Incoming info from my build thread with RCLT HD updates!

    Late April, 2019: RCLT HD Prototype V2.0 is installed!

    Well ladies and gentlemen!! After a crap ton of work I am extremely pleased to announce...

    RCLT HD Prototype V2.0!

    Featuring more than 100 (mostly small) improvements, the biggest being a one-piece integrated double-sheer & angled steering arm--to--wheel hub--to--brake caliper cut via CNC from billet steel to form a 100% solid lower knuckle assembly. Something I couldn't say before is that my original design called for a one-piece CNC billet steel lower assembly but due to time constraints imposed by the King Of The Hammers competition, I had to scramble and whip-up hand-welded plate-steel components which left much to be desired.

    I have also greatly increased strength at the LCA uniball area, with even a bit more strength landing with V3.0.

    [​IMG]

    [​IMG]

    [​IMG]

    Manufacturing for V2.0 was also greatly aided by using full one-piece jigs I designed & created for all six components: D/P LCA, D/P UCA, & D/P HD Knuckle. As a result, despite about a final 20 remaining (mostly small) issues, Rocky and I finished V2.0 in only TWO days as opposed to the nearly 30 days it took to build V1.0 free-hand with the countless issues a first prototype yields.

    As RCLT HD stands currently, I am nearly finished with V3.0 which I am 90% confident will be the final prototype before we make the major shift towards full production.

    Prototype V3.0 is already past Feature Lock with the largest improvements being an enclosed LCA V-Groove saddle (eliminates the need for water drain holes), stronger limit strap mount, dual shock mount (which has been a royal pain in the ass to design on an angled LCA designed for maximum ground clearance), and equipping the 7/8" TREs with larger 5/8" hardware (V2.0 shown here is running 7/8" heims with 1/2" hardware, which is 126% stronger than the single-sheer factory TRE, but we can achieve +253% at no extra cost so whynot).

    [​IMG]

    [​IMG]

    I reached Feature Lock for V2.0 two months ago and looking at these pictures now makes me sick to think of all the issues V1.0 had... Such an inordinate amount of work to get to this point and we're only on the second prototype. This project has been no joke folks and it has taken a lot of time, energy, and money to get this far. I'll probably cry the first time I see a kit out in the wild haha It's ridiculous but true :p

    [​IMG]

    Last edited: May 17, 2019
  19. May 17, 2019 at 7:22 AM
    #279
    BigMike

    BigMike [OP] Applied common sense Vendor

    Joined:
    Apr 2, 2014
    Member:
    #126847
    Messages:
    1,153
    Gender:
    Male
    Fresno, CA
    Vehicle:
    2016 56-speed 580:1 Triple Marlin Crawler-equipped TRD Sport
    Late April, 2019: RCLT HD Prototype V2.0 is installed! (continued)

    Out with the old, in with the new! We are now an OFFICIAL Radflo distributor!! Please give us a call if you're in the area or looking for a deal on Radflo suspension products! (559) 25-CRAWL / 559-252-7295

    These are custom designed and optimized for RCLT and we will be offering them once things go into production. That said however, other LT coilovers should be compatible so long as they have an upper heim joint mount.

    [​IMG]

    SWOOOOON!

    [​IMG]

    DOUBLE SWOOOOON!

    Check out how the axle shaft runs nearly in-line with the lower shock mount at near full down-travel. I love how everything comes together to work as one with RCLT's design!

    The amount of downtravel being demonstrated here wasn't remotely possible with RCLT HD V1.0; So many issues resolved with V2.0. That said, V2.0 still has not yet realized the full downtravel capability of RCLT HD :eek: :eek:

    This is also the improved V2.0 MarRack design (Heavy Duty Rock Crawling Steering) that was featured in this year's King Of The Hammers competition :D :D

    [​IMG]

    Front axle pushed forward yet another inch over the initial prototype LT setup I've been running since July 2017! Great Scott! Has it been that long...

    Speaking of which, the former Long Travel Kit I've been running since 2017... honestly... was a huge pile of crap. I had NO idea how bad it was until I began comparing measurements with what I am doing.

    This is why I wrote, GOOD RIDDANCE, and I CANNOT WAIT to finally experience RCLT HD myself!!!

    [​IMG]

    hoverlover, Alesimo, Hawk373 and 4 others like this.
  20. May 17, 2019 at 7:22 AM
    #280
    BigMike

    BigMike [OP] Applied common sense Vendor

    Joined:
    Apr 2, 2014
    Member:
    #126847
    Messages:
    1,153
    Gender:
    Male
    Fresno, CA
    Vehicle:
    2016 56-speed 580:1 Triple Marlin Crawler-equipped TRD Sport
    April 30, 2019: RCLT HD Prototype V2.0 is installed! (continued)

    RCLT HD V2.0 IS ALIVE!!!!!!!

    [​IMG]

    OHHHHH MAN!!!!!!!! I AM SO EXCITED ABOUT THIS!!!!

    THE FIRST OF ITS KIND EVER INSTALLED INTO A TACOMA!!!!!!!

    THE ONLY BOLT-ON IFS SYSTEM STRONG ENOUGH TO

    ROCK CRAWL WITH 40" TIRES AND TRIPLE T/CASE!!

    COME ON NOW!!!!!!!!!! LET'SSS GOOOOOO!!!!!!!!!!


    Testing it on my wild daily driver Rock Crawler setup means it's gonna be bullet proof for everyone else

    Just driving it out to the dirt area next to our building and I was CrAzY eXcItEd!!!

    [​IMG]

    [​IMG]

    [​IMG]

    Updated pic with my Supercharged 6spd MR2 <3

    [​IMG]

    Finally my front IFS is at least as wide and hopefully wider than the rear. This has been bugging the heck out of me for a long time as I feel Rock Crawlers should always have a wider front than rear to prevent clipping objects during sharp low-speed trail cornering.

    So the front end is now our new & unique +2.75" mid-range Long Travel wider per side, which is +5.50" wider than factory. Right in the middle of +2" & +3.5".
    ..and for the rear I have 1.25" wheel spacers on each side which is +2.50" wider than factory

    Honestly it only looks so wide because I've removed the factory flares. In my opinion the bodies on these "midsize" trucks are just so freak'n wide it's long past ridiculous Toyota, seriously...

    [​IMG]

    hoverlover, Zam15, bayrak and 5 others like this.
