Need help finding a rocker switch for fog lights

Discussion in '2nd Gen. Tacomas (2005-2015)' started by TacoFMS, Nov 30, 2010.

  1. Nov 30, 2010 at 8:14 AM
    #1
    TacoFMS

    TacoFMS [OP] Bubble bubble bubble pop

    Joined:
    Jan 24, 2010
    Member:
    #29938
    Messages:
    5,776
    Gender:
    Male
    First Name:
    Justin
    Louisa County, VA
    Vehicle:
    Just another grocery getter
    One or two things modded... Check out the build
    Hey im getting ready to mount up some PIAA lights on my bull bar and dont like the switch that comes with the kit. Ive seen a switch out there that is supposedly a factory part but have yet to find out how or where to get/order it from. everyone just says it was around 14 dollars shipped to their door but not how to get it shipped to their door. If anyone has any info on this I would greatly appreciate the help.

    Thanks in advance.

  2. Nov 30, 2010 at 8:18 AM
    #2
    davidpick

    davidpick NWXPDTN

    Joined:
    Jan 21, 2010
    Member:
    #29760
    Messages:
    2,238
    Gender:
    Male
    First Name:
    David
    Everett, WA
    Vehicle:
    2004 Xcab 4x4 TRD
    i used this switch (toyota part #00550-35976). my local dealer had it in stock. cost me $18 after tax. it's a little steep, but i wanted something oem.

  3. Nov 30, 2010 at 8:41 AM
    #3
    borderbrat

    borderbrat Watching Chris4x4 o.O

    Joined:
    Nov 15, 2007
    Member:
    #3480
    Messages:
    2,486
    Gender:
    Male
    First Name:
    Jeremy
    Victoria BC, Canada
    Vehicle:
    2008, Black sand pearl, SR5, 4X4
    PIAA fogs, led "puddle" lights, bed lights, in cab 115V, Toyota Devil emblem, Randy Ellis light bar with Hella Black Magics, OME 885 and Dakar leaf springs OME shock all round, 2.5 Gal OBA system with air horns, iPod adapter, scangauge on blend mount, magnaflow catback, bike fork mounts, tinted 2009 tails.
  4. Nov 30, 2010 at 9:30 AM
    #4
    warpwr

    warpwr Junior Senior Member

    Joined:
    Aug 4, 2009
    Member:
    #20667
    Messages:
    177
    Gender:
    Male
    First Name:
    Vaughn
    S.F. Bay Area
    Vehicle:
    09 Sport Access Cab
    DRL mod with switch, rear spring TSB, trans TSB, tailgate mod, snug-top shell.
    This is the switch I used for the DRL mod. Maybe you can use one for fog lights.
    Parts I got from local dealer and www.toyotapart.com , they had pretty good pricing I thought but shipping will bring up the price.

  5. Dec 1, 2010 at 9:18 AM
    #5
    TacoFMS

    TacoFMS [OP] Bubble bubble bubble pop

    Joined:
    Jan 24, 2010
    Member:
    #29938
    Messages:
    5,776
    Gender:
    Male
    First Name:
    Justin
    Louisa County, VA
    Vehicle:
    Just another grocery getter
    One or two things modded... Check out the build
    Hey David, that switch you used. Is that just a simple two wire hookup? just wondering, Im leaning more towards that one. Was wanting something that I dont have to do a lot of splicing and tracking down other wires for. not real fond of cutting into other wires for my truck mainly bc of lack of confidence. also that will fit directly into a knockout that is already in the truck correct?

  6. Dec 1, 2010 at 10:16 AM
    #6
    RZRob

    RZRob Well-Known Member

    Joined:
    Dec 9, 2009
    Member:
    #27315
    Messages:
    518
    Gender:
    Male
    First Name:
    Robert
    Anaheim Hills
    I used the same switch as David and it's nice because it's illuminated when the lights are ON. It's not quite a direct plug-in, you'll need to do a tiny bit of subtle filing. Also, wiring it is pretty easy, although it's got 3 contacts as it needs power to illuminate.

    BTW, this was the OEM switch in my '88 Toyota. While the rounded edges aren't the same as the other current switches, the illumination is worth it to me.

    RZ Rob

  7. Dec 1, 2010 at 10:20 AM
    #7
    Di Trut

    Di Trut Well-Known Member

    Joined:
    Sep 22, 2010
    Member:
    #43675
    Messages:
    87
    Gender:
    Male
    that cheap factory switch is for the 1st gen tacomas, it doens't match the switches for the 2nd gens. the 2nd gen one is an oem part only right now, and online i remember seeing them for 50-60 bucks.

  8. Dec 1, 2010 at 10:46 AM
    #8
    TacoFMS

    TacoFMS [OP] Bubble bubble bubble pop

    Joined:
    Jan 24, 2010
    Member:
    #29938
    Messages:
    5,776
    Gender:
    Male
    First Name:
    Justin
    Louisa County, VA
    Vehicle:
    Just another grocery getter
    One or two things modded... Check out the build
    ok so I guess the main question i have left is when i get the kit in (PIAA 540 complete kit for the bull bar) will it have 3 wires goin to the switch or does anyone know. also if not if it is only a hot and a relay do i just pick up a ground somewhere else or am i just totally confused?????

  9. Dec 1, 2010 at 10:50 AM
    #9
    TacoFMS

    TacoFMS [OP] Bubble bubble bubble pop

    Joined:
    Jan 24, 2010
    Member:
    #29938
    Messages:
    5,776
    Gender:
    Male
    First Name:
    Justin
    Louisa County, VA
    Vehicle:
    Just another grocery getter
    One or two things modded... Check out the build
    by the way RZRob is that a yorkie wearing a helmet on your name tag??? just wondering if i might need to get my yorkie a helmet too.

  10. Dec 1, 2010 at 10:53 AM
    #10
    TacoFMS

    TacoFMS [OP] Bubble bubble bubble pop

    Joined:
    Jan 24, 2010
    Member:
    #29938
    Messages:
    5,776
    Gender:
    Male
    First Name:
    Justin
    Louisa County, VA
    Vehicle:
    Just another grocery getter
    One or two things modded... Check out the build
    the switches that match the factory 2nd gen that i have seen look like they have pigtail conections on the backs. i dont really know what to do with a pigtail connector and kinda liked the "cheap 1st gen switch" better because of the blade style connection. not to mention that fact taht i kinda dont want it to be the exact same thing as my regular fog light switch. for fear of confusion if my girlfriend or someone else ever gets the truck. i want it to look stock aftermarket if that makes sense??

  11. Dec 1, 2010 at 11:15 AM
    #11
    RZRob

    RZRob Well-Known Member

    Joined:
    Dec 9, 2009
    Member:
    #27315
    Messages:
    518
    Gender:
    Male
    First Name:
    Robert
    Anaheim Hills
    Yes that's one of my wife's Bebe wearing a minature helmet. She doesn't like the helmet, but loves riding on our motorcycles or scooters.

    RZ Rob

    [​IMG]

  12. Dec 1, 2010 at 2:34 PM
    #12
    Di Trut

    Di Trut Well-Known Member

    Joined:
    Sep 22, 2010
    Member:
    #43675
    Messages:
    87
    Gender:
    Male
    check this thread. there are a few different styles of switch that came of fj's that you can use. and there are a few install links in there if you need help wiring.

    http://www.fjcruiserforums.com/foru...discounted-oem-aux-offroad-switch-setups.html

  13. Dec 1, 2010 at 2:54 PM
    #13
    davidpick

    davidpick NWXPDTN

    Joined:
    Jan 21, 2010
    Member:
    #29760
    Messages:
    2,238
    Gender:
    Male
    First Name:
    David
    Everett, WA
    Vehicle:
    2004 Xcab 4x4 TRD
    Justin, yep basically a two wire hookup (power coming in on one prong, power going out on the other). the third prong goes to ground (i.e. the truck frame) and that makes the led status light turn on when the switch is in the "on" position.

    lemme know if you have any other questions!
