Need help identifying sensor please.

Discussion in '3rd Gen. Tacomas (2016-2023)' started by scoopdaloop, Feb 19, 2020.

Post Reply

Page 2 of 2

Mar 8, 2020 at 8:07 PM

#21

#21
caribe makaira Well-Known Member

Joined:

Feb 13, 2011

Member:

#51121

Messages:

11,785

Gender:

Male

Caribbean, Puerto Rico

Vehicle:

05 PreRunner TRD Offroad AutoTrans

Hood Struts, My version Fogs always ON, Map & Overhead Light Mod,

scoopdaloop[OP] said: ↑

So here is what happens if you mess up the wiring going into the camshaft position sensor... its $900 from the dealer because they don't sell the small 3 pin connector by itself... its apart of a bigger wiring harness. Shocker.

Dorman Part # 645-744 is the same 3 pin connector. It was $30. Just splice and solder. All codes went away and it starts right up.

Thanks for help
Click to expand...

caribe makaira, Mar 8, 2020

#21

Canufixit, MannyS, scoopdaloop[QUOTED][OP] and 1 other person like this.
