No rear diff lock over 5mph?

Discussion in '2nd Gen. Tacomas (2005-2015)' started by rbeech, Feb 7, 2009.

  1. Feb 7, 2009 at 9:51 AM
    #1
    rbeech

    rbeech [OP] Member

    Joined:
    Feb 5, 2009
    Member:
    #13312
    Messages:
    5
    Gender:
    Male
    Idyllwild
    Vehicle:
    05 PreRunner TRD OR
    I'm new to the board. Just bought a used 05 2wd Prerunner OR-TRD. Thought the rear locker would help in the snow but the manual says not to exceed 5mph. I've seen mixed opinions on other posts. Some say you just need to be under 5mph to engage but it's ok to go faster. Others say it is just for crawling or escaping a ditch etc. Not that I would need to go 50, but 5mph would tend to hold up other traffic. Or just chain up and not worry about it?

  2. Feb 7, 2009 at 9:53 AM
    #2
    Delmarva

    Delmarva Mayor of TW

    Joined:
    Oct 22, 2008
    Member:
    #10148
    Messages:
    35,859
    Gender:
    Male
    First Name:
    Mike
    Tucson, AZ
    Vehicle:
    12 Tundra TRDRW
    Nada, Zip, Zilch, Nothing
    Engage under 5 mph... drive as normal.

  3. Feb 7, 2009 at 10:28 AM
    #3
    rbeech

    rbeech [OP] Member

    Joined:
    Feb 5, 2009
    Member:
    #13312
    Messages:
    5
    Gender:
    Male
    Idyllwild
    Vehicle:
    05 PreRunner TRD OR
    I must have misread the manual. Newbie error.

  4. Feb 7, 2009 at 10:30 AM
    #4
    TacoNut

    TacoNut IgnoringChrisWatchingEdLi veVicariouslyThroughMJP2

    Joined:
    Mar 29, 2008
    Member:
    #5597
    Messages:
    5,243
    Gender:
    Male
    First Name:
    Adam
    Denver, Co
    Vehicle:
    16 TRD OR DCSB Quicksand
    the manual doesn't say it (thank you lawyers) but you can go however you'd like..

    BUT please practice with it in an empty snowy parking lot 1st!

  5. Feb 7, 2009 at 10:34 AM
    #5
    sonjay

    sonjay Well-Known Member

    Joined:
    Oct 9, 2008
    Member:
    #9834
    Messages:
    699
    Gender:
    Male
    With the rear locked it will handle very different then without. Like TacoNut said, try it out slow in a parking lot first, just to get the feel for how it handles while locked!

  6. Feb 7, 2009 at 10:36 AM
    #6
    Khaos

    Khaos Big Member

    Joined:
    Feb 4, 2008
    Member:
    #4570
    Messages:
    6,495
    Gender:
    Male
    First Name:
    Bryant
    Tallahassee FL
    Vehicle:
    2005 Prerunner TRD Off Road
    265/75/16 BFG A/T, 18" Magnaflow, K&N Intake Filter, Ultra-Gauge, Kobalt Toolbox, Metal Tail Light Guards, Cobra 19 and 4ft fiberglass antenna, Plasti dipped Badges/lower valance/rear bumper/grill/bullbar/ac controls, black DIN kit, JVC KD-X40, Wet Suit Seat Covers
    Dont use the locker on pavement. Take it out on a dirt road/parking lot/whatever if you can't take it off road.

  7. Jan 27, 2011 at 7:05 PM
    #7
    TACK

    TACK Well-Known Member

    Joined:
    Aug 16, 2010
    Member:
    #41804
    Messages:
    512
    Gender:
    Male
    Nevada
    Vehicle:
    10 PreRunner TRD Off-Road MGM
    Bilstein 5100s at 1.75", Level 8 Tracker wheels, Sickspeed shift knob, mud flap delete, white lithium grease mod for creaky clutch pedal
    Sorry for bumping an old thread, but I'm looking at my manual right now and it says to only engage the locker while stopped, and it also says "do not drive over 5 mph when the differential is locked".

    So...is this bullshit or not? Has anyone gone over 5 mph with the diff locked? Did your diff explode?

  8. Jan 27, 2011 at 7:09 PM
    #8
    TACK

    TACK Well-Known Member

    Joined:
    Aug 16, 2010
    Member:
    #41804
    Messages:
    512
    Gender:
    Male
    Nevada
    Vehicle:
    10 PreRunner TRD Off-Road MGM
    Bilstein 5100s at 1.75", Level 8 Tracker wheels, Sickspeed shift knob, mud flap delete, white lithium grease mod for creaky clutch pedal
    Gotcha. Should've figured it would be a stupid liability thing.

  9. Jan 27, 2011 at 10:56 PM
    #9
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,982
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    It is for Emergency use only (to get unstuck or through difficult terrain).

    It should be turned of as soon as you don't need it.

    Lockers make steering difficult so the 5 mph speed limit suggestion... Less chance of you hitting a tree or going off a cliff!

    Don't you have the same sticker as I do?

    [​IMG]

  10. Jan 27, 2011 at 11:09 PM
    #10
    Unknown

    Unknown He who angers you conquers you

    Joined:
    Apr 18, 2010
    Member:
    #35554
    Messages:
    8,158
    Gender:
    Male
    First Name:
    Brian
    Los Angeles
    Vehicle:
    Unknown
    Unknown
  11. Jan 27, 2011 at 11:23 PM
    #11
    Matic

    Matic Locked and Lifted "02" DC TRD.

    Joined:
    Sep 8, 2009
    Member:
    #22436
    Messages:
    12,277
    Gender:
    Male
    First Name:
    Rich
    Greenville,sc
    Vehicle:
    2002 TRD prerunner,SR5, doublecab
    OME 881 coils with OME nitrochargers shocks up front. TC UCA's OME Dakars with extra leaf in the rear. Warn 8000 winch with 80ft custom braided synth line. Custom 60ft synth extension. All pro tube bumper, Hi-lift jack, Safari Snorkel, Wilco tiregate.
    How is the rear locker engaged going to affect his steering? Did I miss something in auto mechanics 27 yrs ago?

  12. Jan 27, 2011 at 11:24 PM
    #12
    Matic

    Matic Locked and Lifted "02" DC TRD.

    Joined:
    Sep 8, 2009
    Member:
    #22436
    Messages:
    12,277
    Gender:
    Male
    First Name:
    Rich
    Greenville,sc
    Vehicle:
    2002 TRD prerunner,SR5, doublecab
    OME 881 coils with OME nitrochargers shocks up front. TC UCA's OME Dakars with extra leaf in the rear. Warn 8000 winch with 80ft custom braided synth line. Custom 60ft synth extension. All pro tube bumper, Hi-lift jack, Safari Snorkel, Wilco tiregate.
    Wth? I did not post that picture.

  13. Jan 27, 2011 at 11:24 PM
    #13
    A7XTaco

    A7XTaco Member

    Joined:
    Sep 20, 2010
    Member:
    #43543
    Messages:
    1,069
    Gender:
    Male
    First Name:
    Bryan
    Austin, TX
    Vehicle:
    You don't want to know...
    "Poor owner of this vehicle"? sounds like it wasn't his...

    And that's why you never let your truck out of sight when its in the shop!

  14. Jan 27, 2011 at 11:32 PM
    #14
    Matic

    Matic Locked and Lifted "02" DC TRD.

    Joined:
    Sep 8, 2009
    Member:
    #22436
    Messages:
    12,277
    Gender:
    Male
    First Name:
    Rich
    Greenville,sc
    Vehicle:
    2002 TRD prerunner,SR5, doublecab
    OME 881 coils with OME nitrochargers shocks up front. TC UCA's OME Dakars with extra leaf in the rear. Warn 8000 winch with 80ft custom braided synth line. Custom 60ft synth extension. All pro tube bumper, Hi-lift jack, Safari Snorkel, Wilco tiregate.
    Carefull. Cornering control and large steering effort are entirely 2 different things.
    I can see Carefull cornering control might be an issue. Well.......not really for me, I have the 4 banger.
    However large steering effort seems a bit far fetched. Over or understeer happens after the fact, not during.

    Edit: over or undercorrecting.

  15. Jan 28, 2011 at 10:12 AM
    #15
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,982
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags

    Oh really? Gee thanks, but I never said that! :rolleyes:

    Okay... basic differential mechanics 101...

    When turning a vehicle each tire rotates at a different speed.:cool:

    The differential (when open/ normal) allows this.;)

    If locked, no differential (different) rotation is possible (between the left and right tires). Steering is naturally affected and more difficult. Lockers make the truck want to go straight.:eek:

    If a differential wasn't needed, then there wouldn't be one on vehicles.:rolleyes:

    Taking away the differential temporarily (with the locker) is for increased traction where needed to get through a problem area... :p

    There is no need or reason to have a locked differentail when the truck isn't stuck or struggling to cross or climb anything.;)

    Yes it will work over 5 mph, Toyota says not to... to save you from crashing if you are someone who thinks driving with it locked on dry roads is okay.:eek:

    You guys who know it all, just ignore my posts... I am trying to help those who seriously want to know more about their truck... but still have some fun... I am not trying to pi## any of you off. Sorry if I have!:eek:

  16. Jan 28, 2011 at 10:20 AM
    #16
    blackhawke88

    blackhawke88 wo ai ni bao bei ^_^

    Joined:
    Jan 11, 2009
    Member:
    #12478
    Messages:
    16,670
    Gender:
    Male
    SGV, CA
    Vehicle:
    07 TRD Offroad
    i've gone around 60 in the dirt with my rear locked multiple times, it's fine

  17. Jan 28, 2011 at 10:28 AM
    #17
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,982
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    I am sure it is... So, are you saying your truck wouldn't go around 60 without it being locked?

    The point is, the rear locker is a 'tool' for more traction if one of your tires is over slush or in the air... Open differential will have the loose tire spin, and you are stuck. Lock out the differentail and the power is split equally between the two tires... and you move on if the other tire is on firmer ground.

    If you are driving 60, I don't think you would be stuck unless one side of your truck was in a lake and the other on a highway!

    You are using a tool when nothing needs 'fixing'... that's all.

  18. Jan 28, 2011 at 10:31 AM
    #18
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,982
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    Have a nice day Lrgnr!

  19. Jan 28, 2011 at 10:31 AM
    #19
    chris4x4

    chris4x4 With sufficient thrust, pigs fly just fine. Moderator

    Joined:
    May 8, 2008
    Member:
    #6497
    Messages:
    106,160
    Gender:
    Male
    First Name:
    FlimFlubberJAM
    Tenoe, AZ
    Vehicle:
    2013 Rubicon Unlimited,
    4.10 gears, sliders, and lots of buttons.
  20. Jan 28, 2011 at 10:33 AM
    #20
    blackhawke88

    blackhawke88 wo ai ni bao bei ^_^

    Joined:
    Jan 11, 2009
    Member:
    #12478
    Messages:
    16,670
    Gender:
    Male
    SGV, CA
    Vehicle:
    07 TRD Offroad
    I find it corners a lot better in the dirt with the rear locked, night and day from before i did the rear locker anytime mod

    EDIT: more controllable over-steer as opposed to scary understeer
