No TPMS in a 2023 Toyota Tacoma?

Discussion in '3rd Gen. Tacomas (2016-2023)' started by BulletProofKarma, Nov 28, 2023.

  1. Nov 28, 2023 at 7:07 AM
    #1
    BulletProofKarma

    BulletProofKarma [OP] Active Member

    Joined:
    Nov 30, 2022
    Member:
    #411911
    Messages:
    25
    Nothing on the display, no picture of truck with tire pressures indicated, no problems replacing tires with AT tires.
    I bought a base model, is it possible that TPMS is not a feature on the base model? Went through my manual and there is nothing in it about TPMS.

    Which frankly I would love as I want new wheels.

  2. Nov 28, 2023 at 7:11 AM
    #2
    Mbtstaco

    Mbtstaco Well-Known Member

    Joined:
    Jan 20, 2022
    Member:
    #387909
    Messages:
    746
    Vehicle:
    2023 Tacoma Pro MGM
    I thought all new cars had to have it but I could be wrong. Just change the rims doesn't matter either way.

    BulletProofKarma[OP] likes this.
  3. Nov 28, 2023 at 7:13 AM
    #3
    fourfourone

    fourfourone Well-Known Member

    Joined:
    Mar 12, 2020
    Member:
    #321977
    Messages:
    3,179
    Gender:
    Male
    Vehicle:
    2015 TRD sport(sold) 2023 Tacoma
    It has TPMS. Just not the fancy set up the higher trims have. Yours simply just have a light that comes on if a tire goes low.

    mtip, TheDanimal, jmneill and 2 others like this.
  4. Nov 28, 2023 at 7:13 AM
    #4
    BulletProofKarma

    BulletProofKarma [OP] Active Member

    Joined:
    Nov 30, 2022
    Member:
    #411911
    Messages:
    25
    It does, I'm one of those people that goes nuts if a warning light is blinking even if I know it means nothing, and tape doesn't keep me from knowing.
    Another reason I want to know is the local dealership here told me I would need all new sensors when I went to purchase wheels from them, and of course a charge for programming on top of that.

  5. Nov 28, 2023 at 7:16 AM
    #5
    ace96

    ace96 Well-Known Member

    Joined:
    Sep 1, 2010
    Member:
    #42591
    Messages:
    3,822
    Gender:
    Male
    Western KY
    Vehicle:
    '11 SWB DC TRD SPORT
    AVS bug deflector, Weathertech digital fit floor mats, TRD skid plate w/ Sockmonkey decal, SOS Cocept sliders w/ Line-x, Pioneer 3500, Hybrid Audio Technology Mirus 6X9s & 6.5s, back up cam mod, Wet Okoles-front & rear, TRD exhaust, 17X9 XD Spy w/ Falken Wildpeaks, Avid light bar
    Correct. It’s a requirement after the Ford Explorer fiasco.

    OP there are different sensors for steel and alloy wheels.

    SR-71A and Mbtstaco[QUOTED] like this.
  6. Nov 28, 2023 at 7:18 AM
    #6
    Mbtstaco

    Mbtstaco Well-Known Member

    Joined:
    Jan 20, 2022
    Member:
    #387909
    Messages:
    746
    Vehicle:
    2023 Tacoma Pro MGM
    Try a tire shop and ask if they can be swapped onto the new rims. Maybe cheaper just to have new sensors at an independent shop. Most major tire places can program them. In my area town fair tire is the big one but they will only install new ones.

    ace96 likes this.
  7. Nov 28, 2023 at 7:18 AM
    #7
    SomeTacoDude

    SomeTacoDude Well-Known Member

    Joined:
    Oct 29, 2023
    Member:
    #436422
    Messages:
    463
    Gender:
    Male
    You don't have to do that. You can get aftermarket sensors and clone them to your old ones so the truck won't know the difference.

  8. Nov 28, 2023 at 7:18 AM
    #8
    fourfourone

    fourfourone Well-Known Member

    Joined:
    Mar 12, 2020
    Member:
    #321977
    Messages:
    3,179
    Gender:
    Male
    Vehicle:
    2015 TRD sport(sold) 2023 Tacoma
    If you have steel wheels and want to go alloy, you need new sensors for the new wheels and then have them programmed. Go to a tire shop. The dealer is gonna want big money to do it.

  9. Nov 28, 2023 at 7:18 AM
    #9
    BulletProofKarma

    BulletProofKarma [OP] Active Member

    Joined:
    Nov 30, 2022
    Member:
    #411911
    Messages:
    25
    Yes I'm aware, but if you have TPMS isn't there a display on the MIC (console)? There is no display for this truck, there is nothing in the manual about TPMS, and the toyota site doesn't tell me anything either.

  10. Nov 28, 2023 at 7:19 AM
    #10
    BulletProofKarma

    BulletProofKarma [OP] Active Member

    Joined:
    Nov 30, 2022
    Member:
    #411911
    Messages:
    25
    Then if I let some air out it should pop a warning light?

  11. Nov 28, 2023 at 7:20 AM
    #11
    fourfourone

    fourfourone Well-Known Member

    Joined:
    Mar 12, 2020
    Member:
    #321977
    Messages:
    3,179
    Gender:
    Male
    Vehicle:
    2015 TRD sport(sold) 2023 Tacoma
    You would have to drive for a little while but yes it will turn on.

  12. Nov 28, 2023 at 7:21 AM
    #12
    BulletProofKarma

    BulletProofKarma [OP] Active Member

    Joined:
    Nov 30, 2022
    Member:
    #411911
    Messages:
    25
    OK thanks people, I think I can see where they would put the TPMS in but the firmware doesn't give the pretty display of your tire pressures, it just lights up a light on your dash.

  13. Nov 28, 2023 at 7:23 AM
    #13
    Rock Lobster

    Rock Lobster Thread Derailer

    Joined:
    Dec 14, 2018
    Member:
    #275833
    Messages:
    13,429
    Gender:
    Male
    First Name:
    Ryan
    Dee Eff Dub
    Vehicle:
    I drive a Miata.
    TPMS will show up on the instrument display (between speedo and tach.) Some models of SR trim do not have this display, therefore the TPMS would be warning light only in those.

  14. Nov 28, 2023 at 7:24 AM
    #14
    SR-71A

    SR-71A Define "Well-Known Member"

    Joined:
    Jun 1, 2018
    Member:
    #255145
    Messages:
    7,892
    Gender:
    Male
    First Name:
    Zack
    Southern Maine
    Vehicle:
    2012 DCSB, TX Baja Edition. Barcelona Red
    255/85/R16 Falken Wildpeak MTs, Mobtown sliders, ARB bar, SOS front skid, Icon RXT leafs, extended & adjustable Kings, JBA UCAs, OVS wedge RTT, dual AGM batteries, Gen2 xrc9.5 winch, CB, GMRS, S1 ditch lights...
    Go for a quick drive to wake up the sensors. Come back and drop one tire down to 15psi. Check the dash. Air back up

    BulletProofKarma[OP] likes this.
  15. Nov 28, 2023 at 7:44 AM
    #15
    mit88

    mit88 Well-Known Member

    Joined:
    Oct 5, 2009
    Member:
    #23837
    Messages:
    2,257
    Gender:
    Male
    Planet earth
    Yep, it should come on if the truck was equipped. I believe the air pressure has to drops below 25 percent of the recommended manufacturer number located on your vehicle's door placard to get the the system triggers the warning light.

    BulletProofKarma[OP] likes this.
  16. Nov 28, 2023 at 7:50 AM
    #16
    Chew

    Chew Not so well known user

    Joined:
    Mar 6, 2019
    Member:
    #285575
    Messages:
    8,434
    Gender:
    Male
    First Name:
    Chewy
    Midwest
    Vehicle:
    19 TRD OR
    Amazon dog poo bed mat mod
    Correct, you bought the base model, so you don't have the information screen,,, jus the idiot-light




    BulletProofKarma[OP] likes this.
  17. Nov 28, 2023 at 7:55 AM
    #17
    ace96

    ace96 Well-Known Member

    Joined:
    Sep 1, 2010
    Member:
    #42591
    Messages:
    3,822
    Gender:
    Male
    Western KY
    Vehicle:
    '11 SWB DC TRD SPORT
    AVS bug deflector, Weathertech digital fit floor mats, TRD skid plate w/ Sockmonkey decal, SOS Cocept sliders w/ Line-x, Pioneer 3500, Hybrid Audio Technology Mirus 6X9s & 6.5s, back up cam mod, Wet Okoles-front & rear, TRD exhaust, 17X9 XD Spy w/ Falken Wildpeaks, Avid light bar

    OP a little background on TPMS.

    “The TREAD (Transportation Recall Enhancement, Accountability and Documentation) Act was signed into United States Federal Law in the fall of 2000 and requires all vehicles manufactured on or after September 1, 2007 to be equipped with a tire pressure monitoring system.”

    This all came about after the Ford/Firestone fiasco.

  18. Nov 28, 2023 at 7:56 AM
    #18
    Finn-2187

    Finn-2187 Well-Known Member

    Joined:
    Nov 28, 2021
    Member:
    #383254
    Messages:
    204
    Vehicle:
    2021 White Tacoma SR 4x4 DCSB
    Fog lights, Vision Turbine 16x8 wheels, Goodyear Wrangler Ultraterrain 265/75/r16 AT's, janky LEDs that probably won't catch on fire
    With the SR (at least with my 2021) you can get the readout of individual tire pressures in the Toyota app, but only if you pay for their service subscription thing. It was active for mine during the free trial after buying the truck and it's been an absent feature since the trial expired.

    BulletProofKarma[OP] and RIX TUX like this.
  19. Nov 28, 2023 at 7:57 AM
    #19
    Rock Lobster

    Rock Lobster Thread Derailer

    Joined:
    Dec 14, 2018
    Member:
    #275833
    Messages:
    13,429
    Gender:
    Male
    First Name:
    Ryan
    Dee Eff Dub
    Vehicle:
    I drive a Miata.

    It's been a requirement in the US since 2005, starting with all 2008 model year passenger vehicles.

    I have heard that it is not a requirement in vehicles sold in Canada, surprisingly. The country that requires a warning if you are out of windshield fluid does not have regulations on tire pressures.

  20. Nov 28, 2023 at 1:39 PM
    #20
    Nirango kid

    Nirango kid Well-Known Member

    Joined:
    Jun 17, 2021
    Member:
    #368856
    Messages:
    1,635
    Gender:
    Male
    First Name:
    Gilles
    Ontario
    Vehicle:
    2021 Tacoma TRD Sport Premium in Barcelona Red
    I have them on my Sport and hate them cause everytime one tire is lower than the other light comes on. I men 2 psi less is not a warning but a pain in the ass. I reset the TPMS and it goes away. I notice it more as the cold weather comes. I have 30 during the summer they go up to 36-38. This cold weather they down at 26-27 just confusing. just saying.

    BulletProofKarma[OP] likes this.
