Coming home over the pass from Cle Elum a couple weeks ago, I was in 4 wheel drive on the highway with rain/patchy ice conditions and the transfer case started binding and grinding hard. Large bang before I could take it out. Once home I tried in the driveway and it’s locked up! Never had this happen before, but it’s the first time I’ve used 4 wheel drive since swapping to 4.88’s and a Detroit in the front. I should have been smarter than to run it at 70 down the freeway.



Certainly there are differences between the 1st and 2nd gen but what’s the system state now? Stuck in 4wd, blinking light? Saw a first gen thread talking about vacuum to the front ADD. In my situation it had all been electrical more or less and mostly mechanical components were fine after re-timing all the actuators. You can also apply direct power to all the actuators at 1/2 pins to test but you don’t want to drive them over their valid positions. You can also test the t case actuator sensors, cab switch diodes with diode test, and separately electrical connectors from the wiring harness with an ohmeter I think they should run 12-14v. All the threads I have are relating to the 2nd gen or I would share them as well.

All this was just last month or so of troubleshooting my own system. Most common is the front ADD it seems as a failure component but the cab switch, vacuum line correction, and sensors are cheaper fixes.

You will here your t-case actuator actuating if it’s not toast if you aren’t hearing it and think it is you can double check it with that direct 12v if it’s taking power it’s just out of timing id guess the problem is elsewhere. Seems it’s generally best to start a thread on this since there’s so many avenues it goes down.



Thank you for your time in responding! I don’t believe it’s an actuator issue. It will engage and disengage fine with the button push, but bangs and binds up at the slightest roll of the truck. It ran down the freeway great for probably 30 miles before it had an issue and I’ve ran it countless miles at freeway speeds in the past when it’s been snow and ice conditions. I figure the transfer case was either beginning to fail or there’s something not right with the new gear/locker combo. Although, I don’t know what that issue might be? I’m waiting to have replacement parts before tearing it apart though and now considering some upgrades possibly.



@Shadowhunter recently re-geared up front and I think you could check with him for any insight on orientation and such. As far as I know he hasn’t had any issues yet. Hmmm that is odd, I think digging I have seen broken actuator arms. In your case easiest check may just be to drain a bit of fluid and discover it quick.

Actually I happened to take mine to Toyota for a troubleshoot during all this and they had mentioned even when you’re certain it’s the actuator. Drain the t-case fluid as they have replaced peoples actuators but it was actually the transfer case. Good luck on it I hope it’s one of the cheaper components rather than the whole t-case.



That’s good advice one draining the fluids. If it’s an 02’ a TC probably isn’t too bad in price to buy and its way easier to replace than a front end.



I need to remove it, looks like a broken t-case chain.



Just installed RCI Offroad aluminum transmission and transfer case skids on the truck. Good news, the transfer case crossmember is 100% compatible with BAMF sliders.

I know everyone said "STEEL!" last time I asked about advice on skids...but I just couldn't justify the weight for a daily driver. I'm really trying hard to keep it down, since I still want to add roof racks and a hidden winch mount, and I really don't want to have to replace the Fox suspension. I also don't really wheel hard, this is more for "oopsie" protection when I'm going down a forestry road.

I did have to request an additional hardware pack to get it to work with the OEM front skid, and I lost about an inch or so of clearance there, but small price to pay for the additional protection.



Nice re-route. I need to get mine don't so I can finally put my TC skid on



The guy who did mine did a fantastic job. Unfortunately he moved on from side-project welding shortly after I had mine done, so I consider myself lucky.

TIG welded 2.5" 304 stainless. No kill like overkill.



Been totally happy with my rci aluminum skid. Banged pretty hard a couple times in Moab and held up well. I'd go steel if it was a dedicated rock crawling rig but it isnt



I just asked my bud in Yelm if he has a spare transfer case for 1st gen like mine.



I was gonna suggest the possibility of the chain had broke and wadded up in there.



@JDAM @WrecklessAbandon how much you guys it up there? Trace in own and it melting off rather quick...



Maybe 3 inches. Starting to melt though.



I'm hoping for enough snow to sled dead mans hill before spring



Thank you



He said he has one. DM me and I'll pass your contact info to him



Quick question - I know nothing about welding... At the knuckle, where the manifold connect is, why so many welds? Is it too difficult to shape a piece of pipe at that angle?

Again, just genuinely curious.



I think it is done as a substitute for bending pipe if you don't have the means to do so. And it looks cool.

Reminds me of how high end titanium systems are built



Looks like a compound bend to me. Also a serious flex on the welding skills
