NYCO's '06 Boosted Blue Betty

Discussion in '2nd Gen. Builds (2005-2015)' started by NYCO, May 18, 2011.

  1. Mar 16, 2015 at 6:56 AM
    #4681
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    another update from the weekend...an amazing update :D

    after the install of the clutch and tranny, jace had notice my clutch master cylinder was oozing fluid. so i picked up a OEM master friday and tossed that bad boy in saturday afternoon...

    man it's nice to have a fresh clutch/tranny in working order :woot:

    couple tips for those who ever have to do this...

    #1 hire a midget to do the work
    #2 if no midget is available, take deep breaths as shit will get frustrating working in such a tight spot :D

    procedure
    there's two lines going into the master cylinder, (1) a feeder line coming in from the brake fluid reservoir in the engine bay, rubber (2) the pressure line going from the master down to the slave cylinder on your tranny, driver side

    when you disconnect the pressure line, very little fluid comes out...the feeder line on the other hand will drain onto your floor if you aren't careful..to prevent a mess, put rags or pig mats down in your work space..also clamp off your feeder line to limit the amount of fluid coming out when you disconnect..i clamped off in the engine bay below the reservoir and again inside above the master.

    take out the kick panel to get better access...you will also have to remove your clutch start sensor in order to gain access to the upper mounting bolt on the master

    remove the two bolts holding in the master...carefully loosen and disconnect the pressure line...at this point the master can be moved around a bit easier to gain access to the clamp holding the feeder line onto the master. unclamp and disconnect your feeder...thanks to your clamps, the amount of fluid will be limited coming out...

    get your new master, reconnect the feeder and reposition the clamp...move the master in place and loosely connect the pressure line..put the two bolts back in loosely...snug up your pressure line...tighten down your two bolts...and final tighten on your pressure line

    check for leaks and then bleed the system...the bleeder valve is on the slave cylinder..if you have a tranny skid, it's best to remove it...with somebody pushing down on the clutch, crack the valve til the fluid stops coming out, then close the valve...use a hose and drain pan, or if you have an old 1qt oil bottle, cut a hole in the cap and have your hose drain into it...if you wrap wire around the bottle, you can hang the contraption under your truck as your doing this process (thanks jace!)

    continue this process until all air is out and a nice stream of fluid is coming out...

    then put your dust cap back on your slave valve, reattach your clutch start sensor, put your kick panel back on and enjoy :cheers:

  2. Mar 16, 2015 at 7:17 AM
    #4682
    lotsoftoys

    lotsoftoys pavement is boring....

    Joined:
    Apr 22, 2010
    Member:
    #35790
    Messages:
    7,300
    Gender:
    Male
    First Name:
    Jace
    Denver
    Vehicle:
    98 lifted panda taco
    bunch of crap

    I laughed at steps #1 and #2! nicely done little write up man.

  3. Mar 16, 2015 at 7:21 AM
    #4683
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    :cookiemonster:






    big thanks to you for the work on the clutch/tranny and the helpful tips on the master install :thumbsup:

  4. Mar 17, 2015 at 4:24 PM
    #4684
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    not my video or the clutch i put in, but the crew at Low Range recently put together this how-to on a clutch replacement on an FJ Cruiser that is well put together...

    https://youtu.be/aGlqRJrywbE


    good for future reference

  5. Mar 21, 2015 at 10:35 AM
    #4685
    Drainbung

    Drainbung Somedays you are the show....

    Joined:
    Sep 2, 2010
    Member:
    #42629
    Messages:
    5,289
    Gender:
    Male
    First Name:
    Bob
    Fallon, NV
    Vehicle:
    10 DCLB
    TRD Fleshlight
    Finally got the prefilter installed. Thanks for the legwork Bob.

    [​IMG]

  6. Mar 21, 2015 at 11:12 AM
    #4686
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    :thumbsup:

    glad i could help

  7. Mar 25, 2015 at 12:11 PM
    #4687
    Round II

    Round II Member #12005

    Joined:
    Jan 16, 2012
    Member:
    #70777
    Messages:
    4,991
    Gender:
    Male
    2 months to go....:burnrubber:

  8. Mar 25, 2015 at 12:20 PM
    #4688
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    29 days for our first trip :D

    you coming to moab?

  9. Mar 25, 2015 at 12:35 PM
    #4689
    Round II

    Round II Member #12005

    Joined:
    Jan 16, 2012
    Member:
    #70777
    Messages:
    4,991
    Gender:
    Male
    Lucky dog! I think were gonna skip Mecca this year and spend all 3 week in CO. We should absolutely meet up this year cept this time I wont have gifts not that you need them.:cool:

  10. Mar 25, 2015 at 12:37 PM
    #4690
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    what area you going to be hitting up?

  11. Mar 26, 2015 at 9:23 AM
    #4691
    Round II

    Round II Member #12005

    Joined:
    Jan 16, 2012
    Member:
    #70777
    Messages:
    4,991
    Gender:
    Male
    Pretty much everything near Silverton and then some since we have 3 weeks to muck around. I also plan on doing a lot of fishing as I didn't get to use my CO license all that much last year.

  12. Mar 26, 2015 at 9:38 AM
    #4692
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches

    expect to see snow still...silverton got hit pretty hard this winter...they're showing a 75" base right now...

    some nice areas that could have good fishing would be stony pass, kite lake and heart lake region...it dumps you into the Rio Grande headwater area...not highly traveled...connects the silverton area to lake city area...last time i was going to go through there, fires had the area closed and i couldn't go through...

  13. Mar 26, 2015 at 9:44 AM
    #4693
    Round II

    Round II Member #12005

    Joined:
    Jan 16, 2012
    Member:
    #70777
    Messages:
    4,991
    Gender:
    Male
    Will keep you posted as the dates get closer and who knows we might just make another run on Moab this year? If we do Utah again this go Im gonna hit the canyon lands area a lot and get in some good hiking this time hell might even bring the Mt. bike and run the Whole Enchilada.

  14. Mar 26, 2015 at 10:09 AM
    #4694
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    can't go wrong with that game plan...we're hitting up the maze next month and looking to maybe hit up hell roaring rim and hey joe canyon this year which is just north of where the white rim trail comes back out near mineral bottom


    check out the needles district for some really cool areas to hike into...off elephant hill, trails like the joint trail and others in that area...or in lavender and davis canyon there's really cool shit to see

  15. Mar 26, 2015 at 10:22 AM
    #4695
    Round II

    Round II Member #12005

    Joined:
    Jan 16, 2012
    Member:
    #70777
    Messages:
    4,991
    Gender:
    Male
    The Maze has been on the list for a few years, Hey Joe is fun run that 3 times, also have hiked into the joint that place is cool as all get out.


  16. Mar 26, 2015 at 10:24 AM
    #4696
    Round II

    Round II Member #12005

    Joined:
    Jan 16, 2012
    Member:
    #70777
    Messages:
    4,991
    Gender:
    Male
    Beef basin back side of elephant hill... Man that place is out there for sure!:tumbleweed:


  17. Mar 26, 2015 at 10:43 AM
    #4697
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    view looking the other way is better :cool:

    [​IMG]

  18. Mar 26, 2015 at 11:14 AM
    #4698
    Round II

    Round II Member #12005

    Joined:
    Jan 16, 2012
    Member:
    #70777
    Messages:
    4,991
    Gender:
    Male

  19. Mar 26, 2015 at 11:41 AM
    #4699
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    we came in from the south then through bobby's hole

    [​IMG]

  20. Mar 26, 2015 at 11:44 AM
    #4700
    NYCO

    NYCO [OP] go explore...

    Joined:
    Jul 27, 2010
    Member:
    #40842
    Messages:
    18,401
    Gender:
    Male
    First Name:
    bOb
    Colorado
    Vehicle:
    Blue Betty - '06 TRD OR
    dents & scratches
    but there's definitely beef in the basin
    [​IMG]
