P0174 P0171 Cylinder Misfires on Warm Starts

Discussion in '2nd Gen. Tacomas (2005-2015)' started by Amburgers, Mar 24, 2024.

  1. Mar 24, 2024 at 6:37 PM
    #1
    Amburgers

    Amburgers [OP] Member

    Joined:
    Aug 28, 2012
    Member:
    #85759
    Messages:
    22
    Gender:
    Male
    Florida
    Vehicle:
    2006 SR5 4x4
    I've been sleuthing this too lean air fuel mixture code for over a year now on my 2006 Tacoma, 191,000 miles. On warm starts only I will have cylinder misfires and the truck has died multiple times after startup. I've let it sit for a couple hours then no issue. It's not every warm start, but most times it starts sluggish. Usually after driving for 20-30 minutes then starting it back up 10-15 minutes later. Cold starts in the mornings, never have had an issue. I've checked for vacuum leaks and it tests fine for that. My next best guess is injectors or fuel pump. Anyone else with similar issue? TIA. List below of what I've replaced so far.

    • Ignition Coils
    • Spark Plugs
    • Cleaned Throttle Body
    • Cleaned MAF Sensor
    • Manifold Gaskets
    • PCV Valve

  2. Mar 24, 2024 at 9:37 PM
    #2
    Sethmith

    Sethmith New Member

    Joined:
    Nov 7, 2023
    Member:
    #437053
    Messages:
    1
    Gender:
    Male
    I had this same engine codes but no misfires, roughly 180,000 miles and it ended up being the fuel filter. Cleaned my maf, throttle body, etc and nothing fixed my fuel trims until I swapped the fuel pump. If you've already ensured no vacuum leaks then my bet would be the fuel filter/pump.

    Amburgers[OP] likes this.
  3. Mar 24, 2024 at 9:53 PM
    #3
    Dm93

    Dm93 Test Don't Guess

    Joined:
    Mar 3, 2015
    Member:
    #150066
    Messages:
    10,310
    Gender:
    Male
    Texas
    Vehicle:
    2014 DC OR 6spd 4x4
    Predator tube steps, Ranch Hand grill guard, Magnaflow CatBack exhaust, Toyota tool box & bed mat, 2LO Module by @Up2NoGood, Rearview Compass/Temp Mirror, Tune by @JustDSM.
    Amburgers[OP], TnShooter and Bishop84 like this.
  4. Mar 25, 2024 at 7:45 AM
    #4
    haydendoesmith

    haydendoesmith Well-Known Member

    Joined:
    Oct 9, 2019
    Member:
    #307574
    Messages:
    72
    Vehicle:
    15 DCSB TRD Sport 4X4 Auto
    I had a similar issue on a Scion. When cold, it ran fine. After being driven then parked for 10-20 minutes, it would start up with a miss on cylinder 3 and the CEL would set. Let it sit for several hours and it would start up and ran fine. It turned out to be injector #3.

    The resistance would be in spec (13.5 ohms) when cold. When warm up, the resistance would shoot up in the hundreds of ohms while the others remained in the tens of ohms.

    Amburgers[OP] likes this.
