Power steering issue..WTX is wrong with this..?

Discussion in '2nd Gen. Tacomas (2005-2015)' started by Mr.Tacoma, Oct 19, 2011.

  1. Oct 19, 2011 at 6:08 AM
    #1
    Mr.Tacoma

    Mr.Tacoma [OP] Well-Known Member

    Joined:
    Oct 25, 2010
    Member:
    #45225
    Messages:
    156
    Gender:
    Male
    toronto
    Vehicle:
    DoubleCab4x4
    TRD Exhaust, Side step bar & ARE cap
    It all started with swapping the alternator to HD alt. Thought it was the tensioner that wasnt holding the tension on belt. Got a mechanic to change a new tensioner for me. He took only 1h 20min (??) While driving home it was good lke before. Next day on again same problem. I did top up the ps fluid with toyota when this problem started. It behaves erratic..power goes and comes back. Could this be electrical or may i should flush the fluid/refill...Dealer told me belt is good. :confused:

  2. Oct 19, 2011 at 6:15 AM
    #2
    98tacoma27

    98tacoma27 is gooder 'en chicken Moderator

    Joined:
    Dec 18, 2008
    Member:
    #11714
    Messages:
    49,777
    Gender:
    Male
    First Name:
    Ben
    Beech Creek
    Vehicle:
    05 Tundra SR5 (+250k AND COUNTING), 88 SR5 PU (SOLD), 98 TRD OR (CRUSHED)
    5100's all on fours
    You can try a flush and see what happens. It certainly won't hurt.

  3. Oct 19, 2011 at 6:43 AM
    #3
    maineah

    maineah Well-Known Member

    Joined:
    Mar 24, 2011
    Member:
    #53641
    Messages:
    4,143
    Gender:
    Male
    First Name:
    Tim
    Maine
    Vehicle:
    4X4 SR5 V6 6spd
    I think there is a screen in the tank if the pump is noisy check and see if the screen is plugged up.

  4. Oct 19, 2011 at 7:03 AM
    #4
    98tacoma27

    98tacoma27 is gooder 'en chicken Moderator

    Joined:
    Dec 18, 2008
    Member:
    #11714
    Messages:
    49,777
    Gender:
    Male
    First Name:
    Ben
    Beech Creek
    Vehicle:
    05 Tundra SR5 (+250k AND COUNTING), 88 SR5 PU (SOLD), 98 TRD OR (CRUSHED)
    5100's all on fours
    Good call. I know the first gens have this but didn't know if the second gens did.

  5. Oct 28, 2011 at 12:00 PM
    #5
    Mr.Tacoma

    Mr.Tacoma [OP] Well-Known Member

    Joined:
    Oct 25, 2010
    Member:
    #45225
    Messages:
    156
    Gender:
    Male
    toronto
    Vehicle:
    DoubleCab4x4
    TRD Exhaust, Side step bar & ARE cap
    I did drain /refill few times using the return tube..while my daughter was steering slowly. I do see some improvement..esp..the blank spot (i call it)where i lose power is gone but overall i feel the steerin is little harder than how it was originally. May be should i flush completely and fill again. Whats the best way to flush..???? thnx:confused:

  6. Nov 8, 2011 at 3:50 AM
    #6
    Mr.Tacoma

    Mr.Tacoma [OP] Well-Known Member

    Joined:
    Oct 25, 2010
    Member:
    #45225
    Messages:
    156
    Gender:
    Male
    toronto
    Vehicle:
    DoubleCab4x4
    TRD Exhaust, Side step bar & ARE cap
    I drained the old fluid and refilled new ps fluid. It drove well during test drive, parked it and next i see same shit is happening. Few days ago when the tensioner was changed by mech it drove good only that day. Dont know why this taco is acting up, I do hear some grind noise when steering is fully cranked to either sides..does that ring any bell. If i know for sure its PS pump i could change it..is there anything else in the steering column that should be checked.? Thanks :confused:

  7. Nov 8, 2011 at 4:32 AM
    #7
    98tacoma27

    98tacoma27 is gooder 'en chicken Moderator

    Joined:
    Dec 18, 2008
    Member:
    #11714
    Messages:
    49,777
    Gender:
    Male
    First Name:
    Ben
    Beech Creek
    Vehicle:
    05 Tundra SR5 (+250k AND COUNTING), 88 SR5 PU (SOLD), 98 TRD OR (CRUSHED)
    5100's all on fours
    Sounds like it might be time for a new pump. :notsure:

  8. Nov 8, 2011 at 10:41 AM
    #8
    Wally

    Wally Well-Known Member

    Joined:
    Jul 13, 2011
    Member:
    #59793
    Messages:
    159
    Gender:
    Male
    Ontario (the metric version)
    Vehicle:
    07 Access Cab TRD 4x4 6MT 1GR-FE
    There is a procedure for bleeding the power steering pump. You may want to give it a try first ...

    Starts on page 3

    Power Steering PDF

  9. Nov 13, 2011 at 2:28 PM
    #9
    tacomava

    tacomava Member

    Joined:
    Dec 13, 2009
    Member:
    #27512
    Messages:
    14
    Gender:
    Male
    First Name:
    Chris
    Laconia, NH
    I am having this exact intermittent problem! It is driving me crazy!! its like a switch goes on and off, power one day, gone the next...Let me know what you find and I will do the same.

  10. Nov 13, 2011 at 5:48 PM
    #10
    Gregman

    Gregman Well-Known Member

    Joined:
    Jan 11, 2010
    Member:
    #29166
    Messages:
    577
    Gender:
    Male
    Freddy Beach, NB
    Vehicle:
    05 DC LB 4x4 SR5
    There's a good chance that your problem is the universal joint in the intermediate shaft in your steering column is dried out, corroded, and binding. This is what happened to mine and a shot of oil fixed the problem for 6 months until it reappeared again. Another shot of oil and I'm good to go again. I am going to have the intermediate shaft replaced soon and that should fix it.
    Try crawling under your truck with an oil can with a flexible hose and squirt as much oil on the universal joint as possible, move it to a different position (turn the steering wheel 90 degrees or so) and oil some more. It is easy to see and get at that little universal joint from under the truck. Use a few rags to catch drips and keep things from getting too messy. If this doesn't fix the binding feeling in your steering then all you have done is lubed your universal joint which won't harm anything.
    ;)

  11. Nov 14, 2011 at 1:22 AM
    #11
    landphil

    landphil Wishin' I was Fishin'

    Joined:
    Mar 3, 2011
    Member:
    #52290
    Messages:
    2,390
    Gender:
    Male
    BC, Canada
    Vehicle:
    RIP 2006 Tacoma DCSB
    Tundra 5.7 mod
    X2

  12. Nov 25, 2011 at 7:58 PM
    #12
    Mr.Tacoma

    Mr.Tacoma [OP] Well-Known Member

    Joined:
    Oct 25, 2010
    Member:
    #45225
    Messages:
    156
    Gender:
    Male
    toronto
    Vehicle:
    DoubleCab4x4
    TRD Exhaust, Side step bar & ARE cap
    Gregman...you are awesome..i took it to a toyota mech (refered)and let him to figure..he got the same doubt as you said..truck came out just like how it was b4 all started..after a lube. He said Intermediate shaft is dry and corroded and gave me part cost as C$359 if i need to change plus $130 for install. But for now runs like new. WONDER WHY THIS SHAFT IS SUSCEPTIBLE FOR CORROSION/DRYING. Cant we resand/lube it instead of replacing with a new one ..??????? Thanks to all for input.
