Power Steering leak? You tell me...

Discussion in '1st Gen. Tacomas (1995-2004)' started by AlphaEcho2k5, Sep 30, 2011.

  1. Sep 30, 2011 at 7:06 PM
    #1
    AlphaEcho2k5

    AlphaEcho2k5 [OP] Well-Known Member

    Joined:
    Mar 2, 2011
    Member:
    #52220
    Messages:
    1,838
    Gender:
    Male
    First Name:
    Adam
    Warren AFB, WY
    Vehicle:
    '02 4Runner
    [​IMG]


    [​IMG]

    Residue inside airbox.

    [​IMG]

    I've tried looking for the source of the leak, thinking it's a seal.

  2. Sep 30, 2011 at 7:15 PM
    #2
    98tacoma27

    98tacoma27 :POOPCORN: Staff Member

    Joined:
    Dec 18, 2008
    Member:
    #11714
    Messages:
    48,163
    Gender:
    Male
    First Name:
    Ben
    Beech Creek
    Vehicle:
    05 Tundra SR5, 88 SR5 PU, 98 TRD OR (CRUSHED)
    5100's all on fours
    Is the power steering low? How'd you get residue INSIDE the air box?

  3. Sep 30, 2011 at 7:53 PM
    #3
    AlphaEcho2k5

    AlphaEcho2k5 [OP] Well-Known Member

    Joined:
    Mar 2, 2011
    Member:
    #52220
    Messages:
    1,838
    Gender:
    Male
    First Name:
    Adam
    Warren AFB, WY
    Vehicle:
    '02 4Runner
    It was low and making the "moan" awhile back I filled it up and the level has been consistent since then. The residue in the box... I'm thinking that it's getting in through the (stock) small hole in the bottom right of the box (beneath the air filter clip). It's also on the outside of the box nearest to the P.S and being flung onto the hood.

  4. Oct 1, 2011 at 8:39 AM
    #4
    AlphaEcho2k5

    AlphaEcho2k5 [OP] Well-Known Member

    Joined:
    Mar 2, 2011
    Member:
    #52220
    Messages:
    1,838
    Gender:
    Male
    First Name:
    Adam
    Warren AFB, WY
    Vehicle:
    '02 4Runner
  5. Oct 1, 2011 at 9:29 AM
    #5
    98tacoma27

    98tacoma27 :POOPCORN: Staff Member

    Joined:
    Dec 18, 2008
    Member:
    #11714
    Messages:
    48,163
    Gender:
    Male
    First Name:
    Ben
    Beech Creek
    Vehicle:
    05 Tundra SR5, 88 SR5 PU, 98 TRD OR (CRUSHED)
    5100's all on fours
    That makes sense. For the fluid to be allover the inside like that, I'd say the shaft seal is bad.

  6. Oct 1, 2011 at 10:35 AM
    #6
    4x4Tacoma01

    4x4Tacoma01 Well-Known Member

    Joined:
    Mar 19, 2011
    Member:
    #53296
    Messages:
    82
    Gender:
    Female
    First Name:
    Holly
    Canada Eh?
    Vehicle:
    SR5 Tacoma 4x4
    I have the same issue with my truck, I ended up replacing the seals. It solved the problem. I was going threw about a quart of ps fluid a week lol.

  7. Oct 1, 2011 at 10:47 AM
    #7
    Johnnie

    Johnnie Well-Known Member

    Joined:
    Mar 11, 2009
    Member:
    #14594
    Messages:
    1,764
    Gender:
    Male
    I.E. SoCal
    Vehicle:
    Feds
  8. Oct 1, 2011 at 11:59 AM
    #8
    AlphaEcho2k5

    AlphaEcho2k5 [OP] Well-Known Member

    Joined:
    Mar 2, 2011
    Member:
    #52220
    Messages:
    1,838
    Gender:
    Male
    First Name:
    Adam
    Warren AFB, WY
    Vehicle:
    '02 4Runner
    Thanks guys/gal!

  9. Mar 30, 2012 at 5:35 PM
    #9
    boshak

    boshak Well-Known Member

    Joined:
    May 23, 2010
    Member:
    #37663
    Messages:
    514
    Gender:
    Male
    First Name:
    Tony
    Southern California
    Vehicle:
    2003 Manual 4x4 5VZ-FE
    OME 881's, Wheeler's 5-leaf pack, Bilstein 5100's
    OP, what did you end up doing? Replacing reservoir, pump, shaft seal? Rebuild?

    Looking to do this soon.

  10. Mar 30, 2012 at 7:35 PM
    #10
    AlphaEcho2k5

    AlphaEcho2k5 [OP] Well-Known Member

    Joined:
    Mar 2, 2011
    Member:
    #52220
    Messages:
    1,838
    Gender:
    Male
    First Name:
    Adam
    Warren AFB, WY
    Vehicle:
    '02 4Runner

    [​IMG]

  11. Mar 30, 2012 at 11:23 PM
    #11
    boshak

    boshak Well-Known Member

    Joined:
    May 23, 2010
    Member:
    #37663
    Messages:
    514
    Gender:
    Male
    First Name:
    Tony
    Southern California
    Vehicle:
    2003 Manual 4x4 5VZ-FE
    OME 881's, Wheeler's 5-leaf pack, Bilstein 5100's
    Did you already replace the pump or just have it on order? Did you ever find the exact location of your leak? Hose, resi, gasket?

  12. Mar 31, 2012 at 6:13 AM
    #12
    AlphaEcho2k5

    AlphaEcho2k5 [OP] Well-Known Member

    Joined:
    Mar 2, 2011
    Member:
    #52220
    Messages:
    1,838
    Gender:
    Male
    First Name:
    Adam
    Warren AFB, WY
    Vehicle:
    '02 4Runner
    I replaced the pump with the one above for $81 and a warranty, I said wth. I have a PS cooler on the way should be here next week. Leak was a seal in the pump.

  13. Mar 31, 2012 at 8:26 AM
    #13
    Janster

    Janster Old & Forgetful

    Joined:
    Mar 25, 2007
    Member:
    #1138
    Messages:
    13,831
    Gender:
    Female
    First Name:
    Jandy
    Lancaster, PA
    Vehicle:
    2007 4.0L 4x4 TRD Sport Access Cab A
    Advantage Torza top (tri-fold), Husky floor mats, RuffTuff seat covers, C2C hood struts, Homelink mirror, USA Spec PA15-Toy (120gig Classic & 8gig nano), Garmin Nuvi 660, Protecta Bed mat, Pop-n-lock, TSB Springs, Scangauge II, Heated drivers seat, Fumoto drain valve, Aries pushbar, PIAA 540 fog lights, Hood scoop grahics, Flowmaster 50 series dual catback exhaust, RainX Latitude windshield wipers, Husky rear floor liner (ontop of folded down seats). Console Vault.
    A little late...but you should be able to easily 'find' a power steering leak by jacking up the front end, have a buddy in the cap and turn the steering wheel while you poke your head under the hood and look.

    True story here - a family friend of ours had a power steering leak. He admitted that every DAY he was putting a quart of fluid in the resevoir. :eek::eek::eek: He had us take a look at it.... Jacked up the front end, turned the steering wheel... my god, it was like a frigin garden sprinkler and just about shot me in the eye!!!! Why..oh why.....do people let this shit go???

  14. Mar 31, 2012 at 12:21 PM
    #14
    boshak

    boshak Well-Known Member

    Joined:
    May 23, 2010
    Member:
    #37663
    Messages:
    514
    Gender:
    Male
    First Name:
    Tony
    Southern California
    Vehicle:
    2003 Manual 4x4 5VZ-FE
    OME 881's, Wheeler's 5-leaf pack, Bilstein 5100's
    That's my issue I posted in my other thread here. It's a caked mess in that area but I'm NOT losing fluid... I'm not saying this is okay but the cake must have stopped it. Now I don't know where to start or look.

    I attached the picture from my other thread. Picture taken from front of truck. Top right is reservoir and to the left is my air box.


  15. Mar 31, 2012 at 12:35 PM
    #15
    Janster

    Janster Old & Forgetful

    Joined:
    Mar 25, 2007
    Member:
    #1138
    Messages:
    13,831
    Gender:
    Female
    First Name:
    Jandy
    Lancaster, PA
    Vehicle:
    2007 4.0L 4x4 TRD Sport Access Cab A
    Advantage Torza top (tri-fold), Husky floor mats, RuffTuff seat covers, C2C hood struts, Homelink mirror, USA Spec PA15-Toy (120gig Classic & 8gig nano), Garmin Nuvi 660, Protecta Bed mat, Pop-n-lock, TSB Springs, Scangauge II, Heated drivers seat, Fumoto drain valve, Aries pushbar, PIAA 540 fog lights, Hood scoop grahics, Flowmaster 50 series dual catback exhaust, RainX Latitude windshield wipers, Husky rear floor liner (ontop of folded down seats). Console Vault.
    The 'cake' won't stop a leak. A leak is what creates the 'cake' .

    The first thing you need to do, is clean up all the cake. You can't visualize where the leak is if the residue is covering it.

    Steering lines have High & low pressure lines. High pressure lines are the lines that generate your steering and are under high pressure. Lower pressure lines are the fluid return lines. You can tell the difference by the lines themselves. The high pressure lines are metal and/or rubber (looking from the outside) but have crimped steal ends. Low pressure lines are usually just rubber with hose clamps.

    High pressure line leaks should show up (if large enough of a leak) when you jack the front end up, engine running, and turn the steering wheel while someone else looks around in the engine bay. Everytime the steering wheel turns, you should see a leak if there is one (and large enough to visualize it oozing out). Low pressure lines won't be as 'easy' to spot.

    All in all - clean up the entire area free of 'cake' and oils - and check the area again in a week or so and see if you can spot new oils and where its coming from.

  16. Apr 2, 2012 at 10:59 AM
    #16
    boshak

    boshak Well-Known Member

    Joined:
    May 23, 2010
    Member:
    #37663
    Messages:
    514
    Gender:
    Male
    First Name:
    Tony
    Southern California
    Vehicle:
    2003 Manual 4x4 5VZ-FE
    OME 881's, Wheeler's 5-leaf pack, Bilstein 5100's
    All cleaned up, no leaks present and no sign of fluid getting lower. I'll keep monitoring it though.
