Ready Lift Kit (install)

Discussion in 'Suspension' started by Beefed Taco, Dec 27, 2008.

  1. Dec 27, 2008 at 9:19 PM
    #1
    Beefed Taco

    Beefed Taco [OP] Taco Vending Machine Vendor

    Joined:
    Dec 18, 2008
    Member:
    #11706
    Messages:
    1,309
    Gender:
    Male
    First Name:
    Brian
    My Metal Shop
    Vehicle:
    99 Taco
    streetacos.com parts!
    So my friend Steven (Stupid Hurts) came down last week and I installed the new Ready Lift Kit for 05+ 2WD 5-lug Tacoma. This is a front spacer and rear AAL lift. Here are the 2 snags the company leaves you hanging on. Now prior to the install a while back, I viewed the video that Ready Lift has available and of course they make everything seem like it bolts itself together while you watch. The 2 snags were:

    #1. The leaf center pins (bolts/nuts) they supply for the rear have too big of a head and it doesn't fit into the axle hole properly. Sanded them down just a hair w/sanding wheel on hand grinder.

    #2. The nuts & washers for the leaf center pin (bolts/nuts) are too big to go into the hole on the u-bolt plates. I had to drill the holes bigger and ditch the washer, the factory doesn't use washers either. The picture below of the washer is after I drilled the plate so the nut would fit in.

    The long stud on the top of the front coil overs does have to be cut to the same height as the other 2 are stock. No coil spring compressor needed. When the coil over is unbolted it all comes apart real easy and you just turn the stock top plate 120 degrees by hand.

    The trick for installing the coil over w/spacer was to bolt the upper 3 studs/nuts first (making sure top of shock pokes through also) then use a ratchet strap around the bottom of the coil over and attach both ends of the strap to the lower arm on the other side of the truck to keep the bottom of the shock in place so I could use a pry bar and jack the arm up so the bolt would slip through while the bottom of the shock stayed in place..

    Did my home alignment and he was off and riding higher...tires & sick titanium bronze wheels (Rota Grid style) coming soon. Hope this helps shed some light on this lift kit for future froaders. [​IMG]

    Beefed lift 7.jpg
    Beefed lift 8.jpg
    Beefed lift 2.jpg
    Beefed lift 3.jpg
    Beefed lift 4.jpg
    Beefed lift 1.jpg
    Beefed lift 6.jpg

  2. Dec 27, 2008 at 9:24 PM
    #2
    TRD4x4858

    TRD4x4858 Taco Traitor!

    Joined:
    Oct 20, 2008
    Member:
    #10117
    Messages:
    3,058
    Gender:
    Male
    San Diego
    Vehicle:
    95 Jeep XJ
    BONE STOCK! lol
    Wow looks good! got any pics with new wheels and tires?

  3. Dec 27, 2008 at 9:39 PM
    #3
    Beefed Taco

    Beefed Taco [OP] Taco Vending Machine Vendor

    Joined:
    Dec 18, 2008
    Member:
    #11706
    Messages:
    1,309
    Gender:
    Male
    First Name:
    Brian
    My Metal Shop
    Vehicle:
    99 Taco
    streetacos.com parts!
    Thanks. We will as soon as they get here. He doesn't have the tires yet, only the wheels, and they are gonna look ssaawweett! He'll be running BFG A/T's. Next mod is that inner fender black box/liner removal/trim.

  4. Dec 27, 2008 at 10:09 PM
    #4
    afd23a

    afd23a Well-Known Member

    Joined:
    Sep 26, 2008
    Member:
    #9483
    Messages:
    1,805
    Gender:
    Male
    The Dynamo of Dixie
    Vehicle:
    05 Access Cab 5 Lugger
    Factory Fog Lights, Removed Secondary Air Filter, Metra Ipod Adapter, Int Wiper Stalk, Wet Okole's, URD Short Shifter, Scanguage II w/Blendmount, Fat Bob's 2.75" spacer lift, ARE topper, SP Performance Pads & Slotted Rotors, 4.10 gears
    That looks great. I've been thinking about getting the readylift or the kit from Fat Bob's. I saw a thread on TN (I think) that was saying the same thing about the clearance of the bolt heads on the rear leafs. Not sure if it's true for the Fat Bob's kit though.......How's the travel of the rear shocks? Somewhere I read a thread where the guy said his rear shocks had very travel after the lift. Did you change the rear shocks or have your or your brother noticed if the rear is topping out?

  5. Dec 27, 2008 at 10:18 PM
    #5
    Beefed Taco

    Beefed Taco [OP] Taco Vending Machine Vendor

    Joined:
    Dec 18, 2008
    Member:
    #11706
    Messages:
    1,309
    Gender:
    Male
    First Name:
    Brian
    My Metal Shop
    Vehicle:
    99 Taco
    streetacos.com parts!
    We put some factory Bilsteins from a 4x4/Prerunner and they were about 1.5" longer than mount to mount when fully dropped out. (perfect) I can't remember how much longer the Billie's were compared to the stock shocks though. Oh, and sorry for the confusion, he was a friend / customer not my brother.

  6. Dec 27, 2008 at 10:23 PM
    #6
    afd23a

    afd23a Well-Known Member

    Joined:
    Sep 26, 2008
    Member:
    #9483
    Messages:
    1,805
    Gender:
    Male
    The Dynamo of Dixie
    Vehicle:
    05 Access Cab 5 Lugger
    Factory Fog Lights, Removed Secondary Air Filter, Metra Ipod Adapter, Int Wiper Stalk, Wet Okole's, URD Short Shifter, Scanguage II w/Blendmount, Fat Bob's 2.75" spacer lift, ARE topper, SP Performance Pads & Slotted Rotors, 4.10 gears
    cool, did you do the billie's on the front too? BTW, my bad about the confusion with your friend. It's late and I've had a few drinks. Oh and thanks for the pics.

  7. Dec 27, 2008 at 10:31 PM
    #7
    SocalMan22

    SocalMan22 Founder Socaltacomas.com Staff Member

    Joined:
    Mar 25, 2007
    Member:
    #1146
    Messages:
    8,133
    Gender:
    Male
    First Name:
    Steve-0
    So*Cal
    Vehicle:
    06 PreRunner Dbl Cab
    What Mods!
    Your truck sits nice!

  8. Dec 27, 2008 at 10:41 PM
    #8
    Beefed Taco

    Beefed Taco [OP] Taco Vending Machine Vendor

    Joined:
    Dec 18, 2008
    Member:
    #11706
    Messages:
    1,309
    Gender:
    Male
    First Name:
    Brian
    My Metal Shop
    Vehicle:
    99 Taco
    streetacos.com parts!
    Well have 1 more for me then too! The front Billies couldn't be used because they were way too long. I wanna say the rear Billie's were maybe about 1.5" longer than the stock 2WD 5-lug rears, so yes, the stock rear shocks would be a hair too short for articulating off road, a couple inches longer would be good. (like the 4x4/Prerunner length) I thought the rear Billie's were gonna be side specific, but they were the exact same length.

    That's Steven's (Stupid Hurts) truck, but thanks for the compliment, much appreciated!

    Forgot to add, I didn't use the supplied non locking nuts for the u-bolts, I chose to use my trusty grade 8 nyloc nuts and washers. Then I paint the nuts and threads to keep them from rusting, I make a white paint stripe on the rear of the nuts so you can look under neath and know they are tight. The torque in the instructions said, 33 ft. lbs. or something like that, which is WAY too loose IMO, (that's like hand tight) I put them at 65-70 ft. lbs.

    [​IMG]
    __________________

  9. Dec 28, 2008 at 10:08 PM
    #9
    Stupid hurts.

    Stupid hurts. Hoogie boogie!

    Joined:
    Sep 22, 2008
    Member:
    #9408
    Messages:
    1,513
    Gender:
    Male
    First Name:
    Steven
    So☆Cal
    Vehicle:
    '07 5-Lug Impluse Red Pearl Access Cab 2WD
    American Motorsports Front Long Travel Kit, Total Chaos Rear Dual Shock Hoop Kit, Engage 50T Leaf Pack, Engage Front & Rear Hangers, American Motorsports Shackles
    I can take pics of the wheels tomorrow. Like Beefed said, I have already bought the wheels, but still waiting on the tires.

    Beefed Taco">
    I beg to differ. We ARE practically brothers. Can't you see the resemblance? :eek:

    Brian (Beefed Taco):
    [​IMG]

    Me:
    [​IMG]

    :laugh:

    Thanks! :thumbsup:

    I couldn't be happier with the install. I appreciate Brian (Beefed Taco) taking the time to help me out (I didn't do too much :eek:) even though he was sick. :thumbsup:

  10. Dec 28, 2008 at 10:41 PM
    #10
    SocalMan22

    SocalMan22 Founder Socaltacomas.com Staff Member

    Joined:
    Mar 25, 2007
    Member:
    #1146
    Messages:
    8,133
    Gender:
    Male
    First Name:
    Steve-0
    So*Cal
    Vehicle:
    06 PreRunner Dbl Cab
    What Mods!
    LOL man im hungry from that pic!

  11. Dec 29, 2008 at 10:18 AM
    #11
    Beefed Taco

    Beefed Taco [OP] Taco Vending Machine Vendor

    Joined:
    Dec 18, 2008
    Member:
    #11706
    Messages:
    1,309
    Gender:
    Male
    First Name:
    Brian
    My Metal Shop
    Vehicle:
    99 Taco
    streetacos.com parts!
    LMFAO ! I'm going to kill my wife for putting that pic up and letting people copy it! That's funny right there Steven. BTW, your Raviolies just made her hungry too, me, not so much, I'm more of a Mexican food guy. (you know, like Beefed Tacos & stuff) :D

  12. Dec 29, 2008 at 11:41 AM
    #12
    Stupid hurts.

    Stupid hurts. Hoogie boogie!

    Joined:
    Sep 22, 2008
    Member:
    #9408
    Messages:
    1,513
    Gender:
    Male
    First Name:
    Steven
    So☆Cal
    Vehicle:
    '07 5-Lug Impluse Red Pearl Access Cab 2WD
    American Motorsports Front Long Travel Kit, Total Chaos Rear Dual Shock Hoop Kit, Engage 50T Leaf Pack, Engage Front & Rear Hangers, American Motorsports Shackles
    Haha, it was some good ravioli. As you can see, I love cheese. :D

    Beefed Taco">
    Haha, I knew you'd like that. :laugh: Ravioli is one of the very few things I can actually cook without burning the place down. Can't blame you though; I love Mexican food too. :thumbsup:
