Replace Ball Joints, Links, Tie Rods? OEM, Moog, Proforged, Mevotech?

Discussion in '1st Gen. Tacomas (1995-2004)' started by BenevolentMachination, Aug 12, 2019.

  1. Aug 13, 2019 at 11:18 AM
    #21
    ForestRunnerFrank99

    ForestRunnerFrank99 Well-Known Member

    Joined:
    Mar 10, 2019
    Member:
    #286162
    Messages:
    171
    Gender:
    Male
    First Name:
    Josh
    Rancho Cucamonga, CA
    Vehicle:
    Green 1999 TRD 4x4 Manual 3.4l v6
    Lift, Intake, Tires, Rims
  2. Aug 13, 2019 at 12:01 PM
    #22
    TacoJohn4x4

    TacoJohn4x4 Captain Save-A-Ho

    Joined:
    Jul 10, 2018
    Member:
    #258956
    Messages:
    776
    Gender:
    Male
    Central Valley
    Vehicle:
    2002 Tacoma DC 4x4
  3. Aug 13, 2019 at 12:06 PM
    #23
    TacoJohn4x4

    TacoJohn4x4 Captain Save-A-Ho

    Joined:
    Jul 10, 2018
    Member:
    #258956
    Messages:
    776
    Gender:
    Male
    Central Valley
    Vehicle:
    2002 Tacoma DC 4x4
    Since we are on the subject...

  4. Aug 13, 2019 at 12:32 PM
    #24
    ForestRunnerFrank99

    ForestRunnerFrank99 Well-Known Member

    Joined:
    Mar 10, 2019
    Member:
    #286162
    Messages:
    171
    Gender:
    Male
    First Name:
    Josh
    Rancho Cucamonga, CA
    Vehicle:
    Green 1999 TRD 4x4 Manual 3.4l v6
    Lift, Intake, Tires, Rims
    Those are the ones I just bought. I'm feeling pretty good about my purchase now lol.

    CS_AR likes this.
  5. Aug 13, 2019 at 1:13 PM
    #25
    Kevin Jones

    Kevin Jones Well-Known Member

    Joined:
    Sep 1, 2018
    Member:
    #264881
    Messages:
    507
    Gender:
    Male
    First Name:
    Kevin
    Central Va
    Vehicle:
    1996 Tacoma - 2018 Tacoma
    I owned/operated a chain of auto parts stores for over 16 years, so know a little about parts/parts quality. I just replaced lower ball joints on my '96 a couple weeks ago and used Moog. Having said that the original Toyota went 412,000 miles.

  6. Aug 13, 2019 at 1:29 PM
    #26
    OneWheelPeel

    OneWheelPeel Well-Known Member

    Joined:
    May 19, 2016
    Member:
    #187371
    Messages:
    1,984
    And??? They were good or bad?

  7. Aug 13, 2019 at 1:30 PM
    #27
    eon_blue

    eon_blue moist

    Joined:
    Mar 4, 2016
    Member:
    #180213
    Messages:
    27,479
    Gender:
    Male
    First Name:
    Ryan
    Monrovia, CA
    Vehicle:
    Supercharged 2004 3.4l TRD 4x4 Tacoma XtraCab w/5 speed
    Man my last set of OEM lower ball joints lasted about 55k miles lol. Lot of those miles were some rough 4x4'ing though. They developed a lot of slop/play in them so I changed them out before they left me stranded on the side of the road, or off a cliff

    OneWheelPeel likes this.
  8. Aug 13, 2019 at 1:30 PM
    #28
    CS_AR

    CS_AR Well-Known Member

    Joined:
    Apr 3, 2019
    Member:
    #289019
    Messages:
    2,008
    Gender:
    Male
    Vehicle:
    1999 Tacoma PreRunner TRD
    Everything but the driveshaft.
    The PS line is still going. Good.

    ForestRunnerFrank99 likes this.
  9. Aug 13, 2019 at 2:07 PM
    #29
    Kevin Jones

    Kevin Jones Well-Known Member

    Joined:
    Sep 1, 2018
    Member:
    #264881
    Messages:
    507
    Gender:
    Male
    First Name:
    Kevin
    Central Va
    Vehicle:
    1996 Tacoma - 2018 Tacoma
    They were worn out, but like I said 412,000 miles so no complaints.
    I went with the Moog because I sold Mood parts for many years and never had any problem with them. I toured their plant several times and good people and a first rate organization.

  10. Aug 13, 2019 at 2:10 PM
    #30
    Kevin Jones

    Kevin Jones Well-Known Member

    Joined:
    Sep 1, 2018
    Member:
    #264881
    Messages:
    507
    Gender:
    Male
    First Name:
    Kevin
    Central Va
    Vehicle:
    1996 Tacoma - 2018 Tacoma
    Wow, 55K sucks regardless how it's driven. I'm interested in seeing how my new Moog ball joints last, something tells me I won't be getting another 412,000 miles out of them.

  11. Aug 13, 2019 at 3:03 PM
    #31
    cruiserguy

    cruiserguy Well-Known Member

    Joined:
    Jul 31, 2016
    Member:
    #193416
    Messages:
    8,173
    Gender:
    Male
    First Name:
    Elijah
    SLC
    Vehicle:
    2000 ext cab, 2.7L, auto, 4x4
    Your Moog lower ball joints are just Moog because of the box it came in. Moog doesn't manufacture lower Ball joints for our trucks. They rebox a lower ball joint made by Sankei/555 and sell it. But I have now seen cheap actual Chinese LBJs in AC Delco boxes ordered from Amazon. Buyer beware.

  12. Aug 13, 2019 at 3:09 PM
    #32
    eon_blue

    eon_blue moist

    Joined:
    Mar 4, 2016
    Member:
    #180213
    Messages:
    27,479
    Gender:
    Male
    First Name:
    Ryan
    Monrovia, CA
    Vehicle:
    Supercharged 2004 3.4l TRD 4x4 Tacoma XtraCab w/5 speed
    Yeah it really just comes down to the overall crappy design on the lower ball joint on our trucks, the ball joint is constantly under stress to be pulled out of the socket. On the 2005+ Tacomas, Toyota redesigned it and basically flipped upside down so the ball joint keeps itself seated and doesn't want to pull apart. Probably why we never really see or hear stories about later model Tacomas with LBJ failures, but on 1st gens you see it a lot.

    cruiserguy likes this.
  13. Aug 13, 2019 at 3:10 PM
    #33
    Kevin Jones

    Kevin Jones Well-Known Member

    Joined:
    Sep 1, 2018
    Member:
    #264881
    Messages:
    507
    Gender:
    Male
    First Name:
    Kevin
    Central Va
    Vehicle:
    1996 Tacoma - 2018 Tacoma
    That's not surprising as that type of thing is pretty much commonplace these days. Back when had my auto parts stores it was quite a bit different, for the most part if it was in a manufacturer's box they manufactured it.

    cruiserguy likes this.
  14. Aug 13, 2019 at 3:13 PM
    #34
    cruiserguy

    cruiserguy Well-Known Member

    Joined:
    Jul 31, 2016
    Member:
    #193416
    Messages:
    8,173
    Gender:
    Male
    First Name:
    Elijah
    SLC
    Vehicle:
    2000 ext cab, 2.7L, auto, 4x4
    Yep, believe me man, I miss those days too. Companies made their own parts and sold them and you knew who made good stuff, mediocre, etc. No having to try and figure out who manufactured what where and to what spec, etc like it is nowadays. Ridiculous nowadays.
    But the good news is the Sankei 555 joint you likely used is the next best to the OEM ball joint.

  15. Aug 13, 2019 at 3:23 PM
    #35
    Fatal_Paradox

    Fatal_Paradox Well-Known Member

    Joined:
    Jun 4, 2018
    Member:
    #255460
    Messages:
    278
    Gender:
    Male
    Bardstown, KY
    Vehicle:
    2003 Tacoma DC 4x4
    33's Bedliner Nerf Bars (Custom)
    What pitman arm puller do you guys use ?

  16. Aug 13, 2019 at 3:28 PM
    #36
    Parkvisitor

    Parkvisitor Well-Known Member

    Joined:
    May 27, 2019
    Member:
    #294502
    Messages:
    224
    Gender:
    Male
    First Name:
    Juan
    So Cal
    Vehicle:
    04 prerunner double cab
    Big brakes, tranny cooler, stock.
  17. Aug 13, 2019 at 3:32 PM
    #37
    Fatal_Paradox

    Fatal_Paradox Well-Known Member

    Joined:
    Jun 4, 2018
    Member:
    #255460
    Messages:
    278
    Gender:
    Male
    Bardstown, KY
    Vehicle:
    2003 Tacoma DC 4x4
    33's Bedliner Nerf Bars (Custom)
    More specifically which size works great for our LBJ and our OTR

  18. Aug 13, 2019 at 3:35 PM
    #38
    eon_blue

    eon_blue moist

    Joined:
    Mar 4, 2016
    Member:
    #180213
    Messages:
    27,479
    Gender:
    Male
    First Name:
    Ryan
    Monrovia, CA
    Vehicle:
    Supercharged 2004 3.4l TRD 4x4 Tacoma XtraCab w/5 speed
    I've really only seen 2, a small one and the 'normal' size one that's about as big as the palm of your hand, maybe a little bigger.

    Harbor Freight sells one for about $15 that I use, it's a bit tight to get on but it fits. It's the only size they have that I've seen. The biggest one I've seen in an auto parts store is the same size

    https://www.harborfreight.com/tie-rod-and-pitman-arm-puller-63684.html?_br_psugg_q=pitman+puller

    Last edited: Aug 13, 2019
    CS_AR likes this.
  19. Aug 13, 2019 at 3:41 PM
    #39
    eon_blue

    eon_blue moist

    Joined:
    Mar 4, 2016
    Member:
    #180213
    Messages:
    27,479
    Gender:
    Male
    First Name:
    Ryan
    Monrovia, CA
    Vehicle:
    Supercharged 2004 3.4l TRD 4x4 Tacoma XtraCab w/5 speed
    yeah I ruined a brand new OEM LBJ by tearing the boot with a pickle fork when I went to remove it, that sucked. Not to mention you really gotta hammer on that pickle fork to get it to work, pitman puller does a much cleaner job

    It's like a jack in the box for me though, gives me anxiety each time I turn the bolt on it waiting for the ball joint to pop out with a loud BANG

  20. Aug 13, 2019 at 3:42 PM
    #40
    Parkvisitor

    Parkvisitor Well-Known Member

    Joined:
    May 27, 2019
    Member:
    #294502
    Messages:
    224
    Gender:
    Male
    First Name:
    Juan
    So Cal
    Vehicle:
    04 prerunner double cab
    Big brakes, tranny cooler, stock.

    When you're done with lbj's and tie rods if you cut off about a 1/4" on each side you can use it to press back in upper ball joints, if you are replacing uppers I mean. Just use a stout cats claw as a shim in between the puller and the ball joint.
